King Industrial MA-1020 User manual

INSTRUCTION ANUAL
ODEL: A-1020
COPYRIGHT © 2014 A RIGHTS RESERVED BY KING CANADA TOO S INC.
1/2” HOLLOW CHISEL ORTISER
WITH 4 PC. CHISEL SET
09/2014

WARRANTY INFOR ATION
2-YEAR
IMITED WARRANTY
FOR THIS HO OW CHISE MORTISER
KING CANADA TOOLS
OFFERS A 2-YEAR IMITED WARRANTY
FOR COMMERCIA USE.
PROOF OF PURCHASE
Please keep your dated proof of purchase for warranty and servicing purposes.
REPLACE ENT PARTS
Replacement parts for this product are available at our authorized King Canada service centers across Canada.
LI ITED TOOL WARRANTY
King Canada makes every effort to ensure that this product meets high quality and durability standards. King Canada warrants to the
original retail consumer a 2-year limited warranty as of the date the product was purchased at retail and that each product is free from
defects in materials. Warranty does not apply to defects due directly or indirectly to misuse, abuse, normal wear and tear, negligence or
accidents, repairs done by an unauthorized service center, alterations and lack of maintenance. King Canada shall in no event be liable
for death, injuries to persons or property or for incidental, special or consequential damages arising from the use of our products.
To take advantage of this limited warranty, return the product at your expense together with your dated proof of purshase to an authorized
King Canada service center. Contact your retailer or visit our web site at www.kingcanada.com for an updated listing of our authorized
service centers. In cooperation with our authorized serviced center, King Canada will either repair or replace the product if any part or
parts covered under this warranty which examination proves to be defective in workmanship or material during the warranty period.
NOTE TO USER
This instruction manual is meant to serve as a guide only. Specifications and references are subject to change without prior notice.
KING CANADA INC. DORVAL, QUÉBEC, CANADA H9P 2Y4
www.kingcanada.com

GENERAL & SPECIFIC
SAFETY RULES
1. KNOW YOUR TOOL
Read and understand the owners manual and labels affixed to the
tool. earn its application and limitations as well as its specific po-
tential hazards.
2. GROUND THE TOOL.
This tool is equipped with an approved 3-conductor cord and a
3-prong grounding type plug to fit the proper grounding type re-
ceptacle. The green conductor in the cord is the grounding wire.
NEVER connect the green wire to a live terminal.
3. KEEP GUARDS IN PLACE.
Keep in good working order, properly adjusted and aligned.
4. RE OVE ADJUSTING KEYS AND WRENCHES.
Form habit of checking to see that keys and adjusting wrenches
are removed from tool before turning it on.
5. KEEP WORK AREA CLEAN.
Cluttered areas and benches invite accidents. Make sure the floor
is clean and not slippery due to wax and sawdust build-up.
6. AVOID DANGEROUS ENVIRON ENT.
Don’t use power tools in damp or wet locations or expose them to
rain. Keep work area well lit and provide adequate surrounding
work space.
7. KEEP CHILDREN AWAY.
All visitors should be kept at a safe distance from work area.
8. AKE WORKSHOP CHILD-PROOF.
With padlocks, master switches or by removing starter keys.
9. USE PROPER SPEED.
A tool will do a better and safer job when operated at the proper
speed.
10. USE RIGHT TOOL.
Don’t force the tool or an attachment to do a job for which it was
not designed.
11. WEAR PROPER APPAREL.
Do not wear loose clothing, gloves, neckties or jewelry (rings,
watch) because they could get caught in moving parts. Non-slip
footwear is recommended. Wear protective hair covering to contain
long hair. Roll up long sleeves above the elbows.
12. ALWAYS WEAR SAFETY GLASSES.
Always wear safety glasses (ANSI Z87.1). Everyday eyeglasses
only have impact resistant lenses, thet are NOT safety glasses.
Also use a face or dust mask if cutting operation is dusty.
13. DON’T OVERREACH.
Keep proper footing and balance at all times.
14. AINTAIN TOOL WITH CARE.
Keep tools sharp and clean for best and safest performance. Follow
instructions for lubricating and changing accessories.
15. DISCONNECT TOOLS.
Before servicing, when changing accessories or attachments.
16. AVOID ACCIDENTAL STARTING.
Make sure the swich is in the ‘’OFF’’ position before plugging in.
17. USE RECO ENDED ACCESSORIES.
Consult manual for recommended accessories. Follow the instruc-
tions that accompany the accessories. The use of improper acces-
sories may cause hazards.
18. NEVER STAND ON TOOL.
Serious injury could occur if the tool tips over. Do not store materials
such that it is necessary to stand on the tool to reach them.
19. CHECK DA AGED PARTS.
Before further use of the tool, a guard or other parts that are dam-
aged should be carefully checked to ensure that they will operate
properly and perform their intended function. Check for alignment
of moving parts, breakage of parts, mounting, and any other condi-
tions that may affect its operation. A guard or other parts that are
damaged should be properly repaired or replaced.
20. NEVER LEAVE ACHINE RUNNING UNATTENDED.
Turn power ‘’OFF’’. Don’t leave any tool running until it comes to a
complete stop.
SPECIFIC SAFELY RULES FOR HOLLOWCHISEL ORTISERS
1. DO NOT USE until unit is completely assembled and installed accord-
ing to instructions.
2.IF YOU ARE NOT thoroughly familiar with the operation of mortising
machines, obtain advice from your supervisor, instructor, or other
qualified person.
3. AKE CERTAIN the machine is fastened to a supporting surface to
prevent it from tipping over during operation.
4. NEVER TURN ORTISING ACHINE ON before clearing the table
of all objects (tools, scrap pieces, etc.).
5. ALWAYS KEEP hands, fingers and hair away from the rotating bit.
6. DO NOT ATTE PT to mortise material that does not have a flat
surface, unless a suitable support is used.
7. ALWAYS CLA P workpiece securely to table with holddown to pre-
vent lifting.
8. ALWAYS SUPPORT workpiece securely against fence to prevent ro-
tation.
9. BE SURE drill bit is sharp, not damaged and properly secured in the
chuck before operating.
10. AKE SURE chuck key is removed before starting machine.
11. NEVER START mortising machine with the drill bit of chisel pressed
against the workpiece.
12. NEVER PERFOR LAYOUT, assembly or setup work on mortising
machine with cutting tool rotating.
13. ADJUST DEPTH STOP to avoid drilling into the table.
14. ALWAYS STOP the machine before removing scrap pieces from the
table.
15. SHUT OFF POWER, remove the drill bit and chisel and clean the
table before leaving the machine.
16. DO NOT WEAR gloves, neckties or loose fitting clothing.
17. NEVER OPERATE mortising machine if any part is damaged or bro-
ken until it is properly repaired or replaced.
18. NEVER PLACE YOUR FINGERS in a position where drill or cutting
tool could contact them if workpiece should shift unexpectedly.

WARNING!
A E ECTRICA CONNECTIONS MUST BE DONE BY A QUA IFIED E ECTRICIAN. FAI URE TO COMP Y MAY RESU T IN SE-
RIOUS INJURY! A ADJUSTMENTS OR REPAIRS MUST BE DONE WITH THE MACHINE DISCONNECTED FROM THE POWER
SOURCE. FAI URE TO COMP Y MAY RESU T IN SERIOUS INJURY!
POWER SUPPLY
WARNING: YOUR MORTISER MUST BE CONNECTED TO A 110V-120V,
15-AMP CIRCUIT BREAKER. FAI URE TO CONNECT IN THIS WAY CAN
RESU T IN INJURY FROM SHOCK OR FIRE.
GROUNDING
This mortiser must be grounded. If it should malfunction or breakdown,
grounding provides a path of least resistance for electric current, to reduce
the risk of electric shock. This mortiser is equipped with a cord having an
equipment-grounding conductor and grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded
in accordance with all local codes and ordinances.
Your mortiser must be properly grounded. Not all outlets are properly
grounded. If you are not sure if your outlet is properly grounded, have it
checked by a qualified electrician.
WARNING: TO MAINTAIN PROPER GROUNDING OF YOUR MORTISER,
DO NOT REMOVE OR A TER THE GROUNDING PRONG IN ANY MAN-
NER.
WARNING: IF NOT PROPER Y GROUNDED, THIS MORTISER CAN
CAUSE E ECTRICA SHOCK, PARTICU AR Y WHEN USED IN DAMP
OCATIONS. TO AVOID SHOCK OR FIRE, IF THE POWER CORD IS
WORN OR DAMAGED IN ANY WAY, HAVE IT REP ACED IMMEDIATE Y.
110V-120V OPERATION
As received from the factory, your mortiser is ready to run for 110V-120V
operation. This mortiser is intended for use on a circuit that has an outlet
and a plug which looks like the one illustrated in Fig.1.
WARNING: DO NOT USE A TWO-PRONG ADAPTOR FOR THEY ARE
NOT IN ACCORDANCE WITH OCA CODES AND ORDINANCES. NEVER
USE IN CANADA.
EXTENSION CORDS
The use of any extension cord will cause some loss of power. Use the
chart in Fig.2 to determine the minimum wire size (A.W.G-American Wire
Gauge) extension cord. Use only 3-wire extension cords which have 3-
prong grounding type plugs and 3-hole receptacles which accept the tool’s
plug.
For circuits that are further away from the electrical circuit box, the wire size
must be increased proportionately in order to deliver ample voltage to the
mortiser motor. Refer to Fig.2 for wire length and size.
RESET BUTTON (OVERLOAD PROTECTOR)
This mortiser comes with an overload reset button (A) Fig.3. If the motor
overheats or there is low voltage, a safety mechanism stops the motor.
Press the reset button and restart the mortiser. If the mortiser does not
restart, wait 5 minutes before restarting.
FIGURE 1
FIGURE 2
PROPERLY GROUNDED OUTLET
CURRENT CARRYING PRONGS
GROUNDING PRONG
ELECTRICAL INFOR ATION
Tool’s
Amperage
Rating
3-6
6-8
8-10
10-12
12-16
Cord Size in A.W.G.
Cord Length in Feet
25 50 100 150
18 16 16 14
18 16 14 12
18 16 14 12
18 16 14 12
14 12 - -
FIGURE 3

MODE MA-1020
Chisel capacity 1/4” - 1/2”
Chuck capacity 1/2”
Maximum chisel stroke 5”
Max. distance chisel to table (head extended) 5”
Under table hold down capacity 3-5/8”
Table size 13-3/8” x 5-3/4”
Fence size 13-3/8” x 2”
Speed 1,700 RPM
Motor 120V, 5 Amp., 1 phase, 60 Hz
Assembled dimensions ( xWxH)/weight 13-3/8” x 13-1/2“ x 29-1/2” / 55 lbs
GETTING TO KNOW
YOUR HOLLOW CHISEL ORTISER
1-On/Off -Switch. Turns the machine on or off.
2-Chisel Lock Screw. Fixes the chisel and chisel adaptor to the head
casting flange.
3-Chisel & bit.
4-Table Hold Down. Holds your workpiece against the table during op-
erations.
5-Fence. This adjustable fence moves back and forth and adequately
supports your workpiece.
6-Wooden Table.
7-Depth Stop Bushing and Lock Knob. This bushing acts as a depth
stop which limits the downward travel of the head.
8-Chuck Cover. Open this cover or the other one on the opposite side
to gain access to the chuck.
9-Downfeed Lever. Pulling this lever down brings the head and chisel
towards the workpiece.
10-Chisel and Hex. Key Holder.
11-Gas Cylinder. Keeps the head in the raised position.
12-Fence Lock Handle. ocks the fence in the desired position.
13-Fence Adjust Knob. Turn this knob to move the fence back and
forth.
14-Hold Down Lock Knob.
15-1/2” Chuck.
16-Chuck key.
