KingSlim D1 Pro User manual

USER MANUAL
KingSlim D1 Pro Dash Cam
V1.1

01 - 24English
25 - 48Deutsch
49 - 72Español
73 - 96Français
97 - 120Italiano
145 - 168
日本語
121 - 144

What’s in the Box?
Camera Overview
Icons Introduction
How to Power on
Format microSD Card
Recording
Playing Back Videos
Download the App
Use the “Roadcam” App
Settings on Dash Cam
Specifications
Precautions
Troubleshooting
Contact Us
2
3
4
5
6
7
10
15
15
18
22
22
23
24
CONTENTS
1
EnglishEnglish

WHAT'S IN THE BOX
D1 Pro Dash Cam * 1 Car Charger with
External GPS * 1
32GB MicroSD Card * 1USB Cable * 1
Bracket * 1
GPS Electrostatic
Stickers * 2
D1 Pro
Pry Tool * 1 Cable Clips * 5 Quick Start Guide * 1
Quick Start Guide
KingSlimD1 Pro Dash Cam
V1.0
Note: The USB cable is only used to connect the computer and the dash camera
to read the card.
2
EnglishEnglish

D1 Pro
CAMERA OVERVIEW
1
3
2
4
6
5
8
11
7
9
10
12
13
3
EnglishEnglish

1
2
3
4
5
10
Mini USB Power Port
Bracket Slot
Front Camera
Power Button
Microphone
MicroSD Card Slot
IR LEDs & Indicator Light
6
7
8
9
Screen
Inside Camera
Speaker
Reset
Set Buttons
Wifi Button
11
12
13
Note:
Power Button
① Long press to turn on/off the camera.
②Short press to switch the view mode quickly from either the full-screen display of
front/inside view or picture-in-picture display from both cameras.
ICONS INTRODUCTION
Setup/Wifi
Parking monitor
Start to recording
MIC
Back
Forward
Down
Playback
Switch front and rear camera
Lock video
Stop recording
Backward
Up
Confirm or exit
4
EnglishEnglish

HOW TO POWER ON
1
2
1. Insert the car charger into the car’s cigarette lighter socket.
2. Connect the car charger to the dash cam's mini USB port.
(Charger input: DC 12-24V, Output DC 5V 2A)
D1 Pro
Note:
①After powering on the dash cam through the car charger, the dash cam will
automatically turn on and start recording (if the card has been inserted).
To change settings, please firstly stop recording.
②Please charge for 30 minutes before using this dash cam powered by the built-in
battery.
③When the dash cam is connected to the car’s cigarette lighter socket through the
car charger, the built-in battery will be charging at the same time. The indicator
light glows solid red when charging, and goes off when fully charged.
④The built-in battery is only used to power the "parking monitor" function.
In normal use, please plug the car charger into the cigarette lighter of the car to
power the dash cam. The built-in battery is not recommended as a normal power
supply for the dash cam. This is to avoid parking monitoring failure caused by
running out of battery while the car is parked.
⑤The camera can also be powered by connecting it to a power source such as your
DC 5V phone adapter via the USB cable.
When charging, please shut down the camera by long pressing the power button.
Tips:
① Blue flashing light means the camera is recording.
②Red light means the camera is charging.
③Blue light means the camera is working.
5
EnglishEnglish

FORMAT MICROSD CARD
To record normally, please make sure that you have formatted the microSD card
with the camera. If the card has not been formatted in the camera, "Insert SD Card"
will be prompted on the screen.
Enter the setup setting, press to choose “Format”, press and then press
again to confirm SD card option, press or to choose "Cancel" or "OK", press
to confirm and exit.
01:17:34
1080P60
04/28/2019 03:25:52 PM
Setup
Frequency
GPS Speed
Fatigue Driving Reminder
HZ
Format
Format
HZ
All data will be deleted
Cancel
OK
Note:
①All data will be deleted. Before formatting your memory card, please remember
to backup your important data on your other devices.
② When the microSD card is inserted for the first time, please format it in the
camera to ensure that the microSD card is compatible with the camera.
6
EnglishEnglish

RECORDING
1. Single Recording (Front Camera) 2K @30fps 1080P @60fps
①After turning on the camera, press button to stop recording.
00:00:23
1080P60
04/28/2019 03:25:52 PM
01:17:34
1080P60
04/28/2019 03:26:52 PM
Video
Loop recording
WDR
WDR
Dual cam Display
1
Front
Resolution
SIZE 2K30
1080P60
1080P DUAL1080P
②Press to enter the setting interface and choose “ ”, press to enter the
Video interface. Press to choose “Resolution”, press and choose ”2K30 or
1080P60”, press to save and exit.
7
EnglishEnglish

③Press two times to go back to the main interface, press to record. The saved
video is 2K30 or 1080P60.
01:17:34
2K30
04/28/2019 03:27:52 PM
Quick Set: Press to switch the single recording (front camera) on main interface,
press to record.
2. Dual Recording (Front and Cabin Camera) 1080P @30fps
①After turning on the camera, press button to stop recording.
00:00:23
1080P60
04/28/2019 03:25:52 PM
②Press to enter the setting interface and choose “ ”, press to enter the
Video interface. Press to choose “Resolution”, press and choose ”1080P
DUAL 1080P”, press to save and exit.
8
EnglishEnglish

01:17:34
1080P60
04/28/2019 03:26:52 PM
Video
Loop recording
WDR
WDR
Dual cam Display
1
Front
Resolution
SIZE 2K30
1080P60
1080P DUAL1080P
③Press two times to go back to the main interface, press to record. The saved
video is 1080P DUAL 1080P.
01:17:34
1080P DUAL 1080P
04/28/2019 03:27:52 PM
Quick Set: Press to switch the single recording (front camera) on the main
interface, press to record.
9
EnglishEnglish

Note: The infrared lights of the cabin-facing camera will automatically detect the
light levels inside the car and turn on if light is not sufficient. The recorded video
footage is black and white when the infrared lights are on.
PLAYING BACK VIDEOS
1. Playing back Videos on Dash Camera
You can choose to play back unlocked videos, locked videos, and parking monitor
videos. You can also choose the front camera and the inside camera.
After turning on the camera, press button to stop recording, press to play
back the videos which are stored on the card.
Playing back Unlocked Videos
①After entering the playback interface, press / to choose the folder of
unlocked videos , then press .
00:00:23
1080P60
04/28/2019 03:25:52 PM
01:17:34
1080P60
04/28/2019 03:27:52 PM
10
EnglishEnglish

②Press / to choose the folder of the front camera or inside camera video,
then press .
③Press / to choose the video you want to play, then short press to play.
1080P60
04/28/2019 15:20
1/1 00:00:06 The time schedule
of video playing.
The video's
quantity
The current video's
recording date and
time
The current video's
recording resolution
④ The video is over, press to exit.
Note:
• When playing, press one time to end playing, press twice to exit the current
playing folder.
• When playing, press to pause playing, press to go on playing.
• When playing, press / to rewind or fast forward, 2X/4X/8X for options.
• When pausing playing, press once to end playing, press twice to exit the
current playing folder.
• Long press to delete videos.
11
EnglishEnglish

Playing back Locked Videos
①After entering the playback interface, press / to choose the folder of locked
videos , then press .
②Press / to choose the folder of the front camera or rear camera video,
then press .
③Press / to choose the video you want to play, then short press to play.
1080P60
04/28/2019 15:20
1/1 00:00:06 The time schedule
of video playing.
The video's
quantity
The video is
locked
The current video's
recording date and
time
The current video's
recording resolution
12
EnglishEnglish

④ The video is over, press to exit.
Playing back Parking Monitor Videos
①After entering the playback interface, press / to choose the folder of locked
videos , then press .
②Press / to choose the folder of the front camera or rear camera video,
then press .
13
EnglishEnglish

③Press / to choose the video you want to play, then short press to play.
1080P60
04/28/2019 15:20
1/1 00:00:06 The time schedule
of video playing.
The video's
quantity
The video is
locked
The current video's
recording date and
time
The current video's
recording resolution
④ The video is over, press to exit.
2. Playing back Videos on Your Computer
Downloading Videos from the microSD Card
Option 1: Connect the dash cam to your computer's USB port via the USB cable.
Choose ”Memory Mode” on the screen of the dash cam, press .
”Mass Storage” will display on the screen of the dash cam, then you can copy the
videos from the microSD card.
USB
Record Mode
Memory Mode
Mass Storage
Note: When “Record Mode” is selected, the computer can be directly used as the
power supply to the dash cam.
In this mode, the camera will automatically start recording.
You can preview, record, change settings, etc. in real-time.
14
EnglishEnglish

Option 2: Take out the card from the dash cam, insert the card into a card reader,
and then insert the card reader into a USB port of the computer. You can now
access videos on the card.
Playing Videos on a Computer
Copy the following link to any browser to download the GPS player, and then you
can play videos from the memory card.
https://www.kingslim.net/player
Note: Please close the anti-virus software on the computer before installing the
player or click “allow” when prompted.
DOWNLOAD THE APP
Download the "RoadCam" app on the App Store or Google Play.
USE THE “ROADCAM” APP
CONNECT WITH THE APP
1. Long press the Wifi button on the bottom of camera to enter the Wifi settings
interface.
Wifi Button
D1 Pro
15
EnglishEnglish

Or short press to enter setting interface, press to and press to enter
Setup interface. Press to choose “Wifi”, press and choose “On” to enable
Wifi.
Note: WiFi is on, please
connect
SSID: DVR74ee2aad313d
PWD: 12345678
Setup
Date/Time
Time System
Screen Save
WiFi
WiFi
2. Go to your smartphone’s Wifi settings and connect to the Wifi name that’s
shown on the dash cam. Enter the password and confirm the Wifi network.
3. Open the "RoadCam" app, tap "Add Recorder", wait a few seconds to enter the
preview interface.
4. Tap the video or photo icon to control the dash cam, either recording videos or
shooting photos.
Video
Video Photo
DVR74ee2aad313dExit
2020 07 17 13:47
R
F
Recording instrument
Add Recorder
Connecting camera
16
EnglishEnglish

DOWNLOAD OR DELETE VIDEOS AND PHOTOS
1. Tap the icon to stop the recording.
2. Tap the or icon to check the videos or photos.
3. Tap "Select" and choose videos or photos that you want.
4. Tap the download or delete icon to download or delete.
Note: To exit the Wifi feature, please press the power button on the dash cam.
Video
Movie Select
Loop video Emergency video
2020/07/17 14:00
150.00MB 81.00MB
13:32:26 13:35:47
Movie Select
Loop video Emergency video
2020/07/17 14:00
150.00MB 81.00MB
13:32:26 13:35:47
Video
Video Photo
DVR74ee2aad313dExit
2020 07 17 13:47
R
F
17
EnglishEnglish

CHANGE RECORDING SETTINGS
You can change recording settings in the app.
Settings
Microphone
Cycle record time
G-Sensor sensitivity
Video resolution
Volume
Screensavers
WIFI Setting
Formatted recorder
Firmware version 1.0.0.0.20200811
Resiore factory settings
1MIN
MIDDLE
2KP30
OFF
5MIN
When the vehicle collides, the video is not covered
automatically when it is hit. It is used to provide the basis for
the accident
SETTINGS ON DASH CAM
After turning on the camera, press button to stop recording.
Video Settings
Press button to enter the system setting, choose” ”, press to enter the setting.
01:17:34
1080P60
04/28/2019 03:26:52 PM
18
EnglishEnglish
