KINGSONG KS-S18 User manual

KS-S18
User Manual

WARNING
Eletric unicycle is designed for the outdoors and short distance personal
transport.
SAFETY IS THE NUMBER ONE PRIORITY!
PLEASE RIDE UNDER LOCAL LAW!
The user manual below is a quick and convenient guide of safety & item
functions/features to end user. We can’t ensure all types of situation
emergency are covered. Therefore, we STRONGLY remind you to read
this guide very carefully, and ride with attention to ensure your safety.
Riding like all outdoor activities comes with it’s risks. You risk seroius
danger and injury if you fall, collide or lose of control when riding,
please ride with caution and at your own risk.
Thanks you for purchasing King Song smart electric unicycle!

Contents
1. Product Details-----------------------------------------------------------01
2. Safety --------------------------------------------------------------------08
3. Features -----------------------------------------------------------10
4.Precautions and Preparation -------------------------------------------11
5. Battery ------------------------------------------------------------------14
6. Care and Maintenance -------------------------------------------------15
7. Warranty----------------------------------------------------------------16

1
1. Product Detail
1.1 Diagram: KS-S18
1. Headlight
2. USB Port
3. Charger Port
4. Power Button
5. Trolley Handle
6. Trolley Handle Button
7. Pedal
8. Brake Light
9. Suspension
10. Suspension Support Frame
11. Slide/Lower
12. Outer Shell
13. Padding
14. Mud Flap
15. Battery
16. Tire

2
1.2 Specifications
Model NO
KS-S18
Top Speed
Full speed unlocked after 10km. Max speed of 50km/h
(Factory alarm settings: Level 1- 18km sound alarm
Level 2- 19km sound alarm Level 3- Sound alarm with
tiltback).
Mileage
Around 90~100km
Maximum Grade
Around 35°
Battery
Rated Power: DC 74V
Top Charging Voltage: DC 84V
Rated Capacity: 1110Wh
Smart BMS with balance and protect overshoot / over
discharge / overcurrent / short circuit / overheating
function, support monitoring the battery conditions via
KingSong APP
Operating Temperature
-10℃/+60℃
Max Load
120kg
Charger Voltage
Input AC 80~240 V / Output DC 84V、1.75A/2.5A
Charging Time
1110Wh: about 10h 1.5A / about 6h 2.5A

3
Rated Power
2200w
Max Power
5000w
Color
White / Rubber Black
Dimension & Weight
Dimension
657-557mm(H) * 530mm(L) * 200mm(W)
Package Size
630 * 295 * 750(mm)
Suspension Specification
200-57 Air suspension
Suspension Specification
Using a variable lever the wheel has dampening travel
distance of 100mm, which is transferred to the rear
spring suspension with a travel distance of 57mm.
Pedal Altitude (from ground)
210-110mm
Tire Size
18inch Diameter 3.0" inch
Weight
1110wh around 25kg
Port
Charging port、Switch port、Light sensor port、
USB discharge port
Light Up Displays
Rear light housing displays battery level, braking and
turning signals all in one unit

4
Protective Measures
Lift Sensor
Lift sensor accurately senses and determines when
wheel is lifted off the ground to stop tire rotation.
Roll Protection
45° left and right side. ( Motor stalls when over 45° )
Place the machine vertically on the ground will restart
automatically, no need to restart manually.
Speed Limit Protection
Beep alarm or voice alarm when exceed limit speed
Low Battery Protection
Low battery protection activated on 30% battery, speed
will decreases linearly; when the battery is lower than
5%, voice alarm for charge, when battery at 0%, the front
part of the pedal will rise to decelerate until full stop
Higher Temperature
Protection
When the motherboard reaches 80℃it will result
tilt back. When the motor reaches 120℃it will result in tilt
back.
Alarm & Features
Switch On/Off
Short press power key: turn on
Long press: hear a click then turn off

5
Battery Indicate
Led shows battery level when EUC power on at rest
Hardware Features
Main board
he motherboard is designed with a 4 layer structure,
allowing for better stability performance. 12 large
individual TO-247 imported MOS to sufficiently support
the 2200W motor. MOS is attached to the aluminum
body frame of the wheel for better heat dissipation.
Bluetooth
Bluetooth 4.0. Allowing strong stable data transmission
USB Output
Quick charge 3.0
Front Light
2*5w light high beam with 2*4w short beam. Double the
strength of the 16x, providing excellent illumination at
night.
Temperature System
Temperature of the motherboard is continuously closely
monitored to ensure rider safety.
Handle
Aluminum constructed handle designed for ergonomic
pushing of the wheel or lifting of the wheel.
Motor
Higher power 2200w motor that provides a maximum
torque of 140N.m providing fast acceleration

6
Suspension System
Unique X shaped suspension system. Racing level
suspension provides the ultimate support and shock
absorption
Package
Standard Accessories
1x Charger, 1x Manual, 1x Pump, 1x Warranty card,
1x QC certificate
1.3 Features
1.3.1 Sports Bike inspired design. Aerodynamics with air intake
system. Aggressive curvature design.
1.3.2 Variable Linkage dampening air suspension system using
200-57 suspension.
a. X shaped suspension travel of 100mm.
b. Suspension is interchangeable and allows for personal
modification and custom ride style.
c. Adjustable air suspension system from on to off. Off state still
reacts to big bumps but will ride similar to a wheel without
suspension.

7
d. Rotary switch for sensitivity adjustment.
e. Different pressurization can be adjusted to according to rider
weight.
1.3.3 Padding designed in cooperation with Kujirolls.
1.3.4 User Experience focused ergonomic design to connect wheel
with rider.
1.3.5 12 MOS design connected to aluminum body frame for fast
heat dissipation without the need of fan.
1.3.6 Headlights are 2 times stronger to the 16X with 2*5w (high
beam) and 2*4w (short beam) with automatic sensor to switch
between modes.
1.3.7 Ergonomic handle designed for pushing and lifting which can
be hidden inside body frame when not in use.
1.3.8 First ever high performance wheel with limited wiring with all
key components housed on PCB.
1.3.9 Rear light displaying battery level, braking and turning signals
all within one singular unit.
1.3.10 21700 Battery system for better; efficiency to space ratio.

8
2. Safety
As an outdoor sport and auxiliary transport device, serious injury
may occur any time during riding. PLEASE BE CAUTIOUS ALL THE
TIME, LEARN AND PRACTISE STEP BY SETP BEFORE IT REGULARLY.
READ THE INSTRUCTIONS THROUGHLY AND CAREFULLY TO LIMIT
THE RISK OF INJURY.
2.1 Important
•Do not make rapid acceleration or deceleration or over incline
forward or lean backwards.
•Do not use the EUC if there are any risks of accidental fails.
•When there is alarm of over power, over voltage, low battery,
please decelerate at once.
•Please keep in mind deeply: most accidents are caused by rapid
acceleration or deceleration. So please operate EUC properly to
protect the device and yourself.
2.2 Attention
•Please wear helmet, gloves. Elbow/Knee pads or other protection
garments.

9
•Please check the device before ever ride to make sure no parts are
loose or damaged.
•When there are crowded pedestrians, please slow down to match
their walking speed.
•When carry the device, please make sure the power is off.
•Do not ride on highways or any other prohibited places.
•Do not ride on rough or bumpy surfaces, such as muddy or
pebbled roads.
•Do not ride on wet, slippery surfaces, especially snowy roads.
•Any person under 12 is strictly prohibited to use the EUC.
•Do not ride in bleak winter conditions.
•Riding backwards is dangerous. Try to avoid riding backwards
unless safety guaranteed.
•Don’t jump with the EUC.
Other sudden unpredictable risks may occur during use, please ride
with care. Kingsong Intell Co.,LTD will not be responsible for any
injuries caused by unproperly operations of the device.

10
3. Features
3.1 Integrated trolley bar
3.2 Front illuminating light & Rear Brake light
3.3 APP
• For Android apk: Please access to our official website:
www.kingsong.com, android apk can be downloaded.
• For IOS app: Please download from apple store, ‘kingsong’ is
the exact one.
KINGSONG APP(Android) KINGSONG APP(IOS)
3.4 Riding Mode
Riding Mode refers to the torque during start-off and braking.
Expert Mode / Riding Mode / Learner Mode decelerate,

11
turning and so on.
Riding mode and Expert mode is for rider who want more
performance.
Experient mode can satisfy the group who wants to perform
skills like jumping, also it can avoid pedal tilt back when
climbing up or down steep hills.
3.5 Self-inspection and horizontal calibration
Firstly, switch on the EUC and keep it standing still on the
ground until it finds it’s balance. Then login to the APP and
connect with the wheel to check the device information.
4. Precautions and Preparation
4.1 Precautions
•Please find a smooth surface to practice on.
•Warm up your body and ensure you're wearing safety gear such
as helmets, knee pads, elbow pads and wrist guards.
•Ensure the wheel's battery level.
•Check the unicycle for imperfections such as any looseness,
abnormal sound. We also highly suggest pushing the unicycle
by ahnd to see if there's any friction between tire and the case

12
of the wheel.
•Have a friend assist you if required.
•Please do not accelerate or decelerate rapidly, please also try to
avoid over leaning or leaning too fast to prevent rider injury.
•Padding up the wheel during the learning process is highly
recommended to ensure minimal scrapes on the exterior of the
wheel.
4.2 How to use
4.2.1 Starting on the unicycle
Hold the wheel with one hand and ensure the wheel sits
vertically on the ground. Unfold the pedals and switch on the
wheel, it will self-balance forwards and backwards, if it does
not, please ensure the wheel is upright. Quick pressing the
power button once the wheel is on will toggle different light
modes.
4.2.2 Standing on the unicycle
With the pedals unfolded on both sides please stand on it with
your preferred foot in the center of the pedal. Balance the
wheel under you by keeping the other foot on the other side of
the wheel. If you are left footed, keep your other foot at around

13
5 o’ clock, and if you are right footed please keep the other foot
at around 7 o’clock.
If you are having a difficult time balancing the wheel under you
make sure you find a centre point of balance between these
three points: a) bottom of the tire b)where the top of you leg
touches the wheel c) your foot. Finding the balance point
between these three points will allow you to more easily
control the wheel under you.
4.2.3 Learning to ride forwards and braking
Whilst having the wheel balanced under you, use your
non-preferred foot to push off and lean forwards to begin going
forwards, once the wheel gets going please put your
non-preferred foot back onto the wheel. Focus on balancing and
not falling left or right. Try to look ahead rather than down!
Have your hands out to help you balance!
To come to stop simply lean backwards and the wheel will slow
down and come to a stop. You may dismount your
non-preferred foot when standing.
Note: The harder you lean forwards or backwards will dictate
the speed in which the wheel accelerates and decelerates.

14
4.2.4 Turning
When turning, lean your body gently to the side in which you want
to go and straighten up when you want to go straight again! As
you become more experienced at riding you will find other ways
to turn such as; letting the wheel fall just side to side, just turning
the lower part of your body, leaning your entire body. Advanced
riders will usually incorporate a combination of these.
5. Battery
5.1 Temperature effect on battery
Battery power will vary with the temperature, mileage per charge
will have slight difference under different temperature, following
table is just for your reference.
Temperature（℃）
-20
-10
0
10
20
30
40
50
174Wh using ratio
40%
60%
80%
90%
95%
100%
105%
110%
MPU（Km）
8
12
16
18
19
20
21
22
MPC: Mileage per fully charge
5.2 Charging
Forbidden to use chargers not original from factory to avoid
accident.

15
The device has a built-in lithium battery, no extra battery
installation is required, just charge the device when it indicates
low battery.
6. Care and Maintenance
6.1 Conservation
Don’t place the unicycle in a wet condition.
If left unused, recharge the battery at least once a month to avoid
the battery exhausted and maintain longevity of the battery.
Meanwhile, the battery can’t be dismantled, in case of changing,
please contact us, we will provide you with professional services.
Clean the unicycle with wet cloths and detergent, gasoline, solvent
or any other chemical reagent are forbidden.
Use the inflation tube to inflate the tire. Without the tube, you will
not be able to pump air into the wheel.

16
7. Warranty
7.1 Limited Warranty
Manufacturer Kingsong Intell Co., LTD warrants the EUC by
following limits.
Motor, Controller board for 365 days from the item departure
from factory.
Battery package for 183 days from the item departure from
factory.
Warranty is valid only within a total mileage of 2000km.
7.2 Limited Warranty
Above limited warranty DOES not include damage or lose not
caused item’s defectives (i.e. warranty only covers manufacturer
defectives, Does not cover any damage, unauthorized
modification, improper operation, disassembly etc.).
7.3 After sale service
If need after sale service, please kindly contact your local dealer,
distributor for assistant.

1
Kingsong Intell Co.,LTD
Address : BLDG 7, NO 71 XINGHU RD, 8TH INDUSTRY PARK, HONGXING,
YUTANG,GUANGMING,SHENZHEN
Tel : [phone]
Fax : [phone]
E-mail : [email protected]
