Kipor IG1000 User manual

Beside Jingyi Road
Third Stage Development Section of
Wangzhuang Industry Area, Wuxi High &
New Technology Industry Development Zone
Wuxi, Jiangsu Province, PRC
TEL: [phone]
FAX: [phone]
E-MAIL: [e-mail]
Version 1, Printing date June 1, 2011
MADE IN CHINA
SINEMASTER DIGITAL GENERATOR
IG1000, IG1000P
IG2000, IG2000P
IG2600, IG2600P
OPERATION MANUAL

1
PREFACE
Thank you for purchasing a Kipor generator.
This manual covers operation and maintenance of the IG1000, IG2000, andIG2600 generators
including parallel versions.
All information in this publication is based on the latest product information available at the time of
approval for printing.
We reserve the right to make changes at any time without notice and without incurring any
obligation.
No part of this publication may be reproduced without written permission.
This manual should be considered a permanent part of the generator and should remain with it if it
is resold.
Pay special attention to statements preceded by the following words:
Failure to properly follow these precautions can result in property damage,
serious injury or DEATH!
Read all labels and the owner's manual before operating this generator.
Generators produce carbon monoxide, a poisonous, colorless, odorless
gas that can cause death or serious injury.
Indoor use of a generator can kill quickly. Generators should be used
outdoors only
Generators should be used outdoors only and away from garages and
open windows and protected from rain and snow.
Check for spilled fuel or leaks. Clean and/or repair before use.
Always stop engine before refueling. Wait 5 minutes before restarting.
Keep any source of ignition away from fuel tank, at all times.
The portable generator is not meant to be used as a permanent back-up
power system for the home. A permanently installed stationary generator
is designed to be safely used for this specific purpose.
Indicates a strong possibility of severe personal injury or death if
instructions are not followed.
Indicates a possibility of personal injury or equipment damage if
instructions are not followed

2
Gives helpful information.
If a problem should arise, or if you have any questions about the generator, consult an authorized
dealer.
Our generators are designed to give safe and dependable service if operated according to
instructions. Read and understand the Owner's Manual before operating the generator. Failure to
do so could result in personal injury or equipment damage.

3
CONTENTS
PREFACE .................................................................................................................... 1
1. SAFETY INSTRUCTIONS....................................................................................... 4
2. SAFETY LABEL LOCATIONS ................................................................................. 6
3. COMPONENT IDENTIFICATION............................................................................ 7
4. PRE-OPERATION CHECK...................................................................................... 10
5. STARTING THE ENGINE........................................................................................ 14
6. GENERATOR USE .................................................................................................. 16
7. STOPPING THE ENGINE ....................................................................................... 26
8. PARALLEL GENERATOR OPERATION ................................................................ 27
9. MAINTENANCE ....................................................................................................... 30
10. TRANSPORTING/STORAGE................................................................................ 38
11. TROUBLESHOOTING........................................................................................... 40
12. SPECIFICATIONS .................................................................................................42
13. WIRING DIAGRAMS............................................................................................. 43
14. WARRANTY........................................................................................................... 45
15. APPENDIX A- IG2600H HANDLE ...................................................................... 51
16. APPENDIX B- MOBILE LIGHT KIT..................................................................... 52

4
1. SAFETY INSTRUCTIONS
■This generator is designed to give safe and dependable service if
operated according to instructions.
Read and understand the Owner's Manual before operating the
generator. Failure to do so could result in personal injury or
equipment damage.
■Exhaust gas contains poisonous carbon monoxide. Never run the
generator in an enclosed area.
Be sure to provide adequate ventilation.
■The muffler becomes very hot during operation and remains hot for
several minutes after stopping the engine.
Be careful not to touch the muffler while it is hot.
Let the engine cool before storing the generator indoors.
■The engine exhaust system will be heated during operation and
remain hot immediately after stopping the engine.
To prevent scalding, pay attention to the warning marks attached to
the generator.
■Gasoline is extremely flammable and explosive under certain conditions. Refuel in a well
ventilated area with the engine stopped.
■Keep away from smoking materials,sparks and other sources of combustion when refueling
the generator. Always refuel in a well-ventilated location.
■Wipe up spilled gasoline immediately.
.

5
■Always make a pre-operation inspection before you start the engine. You may prevent an
accident or equipment damage.
■Place the generator at least three feet or one meter away from buildings or other equipment
during operation.
■Operate the generator on a level surface to prevent fuel spillage or oil starvation.
■Know how to stop the generator quickly and understand operation of all controls. Never
permit anyone to operate the generator without proper instructions.
■Keep children and pets away from the generator when it is in operation.
■Keep away from rotating parts while the generator is running.
■The generator is a potential source of electrical shock when misused; do not operate with wet
hands.
■Do not operate the generator in rain or snow and do not let it get wet.

6
2. SAFETY LABEL LOCATIONS
These labels warn you potential hazards that can cause serious injury. Read the labels and safety
notes and precautions described in manual carefully.
If a label comes off or becomes hard to read, contact your dealer for a replacement.
3. COMPONENT IDENTIFICATION
CHOKE LEVER
LOW OIL ALARM
ENGINE SWITCH
HOT CAUTION
SAFETY CAUTION
MODEL

7
FUEL CAP VENT LEVER (Non CARB)
CHOKE LEVER
MAINTENANCE
COVER
STARTER GRIP
ENGINE SWITCH
TYPICALCONTROL
PANEL
FUEL FILLER CAP
SPARK PLUG
MAINTENANCE
COVER
MUFFLER
AIR INTAKE
AIR EXHAUST

8
Control panel
Parallel Control Panel
Smart throttle
switch
DC receptacle
Ground terminal
AC receptacle
overload protector
Parallel Receptacles
Low oil alarm
indicator light
overload indicator
light
output indicator
light
Smart throttle
switch
DC receptacle
Ground terminal
AC receptacle
overload protector
Low oil alarm
indicator light
overload indicator
light
output indicator
light
Overload reset switch
Overload reset switch

9
Serial number identification and location
The generator serial number identifies your particular unit and is important when ordering parts
and accessories. The number is found on a sticker on the carton and on the quality certificate in
the carton along with the accessories and owner’s manual. It is also stamped on the engine block
visible when the service door is removed.
IG1000: to the right of the engine oil dipstick IG2000:above right of the dipstick
IG2600: to the left of the engine oil dipstick
Please record this information below and keep this manual in a safe place along with the bill of
sale.
Serial Number __________________________________
Date and Place of Purchase ______________________________________________________

10
4. PRE-OPERATION CHECK
■Be sure to check the generator on a level surface with the engine stopped.
1. Check the engine oil level.
■Using non detergent oil or 2 cycle engine oil could shorten the engine's service life.
Use a high-detergent, premium quality 4-stroke engine oil, certified to meet or exceed U.S.
automobile manufacturer's requirements for API Service Classification SG/SF. Select the
appropriate viscosity for the average temperature in your area.
SAE Viscosity Grades
AMBIENT TEMPERATURE
Loosen the cover screw and remove the left side maintenance cover. Remove the oil filler cap,
and wipe the dipstick with a clean rag. Check the oil level by inserting the dipstick in the filler hole
without screwing it in.
If the oil level is below the end of the dipstick, refill the recommended oil up to the top of the oil
filler neck.
■Runningtheenginewithinsufficientoilcancauseseriousenginedamage.
Single
Viscosity
Multi-
viscosity

11
NOTE: The Low Oil Alarm System will automatically stop the engine before the oil level falls
below the safe limit. However, to avoid the inconvenience of an unexpected shutdown, it is still
advisable to visually inspect the oil level regularly.
You must screw down the dipstick completely to measure the oil level.
2. Check the fuel level.
Use automotive unleaded regular gasoline only. A fuel preservative and stabilizer should be
added to any container of stored fuel.
If the fuel level is low, refill the fuel tank until the level reaches the specified mark.
Never use an oil/gasoline mixture or dirty gasoline.
Avoid getting dirt, dust or water in the fuel tank.
After refueling, tighten the fuel filler cap securely.
■Gasoline is extremely flammable and is explosive under certain conditions.
■Refuel in a well-ventilated area with the engine stopped. Keep all smoking materials, sparks,
and any other source of combustion away from the generator during refueling.
■Do not overfill the fuel tank (there should be no fuel above the upper limit mark). After
refueling, make sure the tank cap is closed properly and securely.
■Be careful not to spill fuel when refueling. Spilled fuel or fuel vapor may ignite, If any fuel is
spilled, make sure the area is dry before starting the engine.
■Avoid repeated or prolonged contact with skin or breathing of vapor. KEEP OUT OF REACH
OF CHILDREN.
Oil gauge
Oil FILLER HOLE
UPPER LEVEL
UPPER LEVEL
UPPER LEVEL

12
Gasoline containing alternate fuels
If you decide to use a gasoline containing ethanol, be sure its octane rating is no lower than the
specification. Do not use a blend that contains more than 10% ethanol. Do not use gasoline
containing methanol.
■Fuel system damage or engine performance problems resulting from the use of fuels that
contain an improper alcohol blend are not covered under warranty.
■Before buying fuel from an unfamiliar station, Determine if the fuel contains ethanol and if it
does, confirm the type and percentage of ethanol used. If you notice any undesirable
operating symptoms while using a gasoline that contains ethanol, or one that you think
contains ethanol, replace it by a gasoline that you know has the proper blend.

13
3. Check the air cleaner
Check the air cleaner element to be sure it is clean and in good condition.
Loosen the cover screw and remove the left side maintenance cover.
Press the latch tab on the top of the air cleaner body, remove the air cleaner cover, check the
element. Clean or replace the element if necessary.
■Never run the engine without the air cleaner. Rapid engine wear will result from contaminants,
such as dust and dirt, being drawn through the carburetor, into the engine.
CARBONCANISTER
MAINTENANCE COVER
MAINTENANCE COVER
SCREW
AIR CLEANER BODY
AIR CLEANER COVER
AIR CLEANER
COVER SCREW
AIR CLEANER ELEMENTS

14
5. STARTING THE ENGINE
Before starting the engine, disconnect any load from the AC receptacle.
1. Turn the engine switch to the ON position.
2. Move the choke lever to the START position.
NOTE:
Do not use the choke when the engine is warm or the ambient air temperature is high.
3. Pull the starter grip until resistance is felt thenpull the starter grip briskly toward the
arrow as shown below.
ON
OFF
ON
ENGINE SWITCH
CHOKE LEVER
START
START

15
■Donotallowthestartergriptosnapback.Return it slowly by hand.
4. Move the choke lever to the RUN position after the engine warms up.
■If the engine stops and will not restart, check the engine oil level before further
troubleshooting.
STARTER GRIP
CHOKE LEVER
RUN
RUN

16
6. GENERATOR USE
Be sure to ground the generator when loads are connected.
■To prevent electrical shock from faulty appliances, the generator should be grounded.
Connect a length of heavy cable between the generator's ground terminal and an external
ground source.
■Connections for standby power to a building's electrical system must be made by a qualified
electrician and must comply with all applicable laws and electrical codes. Improper
connections can allow electrical current from the generator to back feed into the utility lines.
Such back feed may electrocute utility company workers or others who contact the lines
during a power outage. When utility power is restored the generator may explode, burn, or
cause fires in the building's electrical system.
■Do not connect the generator to an automatic transfer device. Severe damage to the inverter
module may result.
GROUND MARK
GROUND TERMINAL

17
■The total wattage of all appliances connected must be considered.
■Do not exceed the current limit specified for any one receptacle.
■Do not connect the generator to a household circuit. This could cause the damage to the
generator or to electrical appliances in the house.
■Do not modify or use the generator for other purpose than it is intended for. Also observe the
following when using the generator.
■Do not connect an extension to exhaust pipe.
■When an extension cable is required, be sure to use a rubber sheathed flexible cable (IEC
245 or equivalent).
■Limit length of extension cables to 195 ft (60 m) for cables of 1.5mm2and 325 feet (100 m) for
cables of 2.5mm2. Long extension cables will reduce usable power due to resistance in the
extension cable.
■Keep the generator away from other electric cables or wires such as commercial power
supply lines.
■The DC receptacle can be used while the AC power is in use. If you use both at the same time,
be sure not to exceed the total power for AC and DC.
■Most appliance motors require more than their rated wattage for start-up.

18
AC application
1. Start the engine and make sure only the output indicator light (green) comes on.
2. Confirm that the appliance to be used is switched off, and plug in the appliance.
■Substantial overloading that continuously lights the overload indicator light (red) may damage
the generator. Marginal overloading that temporarily lights the overload indicator light (red)
may shorten the service life of the generator.
■Be sure that all appliances are in good working order before connecting them to the generator.
If an appliance begins to operate abnormally, becomes sluggish, or stops suddenly, turn off
the generator engine switch immediately. Disconnect the appliance and examine it for signs
of malfunction.
3. In order to insure the optimum output and the maximum service life of the generator, the
generator should run at a 50% load for the first 20 hours.
overload indicator
light
output indicator
light
插头
plug

19
Output and Overload Indicators
The output indicator light (green) will remain on during normal operating conditions.
If the generator is overloaded or if there is a short in the connected appliance, the output indicator
light (green) will go out, the overload indicator light (red) will illuminate and current to the
connected appliance will be shut off.
Stop the engine if the overload indicator light (red) comes on and investigate the overload source
■Before connecting an appliance to the generator, check that it is in good order and that its
electrical rating does not exceed that of the generator. Connect the power cord of the
appliance and start the engine.
OVERLOAD INDICATOR LIGHT (RED) OUTPUT INDICATOR LIGHT (GREEN)
■When an electric motor is started, both the overload indicator light (red) and the output
indicator light (green) may go on simultaneously. This is normal if the overload indicator light
(red) goes off after about four (4) seconds. If the overload indicator light (red) stays on,
consult your generator dealer.
