I NSTRUCT I ON MANUA L
P T 6 2 0 0
FM H ANDH EL D T RANS CE IV E R

NOTE
I NSTRUCT I ON MANUA L
P T 6 2 0 0
FM H ANDH EL D T RANS CE IV E R
We are very grateful for your purchasing brand
transceivers produced by Kirisun Electronics
(Shenzhen) Co., Ltd.
We believe transceiver, which always
incor-porates the latest technology, can bring great
convenience to your life and work; we also believe that
the quality and function of transceiver can meet your
demands for reliable communication.
NOTICE TO THE USER:
Government laws prohibit radio communication without
permission in government districts.
Illegal operation is punishable by fine and/or imprison-
ment.
Refer service to the well-trained professional
techni-cians only.
31

6.
8
Emergency
Alert
16
7
Auxiliary
Functions
17
7.1
Time
-
out
Timer
(
T
OT)
17
7.2 Battery Saving 17
7.3 Low Battery Warning 18
7.4 VoiceAnnunciation of Channel Number 18
7.5 Busy Channel Lockout (BCL) 18
7.6 Clear TailTone 19
7.7 Remote Kill 19
7.8 CTCSS/ DCS 19
7.9 DTMF 20
7.10 KDC 1200 21
7.11 2-Tone 21
7.12 5-Tone 22
7.13 Transmitting Beginning/ Ending Signaling 23
8
Troubleshooting 24
9
Technical
Specifications
26
10
Settings
(by
the
Dealer)
27
CONTENTS 6.7 Wireless Clone 15
1
Unpacking and Checking the Equipment
1
1.1 Supplied Accessories
1
2
Preparation 2
2.1 Battery Care Tips 2
2.2 Battery Recycling and Disposing 3
2.3 Charging the Battery 3
3
Accessories 5
3.1 Installing/ Removing the Battery Pack 5
3.2 Installing the Antenna 6
3.3 Installing the Belt Clip 6
3.4 Installing the DustCover over the Versatile Connector 6
3.5 Installing the Optional Speaker/ Microphone 7
4
Getting Acquainted 7
4.1 Transceiver Overview 7
4.2 Programmable Auxiliary Functions 9
5
Basic Operation 10
6
Advanced Operations 11
6.1 Key Lock(Backup)
11
6.2 Monitor/Squelch off 12
6.3 Scan 12
6.4 CALL 1/ CALL 2 14
6.5 Scrambler (Backup) 14
6.6 VOX 14

ITEM
QUANTITY
Antenna
1
Belt clip
1
Dust cover 1
Screw 1
Battery
1
Charger 1
Power adapter 1
User's manual
1
Hand strap
1
1UNPACKING AND CHECKING THE EQUIPMENT
Unpack the transceiver carefully. We recommend
that you identify the items listed in the
following table before discarding the packing
material. If any items are missing or have been
damaged during shipment, please contact the dealer
immediately.
1.1 Supplied Accessories
2PREPARATION
2.1 Battery Care Tips
The transceiver is equipped with a KIRISUN Li-
ion/Ni-MH Battery Pack, the following using tips of which
can help you to get the best battery performance and
longest battery life.
1) Charge the new battery pack continuously for
4~7 hours before its initial using, which ensures the
maximum battery capacity and best performance in using.
2) Charging the battery pack in non-KIRISUN equipments will
cause battery damage and the battery warranty invalid.
3) The battery pack can be charged while in the
transceiver, and to ensure it is fully charged it's
recommended to charge the battery pack with the
transceiver turned off.
4) The ideal temperature to store the battery pack
is 25
(room temperature). Charging the battery pack at
a low temperature (below 0 ) will cause electrolyte
leakage and damage to the battery pack.
5) Charging the battery pack at a high temperature
(above
45 ) will cause decrease in battery discharge capacity and
affect the transceiver performance. The KIRISUN
rapid charger has a temperature sensor, which
ensures the battery is charged within the temperature
range mentioned
Antenna Power adapter Belt clip Battery
above.
6) A new battery shows no significant life shortening even
after two-year storage. The new or used battery should be
stored in
a
cool
and
dry
place
.

Charger
Dust cover Screw Hand strap
7) If recharge the battery pack after long storage, you should
charge it continuously for 4~7 hours.8) Do not
leave the
12

Charger Indicator
Status
Red
The battery is in the state of charging.
Green
The battery is in full charge or the
charger
is not connected with the battery.
Flashing red Pre-charge
Yellow
The battery temperature is abnormal.
Dim
The battery is damaged and unable to
be charged.
transceiver and battery in the charger when not
charging. Overlong charging will shorten the battery
life. (Please do not use the charger as the transceiver's
mounting bracket.)
9) Please use KIRISUN charger to ensure battery normal
work and prolong its life. The battery and charger
are designed under an integrated concept of power system.
2.2 Battery Recycling and Disposing
After the battery life expires, the Li-ion battery
can be recycled.
KIRISUN goes in for the recycling of all the
rechargeable batteries. For more details please
contact your local KIRISUN dealer.
2.3 Charging the Battery
A new battery, or a battery the power of which appears low
needs charging before using.
Note:
The battery is not fully charged in the factory, and probably
the new battery is falsely indicated as full charge. Before the
initial use, please charge the new battery
continuously for
4~7 hours.
1 ) Connect the power adapter
with the battery charger.
Plug the adapter into an
AC wall outlet and the
indicator turns green.
2 ) Place the battery or transceiver
into the charger slot.
The indicator turns red or
flashes, then the charger
gets in the state of
charging automatically.
Charging time depends
on battery capacity. When
battery is fully charged
the indicator turns green.
Notes:
1) The battery is not fully charged in the factory.
Before the initial use, please charge the new battery
continuously
for

34

2) The charger will stop charging and the indicator turns yellow
if the charger detects the battery is damaged
or if the temperature of the battery is too high (higher
than 50 for Ni-MH battery or 40 for Li-ion battery).
3) Do not charge the battery longer than the specified
time.
And do not charge the battery again if it is
charged fully, otherwise, its life will be
shortened or it will be damaged.
3.2 Installing the Antenna
Screw the antenna into
the connector at the top
of the transceiver by
holding the bottom of
the antenna and turn it
clockwiseuntilsecure.
3Accessories
3.1 Installing/Removing the Battery Pack
To install the battery pack:
1) Match the 3 bulges
of the battery pac k
with the corresponding
holes at the rear bottom of the
transceiver;
2) Then firmly press the
battery pack downwards to
lock it in place until a click is
heard.
To remove the battery pack:
1) Use your thumb to press the
belt clip, and one side of your
index finger to press the
release button;
2) And then pull the battery
away from the transceiver.
3.3 Installing the Belt Clip
Match the grooves of the
belt clip with those on the rear of
the battery. Then press the belt
clip downwards to lock it in place.
3.4 Installing the Dust Cover over
the Versatile Connector
When not using the
optional Speaker/Microphone,
install the dust cover over
the versatile connector with the
supplied screw.
