KitchenAid KFP0718L User manual

KFP0718L
KFP0718

PARTS AND FEATURES
PARTS AND ACCESSORIES
Heavy-duty
base
Power cord and
cord storage
(not shown)
Lid latch
Drive pin
Lid hinge
Handle hinge
Reversible
slicing/shredding
disc
Drive adapter Multipurpose
stainless steel
blade
Work bowl
cover with
2-in-1 feed
tube
2-piece
food pusher
7-cup (1.7 L)
work bowl

ENGLISH
FOOD PROCESSOR SAFETY | 3
FOOD PROCESSOR SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions.
2. To protect against risk of electrical shock, do not put Food Processor in water or
other liquid.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge, unless they are closely supervised and instructed concerning use
of the appliance by a person responsible for their safety. Close supervision is
necessary when any appliance is used by or near children. Children should be
supervised to ensure that they do not play with the appliance.
4. Turn the appliance OFF, then unplug from the outlet when not is use, before
assembling or disassembling parts and before cleaning. To unplug, grasp the
plug and pull from the outlet. Never pull from the power cord.
5. Avoid contacting moving parts.
6. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest Authorized Service Center for examination, repair, or
adjustment.

4 | FOOD PROCESSOR SAFETY
FOOD PROCESSOR SAFETY
7. The use of attachments not recommended or sold by KitchenAid may cause re,
electric shock, or injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter.
10. Keep hands and utensils away from moving blades or discs while processing
food to reduce the risk of severe injury to persons or damage to the Food
Processor. A scraper may be used, but must be used only when the Food
Processor is not running.
11. Blades are sharp. Handle carefully.
12. To reduce the risk of injury, never place cutting blade or disc on base without rst
putting bowl properly in place.
13. Be certain cover is securely locked in place before operating appliance.
14. Never feed food by hand. Always use the food pusher.
15. Do not attempt to defeat the cover interlock mechanism.
16. Do not ll the bowl above the marked maximum ll line (or rated capacity) to
avoid risk of injury due to damage to the cover or bowl.
SAVE THESE INSTRUCTIONS
ELECTRICAL REQUIREMENTS
This product is designed for household use only.
Voltage: 120 VAC
Frequency: 60 Hz
NOTE: This Food Processor is equipped
with a polarized plug (one blade is wider
than the other). To reduce the risk of
electrical shock, this plug will fit in a
polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a
qualified electrician. Do not modify the
plug in any way.

ENGLISH
USING THE FOOD PROCESSOR | 5
USING THE FOOD PROCESSOR
ACCESSORIES SELECTION GUIDE
ACTION SETTING FOOD ACCESSORY
Chop Low or Pulse
Cheese
Chocolate
Fruits
Fresh herbs
Nuts
Tofu
Vegetables
Multipurpose stainless steel blade
+
Mince or Purée High or Pulse
Mix Low
Pasta Sauce
Pesto
Salsa
Sauces
Batters
Knead High or Pulse Doughs
Slice
Low
Fruit (soft)
Potatoes
Tomatoes
Vegetables (soft)
Reversible slicing/shredding disc
(slicing side)
+
High
Cheese
Chocolate
Fruits (hard)
Vegetables (hard)
Shred
(fine to medium)
Low Potatoes
Vegetables (soft) Reversible slicing/shredding disc (shredding side)
+
High
Cabbage
Cheese
Chocolate
Fruits (hard)
Vegetables (hard)
FOR DETAILED INFORMATION ON USING THE FOOD PROCESSOR
Visit www.kitchenaid.com/quickstart for additional instructions with videos, inspiring
recipes, and tips on how to use your Food Processor.

6 | USING THE FOOD PROCESSOR
USING THE FOOD PROCESSOR
Before using your Food Processor for the first time, wash all parts and accessories either
by hand or in the dishwasher (see the “Cleaning the Food Processor” section). Your Food
Processor is designed so that all accessories may be stored inside the work bowl.
BEFORE FIRST USE
ASSEMBLING THE FOOD PROCESSOR
IMPORTANT: Place the Food Processor on a dry, level countertop with the controls
facing forward. Do not plug in the Food Processor until it is completely assembled.
1
Place the work bowl on the base,
aligning the handle with the raised
button on the right side of the base.
The bowl will click into place and
should be flush against the base
when properly aligned.
2Place the drive adapter in the work
bowl, lowering it onto the drive pin.
1
Lift up the lid latch to unlock the
cover. Tilt the work bowl cover back
and lift it straight up so that the lid
hinge pulls out of the handle hinge.
2Remove all parts and accessories
from the work bowl, and lift the food
pusher out of the feed tube.

ENGLISH
USING THE FOOD PROCESSOR | 7
USING THE FOOD PROCESSOR
NOTE: For ease of assembly, install the desired blade or disc before attaching
the work bowl cover.
NOTE: Your Food Processor will not
operate unless the work bowl cover is
fully closed and the work bowl is properly
seated on the base.
3To attach the work bowl cover, hook
the lid hinge into the handle hinge on
the work bowl and close the cover. 4Once the work bowl cover is closed,
push the lid hinge down into the
locked position.
INSTALLING THE MULTIPURPOSE BLADE
1Place the blade on the drive adapter.
Rotate the blade so it falls down to
the base of the adapter. 2Install the work bowl cover, and be
sure the lid latch is pushed down to
the locked position.

8 | USING THE FOOD PROCESSOR
Alignment
marks
USING THE FOOD PROCESSOR
INSTALLING THE REVERSIBLE SLICING/SHREDDING DISC
1
To slice: Turn the disc so that the
raised slicing blade is facing up.
To shred: Turn the disc so that the
small, raised shredding blades are
facing up.
The disc can be placed in two different
positions: level with the top of the bowl
for processing, and lower, inside of the
bowl, for storage.
NOTE: While the disc will operate in
storage position, it will not perform as
well. Make sure the disc is level with the
top of the bowl for best performance.
2
Hold the disc by its center hub and
lower it onto the drive adapter,
aligning the mark on the center hub
of the disc to the matching mark on
the adapter. When properly placed,
the disc should be level with the top
of the bowl. If the disc falls to the
storage position, lift it out, turn it 90°,
and lower it again.
3Install the work bowl cover, and be
sure the lid latch is pushed down to
the locked position.
Process
Storage

ENGLISH
USING THE FOOD PROCESSOR | 9
OPERATING THE FOOD PROCESSOR
Before operating the Food Processor, be
sure the work bowl, blades/disc and work
bowl cover are properly assembled on
the base (see the “Assembling the Food
Processor” section).
Rotating Blade Hazard
Always use food pusher.
Keep ngers out of openings.
Keep away from children.
Failure to do so can result in
amputation or cuts.
USING THE FOOD PROCESSOR
1
To turn on, press LOW or HIGH. The
Food Processor will run continuously
and the indicator light will glow.
To turn off, press LOW or HIGH again,
or press OFF/PULSE.
2
To use the Pulse function:
Press OFF/PULSE for short bursts,
or press and hold for longer bursts.
The Pulse function runs at high
speed only. The Food Processor will
turn off when the Off/Pulse button
is released.
3
When finished, press the OFF/PULSE
button. The indicator light will go
out and the blade or disc will slow
to a stop.
4
Wait until the blade or disc comes to
a complete stop before removing the
work bowl cover. Be sure to turn off
the Food Processor before removing
the work bowl cover, or before
unplugging the Food Processor.

10 | USING THE FOOD PROCESSOR
USING THE 2-IN-1 FEED TUBE
USING THE FOOD PROCESSOR
The 2-in-1 feed tube features a 2-piece
food pusher. To slice or shred small items,
insert the 2-piece food pusher into the
feed tube.
Use the small feed tube and pusher to
process small or slender items, like single
carrots or celery stalks.
To slowly drizzle oil into ingredients, just fill
the small pusher with the desired amount
of oil. A small hole in the bottom of the
pusher will drizzle the oil at a constant rate.
2-piece
food
pusher
1
Turn the Food Processor off:
Press the OFF/PULSE button and
unplug the Food Processor before
disassembling.
2Lift the lid latch to unlock the work
bowl cover, then lift cover to remove.
REMOVING PROCESSED FOODS
3If using the disc, remove it before
removing the bowl. Holding the disc
by the center hub, lift it straight up. 4
Remove the drive adapter and
multipurpose blade, if using. The
blade will stay in place on the drive
adapter when you remove the
adapter.
