KitchenAid 5FGA Quick guide

English
®
Model 5FGA
Food Grinder
Model 5FVSP
Fruit/Vegetable
Strainer
Model 5FVSFGA
Fruit/Vegetable
Strainer and
Food Grinder
Designed exclusively for
use with all KitchenAid®
Household Stand Mixers.
VOEDSELMOLEN &
FRUIT- EN GROENTEZEEF
INSTRUCTIES EN RECEPTEN
FOOD GRINDER &
FRUIT/VEGETABLE
STRAINER
INSTRUCTIONS AND RECIPES
HACHOIR &
PASSOIRE À FRUITS
ET LÉGUMES
MODE D'EMPLOI ET RECETTES
FLEISCHWOLF UND
PÜRIERAUFSATZ
BEDIENUNGSANLEITUNG UND REZEPTE
TRITATUTTO E
PASSAVERDURE
ISTRUZIONI PER L’USO E RICETTE
PICADORA DE ALIMENTOS
Y COLADOR DE
FRUTAS/VERDURAS
INSTRUCCIONES Y RECETAS
LIVSMEDELSKVARN &
PASSERTILLSATS FÖR
FRUKT OCH GRÖNSAKER
INSTRUKTIONER OCH RECEPT
KJØTTKVERN &
FRUKT- OG
GRØNNSAKSPRESSE
BRUKSANVISNING OG OPPSKRIFTER
LIHAMYLLY &
HEDELMÄ/VIHANNESPUSERRIN
KÄYTTOHJEET JA RESEPTIT
KØDHAKKER &
PURÉPRESSE
INSTRUKTIONER OG OPSKRIFTER
TRITURADOR DE CARNE &
PASSADOR DE PURÉS
INSTRUÇÕES E RECEITAS
HAKKAVÉL &
ÁVAXTAPRESSA
LEIÐBEININGAR OG UPPSKRIFTIR
ΜΗΧΑΝΗ ΑΛΕΣΗΣ & ΑΠΟΧΥΜΩΤΗΣ
ΦΡΟΥΤΩΝ / ΛΑΧΑΝΙΚΩΝ
o∆hΓieΣ KAi ΣYntAΓeΣ

English
Table of Contents
Stand Mixer Attachment Safety.......................................................................................1
Important Safeguards .....................................................................................................1
To Attach Stand Mixer Attachment .................................................................................2
Before Attaching Stand Mixer Attachment...............................................................2
Food Grinder Attachment ...............................................................................................3
To Assemble Food Grinder Attachment....................................................................3
To Use Food Grinder Attachment.............................................................................4
To Clean Food Grinder Attachment..........................................................................4
Fruit/Vegetable Strainer...................................................................................................5
To Assemble Fruit/Vegetable Strainer .......................................................................5
To Use Fruit/Vegetable Strainer ................................................................................6
To Clean Fruit/Vegetable Strainer .............................................................................7
Recipes ...........................................................................................................................8
KitchenAid®Household Stand Mixer Attachment Warranty ...........................................13
Service Centers..............................................................................................................13
Customer Service ..........................................................................................................13

1
English
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your
appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt
you and others.
All safety messages will follow the safety alert symbol and either
the word “DANGER” or “WARNING.” These words mean:
You can be killed or seriously
injured if you don’t immediately
follow instructions.
You can be killed or seriously injured
if you don’t follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to
reduce the chance of injury, and tell you what can happen if the instructions are
not followed.
WARNING
Stand Mixer Attachment Safety
DANGER
WARNING
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
When using electrical appliances, basic
safety precautions should always be
followed including the following:
1. Read all instructions.
2. To protect against risk of electrical
shock, do not put mixer in water or
other liquid.
3. The appliance is not intended for use
by young children or infirm persons
without supervision.
4. Unplug from outlet when not in use,
before putting on or taking off parts,
and before cleaning.
5. Avoid contacting moving parts. Keep
fingers out of discharge opening.
6. Do not operate the mixer with a
damaged cord or plug or after the
mixer malfunctions, or is dropped
or damaged in any manner. Return
the mixer to the nearest Authorized
Service Center for examination,
repair or electrical or mechanical
adjustment.
7. The use of attachments not
recommended or sold by KitchenAid
may cause fire, electric shock or
injury.
8. Do not use the mixer outdoors.
9. Do not let the cord hang over the
edge of table or counter.
10. Never feed food by hand. Always use
combination food pusher/wrench.
11. Blades are sharp. Handle carefully.
12. This product is designed for
household use only.

2
English
Before Attaching Stand Mixer
Attachment
1. Turn Stand Mixer speed control to
“0” (OFF).
2. Unplug mixer or disconnect power.
3. Depending on which type of hub you
have, either flip-up the hinged cover
or loosen the attachment knob (A) by
turning it counterclockwise and remove
attachment hub cover.
4. Insert the attachment shaft housing (B)
into the attachment hub (C) making
certain that attachment power shaft
fits into square hub socket.
5. It may be necessary to rotate the
attachment back and forth. When the
attachment is in proper position, the
pin on the attachment housing will fit
into the notch on the hub rim.
6. Tighten the attachment knob by turning
it clockwise until the attachment is
completely secured to mixer.
A
C
B
To Attach Stand Mixer Attachment

3
English
Food Grinder Attachment
To Assemble Food Grinder Attachment
1. Insert the grind worm (A) into the grinder body (B).
2. Place the knife (C) over the square shank at the exposed end of the grind worm.
3. Place grinding plate (D) over the knife, matching the tabs of the plate with the
notches of the grinder body.
4. Place ring (E) on grinder body, turning by hand until secured but not tightened.
NOTE: The combination food pusher/wrench (F) is used for removal of ring (E) only.
Do not use it to tighten ring (E).
NOTE: Fruit/Vegetable Strainer (Model 5FVSP) is available to convert Food Grinder to
a Fruit/Vegetable Strainer. Sausage Stuffer (Model 5SSA) is available to convert Food
Grinder to Sausage Stuffer.
Fine
B
Coarse
A
E
F
C
D

4
English
To Use Food Grinder Attachment
1. Cut food into small strips or pieces and
feed them into hopper. Meat should be
cut into long narrow strips.
2. Turn mixer to Speed 4 and feed food
into hopper using combination food
pusher/wrench.
NOTE: Liquid may appear in hopper when
processing large amounts of high moisture
foods such as tomatoes or grapes. To
drain liquid, continue to operate mixer.
To avoid damage to mixer, do not process
additional food until liquid has drained
from hopper.
Coarse Plate – Use for
grinding raw or cooked meats,
firm vegetables, dried fruits
and cheese.
Fine Plate – Use for grinding
raw meat, cooked meats for
spreads and breadcrumbs.
Grinding Meat – For better mix and
more tender results, grind beef twice. Best
texture results from grinding very cold or
partially frozen meat. Fatty meats should
be ground only once.
Grinding Bread – To grind bread for
crumbs, be sure that bread is either oven
dried thoroughly to remove all moisture,
or not dried at all. Partially dried bread
may jam the Food Grinder.
NOTE: Very hard, dense foods such as
totally dried homemade bread should
not be ground in the Food Grinder.
Homemade bread should be ground fresh
and then oven or air-dried.
To Loosen Ring – If ring is too tight to
remove by hand, slip the combination
food pusher/wrench over the grooves and
turn counterclockwise.
NOTE: To avoid damage to the food
grinder attachment, do not use
combination food pusher/wrench to
tighten ring to grinder body.
To Clean Food Grinder Attachment
First completely disassemble food grinder
attachment.
The following parts are dishwasher safe:
• Grinder body
• Grinder worm
• Ring
• Combination food pusher/wrench
The following parts should be hand
washed in warm, sudsy water and
dried thoroughly:
• Knife
• Grinding plates
Food Grinder Attachment
Rotating Blade Hazard
Always use food pusher.
Keep fingers out of openings.
Keep away from children.
Failure to do so can result in
amputations or cuts.
WARNING

5
English
Fruit/Vegetable Strainer
To Assemble Fruit/Vegetable Strainer
1. Slide the smaller end of spring and shaft assembly (A) into opening in larger worm (B)
until secured firmly in place.
2. Insert the larger worm into the grinder body (C).
3. Attach strainer cone (D) over the exposed end of the worm matching the tabs of the
cone with the notches in the grinder body (C).
4. Place ring (E) onto the grinder body, turning by hand until finger tight, but
not overtightened.
NOTE: The combination food pusher/wrench (F) is used for removal of ring (E) only. Do
not use it to tighten ring (E).
5. Slide the strainer tray (G) over the cone and latch on the top of ring.
6. Place splash shield (H) on strainer tray (G).
E
H
G
C
AD
B
F

6
English
To Use Fruit/Vegetable Strainer
1. After attaching Fruit/Vegetable Strainer
attachment to mixer, place mixer bowl
under strainer tray to catch strained
food and a smaller bowl under open
end to catch food waste.
2. Cut food into pieces that will fit in the
hopper.
3. Turn mixer to Speed 4 and feed food
into hopper using the combination
food pusher/wrench.
To Strain Fruits and Vegetables
• Cut into pieces that will fit into hopper
• Remove tough, thick skin or rind,
i.e., oranges
• Remove all large pits, i.e., peaches
• Remove hulls or stems, i.e.,
strawberries, grapes
• Cook all tough or firm fruits and
vegetables before straining
NOTE: Liquid may appear in hopper when
processing large amounts of high moisture
foods such as tomatoes or grapes. To
drain liquid, continue to operate mixer.
To avoid damage to mixer, do not process
additional food until liquid has drained
from hopper.
Rotating Blade Hazard
Always use food pusher.
Keep fingers out of openings.
Keep away from children.
Failure to do so can result in
amputations or cuts.
WARNING
Fruit/Vegetable Strainer

7
English
NOTE: To avoid damage to the
fruit/vegetable strainer attachment and/or
mixer, Labruscan or slip-skin type grapes
such as Concord, Catawba and Ontario
grapes should not be processed in the
Fruit/Vegetable Strainer. Only Ninifera
family grapes such as Tokay and Thompson
Seedless may be processed.
To Clean Fruit/Vegetable Strainer
First completely disassemble Fruit/Vegetable
Strainer attachment.
The following parts are dishwasher safe:
• Grinder body
• Grinder worm
• Strainer cone
• Strainer tray
• Splash shield
• Ring
• Combination food pusher/wrench
The following parts should be hand
washed in warm, sudsy water and
dried thoroughly:
• Spring and shaft assembly
Some foods may stain certain parts. These
stains may be removed by using one of the
following methods: (1) place dishwasher
safe parts in dishwasher and use cycle for
normally soiled dishes, or (2) rub a small
amount of oil or shortening over the stains,
wash in warm, sudsy water and rinse. A
small bottle brush can be used to help
remove pulp from the strainer cone.
To Loosen Ring – If ring is too tight to
remove by hand, slip the combination
food pusher/wrench over the grooves and
turn counterclockwise.
NOTE: To avoid damage to the Fruit/
Vegetable Strainer attachment, do not
use combination food pusher/wrench to
tighten ring to grinder body.
Fruit/Vegetable Strainer

8
English
4 large tomatoes,
peeled and cut
into sixths
1 or 2 chipotle peppers
1 medium onion, cut
into sixths
1 clove garlic
80 ml (1⁄3 cup) vinegar
1 teaspoon (5 g) salt
Assemble Food Grinder, using coarse grinding plate.
Attach Food Grinder to mixer. Turn to Speed 4 and grind
tomatoes, peppers, onion, and garlic into large bowl
or saucepan placed under grinder. Add all remaining
ingredients; mix well. For thicker salsa, heat mixture to
boiling in saucepan. Reduce heat to low. Cook 5 to
10 minutes, or until desired consistency.
Tip: Chipotle peppers are dried, smoked jalapeño
peppers. If they are not available, substitute fresh
jalapeño peppers and 2 tablespoons (10 ml)
barbecue sauce.
Yield: 20 servings (30 ml [2 tablespoons] per serving).
Smoky Salsa

9
English
Swedish Meatballs
500 g (1 pound) boneless
beef round steak,
cut into 1-inch
(2.5-cm) strips
250 g (1⁄2pound) boneless
veal, cut into 1-inch
(2.5-cm) strips
1 medium onion, cut
into sixths
2 slices whole wheat
bread, broken into
pieces
1 teaspoon (5 g) salt
1 teaspoon (5 g) nutmeg
1⁄2teaspoon (3 g) allspice
1⁄2teaspoon (3 g) black
pepper
60 ml (1⁄4cup) fat-free egg
substitute or 1 egg
120 ml (1⁄2cup) low-fat
milk
Cream Sauce
60 ml (1⁄4cup) drippings
from meatballs or
margarine or butter
60 g (1⁄4cup) flour
500 ml (2 cups) whole milk
2 teaspoons (10 g)
instant beef bouillon
granules or 1 beef
bouillon cube
1⁄2teaspoon (3 g) black
pepper
Assemble Food Grinder, using fine grinding plate. Attach
Food Grinder to mixer. Turn to Speed 4 and grind beef,
veal, onion, and bread into bowl placed under grinder.
(Return mixture to grinder and grind once or twice more
for extra fine meatballs.) Add all remaining ingredients;
mix well.
Shape mixture into 2.5-cm (1-inch) meatballs and arrange in
40 x 26 x 2.5 cm (16 x 101⁄2x 1-inch) baking pans. Bake
at 230°C (450°F) for 15 minutes, or until browned and no
longer pink in center.
While meatballs are baking, prepare Cream Sauce.
Heat drippings or melt margarine in large saucepan.
Add flour and stir until bubbly. Gradually stir in all
remaining ingredients. Cook over medium-low heat until
mixture thickens and just begins to bubble. Pour over
Swedish Meatballs.
Serve meatballs as an appetizer or combine with cooked
noodles as a main dish.
Yield: 20 appetizer servings (4 meatballs per serving) or
10 main dish servings (8 meatballs per serving).
Swedish Meatballs with Cream Sauce

10
English
30 ml (2 tablespoons)
olive oil
2 carrots, peeled and
cut into 2.5-cm
(1-inch) pieces
2 stalks celery cut into
2.5-cm (1-inch) pieces
1 large onion, cut
into eigths
20 g parsley sprigs
700 g (11⁄2pounds)
ground beef
250 g (1⁄2pound)
ground pork
3 cloves garlic
10 large ripe tomatoes,
cut into sixths
1 teaspoon (5 g) basil
1 teaspoon (5 g)
oregano
1 bay leaf
1 teaspoon (5 g) salt
1⁄2teaspoon (3 g)
pepper
60 ml (1⁄4cup) water
60 ml (1⁄4cup) dry
red wine
200 g (3⁄4cup) tomato
concentrate
Heat oil in a 30-cm (12-inch) skillet over medium heat.
Add carrots, celery, onion, parsley, ground beef, ground
pork, and garlic. Sauté 20 minutes. Remove mixture from
heat and cool 10 minutes.
Assemble Food Grinder using coarse grinding plate and
attach to mixer. Turn to Speed 4 and grind mixture into a
5.7 L (6-quart) pot.
Assemble Fruit/Vegetable Strainer and attach to mixer.
Turn to Speed 4 and strain tomatoes. Measure out
950 ml (4 cups) puree. Add tomato puree and
concentrate, basil, oregano, bay leaf, salt, pepper,
water, and wine to meat mixture. Cover and simmer
on medium-low heat for 1 hour.
Yield: 2 L (2 quarts).
Bolognese Sauce

11
English
4 large peaches, peeled
and cut into chunks
or 1 package
(450 g (16 oz))
frozen peaches,
thawed
120 ml (1⁄2cup) vinegar
1⁄2finely chopped onion
60 g (1⁄4cup) dried
fruit bits
120 g (1⁄2cup) firmly
packed brown sugar
60 g (1⁄4cup) sugar
40 g (2 tablespoons)
finely chopped
crystallized ginger
4 or 5 cloves
1⁄4teaspoon (2 g) allspice
Assemble Fruit/Vegetable Strainer and attach to mixer.
Turn to Speed 4 and strain peaches into large saucepan
placed under strainer. Add all remaining ingredients. Heat
to boiling. Reduce heat to low. Cook about 20 minutes,
or until thick, stirring frequently.
Yield: 24 servings (20 g [1 tablespoon] per serving).
Golden Peach Chutney
80 g (1⁄3cup) fresh
basil leaves
40 g (1⁄6cup) parsley
sprigs
2 cloves garlic
1 teaspoon (5 g) salt
1⁄2teaspoon (3 g)
pepper
100 g Parmesan cheese
120 ml (1⁄2cup) olive oil
50 g (1⁄4cup) pine nuts
(optional)
Assemble Food Grinder using fine grinding plate and
attach to mixer. Turn to Speed 4 and grind basil leaves,
parsley sprigs, and garlic into mixer bowl. Add salt,
pepper, and Parmesan cheese. Attach bowl and wire
whip. Turn to Speed 6 and whip 1 minute. Stop and
scrape bowl. Turn to Speed 8 and gradually add olive oil
in a thin, steady stream, whipping until absorbed. Use
about 30 ml (2 tablespoons) of Pesto Sauce per serving
of pasta.
Tip: If Pesto Sauce is not used at once, place it in a jar and
cover with a thin layer of olive oil to keep it from darkening.
Refrigerate for a week or freeze for longer storage.
Yield: 500 ml (2 cups).
Pesto Sauce

12
English
1 can (565 g [20 ounces] )
chickpeas, drained
60 ml (1⁄4cup) cold water
60 ml (1⁄4cup) fresh
lemon juice
60 g (1⁄4cup) tahini
(sesame seed paste) or
2 teaspoons (10 ml)
sesame oil
2 cloves garlic, minced
1 teaspoon (5 g) salt
1⁄2teaspoon (3 g) paprika
(optional)
Assemble Fruit/Vegetable Strainer and attach to mixer.
Turn to Speed 4 and strain chickpeas into mixer bowl.
Return waste to strained chickpeas.
Add water, lemon juice, tahini, garlic, salt, and paprika.
Attach bowl and wire whip to mixer. Turn to Speed 4 and
whip 1 minute. Stop and scrape bowl. Increase to Speed 10
and whip 1 minute or until smooth. Serve with Pita Bread.
Yield: 475 ml (2 cups).
Hummus
1.5 kg (3 lbs.) cooking
apples, cut into
fourths
200 ml (3⁄4cup)
apple cider
120 ml (1⁄2cup) vinegar
450 g (2 cups) sugar
2 teaspoons (10 g)
cinnamon
4 cloves
11⁄2teaspoon (8 g) allspice
Place apples, cider, and vinegar in large saucepan or
Dutch oven. Cook over medium heat about 15 minutes,
or until very soft, stirring occasionally.
Assemble Fruit/Vegetable Strainer and attach to mixer.
Turn to Speed 4 and strain cooked apples into mixer bowl
placed under strainer. Return apples to pan. Add sugar and
spices; mix well. Cook over low heat until sugar is dissolved,
stirring constantly. Cook 15 to 20 minutes longer, or until
thick, stirring frequently. Ladle into hot, sterilized 235 ml
(1⁄2-pint) jars. Process 10 minutes in boiling water bath.
Remove jars from water. Cool; check seals.
Yield: About 1.2 L (5 cups) (10 ml [2 teaspoons] per serving).
Harvest Apple Butter

13
English
Length of
Warranty:
Europe, Australia and
New Zealand:
Two years Full Warranty
from date of purchase.
Other:
One Year Full Warranty
from date of purchase.
KitchenAid
Will Pay For:
Replacement parts and
repair labor costs to
correct defects in materials
or workmanship. Service
must be provided by an
Authorized KitchenAid
Service Center.
KitchenAid
Will Not Pay For:
A. Repairs when Food
Grinder or Fruit/
Vegetable Strainer are
used for operations
other than normal
household food
preparation.
B. Damage resulting from
accident, alterations,
misuse, abuse, or
installation/ operation
not in accordance with
local electrical codes.
KITCHENAID DOES NOT ASSUME ANY RESPONSIBILITY FOR
INDIRECT DAMAGES.
KitchenAid®Household Stand Mixer
Attachment Warranty
Service Centers
All service should be handled locally by an
Authorized KitchenAid Service Center.
Contact the dealer from whom the
attachments were purchased to obtain the
name of the nearest Authorized KitchenAid
Service Center.
In the U.K.:
Call: 0845 6011 287
In Ireland:
M.X. ELECTRIC
Service Department
25 Alymer Crescent
Kilcock, CO.KILDARE
Call: 1 679 2398/87 2581574
Fax: [phone]
In Australia:
Call: 1800 990 990
In New Zealand:
Call: 0800 881 200
Customer Service
In U.K. & Ireland: Tollfree number 00800 38104026
Address: KitchenAid Europa, Inc.
PO BOX 19
B-2018 ANTWERP 11
BELGIUM
www.KitchenAid.com

14
English
® Registered Trademark of KitchenAid, U.S.A.
TM Trademark of KitchenAid, U.S.A.
The shape of the stand mixer is a trademark of KitchenAid, U.S.A.
© 2007. All rights reserved.
Specifications subject to change without notice.
(5562dZw207)
9709881A
