KitchenAid 5KSMSFTA User manual

EN Use & Care manual 2
DE Gebrauchs- und Pegeanleitung 15
FR Manuel d’utilisation et d’entretien 29
IT Manuale d’uso e manutenzione 43
NL Gebruiks- en
onderhoudshandleiding
55
ES Manual de uso y cuidado 67
PT Manual de utilização e
manutenção
79
EL Εγχειρίδιο Χρήσης και Φροντίδας 91
SV Handbok för skötsel och
användning
103
NO Håndbok for bruk og vedlikehold 115
FI Käyttö- ja huolto-opas 127
DA Vejledning til anvendelse og
vedligehold
139
IS Notenda & Meðhöndlunar
handbók
151
RU Руководство по эксплуатации и
уходу
163
PL Instrukcja obsługi i konserwacji 175
CS Návod k použití a údržbě 187
TR Kullanım ve Bakım kılavuzu 199
AR  1
Sifter+Scale Attachment
5KSMSFTA
W11494233A_01_EN.indd 1W11494233A_01_EN.indd 1 1/6/2021 1:59:57 PM1/6/2021 1:59:57 PM

2
PARTS AND FEATURES
1Sifter Housing
2Digital Scale
3Lid/Scale Plate
4Ingredient Hopper
5Ingredient Valve
6Sifter Assembly (see detail below)
7Swivel Chute
8Digital Scale Display and Control
Panel
9On/Off Button
10 Tare Button
11 Weight Unit Toggle
12 Sifter
13 Screen
14 Collar
lb/oz/g
gozlb
3
4
5
6
7
1
2
9 10 11
8
12
13
14
W11494233A_01_EN.indd 2W11494233A_01_EN.indd 2 1/6/2021 1:59:57 PM1/6/2021 1:59:57 PM

ENGLISH
3
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions. Misuse of appliance may result in personal injury.
2. This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience or
knowledge, unless they are closely supervised and instructed concerning use of
the appliance by a person responsible for their safety.
3. European Union only: This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
4. European Union only: Appliances can be used by persons with reduced physical,
sensory, or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the
appliance.
5. Turn the appliance off, unplug from outlet and detach the Sifter+Scale
attachment from appliance before cleaning and when not in use. Turn the
appliance off and make sure the motor stops completely before putting on or
taking off parts.
6. Children should be supervised to ensure that they do not play with the appliance.
7. Never leave the appliance unattended while it is in operation.
8. Avoid contacting moving parts. Keep hands, hair, and clothing, as well as
spatulas and other utensils away from accessories during operation to reduce
the risk of injury to persons and/or damage to the appliance.
9. To protect against risk of electrical shock, do not put appliance in water or other
liquid.
W11494233A_01_EN.indd 3W11494233A_01_EN.indd 3 1/6/2021 1:59:57 PM1/6/2021 1:59:57 PM

4
PRODUCT SAFETY
10. The use of attachments not recommended or sold by KitchenAid may cause re,
electric shock, or injury.
11. Do not use the appliance outdoors.
12. Also see the Important Safeguards section included in the Stand Mixer Use and
Care Guide.
13. Refer to the “Care and Cleaning” section for instructions on cleaning the
surfaces in contact with food.
14. This appliance is intended to be used in household and similar applications such
as:
- staff kitchen areas in shops, ofces, or other working environments;
- farmhouses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
ELECTRICAL EQUIPMENT WASTE DISPOSAL
Disposal of packing material
The packing material is recyclable and is
marked with the recycle symbol ( ). The
various parts of the packing must there-
fore be disposed of responsibly and in full
compliance with local authority regulations
governing waste disposal.
Scrapping the product
- This appliance is marked in compliance
with European Directive 2012/19/EU,
Waste Electrical and Electronic
Equipment (WEEE).
- By ensuring this product is disposed of
correctly, you will help prevent potential
negative consequences for the
environment and human health, which
could otherwise be caused by inappropri-
ate waste handling of this product.
- The symbol on the product or on the
accompanying documentation
indicates that it should not be treated
as domestic waste but must be taken
to an appropriate collection centre
for the recycling of electrical and
electronic equipment.
For more detailed information about
treatment, recovery and recycling of
this product, please contact your
local city office, your household waste
disposal service or the shop where you
purchased the product.
DECLARATION OF CONFORMITY
This appliance has been designed, constructed and distributed in compliance with
the safety requirements of EC Directives: 2014/35/EU, 2014/30/EU, 2009/125/EC and
2011/65/EU (RoHS Directive).
Instructions are also available online, visit our website at:
www.KitchenAid.co.uk or www.KitchenAid.eu
W11494233A_01_EN.indd 4W11494233A_01_EN.indd 4 1/6/2021 1:59:58 PM1/6/2021 1:59:58 PM

ENGLISH
5
PRODUCT USAGE
To weigh, sift, and slowly feed
ingredients into mixer bowl or separate
container: Use the complete attachment
for recipes calling for ingredients to be
sifted and fed slowly into the mixer bowl
or a separate container.
1
To weigh and feed ingredients into
bowl without sifting: Use the attachment
without the Sifter when weighing and
feeding larger ingredients, such as whole
oats, that do not need to be sifted. To
add those ingredients slowly, you can limit
the flow by using the Ingredient Valve.
2
SIFTER+SCALE CONFIGURATIONS
To use as a countertop scale: Set the
scale on your countertop or table and
place the Lid/Scale Plate on top.
3
The Sifter+Scale attachment is compatible with all household KitchenAid Stand Mixers, including all
accessory stainless steel, glass, and ceramic bowls. It is not compatible with the Precise Heat Mixing
Bowl, Ice Cream Maker, or the Pouring Shield.
The Sifter+Scale attachment can be used in multiple ways: to weigh and sift ingredients while slowly
feeding them into the mixer bowl or into a separate container, to weigh and feed ingredients without
sifting, and to weigh ingredients on your countertop.
W11494233A_01_EN.indd 5W11494233A_01_EN.indd 5 1/6/2021 1:59:58 PM1/6/2021 1:59:58 PM

6
Turn the Stand Mixer OFF(0) and unplug.
1
For Stand Mixers with a hinged
attachment hub cover: Flip up to open.
For Stand Mixers with a removable
attachment hub cover: Turn the
attachment knob counterclockwise to
remove attachment hub cover.
2
PRODUCT USAGE
ATTACHING THE SIFTER HOUSING TO THE STAND MIXER
Before using your Sifter+Scale for the first time, wipe the Ingredient Hopper, Sifter As-
sembly, and Swivel Chute with a warm damp cloth, then wipe clean with a damp cloth.
Do not wash the Sifter Housing or Digital Scale. Dry with a soft cloth. See the “Care and
cleaning” section for complete instructions.
Insert the attachment Shaft Housing
into the attachment hub, making certain
the power shaft fits into the square
hub socket. If necessary, rotate the
attachment back and forth. The pin on
the attachment housing will fit into the
notch of the hub rim when in the proper
position.
3
Tighten the Stand Mixer attachment hub
knob clockwise until the attachment is
completely secured to the Stand Mixer.
4
W11494233A_01_EN.indd 6W11494233A_01_EN.indd 6 1/6/2021 1:59:58 PM1/6/2021 1:59:58 PM

ENGLISH
7
ASSEMBLING THE SIFTER+SCALE ATTACHMENT
To install the Swivel Chute: Lower the
Swivel Chute into the Sifter Housing
at an angle, aligning the marks on the
Swivel Chute with the marks above
the notches on the inside of the Sifter
Housing. Properly installed, Swivel Chute
will be seated securely in the Sifter
Housing and will rotate easily.
1
To install the Sifter Assembly: Lower
the Sifter into the Sifter housing at an
angle so that the drive shaft can be
inserted into the Sifter Housing. Once
the shaft is inserted all the way, press
down on the Sifter, opposite of the
shaft, to click it into place.
2
PRODUCT USAGE
To install the Ingredient Hopper:
Align the Ingredient Valve with the
corresponding notch on the scale, and
lower the hopper onto the scale until
fully seated.
4
To install the scale: Place the scale on
top of the Sifter Housing with the Digital
Scale display facing away from the Stand
Mixer, and slightly left of centre. Twist
the scale counterclockwise until it locks
into place.
3
TIP: Aligning the handle tab on the chute
with one of the notches as you lower the
Swivel Chute into the Sifter Housing will
help you to line up the marks.
W11494233A_01_EN.indd 7W11494233A_01_EN.indd 7 1/6/2021 1:59:58 PM1/6/2021 1:59:58 PM

8
WEIGHING AND SIFTING INGREDIENTS
lb/oz/g
gozlb
Press (On/Off), then press (Tare)
until the display reads 0.
1
Before adding ingredients to the
hopper, be sure the Ingredient Valve is
in the closed position and Swivel Chute
is pointed into the mixer bowl or an
appropriate container.
2
NOTE: If desired, the scale and hopper can sit on the countertop, and ingredients can
be added until the target weight is achieved. The full scale and hopper can then be
installed onto the attachment.
PRODUCT USAGE
lb/oz/g
gozlb
OPTIONAL: Press the lb/oz/g button to
choose between pounds, ounces, and
grams. The default setting is grams.
Add your ingredients to the Ingredient
Hopper until you reach the target
weight.
3
TIP: Make sure your dry ingredients have no large or hard clumps before feeding them
through the Sifter. As with any Sifter, large or hard clumps may not be broken up during
the sifting process.
W11494233A_01_EN.indd 8W11494233A_01_EN.indd 8 1/6/2021 1:59:58 PM1/6/2021 1:59:58 PM

ENGLISH
9
0 Stir 2 4 6 8 10
Turn on the Stand Mixer to the desired
speed, then open the Ingredient Valve.
The ingredients will be sifted and flow
into the bowl according to the selected
speed.
NOTE: The Sifter can operate at any
speed, so select the speed that works
best for your recipe.
4
PRODUCT USAGE
TIP: If your recipe calls for multiple dry ingredients, press between adding ingredients for
weighing, and stir them in the hopper before opening the Ingredient Valve.
NOTE: Once you’ve weighed your ingredients, you may turn off the scale at any time by
pressing . The scale will also shut off automatically after 5 minutes of non-use.
Once sifting appears to be complete,
tap the housing and then the chute to
release all residual ingredients.
5
CARE AND CLEANING
CLEANING THE SIFTER+SCALE ATTACHMENT AND ACCESSORIES
The following parts are dishwasher-
safe, top rack only: Ingredient Hopper,
Sifter Assembly, Swivel Chute, and Scale
Plate.
TIP: When placing the Ingredient
Hopper on the rack, be sure it is lying
on its side with the Ingredient Valve
facing down.
1
Do not immerse the Scale or Sifter
Housing in water or other liquid. Wipe
clean with a warm, damp cloth, and
dry thoroughly with a soft cloth before
re-use or storing.
2
W11494233A_01_EN.indd 9W11494233A_01_EN.indd 9 1/6/2021 1:59:59 PM1/6/2021 1:59:59 PM

10
CARE AND CLEANING
TROUBLESHOOTING GUIDE
Problem Solution
While using the Sifter+Scale
attachment, you may see the
following messages displayed:
Err
The scale has exceeded its weight limit. Remove
ingredients from hopper, and try again with a
smaller amount.
- - - Err1
Tare error. Remove ingredients and turn off power.
Then, turn power back on. If Err1 is still
present, call customer service.
If the problem cannot be
corrected:
See the “Terms of KitchenAid Guarantee ("Guarantee")"
section. Do not return the product to the retailer.
Retailers do not provide service.
To disassemble the Sifter assembly: Turn
the Collar to the left to loosen and release
the screen for cleaning, if desired.
3
REPLACING THE BATTERIES
Flip the digital scale over, and use a
Phillips-head screwdriver to remove the
screw on the compartment cover. Lift
the compartment cover as shown.
1
The digital scale of your Sifter+Scale attachment is powered by 2 AAA batteries
(included).
Replace the 2 AAA batteries in the
compartment. Make sure to replace
the screw when reattaching the
compartment cover.
2
W11494233A_01_EN.indd 10W11494233A_01_EN.indd 10 1/6/2021 1:59:59 PM1/6/2021 1:59:59 PM
