CABINET PARTS
1
For Models: KBCS24LSBS00
(Black Cabinet)
3−06 Litho In U.S.A. (rcg) Part No. 8214860
BEVERAGE CENTER

CABINET PARTS
2
For Models: KBCS24LSBS00
(Black Cabinet)
8214860
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
2300276 Use & Care Guide
4344901 Wiring Diagram
2 Cabinet (Not A
Service Part)
3 4344739 Lens, Light
4 4344740 Bulb, Light
5 4344746 Heater, Defrost
6 4344747 Heat Shield
7 4344761 Grille
8 4344762 Plate, Bottom
9 4344763 Foot, Leveling
10 4344764 Brace, Support
11 4344898 Control Box
12 Frame, Side
4344789 Left Side
4344790 Right Side
13 4344771 Bracket, Grille
14 4344841 Evaporator Fan
Assembly
15 4344860 Thermostat
16 4344768 Knob, Thermostat
17 4344767 Switch, Plunger
18 4344826 Screw
19 4344797 Screw
20 4344819 Clip, Grille
21 4344825 Screw
22 4344823 Seal
23 Frame, Support
4344821 Right
4344820 Left
24 4344824 Clip, Harness
25 4344857 Harness, Wire
26 4344827 Screw
27 4344792 Thermal Fuse
28 4344793 Screw
29 4344791 Screw
30 4344783 Fan Blade
31 4344878 Screw
32 4344865 Evaporator Fan
Motor
33 4344877 Harness, Wire
34 4344832 Screw, Ground
35 4344778 Grommet, Fan Motor
36 4344899 Bracket, Motor
37 Evaporator
(Not Serviced)
38 4344858 Switch, Light
39 4344917 Transformer Cable
40 4344918 Temperature Sensor

SHELF PARTS
3
For Models: KBCS24LSBS00
(Black Cabinet)
8214860
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4344893 Temperature
Separator
2 4344846 Wine Rack, Top
3 4344847 Wine Rack, Middle
4 4344849 Wine Rack, Lower
5 Ladder, Shelf
4344842 Left Side
4344843 Right Side
6 4344794 Screw
7 4344795 Washer
8 4344850 Stop, Lower Rack
9 4344851 Screw
10 4344882 Trim, Top And
Middle Racks
11 Support
4344867 Left
4344866 Right
12 4344884 Trim, Lower Rack
13 Support, Bumper
4344886 Left
4344885 Right
14 Screw
4344915 Left
4344914 Right
15 4344870 Shelf, Large
16 4344871 Glass, Shelf
17 4344868 Shelf, Small
18 4344869 Glass, Shelf
19 4344872 Trim, Shelf
20 4344873 Seal, Rear
21 4344874 Seal, Side (2)
22 4344875 Seal, Front
23 4344895 Transformer Cable
24 4344896 PCB Display Board
25 4344897 Cable
26 4344905 Support, Shelf
(Large)

DOOR PARTS
4
For Models: KBCS24LSBS00
(Black Cabinet)
8214860
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4344854 Door Assembly
(Includes Gasket)
4 4344787 Hinge, Bottom
5 4344754 Hinge, Top
6 4344804 Spacer, Top Hinge
7 4344798 Spacer,
Bottom Hinge
8 4344757 Actuator, Switch
9 4344802 Door Stop
10 4344852 Door Gasket
11 4344810 Handle, Door
12 4344856 Door Skin,
Stainless Steel
13 4344760 Washer
14 4344803 Spacer, Door
15 4344904 Plate
16 4344796 Screw
17 Screw, Lower Hinge
4344906 Quantity 1
4344797 Quantity 3
18 4344827 Screw
19 4344799 Screw
20 4344801 Screw
21 4344808 Screw
22 4344813 Nameplate
OPTIONAL PARTS
NOT ILLUSTRATED
8171420 Cleaner, Stainless
Steel (12 oz)

UNIT PARTS
5
For Models: KBCS24LSBS00
(Black Cabinet)
8214860
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4344772 Drain Pan
2 4344773 Bracket,
Defrost Timer
3 4344774 Defrost Timer
4 4344797 Screw
5 4344776 Start Device
6 4344777 Mounting Plate,
Compressor
7 4344778 Grommet, Fan Motor
8 4344779 Grommet,
Compressor
9 4344780 Bolt, Compressor
10 4344781 Fan Motor,
Condenser
11 4344782 Baffle, Air
12 4344783 Fan Blade
13 4344784 Bracket, Motor
14 4344785 Bracket, Motor
15 4344786 Cover, Rear
16 4344837 Capacitor
17 4344836 Clip
18 4344839 Tube, Drain
19 4344861 Power Cord
20 4344829 Cable Tie
21 4344828 Drier
22 4344838 Bushing
23 4344831 Clip, Bushing
24 4344835 Bushing
25 4344826 Screw
26 4344825 Screw
27 4344832 Screw
28 4344775 Compressor
(Includes Items
5, 8, 16, 17 & 21)
29 4344834 Screw
30 4344833 Screw
31 4344862 Transformer
32 4344863 Thermostat
33 4344864 Bracket,
Thermostat
34 4344907 Trim, Edge
35 4344908 Support, Drain
REFRIGERANT CHARGE
3.5 Ounces
(R−134A)
