Knight Cubit Credenza User manual

Tools Required:
Assembly Instructions
Powered screwdriver.
Cubit Credenza

knightgroup.co.nz
Page 2
Assembly Instructions
Cubit Credenza
· To prevent possible scratches or damage, assemble
the credenza on a soft surface such as a blanket,
carpet or packaging.
Recommended
2-person Step
Item Decription Quantity
A Top Panel 1
X Left side panel 1
Z Right side panel 1
D Back panel 1
G Bottom panel 1
E Moveable shelf 2
V1 Door panel 1
V2 Door panel 1
V3 Door panel 1
V4 Door panel 1
Y Vertical panel 1
Item Decription Quantity
c1 6x35 Cam Bolt 24
d1 8x30 Dowel Pin 24
c2 (5/8”)Cam Cover 24
h4 Handle 4
s7 4x22 Fix Bolt 8
s1 4x16 Screw 32
g2 Big curve Hinge &
Mout Plate 4
g3 Small curve hinge &
Mount Plate 4
g1 Hinge Stand 8
p1 Threaded Dowel Pin 8
s13 4x25 Screw 18
m2 Metal Leg 6
PARTS LIST
IMPORTANT:
Please note the difference between
parts g2 and g3.
Each hinge is specically designed for their
unique position.
Correct installation is essential for a
successful assembly of this credenza.

knightgroup.co.nz
Page 3
Assembly Instructions
Step 1
Preparation for Top panel A, Bottom panel G, Left side panel X, Right side panel Z, Vertical panel Y,
Door panel V1, V2, V3 & V4.
Cubit Credenza
IMPORTANT:
Please note the difference between
parts g2 and g3.
Each hinge is specically designed for their
unique position.
Correct installation is essential for a
successful assembly of this credenza.
1. Insert cams bolts (c1) and dowel pins (d1) into panels A, G, X and Z as illustrated above.
2. Fix hinge stands (g1) to panels X, Z and Y with screws (s1) as illustrated above.
3. Fix hinge bodies (g2) to panels V1 and V4 with screws (s1) as illustrated above.
4. Fix hinge bodies (g3) to panels V2 and V3 with screws (s1) as illustrated above.
5. Fix handle (h4) to panels V1, V2, V3 and V4 with fix bolts (s7) as illustrated above.
6. Fix metal leg (m2) to panel G with screws (s13) as illustrated above.

knightgroup.co.nz
Page 4
Assembly Instructions
Step 2
Fit the pull bar to the top side of the mechanism according to the number corresponding to your
worksurface depth. This number will locate over of the raised cylinder
Top panel A, Back panel D, Left side panel X, Right side panel Z, Vertical panel Y assembly.
Step 2
Cubit Credenza
1. Fix cams on panel X, Z, Y, D into cam bolts (c1) on panel A and tighen in a clockwise direction as illustrated above.
Cams/Holes on the panel Y
should face to panel X.

knightgroup.co.nz
Page 5
Assembly Instructions
Step 4
Step 3
Insert threaded dowel pins (p1) in to panels X, Z and Y as illustrated above. Put the two panels E on
the top of threaded dowel pins (p1) as illustrated above.
Fix cams on panel X, Y, Z and D into cam bolts (c1) on panel G and tighten in a clockwise direction
as illustrated above. Cover the cam covers (c2) on the top of all the cams.
Cubit Credenza

knightgroup.co.nz
Page 6
Assembly Instructions
Fit the pull bar to the top side of the mechanism according to the number corresponding to your
worksurface depth. This number will locate over of the raised cylinder
Door panel V1, V2, V3 and V4 assembly.
Step 5
Cubit Credenza

knightgroup.co.nz
Page 7
Assembly Instructions
Cubit Credenza
Complete
