Knight Ergoplan Fixed Return User manual

knightgroup.co.nz
Tools Required: Powered Screwdriver
Assembly Instructions
Ergoplan Fixed Return
(Suits 1500/1800mm Desk)

Assembly Instructions
knightgroup.co.nz
Ergoplan Fixed Return (Suits 1500/1800mm Desk)
Recommended
2 Person Assembly
Thank you for purchasing Knight product, please carefully read the assembly instructions prior to installment to gain a complete
understanding of the product. It provides you with important information about the safety, use, installation and maintenance.
WARNING: FAILURE TO COMPLY WITH OR OBSERVE ALL ASSEMBLY, SAFETY AND OPERATION INSTRUCTIONS REGARDING
THE USE OF THIS PRODUCT MAY RESULT IN SERIOUS BODILY INJURY.
SAFETY
• The product must be used in a safe manner. Inappropriate use may cause damage to the product and/or cause bodily harm to
the user or persons nearby.
• Don’t locate furniture in direct sunlight or near air-conditioning inlet or heating radiator.
• Don’t put high-temperature or frozen objects on furniture.
• Safely carry product to location of assembly.
• Retain this operation manual and pass it on to any future owner.
SET UP AND INSTALLATION
• Assemble the product according to the assembly instructions.
• To prevent possible scratches or damage, assemble the product on a soft surface such as a blanket, carpet or packaging.
• Place the product a safe distance from window frames, radiators, furniture etc. so that persons cannot become trapped.
It is recommended that this product is assembled by 2 people.
Any questions contact Knight on 0800 143 143
Due to continuous improvement of our products, our assembly instructions may not be in complete accordance with the product
and we apologise in advance.

Assembly Instructions
knightgroup.co.nz
Parts
The turning direction
of attaching
Incorrect Correct
Item Description Quantity
ATop Panel 1
XEnd Panel 1
DModesty Panel 1
X
A
D
Ergoplan Fixed Return (Suits 1500/1800mm Desk)

Assembly Instructions
knightgroup.co.nz
Item Description Quantity
c1 6x35 Cam Bolt 6
d1 8x30 Dowel Pin 6
c2 Cam Sticker 6
b1 Bracket 2
c3 Connector Plate 2
s1 3.5x15 Screw 8
s5 6x12 Screw 16
s10 6x28 Screw 2
Parts
c1 6x35 Cam Bolt d1 8x30 Dowel Pin c2 Cam Sticker b1 Bracket c3 Connector Plate
Cam
(pre-installed)
s5 6x12 Screw s10 6x25 Screws1 3.5x15 Screw
Ergoplan Fixed Return (Suits 1500/1800mm Desk)

Page 1
Assembly Instructions
knightgroup.co.nz
Step 1
Page 1
Assembly Instructions
Preparation for top panel A, end panel X and modesty panel D for right hand return.
1. Insert cam bolts (c1) and dowel pins (d1) into panels A and X.
2. Fix connectors (c3) to panel A using screws (s5).
3. Insert dowel pins (d1) into panels X and D.
X
D
A
c3
s5
d1
d1
d1
c1
c1
c1
Please note: If you require
the return to be on the left
side of the desk, change the
position of the cam bolts on
the long side of panel A and
X to the opposite long side.
Ergoplan Fixed Return (Suits 1500/1800mm Desk)

Page 2
Assembly Instructions
knightgroup.co.nz
Page 2
Assembly Instructions
Step 2
End panel X and modesty panel D assembly for right hand return.
Insert cam bolts (c1) on panel X into cams on panel D and tighten in a clockwise direction.
X
D
c1
d1
Ergoplan Fixed Return (Suits 1500/1800mm Desk)

Page 3
Assembly Instructions
knightgroup.co.nz
Page 3
Assembly Instructions
Step 3
Top panel A assembly for right hand return.
1. Insert cam bolts (c1) on panel A into cams on panel X and D and tighten in a clockwise direction.
2. Cover top of cams with cam stickers (c2).
3. Secure panels X and D with brackets (b1) using screws (s1).
4. Turn return over to upright position and attach to 1500 or 1800mm Ergoplan desk with connector plates (c3).
X
D
A
c2
c2
s1
b1
Ergoplan Fixed Return (Suits 1500/1800mm Desk)

Page 4
Assembly Instructions
knightgroup.co.nz
Page 4
Assembly Instructions
Complete
Ergoplan Fixed Return (Suits 1500/1800mm Desk)
