Knight Ergoplan Bookcase 1200H User manual

knightgroup.co.nz
Tools Required: Powered Screwdriver
Assembly Instructions
Ergoplan Bookcase 1200H

Assembly Instructions
knightgroup.co.nz
Recommended
2 Person Assembly
Thank you for purchasing Knight product, please carefully read the assembly instructions prior to installment to gain a complete
understanding of the product. It provides you with important information about the safety, use, installation and maintenance.
WARNING: FAILURE TO COMPLY WITH OR OBSERVE ALL ASSEMBLY, SAFETY AND OPERATION INSTRUCTIONS REGARDING
THE USE OF THIS PRODUCT MAY RESULT IN SERIOUS BODILY INJURY.
SAFETY
• The product must be used in a safe manner. Inappropriate use may cause damage to the product and/or cause bodily harm to
the user or persons nearby.
• Don’t locate furniture in direct sunlight or near air-conditioning inlet or heating radiator.
• Don’t put high-temperature or frozen objects on furniture.
• Safely carry product to location of assembly.
• Retain this operation manual and pass it on to any future owner.
SET UP AND INSTALLATION
• Assemble the product according to the assembly instructions.
• To prevent possible scratches or damage, assemble the product on a soft surface such as a blanket, carpet or packaging.
• Place the product a safe distance from window frames, radiators, furniture etc. so that persons cannot become trapped.
It is recommended that this product is assembled by 2 people.
Any questions contact Knight on 0800 143 143
Due to continuous improvement of our products, our assembly instructions may not be in complete accordance with the product
and we apologise in advance.
Ergoplan Bookcase 1200H

Assembly Instructions
knightgroup.co.nz
Ergoplan Bookcase 1200H
Parts
Item Description Quantity
ATop Panel 1
XLeft Side Panel 1
ZRight Side Panel 1
DBack Panel 1
GBottom Panel 1
EMovable Shelf 2
The turning direction
of attaching
Incorrect Correct
A
X
Z
D
E
E
G

Assembly Instructions
knightgroup.co.nz
Ergoplan Bookcase 1200H
Item Description Quantity
c1 6x35 Cam Bolt 18
d1 8x30 Dowel Pin 16
c2 Cam Sticker 18
p1 Shelf Pin 8
c6 Foot 4
s2 3.5x35 Screw 4
Parts
c1 6x35 Cam Bolt d1 8x30 Dowel Pin c2 Cam Sticker s2 3.5x35 Screwp1 Shelf Pin c6 Foot
Cam
(pre-installed)

Page 1
Assembly Instructions
knightgroup.co.nz
Step 1
Page 1
Assembly Instructions
Ergoplan Bookcase 1200H
Preparation for top panel A, bottom panel G, left side panel X and right side panel Z.
1. Insert cam bolts (c1) and dowel pins (d1) into panels A, G, X and Z.
2. Assemble feet (c6) with screws (s2) on underneath of bottom panel G.
Z
c1
d1
X
c1
d1
A
c1
d1
G
c1
d1
s2
c6

Page 2
Assembly Instructions
knightgroup.co.nz
Page 2
Assembly Instructions
Step 2
Ergoplan Bookcase 1200H
Left side panel X, right side panel Z and back panel D assembly.
Insert cam bolts (c1) and dowel pins (d1) on panel X and Z into cams on panel D and tighten in a
clockwise direction.
X
Z
D
d1
c1
c1

Page 3
Assembly Instructions
knightgroup.co.nz
Page 3
Assembly Instructions
Step 3
Ergoplan Bookcase 1200H
Bottom panel G and top panel A assembly.
1. Insert cam bolts (c1) and dowel pins (d1) on panel G and A into cams on panel X, Z and D and tighten
in a clockwise direction.
2. Cover top of cams with cam stickers (c2).
c2
c1
d1
A
X
ZD
G

Page 4
Assembly Instructions
knightgroup.co.nz
Page 4
Assembly Instructions
Step 4
Ergoplan Bookcase 1200H
Moveable shelf E assembly.
1. lnsert shelf pins (p1) into panels X and Z at desired shelf height.
2. Place the two panels E on the top of the shelf pins (p1).
p1
A
X
Z
D
E
E
G

Page 5
Assembly Instructions
knightgroup.co.nz
Page 5
Assembly Instructions
Ergoplan Bookcase 1200H
Complete
