KOBE RA02 SQB-1 Use and care manual

KOBE Range Hoods
“So Quiet…You Won’t Believe It’s On!”
Page 1 of 5
Version 20160725
RA02 SQB-1 Parts Location and Replacement
This basic guide is to show the parts location of the RA02 SQB-1 and how to remove or install certain parts.
To see more detailed guidelines, please visit: Kobe Service and Repair
For models (w/ Standard Duct Cover): RA0230SQB-DC-1, RA0236SQB-DC-1, RA0242SQB-DC-1, RA0248SQB-DC-1 or
RA0230SQB-1, RA0236SQB-1, RA0242SQB-1, RA0248SQB-1
For models (w/ 24” Duct Extension): RA0230SQB-DC24-1, RA0236SQB-DC24-1, RA0242SQB-DC24-1,
RA0248SQB-DC24-1
Overall Snapshot of RA02 SQB-1
1. Blower System (Manual Part #8 –See “Parts List” page on manual)
2. Knobs (Manual Part #5 –See “Parts List” page on manual)
3. LED Light (3W) (Manual Part #3 –See “Parts List” page on manual)
2
1
3
3

KOBE Range Hoods
“So Quiet…You Won’t Believe It’s On!”
Page 2 of 5
Version 20160725
Removing the Capacitor Panel
.
Figure 1 Figure 2
Figure 3 Figure 4
4. Capacitor Panel (Manual Part #11 –See “Parts List” page on manual)
4
4
4
4
Warning: Loosen the screw first with a
hand tool screw driver.

KOBE Range Hoods
“So Quiet…You Won’t Believe It’s On!”
Page 3 of 5
Version 20160725
Accessing the Capacitor and LED Driver
5. Capacitor (Manual Part #9 –See “Parts List” page on manual)
6. LED Driver (Manual Part #10 –See “Parts List” page on manual)
5
6

KOBE Range Hoods
“So Quiet…You Won’t Believe It’s On!”
Page 4 of 5
Version 20160725
Removing the Control Knobs
Figure 1 Figure 2
Figure 3 Figure 4
Accessing the LED Light
For a more detailed guideline,
visit:
How to Replace LED Lights
3
2
2
2
2

KOBE Range Hoods
“So Quiet…You Won’t Believe It’s On!”
Page 5 of 5
Version 20160725
Removing the Motor
Figure 1 Figure 2
Figure 3 Figure 4
1. Blower System (Manual Part #8 –See “Parts List” page on manual)
1
1
Warning:
1. Loosen the screw first with a hand tool screw driver.
2. Place a support or hold the blower before removing it.
