KOCOM KDP-601AM Instruction Manual

Thank you very much
for purchasing KOCOM
Doorphone.
Please read this manual
thoroughly to ensure
correct usage,
before operating.
DOOR PHONE
KDP 601AM & KDP 601DM Manual for Operation and Installation
Gentle chime sound.
KDP 601AM : AC 220V(only) or 110V(only)
KDP 601DM : Used DC 6V(4 Piece of 1.5V batteries)
: Used DC 12V / 300mA(External Power Source)
Communication range:0.65mm wire, 300m line
Can be combined with door opener.
Easily mounted on wall, desk
Features
KDP-601AM & KDP-601DM
DS-2D
or
This manual is based on the date as shown in the right and specifications
are subject to change without notice for quality improvement.
Door Phone 06.09
MS-2D

PRODUCT
MODEL
DATE PURCHASED
WARRANTY PERIOD
AGENCY
AGENCY ADDRESS
KOCOM Warranties the original purchaser of this product as follows.
1) This product is produced under strict quality control and inspection procedures.
2) If this product breaks down during proper use as a result of product defect,
KOCOM will repair it within one year from date of purchase free of charge.
3) The following cases will be subject to charge, even during warranty period :
a. Breakdown during transport, or through careless treatment, by consumer.
b. Breakdown caused by unauthorized repair, or system modification.
c. Breakdown caused by natural disaster or power disorder.
To receive a ter sales service, have the ollowing ready
when you contact our branches.
1. Name of the product.
2. Model number of the product.
3. The area of problem.
4. Phone number and address at which you can be contacted.
Warranty
Warranty Card
DOOR PHONE
KDP 601AM & KDP 601DM

Do not throw used up battery into fire places, which may cause fire and explosion.
Cautions for installation
The relevant law obliges users to have a qualified electrician carry out wiring work for power supply. Work by disqualified
persons may cause fire and electric shock.
Wiring work for communication cables needs techniques and experiences. For this type of wiring work, please consult to your
local sales agent.
According to the standard for electric work and other relevant regulations, install communication cables at the place away
from power cables. The failure to install cables separately may cause fire, electric shock and communication troubles.
Do not install the product on rolling table or sloping place.
Dropping or falling may cause damage on your product.
In installation, avoid the place exposed to tremor or shocks, which may cause damages on your product.
Even if your product is waterproof, do not install it slanted place of water leakage, which may cause a short circuit.
For the product of wall mounting type with fixing pegs, keep it safely.
Fixing pegs may cause injury of user.
Install the product of wall mounting type carefully not to drop from the wall. Dropping due to earthquake or tremors may
cause injury of user.
When installing the product on the wall, consider the thickness and material of the wall.
Dropping in use may cause injury of user.
Cautions for Use
Do not put heavy thing on the product. Dropping or falling due to heavy things on it may cause injury of user.
Cautions for Repairs and Maintenance
Clean the dust inside the product regularly. Failure to clean the dust for long time may cause fire. For inspection and cleaning
of the inside of product, please contact your local sales agent.
When putting your hands into the inside of equipment, be sure that plug is already detached form an outlet or circuit breaker is
turned off.
Be careful not to expose the product to benzene, thinner or hot water.
Do not expose detergent directly to the product in a way of spaying, etc.
Moving equipment, be sure that the plug is detached from an outlet.
For equipment whose cables are connected to terminals, please contact your local sales agent or qualified electrician.
When replacing old fuse with new one, do not directly touch it with bare hands.
Use insulated tools or contact A/S center.
Cautions


















Warnings for disposal
Read this cautions carefully and keep it within easy reach of you.
For right installation, read this cautions thoroughly. Please install the product according to its specifications.
This Cautions for Safety may include items that are not contained in specifications of the product that consumer
purchases.
Reading this cautions, use the product in a right manner. For further information, please contact our A/S center.
About Symbol
A variety of symbols are used in this Cautions for Safety and your products to guide you to use products in a right
and safe manner and to prevent possible risks for users and other persons and damages to their property. The meaning
of each symbol is as follows. After fully aware of meaning of each symbol, read the following cautions.
This symbol means that wrong handling or ignorance of matters that this symbol indicates
may cause serious injury or even death of user.
This symbol means that wrong handling or ignorance of matters that this symbol indicates
may cause serious injury or property damage of user.
This symbol means the matter that user should not do at nay event.
This symbol means that user should follow the instructions.
Symbols on Drawing
This symbol means that contents (high voltage, electric shock, warnings, etc.) to which user
should pay attention are included.
This symbols means that a certain action is not permitted. Specific points not permitted are
depicted around this symbol (for example, in the left drawing, disassembly is not permitted.).
This symbol means instructions or is used to force user to do a certain action. Specific
instructions are depicted on the drawing
(for example, the left drawing instructs user to detach power plug from an outlet).
Cautions for Safety
Warnings
Cautions
For safe use, please stick to the following cautions.
Warnings

This product is only for home. Do not the product for industrial or military use.
Do not handle the equipment with wet hand, which may cause electric shock.
Do not place wet or metallic materials on equipment. Water leakage or intrusion of metallic materials may cause fire and
electric shock.
Do not block the ventilating opening of equipment or put alien substances into it, which may cause fire and electric shock.
Do not use battery that is not designated or mix new battery with old ones. Insert batteries to fit their polarity. Explosion or
leakage of battery may cause fire and injury of user.
When visitor's image or voice is not displayed on screen or not sounded from speaker, please check his/her identity before
opening the door and contact our A/S center.
Do not use equipment when lighting is expected or strokes. It may cause fire and electric shock.
Do not open rear cover, cabinet and cover of equipment. It may cause electric shock.
Do not modify power cable or pull it with excessive strength, which may cause fire and electric shock.
Do not modify equipment. It may cause fire and electric shock.
Call signal may cause damage on user's hearing ability.
Cautions for Abnormality
When power cable is broken (exposure of core or short circuit), do not fail to replace broken cable with new one. Failure to
replace broken power cable may cause fire and electric shock.
When detecting any abnormalities in equipment (communication is not available, images do not be displayed on screen, calling
is not available, or abnormal sound is heard), immediately detach plug from an outlet, or turn off circuit breaker or detach
batteries from equipment (in case that equipment has no plug) before requesting repairs to sales agent or A/S center. Keeping
connection to power supply may cause fire and electric shock.
When alien substances go into equipment, immediately detach plug from an outlet, or turn off circuit breaker or detach batteries
from equipment (in case that equipment has no plug) before requesting repair to sales agent or A/S center.
In the case of smoke or smell of unknown origin from equipment, keeping use it may cause fire and electric shock. Detach
plug from an outlet, or turn off circuit breaker or detach batteries from equipment (in case that equipment has no plug) and be
sure to check no more smoke or smell from equipment before requesting repair to sales agent or A/S center. Since personal
repairing work by user may serious accidents. In any case, do not repair equipment with your own hand.
When dropping equipment or breaking its cabinet, detach plug from an outlet, or turn off circuit breaker or detach batteries
from equipment (in case that equipment has no plug) before requesting repair to sales agent or A/S center. Keeping use
equipment may cause fire and electric shock.
Avoid direct exposure to sunlight and store equipment at the place free from dust and high temperature as you can. High
temperature of equipment may cause fire and electric shock.
Warnings Warnings
Cautions for Use
Do not install the product at bathroom or at the place near a washing machine, or at other humid places. It may cause fire or
electric shock.
Do not install the product at the place near a dresser, humidifier or heater. Also avoid the place exposed to spark, heat or
humidity. All of them may cause fire and electric shock.
Do not install the product at the place exposed to dust, metals and harmful gas such as hydrogen sulfide gas, all of which
may cause fire and electric shock.
Do not install the product at the place exposed to water and chemicals. This may cause fire and electric shock.
Do not scratch, break or arbitrarily process power cable, which may cause fire and electric shock. Putting a heavy thing on a
cable, heating it or pulling it may cause impairment on it.
Do not place power cable at the place near heating equipment. It may cause damage of cable's clothing material, which
result in fire ad electric shock. When detaching plug from an outlet, do not pull power cable.
Damages on power cable may cause fire and electric shock. When detaching plug from an outlet, please hold the plug
tightly.
Do not detach plug from an outlet with wet hand. I may cause electric shock.
When using the existing wiring, be sure of the suitability of it to the product and install the product. Failure to this caution
may cause fire.
When moving equipment, be sure that plug is detached from an outlet and communication cable is disconnected. Damage
on cables may cause fire.
Voltage other than prescribed rated voltage is not permitted, which cause fire and electric shock.
Do not use power terminal of product's main body in other equipment than prescribed ones. It may cause fire and short
circuit.
In wiring work, use the designated wiring materials.
Wiring work using other materials than designated ones may cause fire.
The equipment without waterproof marking shall not be installed at the place water leaks. It may cause electric shock and
short circuit.
When working, be sure that power is disconnected. Failure to disconnect power may cause electric shock.
Be sure that the power cable is connected and earths according to designated method. Failure to connection and earth may
cause fire.
Do not connect power to other terminals than designated ones.
It may cause fire and electric shock.
When building a system with the product, do not connect the product other equipment than designated one. It may cause
fire.
When installing A/C switch, do work after removing the substance that may cause short circuit or electric shock.
Before installing or providing A/S service, be sure that the power is disconnected.
Cautions for Use

Please install motion detector at a place easily detect the motions of subjects. When detector is installed at a wrong place or obstacles block the front
side of detector, it cannot work well.
When setting night guard mode, be sure that detector should be connected well.
Sufficiently charge the battery of wireless handset before using it. Be careful that children should not throw battery. Be sure to close battery cover
(When children throw or disassemble battery, it may cause serious accidents).
Be careful that the polarity of the product matches to that of guardroom communication cable. When polarity is reversed, it may cause abnormal
operations of the product or apartment system as a whole.
4 Line Related Products: KVM 604, 624, 524RG, 524G, 524GS, 520, KCV 346/356
In wiring work, be careful that wirings should keep away from the wall mounting pegs or other furniture at regular interval. Contact of wiring with
wall mounting pegs, etc. may cause short circuit, electric shock and fire (it is applied to all products with wall mounting pegs).
Use the prescribed standard wirings. Non standardized wirings may give adverse effects on operation of product
(it is applied to both video phone and CCTV).
CCTV Camera
Do not install at noisy places.
Do not install at the place exposed to electromagnetic waves.
Excessive electromagnetic waves may cause continuous noise on screen and mechanical troubles.
When installing camera outdoor, please put it in the outdoor case. Otherwise, when it rains, the camera may be broken or operate incorrectly.
Install the product at well ventilated places.
Do not use the product for medical or military uses.
Do not install the product at humid places. It may cause reduction of the product's durability as well as fire and electric shock.
When lens is stained with alien substances, clean it with soft cloth to prevent the damages on it.
Install the product out of reach of children.
System for Multi unit Housing
In installation, be careful that other wiring or metallic substances should not contact to the system for multi unit housing.
In installation, be careful that alien substances should not go into the system.
Before installation, be fully aware of wiring specifications of each model.
In installation, be sure that the length and dimension of wiring meet the requirement prescribed in installation manual.
Excessive strength and external shock may cause mechanical breakdowns of equipment.
Do not arbitrarily open the case of the product
(When user opens the case arbitrarily, KOCOM may reject to provide A/S service).
Lobby Phone: KLP (100, 104, 108, 112), KLP (P100, P104, P108, P112), KDP (100, 104, 108,112)
A stroke of lighting or strong shock may give fatal and adverse effects on system. Thus, do not fail to ground the system.
For registration of household password, please refer to user manual of the concerned product (it is applied to ten key lobby phone products
[KLP 100, KLP P100 and KDP 100]).
Image Splitter: KSV 104P
An image splitter can support up to four households.
In the case of over four householders, additional image splitters are needed.
Image Amplifier: KHU 102P
In installation, follow the specification for image in/output.
Video Phone
In assembling the product, be careful that wall mounting pegs should not contact with wirings.
In connection of cables, strip its insulation off as much as necessary (Excessive stripping off its insulation may cause short circuit).
Be careful that signal cables should not be wired with A/C wiring (it may cause poor display quality).
Do not drop handset (its damage or short circuit due to drop may make communication impossible).
When connecting wires to terminals, use standard screwdriver (otherwise, screws may loosen, which will result in disconnection of wiring).
Do not clean CRT screen with wet towel or cloth. When water penetrates into the product, it may cause short circuit.
Do not fail to clean it with dry towel or soft cloth.
Do not install camera at the place where water penetrates or leaks. Penetration or leakage of water may cause electric shock or short circuit.
Home Auto: KHV 444/454/446/456
Do not insert any metallic materials into the inside of fuse cover. It may cause electric shock.
Do not close ear to speaker. Abrupt call or signal may give harmful effects on user's hearing.
After turning power on and off, check again that input contents are saved correctly. Otherwise, data may be missed when auto signal mode operates.
Use a standard detector. Non standardized detectors are likely to cause fire due to excessive voltage or current.
Safety Instructions, Warnings, and Cautions of Each System
This equipment is electronically precision equipment, so do not arbitrarily disassemble it.
In installation of the product, do not fail to follow the specifications (specifications offered by KOCOM).
Do not touch the product with alien materials (for example, sticker, magnet, opener, metal chopstick, etc.)
or insert them into the product (it may cause reduction of the product's durability and harmful results to user as well).
In the rainy season, water is likely to penetrate into the product along the wiring. Thus, U type finishing is recommended
as a desirable method of end part finishing.
B
E
N
Z
E
N
E
T
H
I
N
N
E
R
Keep away from humidifier and
stove. High temperature and
humidity can cause malfunction.
When cleaning, never use wet
hands, volatile benzene or paint
thinner.
Maintain the product clear by
frequently cleaning with soft
cloths.
As this device consists of precise electronic components, and high voltage is generated
internally, do not attempt to disassemble.
Do not drop lndoor station, and
avoid strong impact.
Precautions or Operation

Power Lamp
Indoor station Outdoor station
Door open
Handset
Installation
Speci ications
How to operate (Instruction or operating)
Name o Each Part Wiring Diagram
Component
Description KDP-601AM KDP-601DM
Electric source AC 220V(only) or 110V(only) BATTERY: DC 6V(4 Piece of 1.5V batteries)
LINE TERMINAL: DC 12V / 300mA
Consumption Un load: 0.5W Inload: 3.3W Un load: 0.25mW Inload: 1.3W
Signal Sound Chime Chime
Wiring 2Wired polarity 2Wired polarity
Range 300m(0.65mm) 300m(0.65mm)
Master station for indoor use Out door pannel Wall hanger for master station
♪
♬
Pick up the handset and
communicate with a visitor.
After end of communication,
return the handset where it is
locked.
The indoor station
is ringing. To release the door, press
the “Door open” button.
When a visitor
pushes the outdoor
station bell.
A Choose a place on the wall where you
want to hang the Indoor station.
B Fasten the wall hanger on the wall.
C Indoor station can be hung on the wall
hanger easily now.
Installation of Indoor station Installation of outdoor station
After attaching the body supporter with 2screws,
put the indoorstation into the grooves of body
supporter,and then fix it with screws.
Call Button
DS 2D
MS 2D
C Mic
Speaker
Volume
Switch
Wiring Diagram
KDP-601AM
MS 2D or DS 2D
KDP-601DM
MS 2D or DS 2D
CAUTION
When DC 12V
Power line terminal
is used.
