Kodak SV 710 - EASYSHARE Digital Picture Frame User manual

www.kodak.com/go/digitalframesupport 1
ENGLISH
See your extended user’s guide – for more information about using your frame,
visit www.kodak.com/go/digitalframesupport.
Remote control
Button Press to
power* turn on/off the picture frame.
home return to the home screen.
pics/music toggle between viewing pictures and selecting music.
menu display menu choices.
back return to the previous screen.
stop a slide show, display thumbnails.
OK accept the current selection.
4-way navigate through pictures or menus.
zoom magnify the picture.
rotate rotate the picture, 90°clockwise each press.
select mark pictures for an operation.
slide show play a slide show.
play/pause play/pause a video or slide show.
rewind rewind a video.
fast forward fast forward a video.
stop stop a video, display the first frame.
stop a slide show, display thumbnails.
volume decrease (-) or increase (+) the volume.
mute mute audio.
back
OK
menu
First, turn on the
power switch on the
frame.
*
Remove tab to
activate the
remote.
*

2www.kodak.com/go/easysharecenter
ENGLISH
Front View
Back/Left Side View
1Speakers 5Memory card slot - SD, MS, xD, MMC
2Wall mount hangers 6On/Off switch
3Frame stand 7Remote control holder (removable)
4Memory card slot - CF, MD 8Slots for remote control holder
1 LCD screen
2 Faceplate
3 Remote control sensor
3
2
1
6
4
7
2
5
1
1
2
3
Slide the holder
into slots. 8
8

www.kodak.com/go/digitalframesupport 3
ENGLISH
Top/Right Side View
1Picture/music toggle 8USB connector (connect to computer)
2Play/Pause 9USB connector (connect to camera/USB device)
3Stop/Back 10 Volume control
4Menu 11 Headphone jack
5OK 12 DC-In (12 V)
6 Down 13 Reset button
7Up
8
9
6432
12
5
11
71
10
13

4www.kodak.com/go/easysharecenter
ENGLISH
Installing the software
Insert the EasyShare software CD
■Install or upgrade to this special version of
EasyShare software to easily copy pictures and
videos from your computer to your frame.
Connecting the power cable
CD packaged
with your frame.
Your power cable (included with the frame) may be
different from the one pictured. Use the plug that
accommodates your type of power outlet.

www.kodak.com/go/digitalframesupport 5
ENGLISH
Turning on the frame
Setting your language
back
OK
menu
Press the switch
to On.
Then use the remote control
to turn the power off and
on.
1. 2.
2.
1.
OK to accept.
to change.
The language
setup screen
appears the first
time you turn on
the frame.
back
OK
menu
A slide show starts from sample
pictures pre-loaded in internal
memory (not available on the
SV710 frame).

6www.kodak.com/go/easysharecenter
ENGLISH
Viewing your first pictures
To play a slide show, insert a memory card or USB device (see step on the
next page).
If a slide show is already playing (for example,
from the pre-loaded sample pictures*), your slide
show starts automatically.
If you are at the Home screen, press on
the remote control to highlight your picture source,
then press to start the slide show.
— To play music with your pictures or slide
shows, see page 10.
* Not available on the SV710 frame.
6

www.kodak.com/go/digitalframesupport 7
ENGLISH
Inserting memory card/USB device
Memory card
(sold separately)
CompactFlash/
MicroDrive
Secure Digital/
Memory Stick/
xD/
MultiMediaCard
USB device
(digital camera, flash drive, card reader, etc.—sold separately)
(USB cable included
with your USB device.)

8www.kodak.com/go/easysharecenter
1Doing more
All buttons and controls described are on the remote control unless otherwise specified.
Home screen—picture sources and settings
1Press .
All connected sources and the Settings icon are
displayed.
2Press to highlight a picture source, then:
■Press to start a slide show.
■Or, press OK to display thumbnails and folders.
Home screen options:
My Frame—the frame’s 128 Mb internal memory (unavailable on the SV710 frame).
Copy your pictures into My Frame from a memory card or other device (page 11).
Memory card—appears when you insert a card (page 7). The label and icon indicate
the type of card.
Camera—appears when you connect a digital camera via USB cable (page 7).
USB drive—appears when you insert a USB flash drive (page 7).
Settings—customize your frame settings. For example; set slide show durations and
transitions, set viewing options, screen brightness, clock, and timer. See the extended
user’s guide at www.kodak.com/go/digitalframesupport.

Doing more
www.kodak.com/go/digitalframesupport 9
Viewing pictures and videos
For supported picture, video, and music file formats, see the extended user’s guide.
Running a slide show
There are three ways to start a slide show:
■Insert a memory card or connect a USB device, then turn on the frame.
■Turn on the frame, then insert a card or connect a USB device – a new slide show
starts automatically, replacing a currently running slide show or single view picture.
■Select a picture in thumbnail view or select a picture source on the Home screen,
then press or .
Viewing thumbnails
There are two ways to view your pictures as thumbnails:
■Press , select a picture source (see page 8), then
press OK.
■Press or from a slide show or single view.
Other things to do in thumbnails view:
■To navigate through the thumbnails, press .
■To play a video ( ), highlight it and press OK.
■To view the pictures in a different folder, highlight it and press OK.

Doing more
10 www.kodak.com/go/easysharecenter
Single view
■To view a single, full-screen picture, highlight it in thumbnails view and press OK.
■To magnify a picture up to 8X, press . To view other parts of the picture, press
. Continue pressing to return to full view.
■To rotate a picture, press .
Playing music
1Press to pause your picture or slide show and
display the Audio screen.
2Press to highlight a music source, then press OK.
3Press to go to the next or previous song, or select
Play all songs. Then press OK.
Your music starts playing.
4Press to return to your picture or slide show.
Your selected music continues to play as the slide show resumes. When music is playing,
videos play without their related audio (default setting).
5To turn off music, press , then .
6Press again to return to your pictures.
NOTE: To copy audio files to internal memory, drag and drop them from your computer via the included USB
cable. See your extended user’s guide.
