Kogan androidtv 9 Series User manual

(KALED55RT9220SVA)
USER GUIDE
55” SMART HDR 4K UHD LED TV SERIES 9 RT9220

Safety InformationImportant Safety PrecautionsTV Buttons And Terminal InterfaceExternal device connection diagramTV Install And ConnectTV Stand Installation InstructionsOSD1Initial Installation2HOME3Settings5TV Source setting4App Install/Move/UninstallHow to turn off auto sleep functionSAFETY INFORMATIONIMPORTANT SAFETY PRECAUTIONSThe exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating in the literature accompanying the appliance.WarningThe lightning flash with arrowhead symbol within an equilateral triangle,is in tended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.High, voltage are used in the operation of this product to reduce the risk of elect shock,do not remove cover of the cabinet, refer servicing to qualified service personal.CAUTIONRISK OF ELECTRIC SHOCKDO NOT OPENIf the TV any changes or coarse adjustment, electric shocks to be hurt, do not attempt to open a machine-maintenance, customer contact centres needed overhaul.1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions.5) Do not use his apparatus near water. 6) Clean only with dry doth.7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety, If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.10) Protect the power cord from being walked on or pinched particularly at Plugs, convenience receptacles, and the point where they exit from the apparatus.11) Only use attachments /accessories specified by the manufacturer.12) Use only with the cart, stand,tripod, bracket or table specified by the manufacturer, or sold with the apparatus. When a cart is used caution when moving the cart/apparatus combination to avoid injury tip-over.13) Unplug this apparatus during lightning storms or when unused for long periods of time. Caution:14) To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.15) The mains plug is used as disconnect device,the disconnect devices hall remain readily operable.16) The socket-out shall be installed near the equipment and shall be easily accessible.17) This product should never be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacture's instructions have been adhered to.18) The apparatus shall not be exposed to dripping or splashing and that no objects filed with liquid, such as vases, shall be placed on the apparatus.23) The battery shall not be exposed to excessive heat such as sunshine,fire or the like.24) This equipment is a Class Il or double insulated electrical appliance.It has been designed in such a way that it does not require a safety connection to electrical earth19) Do not place any sources of danger on the apparatus(e.g.liquid filled objects,lighted candles).20) Wall or Ceiling Mounting-The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.Never place the TV,remote control or batteries near naked flames or other heat sources, including direct sunlight.To prevent the spread of fire,keep candles or other flames away from the TV, remote control and batteries at all times.22) PThe USB terminal should be loaded with 0.5A under normal operation. These servicing instructions are for use by qualified service personnel only.To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions. unless you are qualified to do so.21) 25) The maximum using environment temperature is 45 degrees. The Maximum using altitude is 2000 metersComponents2 .............................................................02 .........................................02 .......................................................................03 ...............................04CONTENTSTHIS USER GUIDE COVERS THE FOLLOWING MODELSKogan 55” Smart HDR 4K UHD LED TV (Series 9 RT9220).............................04....................................................05.................................05Remote Control overview .................................................06......................................................................................07...................................................07.....................................................................10..................................................................11...............................13.................................................13...............................14Specifications.....................................................................15Troubleshooting.................................................................16Help......................................................................................17

BCDEGA Kogan 55” Smart HDR4K UHDLED TV B Remote controlC Stand (x2)D BB4 x 16mm screw (x6)E AAA battery (x2)F Quick-start guideG Warranty cardNOT INCLUDEDPhillips head screwdriver, antenna cable, broadband internet connection.(KALED55RT9220SVA)SERIES 9 RT922055" S MART HDR 4K U HD LED TVQUICK START GUIDEFCOMPONENTSA3

One key:Seven keys:Terminal InterfaceNote: The following is only functional schematic,And the actual position and arrangement of different models may be different.Press this button in standby mode to turn on/off the TV.Turn ON/OF Power.External Signal Input SelectionDisplay Main MENU And Confirm MENU Item Selection.Selecting Channel.Adjusting Volume.MENU/ OKCH + / -VOL + / -SOURCE/Note: The following are the various terminal interface,the actual position and arrangement, the number of different models may be different.AV inputExternal Av Signal Input.EARPHONE outputWhen earphones are plugged in, speakers are disabled.HDMI inputDigital signal input from HDMI video connector.USB inputConnect a USB device here to play its media files or to record programs via the PVR function.OPTICAL outputConnect the SPDIF receiver.ANT 75Connect the antennal/cadle tv input (75/VHF/UHF).LANConnect the Internet.LANEXTERNAL DEVICE CONNECTION DIAGRAMLANDVDSet-top boxesHDMI input connectionAV input connectionAV input connectionAV output connectionLAN connectionTV connectionUSB connectionTV BUTTONS AND TERMINAL INTERFACE4

TV INSTALL AND CONNECTTV ANTFM ANT
TV signal output
132Set your TVConnect antenna and powerTurn on TVNote:10cmTo avoid danger, please don't positions the TV near water or heating place (such as light, candle, heating machine),do not block the ventilation at the back of TV.To put your TV on a firm place which can bear the weight of the TV.10cm10cm1.Connect the antenna cable to the antennasocket on the back of the TV.2.To plug the power cord of TV (AC 100-240V~ 50/60Hz).3.Connect the power supply, enter the standby mode (red light), press the power button of the TVor the power button on the remote control to turn on the TVPicture for reference purposes only.1. Open the carton and remove the TV and scattered accessories and base (some models without base).2. In order to avoid damaging the TV,please cover it with soft mattress,put it on the table, face down on the soft material and screw the neck of the base to the TV.3. screw the base and connected to the TV.4. the installation is complete.Picture for reference purposes only.Please prevail in kindNote:TV STAND INSTALLATION INSTRUCTIONS5

Figures 0-9 are used to directly input channel numberPress to display Electronic Program Guide and select the favorite channelIncrease the volumeDecrease the volumeIncrease the programDecrease the programDisplays the OSD(On Screen Display) menuTo confirm the choice with program the highlighted menu itemPress to start recording the programEPG
INFO
VOL +VOLCH +CHGoogle AssistantPress to info the source and channel’s infoSwitches the TVbetween on and standby modeMute or restore TV soundDisplay/Select signal source optionsMicrophone holePress these buttons to select itemsPress these buttons to select and adjust itemsAccesso diretto a Amazon Prime VideoTo open app homepageGo back to the previous stepPress to exit the OSD menuPress to play the video and press again to pause the videoPress these buttons accordingPress to fast forward in USB modePress to fast reverse in USB modeHold on or off for current page displayPress to change the language when playing the stream which contains multi-languageto different promptsPress to enter Teletext when play the program
AUDIO
SUBT
SUBTEXIT
BACK
Displays the home screen
Connects to NETFLIX for viewingonline TVshows and films(internetconnection required).Connects to YouTube (internet connection required). REMOTE CONTROL OVERVIEW6

The first time you switch the TV on, the initial step screen appears which guides you through the initial proces.Please according to the Text Tips to inish initial installtion.1. Initial Installation1. 1 Language select->Press / remote control to select the language option,then click【OK】to confirm. Quickly set up your TV with your Android phone? (Continue/skip) Steps:1.2 1. On your Android Phone, open the Pre-installed app "Google".
2. Type or say, "Ok Google, set up my device".3. Tap the model name on the list. Configure the network->Select wired or wireless to connect to internet.->If you select skip,it could be performed in homepage or settings menu.Google Account Sign inSign in to get new apps,recommendations,movies,the Assistant,and more from Google.Two ways to login Google account:1.31.4 ->Use your phone or computer:
1. Visit androidtv.com/setup on your phone or computer, Make sure your other device is on the same Wi-Fi network as your Android TV ™
INITIAL INSTALLATION7

2.Enter the display code on your phone or computer->Use your remote:Use the remote to enter your Google account and password to sign in to Google account. In these steps you will setup the Terms of Service, Location, Help improve Android, Google Assistant and additional Google functions. Select install or un-install he recommended apps and Google apps by using this process.->Press "Continue" to the next setting page.Google setting1.5 Play Auto Installs1.6 1.7 Pairing Bluetooth Remote-> Press'BACK 'and ' VOL- ' simultaneously on remote control to enter the Bluetooth pairing mode. The Indicator light on remote control will flash whenenter the pairing mode.-> Press【OK】to begin pairing.-> Press on remote control to skip the pairing mode.INITIAL INSTALLATION8

Country select1.8 1.9 1.101.111.121.13->Press / on remote control to select the country option,then click【OK】to confirm. Set the TV password for Parental Controls, "0000" is invalid. Select TV mode(Home/Retail)Home mode is optimized for efficient energy usage for home use. Retail mode is optimized to store demo with fixed settings. Chromecast built-in™Select On/Off to make Chromecast built-in available. TV Channel Setting->Select Antenna/Cable/Satelite to scan TV channel.->If you select skip, the channel scan could be performed in menu.Setup completed and Disclaimer TermsINITIAL INSTALLATION9

2. HOMEWhen initial setup is complete,the TV will enter the homepage by default,or press on remote control to display the homepage.->Press / / / on remote control to switch between Google Assistant, Apps, Play Next, Netflix, YouTube, and more on the Homepage.-> Press【OK】to enter.Google AssistantUse your voice to jump to shows,control devices,and more—with Google AssistantAppsPlay NextList of downloaded and pre-loaded apps on your deviceBased on your watch history and includes next episode in a series or unfinished moviesSettingsFavorite appsChannelsManage apps and TV controls, changepreferences, sounds,and accountQuick access to frequently used appsFor easy content discoveryHOME10

3.SettingsAllows to set various performance of your TV.-> Press / on remote control to select "Settings"which is in the upper right corner of the screen. -> Press / on remote control to select the option which you want to adjust in the Settings menu.-> Press【OK】to enter.3.1 Network&internet3.2 ChannelAdjust all network setting and check connection if you have connection problems.-> Press / remote control to select "Network&internet" in the settings menu.-> Press / remote control to select:Wi--Fi/Add new network/Scanning always available/Proxy settings/IP settings.-> Press / on remote control to select "Channel" menu.->Press【OK】to enter"Parental Controls", then click / or use the number buttons on remote control to enter your PIN(Password forParental Controls).3.3 Device Preferences-> Press / on remote control to select "Device Preferences".-> Press / on remote control to select the options of About, Date&time, Timer, Language, Inputs, Picture, Sound, Google Assistant, Reset,etc.SETTINGS11

->Press【OK】to jump to the corresponding sub-option.3.3.1 About-> Press / on remote control to select "About".-> Press / on remote control to check additional information such as System update, Device name, R estart, Status, and more.-> Press on remote control to return to the previous menu.Press on remote control to exit the menu.3.3.2 ResetIf select reset, it will erase all data from your device's internal storage, including:your Google account, System and app data and settings, and downloaded apps.-> Press / on remote control to select "Reset".-> Press / on remote control to select "Cancel" or "Erase everything".SETTINGS12

4 App Install/Move/Uninstall->Press / on remote control to select"Apps"on Homepage, then click【OK】to enter.-> Select "Get more apps" and input app name.-> Select "search" which is in the upper right corner of the page.Example for "Facebook" 4.1 Install->Input "Facebook", find "Facebook"App will show in the list,then click【OK】 to select it.->Select "Install",when completed select to open or Uninstall. 4.2 Move->Select"Facebook", press and hold【OK】on remote control, then click / remot e control to select"Move"-> Press / / / on remote control to move,then click【OK】to confirm. 4.3 Uninstall->Select "Facebook", press and hold【OK】on remote control, then click / on remote control to select"Uninstall".-> press【OK】to uninstall.APP INSTALL/MOVE/UNINSTALL5 TV source settingThe way to enter TV source in Homepage:->Press on remote control or Select"Live TV"on Homepage.->Press on remote control.->Press on remote control to select"Channels"and select"New Channels Available"to enter.TV SOURCE SETTING13

MenuMenu - > Settings - > Device Preferences -> Power - > OffSettingsDevice PreferencesPowerOffHOW TO TURN OFF AUTO SLEEP FUNCTION14

15SPECIFICATIONSAudioSpeakers 2 x 8WConnectivityEthernet (RJ45) YesHDMI 2.0HDMI-ARC Yes | HDMI 1HDMI-CEC Yes | HDMI 1, HDMI 2, HDMI 3USB 2 x USB 2.0Wi-Fi IEEE 802.11b/g/nDimensionsDistance Between Legs 963.0mmWithout Stand 1234.6 x 715.9 x 74.8mm With Stand 1234.6 x 786.8 x 283mmVESA Wall Mount Pattern 200 x 200Weight 17.15kgDisplayColours 1.07GComputer Supported Resolutions 640×360, 853x480, 1024x576, 1280x720, 1366x768, 1920x1080, 3840x2160 (@60Hz)Contrast Ratio 5000:1Native Aspect Ratio 16:9Refresh Rate 60HzResolution 3840 x 2160Response Time 6.5msSize 55”Viewing Angle 178°/178°FeaturesEPG YesHDCP Yes | 2.2TV Resolution 4K UHDBrowser PangoUSB Media Playback YesUSB Media Playback Formats JPG, JPEG, PNG, BMP, MP3, DD, DD+, AAC, MPG, MPEG4, H.265, VP9 (4K@60P)InputsComposite (AV) 1 HDMI 3Outputs3.5mm Stereo Audio 1Optical Audio Out 1PerformanceCPU ARM CA55 Quad Core with TEE1.2GHzGPU MAli470 MP3 OS Android 9.0RAM 1.5GBStorage Capacity 8GBPowerAverage Consumption 135WEnergy Consumption 320kWh per yearEnergy Rating 5 StarTuning And SignalTuner Type DVB-TNote:• Design and specifications are subject to change without notice.• Weight and dimension shown are approximate.

TROUBLESHOOTINGCare & maintenanceUnplug the television from the power supply before cleaning. Do not use any liquid cleaners or harsh chemicals. Always use a soft, damp cloth.Cleaning the screenWet a soft cloth in a mixture of lukewarm water and a little fabric softener or dish washing detergent. Wring the cloth until it’s almost dry, and then use it to wipe the screen.Make sure the excess water is off the screen, and then let it air-dry before you turn on your TV.Cleaning the casingTo remove dirt or dust, wipe the TV casing with a soft, dry, lint-free cloth. Please be sure not to use a wet cloth.Common fixesMany minor issues can be resolved by hard resetting, or power cycling the unit or upgrading the firmware.To perform a hard reset, or power cycle, please use the following steps.•Unplug it from the main power socketand leave it for 10-15 minutes.•Press and hold the power button onthe TV for 5 seconds.•Connect the TV back to the power andturn it on.Poor picture and sound quality•Try a different channel•Adjust the antenna•Check all connectionsNo picture or sound in TV status•Try another channel•Press the TV/AV button•Make sure TV is plugged in•Check the antenna connectionNo sound or sound is too low at maximum volume•Check the volume settings on anyexternal speakers connected to yourtelevision•Adjust the TV volume accordingly•Check another channel or input•Check that MUTE hasn’t been turnedonPicture rolls vertically•Check all connectionsNo colour, wrong colour or tints•Make sure the program itself is broad-cast in colour•Select the picture menu, then adjustthe colour and tint submenusBlurred or snowy picture, distorted sound•Check direction, location and connec-tions to your antenna•Issues may be caused by the use of anindoor antenna (poor signal)Remote control malfunctions•Replace remote control batteries•Check battery terminals•Remote is out of range, move closer toTV•Remove any obstructions betweenremote and IR sensor of TV•Make sure the power cord to your TV isplugged in and turned onImage is not centred on the screen•Adjust the horizontal and verticalposition“No Signal” on HDMI source•Test the device with a different HDMIcable•Plug the device into another HDMIport•Try a different device connected to thesame cable and port•For our Perform a factory reset on your TVfull TV troubleshooting guide, head online to help.kogan.com © Copyright 2020, Kogan.com – KALED55RT9220SVA16
