Kogan SMARTERHOME G30 User manual

KOGAN SMARTERHOME™ G30
SMART ROBOT VACUUM CLEANER
WITH MOPPING FUNCTION
KAVACRBG30A

Before using this product, please read the following safety instructions and follow all
routine safety precautions!
•Please read these instructions carefully.
•Please keep this book for future reference.
•Any operation not in compliance with these instructions is likely to cause
damage to the product.
Warning
•Only qualified service technicians should disassemble, repair or modify the product.
Unauthorised repair may lead to fire, electric shock or injury.
•Do not use any charger other than the one accompanying this vacuum. Alternate
chargers may cause fire, resulting in product damage, electric shock or high
voltage.
•Do not touch any high voltage power cable of the appliance with wet hands, as
this may cause electric shock.
•Do not over bend the power cord or place heavy objects on it. Doing so may
damage the cord, causing a fire or electric shock.
•Always be cautious to avoid clothes or any part of the body (head, fingers, etc.)
getting caught in the brush or wheels of the vacuum cleaner. Doing so may result
in personal injury.
•Keep the vacuum away from cigarettes, lighters, matches and other heat sources.
Keep away from flammable materials.
Attention
•Turn off the power before transporting or moving the vacuum into prolonged
storage. Otherwise, the battery may be damaged.
•Insert the power cord of the charger tightly or it may cause electric shock, a short
circuit, smoke or fire.
•Inspect the connection between the charger and the socket regularly.
•To prolong battery life, charge the vacuum for at least 16 hours before the first use
or before reuse after a long idle period. The battery will not achieve its optimum
performance until 2-3 complete recharging-discharging cycles.
•Before leaving the vacuum cleaner idle for extended periods, please recharge the
battery to full, then take the battery to a cool place, and keep the bottom of the
appliance dry.
•Prior to use, remove all damage-prone objects from the cleaning area (luminous
objects, fabrics, glass bottles, etc.). Otherwise it may cause damage to these
objects or affect the performance of the appliance.
•Please use the cleaner with caution in the presence of children to avoid hurting
them.
•Do not stand or sit on the vacuum cleaner so as not to cause damage to it or
injuries.
SAFETY AND WARNINGS

•Never let the device vacuum up water or other liquids, this will cause damage to
the vacuum.
•Do not use the vacuum cleaner in confined spaces (small table, chair) which may
lead to product damage.
•Outdoor use is prohibited.
•The vacuum is designed for residential use only.

Cleaner Remote control Charging dock station
Power adapter Mop Water tank
Dustbin HEPA Side brush (x2)
COMPONENTS

To p :
Bottom:
Dustbin:
OVERVIEW

Water Tank:
Charging Dock:
Remote Controller:

Installation of the Water Tank
1. Fill the tank with water or any desired plastic-safe cleaning solution by removing
the plastic stopper, marked with a nozzle symbol located on the top of the tank,
and filling until it is full. Reinsert the plastic stopper.
2. Completely dry off the water tank before inserting into the robot.
3. Certain cleaning solutions may need to be diluted with water before inserting into
the water tank. Certain cleaning solutions may stain the mop pad.
4. Insert the water tank into the robot securely.
Installation of the Roller Brush and Sweeping Bracket
1. Turn off the power to the robot by flipping the power switch.
2. Gently pick up the robot and lay it with its wheels facing up.
3. Insert the roller brush into the hollow section in between the two side brushes. Do
this by placing the square shaft on the brush into the corresponding square hole on
the left side of the compartment.
4. Lower the other side of the roller brush by inserting the rubber piece of the roller
brush into the semi-circle slot on the right side of the compartment.
ASSEMBLY

5. Taking the sweeping bracket with the rubber extension facing up, insert the two
front prongs into the corresponding holes in the same compartment containing the
roller brush.
6. Lower the left and right clips located on the sides of the sweeping bracket into their
corresponding holes until a click is heard.

Charging Your Vacuum
1. Connect the power adapter to the power adapter jack on the charging dock.
2. Locate an electrical outlet on the wall close to the ground and plug in the power
adapter.
3. Place the charging dock in a flat position on the ground with the back pushed up
against a wall. There should be no other objects or obstructions for two metres in
front of and one metre to the left, right and above the charging dock. Place the
dock out of direct sunlight.
When the robot has finished the planned clean, it will return to the charging dock
automatically. It will also return to the charging dock automatically when it has low battery.
INSTALLATION
Note
The cord should not be on the ground or obstructing the charging dock as it will result
in the robot being unable to find the charging dock.
The charging dock should always be plugged in to ensure charging when needed.

When the robot is cleaning or on the standby mode, press the “Return Home” button on the
remote controller, the robot will return to the charging dock.
Turn on the power of the robot by flipping the power switch, “-” is turn on, “0” is turn off.
When the robot is on, it will emit a blue light. When you press the button on the panel, the
robot will start working.
Alternatively, to using the charging dock, the robot can also be charged by connecting the
power adapter to the DC recharging port on the side of the robot.

Charging Status
1. When the red/blue light on the button is blinking, the robot is charging. The charge
level is below 15% when the red light blinks, and the charge is above 15% when the
blue light blinks. When the blue light on the panel is solid, the robot is fully charged.
2. The robot can also be charged by connecting the power adapter to the DC
recharging port on the side of the robot.
Note: Do not charge the robot while the water tank and mop is installed and filled with
solution.

Install App
Download the “Kogan SmarterHome” app from the Play Store (Android) or App Store (iOS).
Register
If you do not have a Kogan SmarterHome™ account, register or sign in with a verification
code sent by SMS.
To register:
1. Tap to enter registration page.
2. The system automatically recognises your country/area. You can also select your
country code manually. Enter your email address and tap ‘Next.’
3. Alternatively, you can select ‘Register by mobile number’ and enter the verification
code sent to you by SMS.
4. Create a profile on the next page to define your location and room.
CONNECT TO SMARTERHOME™ APP

Set device in pairing mode
When the device is first turned on, it may automatically enter pairing mode (the indicator
light will be continuously flashing).
If not automatically in pairing mode when powered on, you can manually set the device in
pairing mode by holding down the Home button while pressing the anti-collision strip
simultaneously until the light begins flashing.
Using AP Mode to add device
5. Once registered, tap “+” in the upper right corner of the app’s home page to add a
new device through the network.
6. Select the product type from the list of options in the app (Cleaning Appliances >
Vacuum Cleaners), and then select “Other Mode” from the top-right corner when
asked to reset the device.

7. Select “AP Mode” for the set-up type.
8. Ensure that the device is in pairing mode, with the light flashing, and tap “Confirm
light is slowly flashing”.
9. Enter your Wi-Fi details. It is important that your SmarterHome™ device and the
app are connected to the same Wi-Fi network during setup.

10. Follow the in-app prompts to continue AP Mode connection, which will pair your
mobile phone to the device’s Wi-Fi hotspot to ensure a connection.
11. The device will commence the pairing process and connect to the app. Ensure your
Wi-Fi router, mobile phone, and the SmarterHome™ device are kept close until
connection is complete.
12. After successfully being added, you will have the option to rename the device and
assign it to a location. It will now be listed on the app’s home page. Tap the device
listing to enter its control page.
Notes:
•The device and the app have to use the same Wi-Fi network.
•
The device is only compatible with 2.4Ghz networks.
Note:
If the Wi-Fi hotspot does not appear on your phone in the list of available
networks, your device may not be set in AP Pairing Mode correctly. Try repeating
the steps outlined above to ensure your device is ready for connection.

Having trouble connecting?
The prior steps detail the process for “AP Mode” connection. If that does not work for your
connection, we suggest trying it again, and if still no success, attempting the following
method for Standard (non-AP Mode) connection.
Add device through network
5. Once registered, tap “+” in the upper right corner of the app’s home page to add a
new device through the network.
6. Select the product type from the list of options in the app (Cleaning Appliances >
Vacuum Cleaners).
7. Ensure that the device is in pairing mode, with the indicator light flashing, and tap
“Confirm light is rapidly flashing”. In Standard mode, it will refer to rapid flashing,
not slow flashing.

8. Upon successfully confirming pairing mode, enter your Wi-Fi details. It is important
that your SmarterHome™ device and the app are connected to the same Wi-Fi
network during setup.
9. The device will commence the pairing process and connect to the app. Ensure your
Wi-Fi router, mobile phone, and the SmarterHome™ device are kept close until
connection is complete.
10. After successfully being added, you will have the option to rename the device and
assign it to a location. It will now be listed on the app’s home page. Tap the device
listing to enter its control page.
If neither Standard or AP Mode methods are successful, please contact kogan.com for
assistance.
Notes:
•The device and the app have to use the same Wi-Fi network.
•The device is only compatible with 2.4Ghz networks.

1. To start your robot, turn on the power switch on the side of the robot. The blue light
on the button will illuminate. The robot will enter standby mode. Press the button
on the panel, the robot will begin the planned clean.
2. If you press the button on the panel whilst the robot is cleaning, the robot will enter
into standby mode and wait for the next instruction.
3. To send the robot back to the charging dock manually, press the button on the
panel two times. The light will glow red, and the robot will begin to find the
charging dock. When it docks, and you see the red/blue light blinking, the robot is
charging. When the blue light is solid, the robot is charged.
4. Leave the robot on the charging dock after cleaning has finished, in order to do the
next cleaning.
Note: If the robot is not used for an extended period, please turn off the robot to protect
the battery. Please recharge the robot once a month to maintain the battery.
OPERATION

Wi-Fi mode:
Use your thumb to press and hold the power button, while the index finger presses against
the anti-collision strip of the machine. When you hear the voice of “Di”, release the button
and the blue light on the panel will begin blinking. The robot will enter into Wi-Fi mode.
Note
•If you lift the robot up 10cm or higher when it is cleaning, the planned path will
be deleted.
•The remote control directional buttons will have no effect when the robot has
entered into planned cleaning mode. The directional buttons can be used
when the robot is in standby mode or on the charging dock.
