USER GUIDE
AMOLED DISPLAY
SMART WATCH
(KAM1ALEDWCA & KAM2ALEDWCA)

2
CONTENTS
Safety and warnings ............................03
Components..........................................04
Product overview...................................05
Getting started..............................06 - 07
Functions ....................................... 08 - 09
Using the app ................................... 10 - 11
Sports Mode..................................... 12 - 13
Customise ........................................ 14 - 15
Specifications.......................................... 16
Troubleshooting.......................................17
THIS USER GUIDE COVERS THE FOLLOWING MODELS
Kogan M1 AMOLED Display Smart Watch (KAM1ALEDWCA)
Kogan M2 AMOLED Display Smart Watch (KAM2ALEDWCA)

3
SAFETY AND WARNINGS
Thank you for buying this Kogan product. Please read all safety instructions before using
your smart watch.
Battery Warning
Do not disassemble, bore or damage the battery. Do not disassemble the built-in batteries
of non-replaceable battery devices. Do not use sharp objects to remove the battery.
Cycling Warning
Please always maintain good judgment and ride in a safe manner. Make sure your bike and
hardware are properly maintained and all components are properly installed.
Attention
• The watch’s data needs to be synced at least once every 5-7 days to avoid data loss.
• The device is IP68 dust and water resistant, supporting cold water showers and freshwater
swimming, but not diving.
• The watch has no waterproof resistance from seawater/saltwater, acidic and alkaline
solutions, chemical reagents and other corrosive liquids. The damage or defects caused by
misuse or improper use are not covered by the warranty.
• Avoid wearing the watch too tight in daily use. Please keep the parts of the watch touching
the skin dry.
• When your heart rate is measured, keep your arm still during the test.
WARNING
• Contact your physician before beginning any exercise regime, especially if you have any
blood disease or circulation disorder. The measurement results of this product are for
reference only and are not intended for any medical use or basis.
• If you are wearing a pacemaker or other implanted electronic devices, please consult
your doctor before using the heart rate monitoring strap.
• The watch’s optical heart rate sensor glows green and flashes. If you suer from epilepsy
or are sensitive to blinking light sources, please consult your physician if you can wear
this smartwatch.
• The device tracks your daily activities through sensors. This data is intended to tell you
about your daily activities, such as steps, sleep, distance, heart rate and calories, but
may not be completely accurate.
• The device, accessories, heart rate sensors and other relevant data are designed
for entertainment and fitness, not for medical purposes. They are not applicable to
the diagnosis, monitoring, treatment or prevention of any diseases or symptoms.
The heart rate data is for reference only. The manufacturer is not responsible for any
consequences caused by any data deviation.
Handle with care and inspect regularly to ensure product is in good working order.
If this product, power supply cord or plug shows any signs of damage: Stop use, unplug
the product and contact Kogan.com support.

4
COMPONENTS
A Kogan AMOLED Display Smart Watch
B Magnetic Charger (with USB cable)
NOT INCLUDED
iOS or Android smartphone; additional wrist straps.
A B

5
PRODUCT OVERVIEW
M1 model
M2 model
M1 model
1 AMOLED touchscreen display
2 Sports mode button
3 Power button
4 Function button
5 Quick-release wrist band
6 Heart rate sensor
7 Magnetic charge point
M2 model
1 AMOLED touchscreen display
2 Power button
3 Quick-release wrist band
4 Heart rate sensor
5 Magnetic charge point
5
7
6
3
5
4
1
4
2
3
12

6
GETTING STARTED
1. Charge the watch
a. Plug in charger
Insert the magnetic charger’s USB cable into
any 5V/1A USB outlet. If you have a laptop or
phone charger, this will work.
b. Attach device
Place the magnetic charger on the underside
of the watch, aligning the charger’s two metal
pins with the two metal circles on the watch.
When contact is made, the device will begin
charging, as identified by the onscreen icon.
2. Download the app
Using the Google Play Store (Android) or App
Store (iOS), download and install the Connect
Gear app. Upon opening the app, you will be
asked to grant user permissions for the tasks
the smart watch can perform, such as making
phone calls and SMS messages, and accessing
location information.
Charging icon

7
3. Pairing phone
a. Turn Bluetooth on
Ensure Bluetooth is enabled
on your smartphone.
b. Connect in app
In the Connect Gear app,
open the Navigation menu
and select Device. Select
your model from the list
and follow the prompts to
connect.
4. Syncing device
When you are connected, the sync icon will
display blue (lower right corner). Tap this icon
to update your data and sync between your
smartphone and the device.
Your device is now ready for use!
NOTE
Do not switch o Bluetooth notifications or close the app’s background activity, as this
will aect data synchronisation.
Default M2 dialDefault M1 dial

8
FUNCTIONS
Swipe to the left
to view the full
list of functions
Swipe to the right
to select alternative
dials. More dials can
be downloaded on the
Connect Gear app.
Swipe up from home
to view quick settings
options.
1. System
2. Always on display
3. Find phone
4. Power off
5. Timer mode
2
5
1
43
Swipe down to see quick info
from your connected functions,
such as messages, steps and
heart rate.
Enable always on display
To enable the always-on 24-hour
digital display, swipe up from
the home screen and select the
clock icon from the quick settings
options. Confirm with the green
tick, or cancel with the red x.

9
Functions/Modes
Sports Data
Display daily totals of the user’s number of steps, walking distance and
calories burned. The data resets at midnight daily. Tap motion data
display to switch to the step counter interface.
Heart Rate
Measure the user’s heart rate. Aer the test is measurement is taken,
the watch will vibrate and the result will be displayed. Heart rate
measurement begins automatically when the interface is entered.
Message
When connected via Bluetooth, push notifications from your phone will
be sent to your watch.
Sleep
Display the user’s sleep time from the previous night (from 21:30 to 12:00
the following day). Open the interface to view the sleep time of the
previous night.
Weather
Displays local weather when connected.
Sports Mode
When in sports mode interface, you can log sports data for such
activities as walking, running, hiking and biking.
Timer
Tap to start timing and to pause/resume. Swipe back to return to the
home page.
Brightness
Adjust display brightness.
Find Phone
When you connect your phone, this option will make your phone vibrate
and ring.
System
View the Bluetooth name, version and other information.
Power O
Tap to turn the watch o.

10
USING THE APP
1 Navigation sidebar
Tap to open the sidebar for connectivity,
account and other settings.
2 Motion record
Tap to begin logging an exercise
activity’s GPS data in conjunction with
the watch’s sports mode.
3 Weather
This is the current weather forecast for
your area.
4 My Sport Data
On the home screen this has a readout
of your steps and other fitness activity
for today. Tap for more detail. By
default, you will see walking statistics,
but tap the ‘+’ to add hiking, cycling,
swimming or other exercise categories.
5 Weekly Workouts
Tap here to setup and manage your
weekly sport targets. You can select
from recommended settings, or create
your own weekly exercise plan.
6 Activity Hours
Tap to view your activity history. Set
active hours and isolate your stats to
just these times.
7 Heart Rate
See your average heart rate on the
homescreen, and tap to view your day-
to-day history (with highest and lowest
heart rates) or monitor your current
resting heart rate.
8 Sleep Monitor
Tap to view your daily sleep data and
keep track of your sleep depth.
9 Sync App
This icon will display blue when
connected to your smartphone, or red
when disconnected. Tap here when
blue to sync your data between the
device and your phone.
4
1
5
3
2
6
9
7
8

11
Heart Rate stats Device optionsNavigation sidebar
Navigating the app
All adjustable settings can be located from the navigation sidebar, such
as downloadable dials, units of measurement, and an extensive FAQ.
Device options
When connected, select the device from the navigation sidebar to view
the device options. Here you will see the following items:
• Photo switch: Take photos on
your smartphone with the shake
of a wrist.
• Alarm setting: Set alarms on
the watch. These will remain
separate from your phone’s
alarms.
• Sedentary alert: Set reminders
when user is inactive (sitting,
watching TV), reminding the user
to take breaks or stretch.
• Drinking water alert: Set
reminders for regular hydration.
• Turn wrist light: Wake up the
screen and your wrist is lifted/
turned towards your. (Note, this
will not work if Always On Display
is enabled).
• Left hand or right hand: Set
which side you wear the watch
on.
• Message push: Control message
notification options. Select from
multiple apps to decide which will
appear on the device.
• Unpair: Disconnect your
smartphone from the device.

12
Sports data can be logged
when using the Connect
Gear app with the watch.
To successfully log the data,
you must begin your activity
with both the app and your
watch simultaneously.
Beginning activity
From the Connect Gear
app’s homepage, open the
Motion record page. From
here you will be able to
review previous data (from
both phone and watch)
and start a new session by
pressing ‘Start’.
This will take you to a list of available activities
(walking, running, biking, etc). Press ‘Start’ again
when you have selected your desired activity.
On the following screen, you will be instructed to
begin Sports Mode on your watch. Do not press
‘Start’ on the phone screen until this is complete.
Ensure your watch’s Sports Mode is set for the
same activity as the phone for correct data, and
then select ‘Start’ on the phone app. You will have
a 3 second countdown on the phone to ensure you
begin the watch task at the same time.
Completing activity
When finished, ensure you end the activity on both
your watch and the Connect Gear app. Your data
will now be viewable within the app, and can be shared with other
services (such as Strava and Google Fit) if you desire.
SPORTS MODE Motion record

13
Tap the share button (top
right) to export your data to
Strava or Google Fit.
Authorise Strava app
For Strava use, select the
Strava option from the
Navigation sidebar and log
into your account. If you do
not yet have an account,
you can set one up for free
at Strava.com
Once you have logged
into your account via the
Connect Gear app, you will
be asked to authorise the
app to upload your data.
When this is complete, you
will be able to export your
data simply by selecting
‘Strava’ from the share
options in each activity’s log.
The above activity as it appears in Strava
Authorise Strava for use via the Connect Gear app
Completed activity as it appears in Connect Gear

14
CUSTOMISE
M1 model options
M2 model options
Changing face dials
You can quickly change the clockface by simply swiping right from the
homescreen of the watch. When you would like to set the screen, wait
on the clockface until the green “tick” icon appears. This will confirm
that the new dial has been selected.
Downloading from app
More dials can be accessed via the Connect Gear
app, selecting Personalise Dials in the Navigation
sidebar. Select a dial and it will transfer to your
watch. When the transfer is complete, your watch
will update and it will be selectable in the same
method described above. The new face will have
replaced the final dial from the default set; there will
always be a total of 5 options to select from.

15
NOTE
Additional straps are sold separately,
not supplied with this watch.
Removing straps
Each strap is fitted with an easy
quick-release latch to make removing
easy and convenient. Simply pull the
latch back to detach the strap from
the watch. You will need to repeat this
step for both straps to remove one
strap pair.
Attaching straps
To attach a strap, simply repeat the same removal steps – pulling the
latch back to allow the strap clearance into the watch’s lugs. Once in
position, replace the latch back to its fully extended position, locking it
in place.
Additional straps are sold separately.
release latch

16
SPECIFICATIONS
Note:
• Design and specifications are subject to change without notice.
• Weight and dimension shown are approximate.
Connectivity
Bluetooth 5.0
Dimensions
Dimensions 245 x 45 x 10mm
Weight 0.055kg
Display
Resolution 360 x 360
Screen Size 1.3”
General
Strap material Leather + TPU
Water Resistant IP68
Memory
RAM Size 128KB
ROM Size 128MB
Performance
CPU RTL8762C
Power
Battery Capacity 310mAh

17
BASIC TROUBLESHOOTING
App cannot detect the watch
• Ensure Connect Gear is updated to
the latest version.
• Close all programs/apps in running
in the background, restart the
Bluetooth and then attempt again.
• Confirm that the mobile phone
operating system meets Android 4.4
or iOS 8.0 or above.
The watch receives no alerts, text
messages or phone calls
• You need to turn on the smart
reminder function and the call
reminder switch in the app and sync
to the watch.
• The iPhone needs to be paired with
the watch via Bluetooth. (Please
check “Syncing Data” for details).
• You need to keep your watch
connected to Bluetooth.
• App notifications in your mobile’s
settings should be turned on.
Bluetooth is often disconnected
• If the distance between the watch
and the mobile phone is too far,
Bluetooth connection stability will
be weakened.
• If there is an obstruction between
the watch and the mobile phone
(ie, the human body, wearing metal
jewellery) this will interfere with the
Bluetooth connection signal.
• Check whether the Bluetooth
function of the mobile phone is
abnormal.
Data backup
• The data of the watch should be
synchronised at least once every 7
days to the mobile phone.
How to restart or unpair device
• Shutdown operation: Select shut
down ( ) from quick settings or
functions menus, and confirm
selection. Alternatively, hold down
power button for 5 seconds.
• Unpair device: Within the Connect
Gear app, select Navigation >
Device > Unpair.
Do I need to keep my Bluetooth on
when I wear my watch?
• For some functions (counting steps,
sleeping), you do not need to keep
the watch connected constantly.
If you only need to wear a watch
when you exercise, you can connect
the watch and your smartphone to
view the data via syncing after the
exercise.
• For the functions of call alert,
message alert and find phone, you
need to turn on the smartphone’s
Bluetooth and maintain the
connection with the smartphone.
For more troubleshooting advice,
head online to help.kogan.com
© Copyright 2019, Kogan.com – KAM1ALEDWCA, KAM2ALEDWCA UM 12-19
