Kohler K-1106 User manual

Installation Guide
ProFlex™ Series Bath Whirlpool
K-1106, K-1106-H, K-1126,
K-1126-H, K-1131, K-1131-H,
K-1139, K-1139-H, K-1144,
K-1144-H, K-1146, K-1146-H,
K-1148, K-1148-H, K-1154-CC,
K-1154, K-1154-H, K-1154-HC,
K-1157, K-1157-H, K-1192,
K-1192-H, K-1194, K-1194-H,
K-1196, K-1196-H, K-1198,
K-1198-H, K-1201, K-1201-H,
K-1209, K-1209-H, K-1221,
K-1221-H, K-1224, K-1224-H,
K-1226, K-1226-H, K-12441B,
K-1244, K-1246, K-1246-H,
K-1231, K-1231-H, K-1239,
K-1239-H, K-1244-H, K-1248,
K-1248-H, K-1257, K-1257-H,
K-1263, K-1263-H, K-1266,
K-1266-H, K-1337, K-1337-H,
K-1458, K-1458-H
Mproduct numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de Mcorresponden a México
(Ej. K-12345M)
Français, page “Français-1”
Español, página “Español-1”
1010564-2-B

Important Information
WARNING: When using electrical products, basic precautions should always be followed, including
the following:
DANGER: Risk of electric shock. Connect only to a circuit protected by a Ground-Fault
Circuit-Interrupter (GFCI).
Building materials and wiring should be routed away from the pump body and other heat-producing
components of the unit.
Install to permit access for servicing.
Grounding is required. The unit should be installed by a qualified service representative, and grounded.
WARNING: Risk of electric shock. A licensed electrician should make all electrical connections.
WARNING: Risk of electric shock. Disconnect power before servicing.
WARNING: Risk of injury or property damage. Please read all instructions thoroughly before
beginning installation, including the following requirements.
NOTICE: Follow all local plumbing and electrical codes.
Product Information
Electrical Requirements
The installation must have a Class A Ground-Fault Circuit-Interrupter (GFCI). The GFCI protects against
line-to-ground shock hazard. Use a 120 V, 15 A, 60 Hz dedicated service for the whirlpool.
“H” models require a separate 120 V, 15 A, 60 Hz dedicated service for the in-line heater.
Product Notices
WARNING: Unauthorized modification may cause unsafe operation and poor performance of the
whirlpool. Do not relocate the whirlpool pump, or make other modifications to the whirlpool system,
as this could adversely affect the performance and safe operation of the whirlpool. Kohler Co. shall not
be liable under its warranty or otherwise for personal injury or damage caused by any such
unauthorized modification.
Factory-Assembled Features
Factory installed components include pump with power supply cord and air switch transmitter. No
installation is needed.
“H” models are also supplied with a factory assembled, in-line heater.
An optional timer kit is available for this product.
The whirlpool pump and piping are factory-assembled.
Connections and Service Access
Before installation, ensure proper access to the final connections.
1010564-2-B 2 Kohler Co.

Product Information (cont.)
NOTICE: Provide unrestricted service access to the pump. You must provide access for servicing the
pump and controls. The access must be located immediately next to the pump. Study the roughing-in
information packed with the whirlpool.
Table of Contents
Important Information .............................................................. 2
Product Information ............................................................... 2
Electrical Requirements .......................................................... 2
Product Notices ................................................................ 2
Factory-Assembled Features ...................................................... 2
Connections and Service Access ................................................... 2
Thank You For Choosing Kohler Company .............................................. 4
Tools and Materials ............................................................... 4
Before You Begin ................................................................. 4
Prepare the Site ................................................................. 5
Prepare the Whirlpool ............................................................. 5
Secure the Unit — Models With Support Blocks .......................................... 6
Option Using a Cement or Mortar Bed ............................................... 6
Option Using Construction Adhesive ................................................. 6
Option Using Silicone Sealant ..................................................... 7
Secure the Unit — Models With Whirlpool Base .......................................... 8
Option Using a Cement or Mortar Bed ............................................... 8
Option Using Construction Adhesive ................................................. 8
Option Using Silicone Sealant ..................................................... 8
Cut the Pump Banding Straps — Models With Support Blocks ............................... 9
Install the Plumbing ............................................................... 9
Install a Rim-Mounted Faucet ....................................................... 10
Make Electrical Connections ........................................................ 11
Pump Wiring ................................................................. 11
In-Line Heater Wiring ........................................................... 11
Test Run the Whirlpool ............................................................ 11
Complete the Finished Deck ........................................................ 12
Clean-Up After Installation ......................................................... 12
Confirm Proper Operation .......................................................... 13
Fill the Whirlpool .............................................................. 13
Operating Sequence ........................................................... 13
Troubleshooting Procedure ......................................................... 14
Remove the Factory Installed Jets ................................................. 14
Reinstall the Jets .............................................................. 14
Troubleshooting Guide .......................................................... 14
Kohler Co. 3 1010564-2-B

Thank You For Choosing Kohler Company
We appreciate your commitment to Kohler quality. Please take a few minutes to review this manual before
you start your installation. If you encounter any installation or performance problems, please don’t hesitate
to contact us. Our phone numbers and website are listed on the back cover. Thanks again for choosing
Kohler Company.
Tools and Materials
Before You Begin
CAUTION: Risk of product damage. Do not lift the whirlpool by the piping or pump, or use the
piping or pump for structural support of the whirlpool.
We recommend this whirlpool for drop-in installation.
Inspect the whirlpool for damage before you begin installation.
You must install this whirlpool to an adequately supported, level subfloor.
Confirm adequate mounting and connection space for the faucet specified for your installation.
Pencil
Safety Glasses Level
Silicone Sealant Measuring Tape
Pipe Wrench
Plus:
Conventional woodworking tools
and materials or conventional
bricklaying tools and materials
Drop cloth
Construction adhesive (optional)
Cement or mortar (optional)
2x4’s or 2x6’s
1010564-2-B 4 Kohler Co.

1. Prepare the Site
NOTICE: Unless otherwise specified, floor support under the whirlpool must provide for a minimum of
80 lbs./square foot (390 Kg./square meter) loading.
NOTICE: Do not support the whirlpool by the rim.
Make sure the flooring offers adequate support for your whirlpool, and verify that the subfloor is flat and
level.
The whirlpool should be installed in a drop-in installation. Construct 2x4 or 2x6 stud framing designed for
your particular installation. Provide for a 1/16” (2mm) gap between the bottom of the whirlpool rim and
the stud framing. Frame the floor, or construct a frame for a raised installation in accordance with the
roughing-in information packed with the whirlpool.
Carefully lay out and cut the rough deck material. Use the cut-out template if one is provided, or refer to
the roughing-in cut-out information.
Position the plumbing according to the roughing-in information packed. Cap the supplies, and check for
leaks.
2. Prepare the Whirlpool
Install the drain to the whirlpool according to the drain manufacturer’s instructions. Do not connect the
trap at this time.
Position a clean drop cloth or similar material in the bottom of the whirlpool. Be careful not to scratch the
surface of the whirlpool.
Position
the rough
plumbing
Frame the floor
according to the
roughing-in
information
Verify that the
subfloor offers
adequate support,
and is flat and level
Provide a 1/16"
(2mm) gap
between the
whirlpool rim
and framing.
Construct 2x4
or 2x6 stud
framing according
to the roughing-in
information
Kohler Co. 5 1010564-2-B

3. Secure the Unit — Models With Support Blocks
CAUTION: Risk of product damage. Do not lift the whirlpool by the piping or pump, or use the
piping or pump for structural support of the whirlpool.
CAUTION: Risk of product damage. Do not support the whirlpool by the rim.
Choose the installation option that best applies to your particular installation. Follow the appropriate
instructions.
If the subfloor is not level, shim the whirlpool support blocks as necessary.
Option Using a Cement or Mortar Bed
NOTE: Do not use gypsum cement or drywall compound for this application, as they will not provide an
acceptable, durable bond.
NOTE: The pump support bracket (when the pump banding straps are cut) and support blocks must
rest directly on the subfloor.
Spread a 2” (5cm) thick layer of cement or mortar on the subfloor where the whirlpool will be set. This
will help secure, level, and support the unit. Clear all the material away from the pump support bracket
and support block locations.
Position a piece of plastic drop cloth material on top of the cement or mortar bed. With help, carefully lift
the whirlpool into place, and make sure the pump support bracket and support blocks do not rest in the
bed material.
Insert the drain tailpiece into the trap. Make sure the whirlpool is level and resting on all support blocks.
Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant around
the entire rim of the whirlpool.
Option Using Construction Adhesive
Apply a generous amount of high-quality construction adhesive to the bottom of the support blocks. With
help, carefully lift the whirlpool into position.
Insert the drain tailpiece into the trap. Make sure the whirlpool is level and resting on all support blocks.
Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant around
the entire rim of the whirlpool.
Clear spaces
for support
blocks
Spread a 2" (5cm)
layer of cement or
mortar bed materia
l
Clear space
for pump
Apply a bead of
silicone sealant
around the entire
rim
Apply construction
adhesive to the
support blocks
or
1010564-2-B 6 Kohler Co.

Secure the Unit — Models With Support Blocks (cont.)
Option Using Silicone Sealant
With help, carefully lift the whirlpool into position.
Insert the drain tailpiece into the trap. Make sure the whirlpool is level and resting on all support blocks.
Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant around
the entire rim of the whirlpool.
Kohler Co. 7 1010564-2-B

4. Secure the Unit — Models With Whirlpool Base
CAUTION: Risk of product damage. Do not lift the whirlpool by the piping or pump, or use the
piping or pump for structural support of the whirlpool.
CAUTION: Risk of product damage. Do not support the whirlpool by the rim.
Choose the installation option that best applies to your particular installation. Follow the appropriate
instructions.
If the subfloor is not level, shim the whirlpool base as necessary.
Option Using a Cement or Mortar Bed
NOTE: Do not use gypsum cement or drywall compound for this application, as they will not provide an
acceptable, durable bond.
Spread a 2” (5cm) thick layer of cement or mortar on the subfloor where the whirlpool will be set. This
will help secure, level, and support the unit.
With help, carefully lift the whirlpool into place.
Insert the drain tailpiece into the trap. Make sure the whirlpool is level. Use screws or lag bolts to secure
the whirlpool base to the floor. Drill small pilot holes through the whirlpool base as needed.
Position a piece of plastic drop cloth material on top of the cement or mortar bed. With help, carefully lift
the whirlpool into place.
Apply a continuous bead of high-quality silicone sealant around the entire rim of the whirlpool.
Option Using Construction Adhesive
Apply a generous amount of high-quality construction adhesive to the bottom of the whirlpool base. With
help, carefully lift the whirlpool into position.
Insert the drain tailpiece into the trap. Make sure the whirlpool is level and resting on all support blocks.
Use screws or lag bolts to secure the whirlpool base to the floor. Drill small pilot holes through the
whirlpool base as needed.
Apply a continuous bead of high-quality silicone sealant around the entire rim of the whirlpool.
Option Using Silicone Sealant
With help, carefully lift the whirlpool into position.
Insert the drain tailpiece into the trap. Make sure the whirlpool is level. Use screws or lag bolts to secure
the whirlpool base to the floor. Drill small pilot holes through the whirlpool base as needed.
Apply a continuous bead of high-quality silicone sealant around the entire rim of the whirlpool.
Spread a 2"
(5cm) layer
of cement o
r
mortar bed
material
Apply a bead of
silicone sealant
around the entire
rim
or
Apply construction
1010564-2-B 8 Kohler Co.

5. Cut the Pump Banding Straps — Models With Support Blocks
NOTE: For models with a whirlpool base, proceed to the next section.
IMPORTANT! This step is necessary to make your Kohler whirlpool operate more quietly.
NOTE: Do not raise the pump higher than it was before you cut the pump banding straps. If the pump is
raised too high, it will not prime properly.
Use tin snips to cut the two pump banding straps. When the banding straps are cut, the pump support
bracket and pump will drop about 1/2” (1.3cm) until they rest on the subfloor. If the pump drops more
than 1/2” (1.3cm), shim under the pump support bracket so there is a 1/2” (1.3cm) gap between the pump
and bracket to allow for proper drainage.
To minimize whirlpool noise and vibration, be sure the pump is not in direct contact with the shipping
bracket after the pump banding straps are cut.
Secure the pump support bracket to the subfloor with screws or lag bolts (not provided).
6. Install the Plumbing
CAUTION: Risk of property damage. Ensure a watertight seal on the whirlpool drain.
Connect the drain to the trap according to the drain manufacturer’s instructions.
NOTICE: An access panel will simplify future maintenance.
Install the faucet valving according to the faucet manufacturer’s instructions. Do not install the faucet trim
until instructed. Open the hot and cold water supplies, and check the supply connections for leakage.
Run water into the whirlpool, and check the drain connections for leakage.
Kohler Co. 9 1010564-2-B

7. Install a Rim-Mounted Faucet
Measure and cut a piece of 1/2″exterior grade plywood 4″(10.2cm) x 11-1/2″(29.2cm) for the K-1226, or
4″(10.2cm) x 15-1/2″(39.4cm) for the K-1231.
The faucet should be located in the center of the flat area of the rim. Refer to the faucet manufacturer’s
instructions. Use a pencil to mark the faucet centerlines for drilling.
NOTE: The K-1226 will accept faucets with 4″centers, and the K-1231 will accept faucets with 4″or 6″
centers.
CAUTION: Risk of product damage. Position a thin piece of cardboard on the finished surface of the
whirlpool before clamping the plywood in place. Make sure the clamps do not make direct contact
with the finished surface of the whirlpool.
Set a thin piece of cardboard on the finished surface of the whirlpool rim. Position the plywood on the
bottom of the rim, and carefully clamp the plywood in place. Make sure the clamps are in contact with the
cardboard, not the finished surface of the whirlpool.
Carefully drill the faucet holes to the size required by the faucet manufacturer. Remove the clamps and
cardboard.
Install the faucet to the rim and plywood according to the faucet manufacturer’s instructions.
Open the hot and cold water supplies, and check the supply connections for leakage.
Run water into the whirlpool, and check the drain connections for leakage.
Measure, cut, and drill a piece o
f
1/2” exterior grade plywood 4”
(10.2cm) x 11-1/2” (29.2cm) for
the K-1226, or 4” (10.2cm) x
15-1/2” (39.4cm) for the K-1331
4” 4”
Whirlpool Rim
Install the faucet to the ri
m
and plywood according to
the faucet manufacturer’s
instructions
1010564-2-B 10 Kohler Co.

8. Make Electrical Connections
WARNING: Risk of electric shock. To reduce the risk of electrical shock, connect the pump and in-line
heater (if heater option included) to properly grounded, grounding-type receptacles protected by
Ground-Fault Circuit-Interrupters (GFCI’s). Do not remove the plugs’ grounding pins. Do not use
grounding adapters.
Pump Wiring
NOTE: The whirlpool model number is printed on a label near the whirlpool pump. This label also
identifies the electrical rating of the whirlpool.
Your Kohler whirlpool bath is equipped with a cord and plug. All wiring of the pump and control has
been completed at the factory. A licensed electrician must install a GFCI-protected, 120 V, 15 A, grounded
outlet. No other load should be on this circuit. Locate the outlet behind the whirlpool, and within 24”
(61cm) of the pump.
Plug the pump into this outlet.
NOTE: Make sure the air actuator tubing is securely attached to the pump, and is not kinked or damaged.
If a K-1639 Timer Kit will be used, install it now according to the instructions packed with the timer kit.
In-Line Heater Wiring
The in-line heater is equipped with a cord and plug. All wiring of the heater has been completed at the
factory. A licensed electrician must install a GFCI-protected, 120 V, 15 A, grounded outlet. No other load
should be on this circuit. Locate the outlet behind the whirlpool, and within 24” (61cm) of the heater.
Plug the in-line heater into this outlet.
9. Test Run the Whirlpool
Check all electrical connections, and make sure the electrical power to the whirlpool and in-line heater (if
equipped) is on.
Make sure all union connections to the pump and in-line heater (if if equipped) are securely hand
tightened.
Fill the whirlpool to a level at least 2” (5.1cm) above the top of the highest jet.
Verify that the pump banding straps have been cut (if applicable), and that the pump is resting directly on
the subfloor or whirlpool base.
Operate the whirlpool for 5 minutes, and check all whirlpool piping connections for leaks.
For additional information on whirlpool operation, refer to the “Confirm Proper Operation” section.
Make sure air actuator tubing is
securelyattachedtothepump
Plugthein-lineheater
intothis outlet.
Plugthe pump
intothis outlet
Install a GFCI-protected 120 V, 15 A grounded outlet. Install a
secondGFCI-protectedoutletfor H models for thein-lineheater.
Bondin accordance
withapplicablecodes
Kohler Co. 11 1010564-2-B

10. Complete the Finished Deck
If you have not already done so, carefully remove the protective tape from the whirlpool rim.
Cover the framing with water-resistant deck material. Seal the joints between the whirlpool rim edge and
the water-resistant deck material with silicone sealant.
Tape and mud the water-resistant deck material. Install the finished deck to the water-resistant deck
material. Seal the joints between the whirlpool rim and the finished deck material with silicone sealant.
Install the faucet trim according to the trim manufacturer’s instructions.
11. Clean-Up After Installation
When cleaning up after installation, do not use abrasive cleansers, as they may scratch and dull the
whirlpool surface. Use warm water and a liquid detergent to clean the surface.
Remove stubborn stains, paint, or tar with turpentine or paint thinner. Do not allow cleaners containing
petroleum distillates to remain in contact with any whirlpool surfaces for long periods of time. Remove
plaster by carefully scraping with a wood edge. Do not use metal scrapers, wire brushes, or other metal
tools. Use a powder-type detergent on a damp cloth to provide mild abrasive action to any residual
plaster.
Whirlpool
Framing
Water-Resistant
Deck Material
Finished
Deck
Material
Apply silicone sealant to the edges
of the water-resistant deck material
and the finished deck
1010564-2-B 12 Kohler Co.

12. Confirm Proper Operation
Fill the Whirlpool
NOTE: Please read these steps carefully before you operate your whirlpool.
Position the jet nozzles so they face down toward the basin. Turn the jet trim rings fully counterclockwise.
Fill the whirlpool to a water level at least 2” (5.1cm) above the top of the highest jet.
NOTE: The water temperature in the whirlpool should not exceed 104° F (40° C).
Operating Sequence
Press the air actuator to turn on the whirlpool jets.
Adjust each jet for optimum air/water mixture. Turn the trim ring clockwise to reduce the air flow, and
counterclockwise to increase the air flow.
If equipped with an in-line heater, the heater will engage automatically when the pump is turned on and
will disengage when the pump is turned off. The heater will not turn on if the water temperature exceeds
104° F (40° C).
Press the air actuator a second time to turn off the whirlpool.
NOTE: The optional K-1639 Timer Kit automatically stops the whirlpool after approximately 20 minutes of
operation.
Fill with water 2" (5cm)
above the highest jet
Turn the jet trim
ring clockwise to
decrease the flow Position the jet
nozzles to direct
the water flow as
desired
Turn the jet trim ring
counterclockwise to
increase the flow
Press the air actuator to turn on and
off the whirlpool
Kohler Co. 13 1010564-2-B

13. Troubleshooting Procedure
Remove the Factory Installed Jets
NOTE: A special tool is provided with the replacement jets that will allow you to remove the jets from the
whirlpool. This tool is also supplied with each trim kit.
Position the jet ball nozzle so it is pointing upward.
NOTE: The nozzle must remain pointed up or the tool will slip off.
Insert the removal tool, hooked end up, into the opening of the jet and hook the inside top of the nozzle.
Grasp the tool firmly and place your thumb against the whirlpool wall. Pull steadily on the tool until the
jet assembly pulls free of the hole. Be careful not to lose the O-ring.
Reinstall the Jets
NOTE: The jet O-ring must be correctly positioned, must be lubricated, and must be in good condition to
permit easy rotation and proper operation of the jet.
Install the O-ring onto the first shoulder of the jet. Lubricate the O-ring with silicone lubricant to prevent
noisy operation of the jet.
Carefully insert the jet into the housing, and lightly push and rotate the jet until it snaps into position. Do
not force the jet.
NOTE: When installed correctly, the jet should turn smoothly both clockwise and counterclockwise.
Troubleshooting Guide
This troubleshooting guide is for general aid only. A Kohler Authorized Service Representative or qualified
electrician should correct any electrical problems. For warranty service, contact your dealer or wholesale
distributor.
Symptoms Probable Causes Recommended Action
1. Whirlpool does not start or
stop. A. No power to motor. A. Set/reset GFCI breaker; check wiring.
B. Air actuator does not work. B. Replace air actuator.
C. Air actuator tubing is
disconnected, loose, kinked,
plugged, or damages.
C. Connect, straighten, clean, or
replace air actuator tubing.
Remove the Jets
Insert the tool hook as shown and pull the jet out of the
housing. The jet should be facing up when this is done. Housing
Re-install the Jets
Slide the O-ring
onto the first
shoulder of the jet
Inspect and
lubricate th
e
O-ring
Insert the jet into the housing, and lightly
push and rotate until it snaps in position
1010564-2-B 14 Kohler Co.

Troubleshooting Procedure (cont.)
Symptoms Probable Causes Recommended Action
D. Motor/pump does not work. D. Rebuild or replace
motor/pump.
2. Motor starts, not all jets are
functioning. A. Jet is closed. A. Rotate jet trim ring counterclockwise to open.
B. Jet not installed correctly. B. Reinstall jet; check for O-ring
damage.
C. Jets are blocked. C. Remove blockage.
3. Whirlpool stops
automatically before 18
minutes.
A. GFCI trips. A. Identify source of fault, and
correct.
B. Suction blocked. B. Remove obstruction.
C. Jets are blocked. C. Remove blockage.
D. Motor overheated and
protection device activated. D. Check for blockage at motor vents. Remove blockage and
allow motor to cool.
Check for suction blockage.
Remove blockage and allow
motor to cool.
Check for jet blockage.
Remove blockage and allow
motor to cool.
4. Pump does not prime.
(Models with support blocks
only.)
A. Pump shimmed too high. A. Lower pump support
bracket.
5. Noisy operation. A. Pump banding straps have
not been cut. (Models with
support blocks only.)
A. Cut pump banding straps
with tin snips.
B. Jet O-ring dislodged. B. Remove jet, replace and
lubricate O-ring, and reinstall
jet.
6. Heater does not operate.
(“H” models only) A. No power to heater. A. Reset GFCI.
B. Water temperature exceeds
104° F (40° C). B. Allow water to cool and heater will reengage.
C. Heater does not work. C. Replace heater.
Kohler Co. 15 1010564-2-B

Guide d’Installation
Série Proflex™ Baignoire d’hydromassage
Renseignements importants
AVERTISSEMENT : Des précautions de base seront observées pour l’installation d’équipements
électriques, incluant :
DANGER : Risque de secousse électrique. Raccorder uniquement à un prise à la terre, protégée par
un disjoncteur de fuite à la terre.
Les matériaux de construction et le câblage doivent être acheminés loins du corps de pompe et d’autres
composants conducteurs de chaleur de l’unité.
Installer de façon à permettre l’accès pour l’entretien.
Le disjoncteur differentiel est requis. L’unité doit être installée et mise à la terre par un électricien qualifié.
AVERTISSEMENT : Risque de secousse électrique. Tous les raccords électriques doivent être réalisés
par un électricien qualifié.
AVERTISSEMENT : Risque de secousse électrique. Débrancher l’alimentation avant de procéder à
l’entretien.
AVERTISSEMENT : Risque de blessures ou de dommages matériels. Veuillez lire avec attention cette
notice avant de commencer l’installation, incluant :
AVIS : Respecter tous les codes de plomberie et de bâtiment locaux.
Renseignements du produit
Branchement électrique requis
Raccorder uniquement à un prise à la terre, protégée par un disjoncteur de fuite à la terre. Le GFCI préviens
la possibilité d’un choc électrique. Raccorder la baignoire d’hydromassage à une alimentation indépendante
de 120 V, 15 A, 60 Hz.
Les modèles “H” nécessitent d’une alimentation indépendante de 120 V, 15 A, 60 Hz pour le chauffe-eau en
ligne.
Directives d’utilisation du produit
AVERTISSEMENT : Des modifications non approuvées pourraient provoquer un fonctionnement
dangereux ou un mauvais rendement de la baignoire d’hydromassage. Ne pas relocaliser les pompes
d’hydromassage ou effectuer d’autres modifications au système d’hydromassage car il pourrait en
résulter une dégradation du rendement de la baignoire d’hydromassage ou cela pourrait affecter son
fonctionnement sécuritaire. La société Kohler décline toute responsabilité quant à toute blessure ou
endommagement causés par des modifications non autorisées.
Pièces assemblées à l’usine
Les composants installés à l’usine comprennent la pompe avec câble d’alimentation électrique et
l’interrupteur à l’air. D’autres installations ne seront pas nécessaires.
Kohler Co. Français-1 1010564-2-A

Renseignements du produit (cont.)
Les modèles “H” comprennent aussi le chauffe-eau en ligne, assemblé à l’usine.
Le jeu de relais est disponible en option pour ce produit.
La pompe et la tuyauterie de la baignoire d’hydromassage ont été assemblées à l’usine.
Raccordement et Entretien
Avant l’installation, assurez-vous d’avoir suffisamment d’accès pour les raccords finaux.
AVIS : Faire en sorte qu’il soit possible d’avoir accès aux pompes en tout temps. Prévoir suffisamment
d’accès pour l’entretien futur de la pompe et des commandes. La panneau d’accès doit être placé tout près
de la pompe. Consulter le diagramme de raccordement qui accompagne le produit.
Sommaire
Renseignements importants ......................................................... 1
Renseignements du produit ......................................................... 1
Branchement électrique requis ..................................................... 1
Directives d’utilisation du produit .................................................... 1
Pièces assemblées à l’usine ....................................................... 1
Raccordement et Entretien ........................................................ 2
Merci d’avoir opté pour les produits de la Société Kohler .................................... 3
Outils et matériaux ................................................................ 3
Avant de commencer .............................................................. 3
Préparer le site .................................................................. 4
Préparer la baignoire d’hydromassage ................................................. 4
Assujettir l’unité — Modèles avec blocs de support ........................................ 5
Option pour utilisation de lit de ciment ou de mortier ..................................... 5
Option pour l’utilisation de mastic adhésif de construction ................................. 5
Option d’utilisation de mastic d’échantéité à la silicone ................................... 6
Assujettir l’unité — Modèles avec base de baignoire ....................................... 7
Option pour utilisation de lit de ciment ou de mortier ..................................... 7
Option pour l’utilisation de mastic adhésif de construction ................................. 7
Option d’utilisation de mastic d’échantéité à la silicone ................................... 7
Couper les sangles de la pompe — Modèles avec blocs de renfort ............................ 8
Installer la plomberie .............................................................. 8
Installer un robinet sur plan ......................................................... 9
Faire le raccordement électrique ..................................................... 10
Cablâge de pompe ............................................................. 10
Cablâge de chauffe-eau en ligne .................................................. 10
Faire un essai de fonctionnement de la baignoire d’hydromassage ........................... 10
Compléter le plan fini ............................................................. 12
Nettoyage après l’installation ....................................................... 12
Vérifier le fonctionnement approprié .................................................. 13
Remplir la baignoire d’hydromassage ............................................... 13
Séquence de fonctionnement ..................................................... 13
Procedures de dépannage ......................................................... 14
Retirer les gicleurs installés à l’usine ............................................... 14
Réinstaller les gicleurs .......................................................... 14
Tableau de dépannage .......................................................... 14
Kohler Co. Français-2 1010564-2-A

Merci d’avoir opté pour les produits de la Société Kohler
Nous apprécions votre engagement envers la qualité de Kohler. Veuillez lire attentivement ce guide avant de
commencer l’installation. En cas de problèmes d’installation ou de fonctionnement, n’hesitez pas à nous
contacter. Nos numéros de téléphone et site web sont contenues au plat verso. Merci encore d’avoir choisi
des produits Kohler.
Outils et matériaux
Avant de commencer
ATTENTION : Risque d’endommagement du produit. Ne pas soulever la baignoire par la tuyauterie
ou par la pompe. Ne pas utiliser la tuyauterie ou la pompe pour supporter l’unité.
Nous conseillons une installation surbaissée pour cette baignoire.
Avant l’installation, examiner la baignoire pour déceler tout dommage.
Cette baignoire d’hydromassage doit avoir le support nécessaire sur un sous-plancher de niveau.
S’assurer que l’espace de montage et de raccordement soit suffisant pour l’installation du robinet.
1010564-2-A Français-3 Kohler Co.

1. Préparer le site
AVIS : Le support de plancher sous la baignoire doit pouvoir soutenir une charge minimale de 80 lbs. / pi
carré (390 Kg/m
2 ).
AVIS : Ne pas appuyer la bagnoire sur le rebord.
S’assurer que le plancher constitue un support adéquat pour votre baignoire d’hydromassage et que le
sous-plancher soit plat et de niveau.
Cette baignoire d’hydromassage devrait être installée dans un espace surbaissé. Construire une ossature en
montants de 2x4 ou de 2x6 pour votre installation. Laisser un dégagement de 1/16 po (2 mm) entre la
base du rebord de la baignoire d’hydromassage et l’ossature. Préparer le plancher ou construire une
ossature pour une installation sur podium, selon le diagramme de raccordement.
Disposer et couper soigneusement les matériaux de base du plan de baignoire. Employer le gabarit inclus
ou se reporter à l’information du diagramme de raccordement.
Déterminer l’emplacement de la plomberie, selon le diagramme de raccordement. Fermer les robinets
d’arrêt et vérifier s’il y a des fuites.
2. Préparer la baignoire d’hydromassage
Installer le vidage à la baignoire d’hydromassage selon la notice du fabricant qui accompagne le produit.
Ne pas brancher le siphon à ce moment.
Placer un linge ou matière similaire à la base de la baignoire. Travaillez soigneusement pour ne pas
égratigner la surface de la baignoire d’hydromassage.
Kohler Co. Français-4 1010564-2-A

3. Assujettir l’unité — Modèles avec blocs de support
ATTENTION : Risque d’endommagement du produit. Ne pas soulever la baignoire par la tuyauterie
ou par la pompe. Ne pas utiliser la tuyauterie ou la pompe pour supporter l’unité.
ATTENTION : Risque d’endommagement du produit. Ne pas appuyer la bagnoire sur le rebord.
Choisissez l’option qui mieux correspond à votre installation. Suivez les instructions correspondantes.
Si le sous-plancher n’est pas de niveau, placer des blocs de renfort sous la baignoire au besoin.
Option pour utilisation de lit de ciment ou de mortier
REMARQUE : Ne pas utiliser de plâtre dur ou de pâte à jointoyer pour ce type d’installation car ces
produits ne procurent pas le scellement requis.
REMARQUE : Le support de pompe (une fois les sangles de retenue coupées) et les blocs de support
doivent être appuyés directement sur le sous-plancher.
Étendre une couche de ciment ou mortier de 2 po (5 cm) d’épaisseur sur le plancher à l’endroit
d’installation de la baignoire. Ceci pour assujettir, mettre de niveau et supporter l’unité. Enlever tout
matériau se trouvant au support de la pompe ou à l’emplacement des blocs de support.
Déposer une bâche de plastique sur le lit de ciment ou de mortier. Demander de l’aide pour soulever et
installer soigneusement la baignoire en place et s’assurer que le support de pompe et les blocs de support
ne soient pas appuyés contre le matériau de l’embase.
Introduire l’about dans le siphon. S’assurer que l’unité soit de niveau et qu’elle s’appuie sur les blocs de
renfort.
Enlever la pellicule protectrice du rebord. Appliquer du mastic à la silicone autour du rebord de la
baignoire d’hydromassage.
Option pour l’utilisation de mastic adhésif de construction
Appliquer du mastic adhésif de construction à la base des blocs de renfort. Avec de l’aide, positionner la
baignoire d’hydromassage.
Introduire l’about dans le siphon. S’assurer que l’unité soit de niveau et qu’elle s’appuie sur les blocs de
renfort.
Enlever la pellicule protectrice du rebord. Appliquer du mastic à la silicone autour du rebord de la
baignoire d’hydromassage.
1010564-2-A Français-5 Kohler Co.
