INSTALLATION INSTRUCTIONS
1287417-2A-B 1
TAUT
TAUT
SERVICE PARTS
1287417-2A-B 4
**Color code must be specified when ordering.
**For all Asia Pacific regions (excluding China) add SP in front of code number to SPxxxxxxx** when ordering.
73193T-4CD Recessed Shower Valve-Cold Water Only73193T-4CD Recessed Shower Valve-Cold Water Only
Ø 49
120
7
50-80
13
G1/2"
Max 86
Finished Wall
120
79
139
G1/2"
BEFORE YOU BEGIN
ROUGH-IN DIMENSIONS
*Dimensions are approximate.
*Unit: mm
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions with the customer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
3. Observe local plumbing codes.
4. Shut off the water supply to the fitting.
5. Recommended water pressure 1-5 bar.
6. Refer to product specification sheet for flow curve. If flow is less than stated, inspect system for other
restrictions such as flow controller, instantaneous hot water heater, clogged supply line, etc.
1217139**
1217879
1217135
1167323**
834792
1186138
1061576
1285196**
833438
3008523
833730

1287417-2A-B 21287417-2A-B 3
INSTALLATION
CLEANING INSTRUCTIONS
INSTALLATION CHECKOUT
Ensure that all connections are tightened and the handle is in the off position.
Turn on main water supply and check for leaks. Repair as required.
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc, which could
adversely affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
Determine where the valve body will be located on the wall. Make a suitable hole
in the wall.
Install the anchors (1). Be sure the “UP” marking on the valve body (2) is facing
upward. Wrap the threads on the inlet and outlet with tape at least 4 layers.
Connect outlet pipe and inlet pipe to valve body. Tighten screws (3) to secure the
valve body.
NOTE: Do not remove the valve guard before complete the finished wall.
Remove the valve guard. Assemble escutcheon (4) onto the valve (5) and position
in correct orientation against the wall. Remove gasket film by pulling the tab.
Install the handle (6). Tighten the setscrew (7) with hex wrench (8). Press plug
button (9) to the hole.
5
4
6
7
8
9
3
12
