Kohler 97345IN-4 Series User manual

INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
1 1246092-IN2-A 4
AVID
97345IN-4-**
Kohler India Corporation Pvt. Ltd.
6th Floor. Office Block, Ambience Island, NH-8
IN
Gurgaon - 122002, Haryana, India
Customer Care No : 1800 103 2244
(Toll Free) & [phone] / 86
Customer Care Email : [e-mail]
www.kohler.co.in
Bar
P
°C
T
0.5 < 3 < 5.5
22
CLEANING INSTRUCTION
SERVICEABLE PARTS
TOOLS REQUIRED
SINGLE HANDLE LAVATORY FAUCET
.
reserves the right to make changes in product characteristics, packaging, or
availability at any time without notice.
1. Flush the water supply pipes thoroughly to remove debris.
2. Inspect the supply tubing for damage. Replace as necessary
3. Observe local plumbing codes.
4. Check for leaks before covering the pipes, repairs as needed.
NOTES:
All information is based on the latest product information available at the time of publication.
Kohler Co.
< 65
97347IN-4-** TALL SINGLE HANDLE LAVATORY FAUCET
**Color code must be specified when ordering.NOTE:
3022101**
3006148
833730
1149430-A**
1249005
1244428**
1240864
1080817
834704
1228834
1231664
1219254
1241808**
1231664
880008**
1080817
880406
834753**
880037
1205262
1205261
Please leave these instructions for the consumer. They contain important information.
97347IN-4-** 97345IN-4-**
1246092-IN2-A

97345IN-4-**
ROUGH IN DIMENSIONS
2
INSTALLATION INSTRUCTIONS
3
INSTALLATION INSTRUCTIONS
13
2
AVID
22
130
Ø68
Ø38
Ø43
66
27
Ø58
Ø36.5
Ø31.75
97.5 110
135
176.5
467
89
138
Ø32~Ø38
45 Max.
Ø51
173
148
3.5°
G1/2˝
402
204
253
Ø32~Ø38
45 Max.
Ø51
173
148
3.5°
G1/2˝
97347IN-4-**
1246092-IN2-A 1246092-IN2-A
