Kohler Co. 1 1194814-X2-A
BEFORE YOU BEGIN 
TOOLS 
ROUGH-IN 
Observe all local plumbing and building codes.
Prior to installation, unpack the new lavatory and inspect
it for damage. Return the lavatory to its protective carton
until you are ready to install it.
The walls and floor must be square, plumb, and level.
All information in these instructions is based upon
the latest product information available at the time of
publication. Kohler Co. reserves the right to make
changes in product characteristics, packaging, or
availability at anytime without notice.
Dimensions are approximate.
Unit: mm


*Kohler reserves the right to change marked dimensions without prior notice.

K-2749X-1 K-2749X-8
Install for the K-45764X** Aleutian/Forefront Cabinet.
สําหรับติดตั้งรวมกับ K-45764X**
ตูเฟอรนิเจอร รุนอลูเชียน/ฟอรฟรอนท
Ø44
280
900
90
330
100 195
520
102 102
90
45
102 102
Ø35
Ø35
345 345
102 102
1/2" Cold/นํ�าเย็น
Anchor Holes/รูพุกยึดอ่างล้างหน้า
Ø10
1/2" Hot/นํ�าร้อน
1/2" Cold/
นํ�าเย็น
1/2" Hot/นํ�าร้อน
OD/
เส้นผ่าศูนย์กลาง 1-1/2"
OD/เส้นผ่าศูนย์กลาง 1-1/2"



 

 
 

 
INSTALLATION AND CARE GUIDE
ขอแนะนําการติดตั้งและการดูแลรักษา
FOREFRONT VANITY LAVATORY

K-2749X
1194814-X2-A 2 Kohler Co.
INSTALLATION 
280
Anchor/พุก
Bolt/
โบลท์
Anchor Holes
รูพุกยึดอ่างล้างหน้า
Ø
10
Install the faucet and drain to the lavatory according to
the manufacture's instructions.
Apply silicone sealant to the joint between the lavatory
and the wall.
Carefully position the lavatory on the hanger bolts.
Install flange nut, washer, and nut on the bolts.
Ensure that the lavatory is level. Carefully tighten the
nuts until the lavatory is secure to the wall.
CAUTION: Risk of product damage. Do not
overtighten the wood screw. Overtightening may
cause damage the product.

 




 
  

  
Install the Lavatory
NOTE: The lavatory must be installed on a cabinet.
Please refer to Installation and User Guide packed with
the cabinet for installation details.
Install the water supplies and drain piping according to
the roughing-in information.
Locate and mark the two anchor holes according to the
roughing-in diagram.
Drill Ø10 mm anchor holes at the marked location.

Mount hanger bolts to the wall so approximately 65-75mm
of each bolt remain exposed.

 



 


 
Flange Nut
นอตพลาสติก
Nut
นอต
Washer
แหวนรอง
Silicone Sealant
ซิลิโคน
Kohler Co. 3 1194814-X2-A
CARE AND CLEANING 
Carefully read the cleaner product label to ensure the
cleaner is safe for use on the material.
Always test your cleaning solution on an inconspicuous
area before applying to the entire surface.
Wipe surfaces clean and rinse completely with water
immediately after cleaner application. Rinse and dry
any overspray that lands on nearby surfaces.
Do not allow cleaners to sit or soak on the surface.
Use a soft, dampened sponge or cloth. Never use an
abrasive material such as a brush or scouring pad to
clean surfaces.
Be careful not to leave staining materials in contact
with the surface for extended periods of time.
The ideal cleaner technique is to rinse thoroughly and
blot dry any water from the surface after each use.
 
 

 

  
 
  
 

 
 
Install the Plumbing
Install the drain in accordance with the manufacturer' s
instructions.
NOTICE:
Make sure a watertight seal existing on all
washbasin drain connections.
NOTE: Provide access to the plumbing connections for
future plumbing maintenance.
Connect the hot and cold water supplies.
Open the hot and cold water valves, and check the
supply connections for leaks.
Run water into the lavatory, and check for leaks.

   
  
 


 


 

