Kohler K-3482K-NS Assembly instructions

Installation and Care Guide
Two Piece Toilet


1042176-X2-D ©2012 Kohler Co.
K-3482K-NS, K-3482VN, K-4447K,
K-4605X, K-4609K-WA, K-4609X,
K-4419X, K-11458X, K-11460X,
K-11468X, K-11472X, K-12698X
K-72635X

1042176-X2-D 2 Kohler Co.

Thank You For Choosing Kohler Company
Thank you for choosing Kohler. Kohler crasmanship oers you a rare
combination of proven performance and graceful sophistication that will
satisfy you for years to come. The dependability and beauty of your Kohler
product will surpass your highest expectations. We’re very proud of our
products here at Kohler and we know you will be too.
Please take a few minutes to review this manual before you start installation. If
you encounter any installation or performance problems, please don’t hesitate
to contact us. Our phone numbers and website are listed on back cover.
All information in this manual is based upon the latest product information
available at the time of publication. At Kohler, we constantly strive to improve
the quality of our products. We reserve the right to make changes in product
characteristics, packaging or availability at any time without notice.
Thank you for choosing Kohler Company.
  
 
 
 
 

  

  


 

Kohler Co. 3 1042176-X2-D
Before You Begin

Important Information
IMPORTANT NOTICE TO INSTALLERS!: Please leave these instructions for
the consumer. They contain important information.
In addition to installation procedures, this manual contains important care and
cleaning. Please retain for future reference.
NOTE: Some installation parts might not be provided.
NOTE: The toilet pictured in the installation steps may dier from the model
being installed.
 
 

 
 

CAUTION: Risk of personal injury or product damage. Handle with
care. Product can break, chip, or cause injury if handled carelessly.
¨ Observe all local plumbing and building codes.
¨ Prior to installation, unpack the new product and inspect it for damage.
Return the product to its protective carton until you are ready to install it.
¨ Failure to follow these precautions may result in a poor installation.
¨ If the existing toilet does not have a supply shut-o valve below the tank,
install one before installing the new toilet.
¨ Fixture dimensions are nominal and conform to tolerances established by
Standards ASME A112.19.2 and TIS.
CAUTION: Risk of property or product damage. Turn on the water
and allow water to ow through the supply pipe to ush the system of
any debris before connecting ll valve.
CAUTION: Risk of hazardous gases. If the new toilet is not installed
immediately, temporarily place a rag in the closet ange.

1042176-X2-D 4 Kohler Co.

Tools/
1/2"



¨ 
¨ 

¨ 
¨ 

¨ 

 

 



Kohler Co. 5 1042176-X2-D
Installation/
7
ไมเกิน 6 มม
กรณีเปลี่ยนสุขภัณฑใหม,
ใหนำอุปกรณชุดเกาออก ทีโบลท
ประเก็น
พุก ประเก็นยาง
วางสุขภัณฑอยางระมัดระวัง
หามเคลื่อนยาย
หลังจากติดตั้งแลว!
ประเก็นยางอาจเคลื่อนได
อยาขันแนนจนเกินไป!
ตัดสวนที่เกินออก
วางดานนี้ขึ้น
ไมเกิน 6 มม
Rubber Gasket
If replacing a toilet,
remove the old component.
1 3
64
2
5/16"
Tee Bolts
Gasket
Anchor
Do not move after
placement! Watertight
seal may be broken!
Apply weight evenly.
6 mm Max
6 mm Max
Do not overtighten!
อยาขันแนนจนเกินไป!
Do not overtighten!
5
This side up.
Cut excess.
98
ขันโบลทใหแนน ปรับขันโบลท
เพื่อปรับระดับ
ถังพักนํ้า
Adjust the tank
bolts to level
the tank.
Tighten the tank
bolts evenly.

1042176-X2-D 6 Kohler Co.
Installation/
Adapter
15/16"
to1/2"
(Optional
Part)
CAUTION:
Turn on the water
and allow water
to flow through the supply pip e
to flush the system of any debris
befor connecting fill valve.
ขอควรระวัง: เปดนํ้าเพื่อ
ทำความสะอาดและขจัดเศษตางๆ
ออกจากทอนํ้าดีกอนประกอบกับ
วาลวนํ้าเขา
11
13
10
12
Turn here to adjust the water level.
Flush several times and check for leaks.
Do not overtighten!
Install the tank lid
and the seat.
+
-
หมุนทีี่นี่เพื่อปรับระดับนํ้า
ติดตั้งฝาปดถังพักนํ้า
และที่รองนั่งสุขภัณฑ
กดชักโครกหลายๆ ครั้ง เพื่อตรวจสอบการรั่วซึม
อยาขันแนนจนเกินไป!
Waterline
ระดับน้ำ

Kohler Co. 7 1042176-X2-D
Care and Cleaning
For best results, keep the following in mind when caring for your product:
• Carefully read the cleaner product label to ensure the cleaner is safe for use
on the material.
• Always test your cleaning solution on an inconspicuous area before applying
to the entire surface.
• Wipe surfaces clean and rinse completely with water immediately aer
cleaner application. Rinse and dry any overspray that lands on nearby
surfaces.
• Do not allow cleaners to sit or soak on the surface.
• Use a so, dampened sponge or cloth. Never use an abrasive material such as
a brush or scouring pad to clean surfaces.
• Be careful not to leave staining materials in contact with the surface for
extended periods of time.
• The ideal cleaning technique is to rinse thoroughly and blot dry any water
from the surface aer each use.
WARNING: Risk of property or product damage. Do not use in-tank
cleaners in your toilet. Products containing chlorine (calcium hypochlorite)
can seriously damage ings in the tank. This damage can cause leakage
and property damage.

1042176-X2-D 8 Kohler Co.





 

• 

• 

• 

• 
• 

• 
• 
 

Kohler Co. 9 1042176-X2-D
Troubleshooting
Symptoms Recommended Action
1. Poor ush. A. Adjust the tank water level to match the waterline.
B. Fully open the water supply shut-o valve.
C. Clear obstructions from the trapway, jet, or bowl rim
holes.
D. Clear obstructions from the waste line.
2. No ush. A. Reconnect the apper chain to the trip lever or ush
valve.
B. Adjust the apper chain assembly to remove
excessive slack.
3. The ll valve
turns on/o by
itself without
the toilet being
ushed, or it
runs, allowing
water to enter
the tank.
A. Adjust the apper chain for proper slack so the
apper closes.
B. Clean or replace the apper if it is worn, dirty, or
misaligned with the opening.
C. Clean the area around the opening to allow the
apper to seal.
D. Adjust the tank water level if it is too high.
E. Replace the ll valve if the valve oat sinks.
F. Adjust the tank water level if it is too high.
4. Tank takes
excessive time
to ll.
A. Fully open the water supply shut-o valve.
B. Check the exible supply line (if applicable) for
a kink. Remove the kink.
C. Clean the valve inlet, valve head, or supply line.
Flush the lines.
5.
There is excessive
noise when the
tank is lling.
A. Partially close the water supply shut-o valve if the
waterpressure to the toilet is too high. Check the
toilet performance following any such adjustment.
B. Remove dirt or obstructions from the valve head.
Flush the lines.
6. Trip arm strikes
tank lid underside.
A. Adjust ush ball chain assembly to remove excessive
slack.
B. Adjust trip arm bracket and ange so they are parallel
with tank top.
