KOMFI-RIDER Aerolite PLUS User manual

Aerolite Plus/Super Mobility Scooter User Manual
1 | P a g e
1.
INTRODUCTION……………………………………………………………. 2
2.
SAFETY NOTICE………………………………………………….. 3 - 5
2.1 Safety Precautions
2.2 Before driving
2.3 While driving
2.4 Labeling
3.
EMI …………………………………………………………………... 6 - 7
4.
PARTS INTRODUCTION………………………………………. 8
Parts description
5.
OPERATION……………………………………………………….. 9 - 14
5.1 How to operate your scooter
5.2 How to set to freewheel mode
6.
CHARGING AND THE BATTERY PACK………………………………….. 15
6.1 Charging the battery
6.2 Charger
6.3 Battery
7.
INSPECTION AND MAINTENANCE……………………… 16 - 17
7.1 Daily checking
7.2 Regular checking record
7.3 Circuit Breaker
7.4 Tyres
7.5 Maintenance
8.
BASIC TROUBLESHOOTING……………………………….. 18 - 19
9.
SPECIFICATION………………………………………………….. 20 - 21
10.
WARRANTY……………………………………………………….. 22 - 25
10.1Three-year limited warranty
10.2 One-year limited warranty
10.3 Batteries 6 month warranty
10.4.Warranty exclusions
10.5 Service checks and warranty service
10.6 Notice to consumer
TABLE OF CONTENTS

Aerolite Plus/Super Mobility Scooter User Manual
2 | P a g e
INTRODUCTION
Congratulations on the purchase of your new Aerolite Mobility Scooter! The advanced light-weight design of the
Aerolite with its superb leg room and streamline design ensures many years of enhanced trouble-free mobility.
Correct use improves your mobility and quality of life.
Your safety is important to us.
Please read this owner’s manual before using the scooter. Improper use of the scooter could result in harm, injury
or traffic accidents. Correct use improves your mobility and quality of life.
This owner’s manual includes operation instructions for every aspect of the scooter.
The symbols used in this manual are explained below. Read carefully, especially the parts marked with these
symbols:
Warning
Improper usage could lead to death or serious injury
Caution
Improper usage could lead to injury and/or damage to your scooter.
Suggestion
Follow these instructions to keep the status of the scooter working well and ease your
operation.
Please read and follow all instructions in this manual before operating your scooter. Complete understanding of
these operating instructions, prior to driving your scooter, is essential for your safety and enjoyment.
No liability can be taken by us for personal injury or damage to property arising from the failure of any person
and/or user of this scooter to follow the instructions and recommendations either contained in this manual, in
other scooter-related literature issued by the manufacturer; or displayed on the scooter itself.
This Owner’s Manual was compiled from the latest specifications and product information pertaining at the time
of publication. We reserve the right to make such changes as become necessary. Changes to our products may
cause slight variances between illustrations and explanations shown in this manual, to the product purchased by
you.
If you feel incapable of safely following the instructions and or recommendations contained in this manual, or
experience any problems with your scooter which you are unable to resolve, please contact your authorized dealer
for assistance.
Feedback
With our ongoing product development, we appreciate your feedback with any questions, comments or
suggestions. Please contact us through www.onerehab.co.uk

Aerolite Plus/Super Mobility Scooter User Manual
3 | P a g e
SAFETY
2.1 SAFETY PRECAUTIONS
■Lock your seat into place and remove the key before you get on or off your scooter.
■Lock the seat into position before you operate your scooter.
■Do not operate your scooter with the seat in the reclined position (if so equipped).
■Do not operate your scooter if you are taking medication which may impair your ability to operate your
scooter in a safe manner.
■Do not drive your scooter across the side of an incline or diagonally up or down an incline; avoid stopping
whilst driving on inclines.
■Keep both hands on the tiller and your feet on the floorboard at all times while operating your scooter. This
driving position gives you the most control over your vehicle.
■Proceed with extreme caution when driving near raised surfaces or unprotected ledges or drop-offs (kerbs,
porches, stairs, etc.)
■Drive slowly when turning.
■Secure the batteries before loading your scooter into another vehicle for transport.
■Disconnect the batteries if you are not going to operate your scooter for more than 48 hours.
■Do not operate or store your scooter where it may be exposed to inclement weather conditions such as rain,
snow, mist, and below-freezing temperatures. Attempting to operate your Scooter in such conditions may
damage the electronics and potentially result in loss of control.
■Always protect batteries from freezing temperatures and never charge a frozen battery. This damages the
battery and may cause personal injury. Attempting to charge a battery in freezing conditions does not prevent
a battery from freezing.
■Do not expose the electronics to any type of moisture at any time. Such exposure may damage the
electronics. Never attempt to ride a scooter that has been exposed to moisture until it has dried thoroughly.
■Never sit on your scooter when it is being used with any type of lift/elevation product. Your scooter was not
designed with such use in mind, and any damage or injury incurred from such use is not the responsibility of
the manufacturer.
2.2 BEFORE DRIVING
The user needs to be familiar with the operation of this scooter before driving the scooter.
1. Ride on the pavement, park way or pedestrian areas only.
2. Be aware of the cars on the road at all times.
3. Be extremely cautious when driving your scooter in crowded areas, such as shopping centers or
near busy roads.
4. Do not drive your scooter after drinking alcohol or feeling tired.

Aerolite Plus/Super Mobility Scooter User Manual
4 | P a g e
Practice operating your scooter
Until you are familiar with the operation of your scooter, please practice in a wide and open area like a park. To
prevent the possibility of falling off your scooter while driving, bear in mind the status of the driving motion, such
as accelerating, stopping, turning, reversing, up-and-down ramps etc.
Please set the speed dial to the lowest speed initially until competent.
The scooter is limited to one passenger
Do not carry any passengers on your scooter. (Including children and pets)
Do not use this scooter to carry or transport goods
The maximum weight to be carried is (includes goods) 250 lbs.
Maximum loading weight for the basket is 6 lbs.
2.3 WHILE DRIVING
Please carry out daily inspections. Refer to page 15 of “DAILY CHECKING”.
Mobile Phones and other electrical equipment.
Do not use a mobile phone or other wireless communication device while driving.
Do not charge a mobile phone or other electrical devices from your scooter.
Ramps, incline and drops
Be careful while driving up a steep ramp. Refer to pages 20 & 21 “MAX CLIMBING ANGLE” in the SPECIFICATION
table.
When climbing up an inclined road please drive slowly. When going down a steep incline never reverse your
scooter, you should set the speed dial to the lowest speed setting. Avoid potholes in the pavement. Refer to
pages 20 & 21 “GROUND CLEARANCE”.
Do not pass through water crossing the pavement, unless the water is less than 1” deep. Please drive slowly
when driving on roads with drops or dips. Do not make sudden turns while driving on gravel roads or ramps.
Suggestion
When approaching Drop-Offs, such as kerbs, please make sure that the speed control
is set a minimum and that the scooter is driven carefully and slowly to ensure no
damage is done to the anti-tip wheels at the rear of the scooter.
WARNING!
Do not set the scooter in freewheel mode when driving on an incline or decline.

Aerolite Plus/Super Mobility Scooter User Manual
5 | P a g e
Maximum User Weight Limit
Refer to pages 21 & 22 “WEIGHT CAPACITY”. Overloading your scooter will invalidate your warranty and
could cause your scooter to malfunction.
2.4 LABELING
Please read all the labeling on the scooter before driving it. For your future reference, do not remove them.
WARNING!
※Do not operate the scooter unless the tiller (handlebar column) is up, the teeth in the tiller adjustment bolt fit
together and the bolt is fully tightened.
※Do not lean against or pull forward on the handle bar while mounting or dismounting from the scooter. Serious
harm or injury may occur.
※The manufacturer disclaims all responsibilities for any personal injury or property damage which may occur as
a result of importer unsafe use of its products.

Aerolite Plus/Super Mobility Scooter User Manual
6 | P a g e
EMI
This portion of the content will provide the user with basic information about the problems with EMI
(electromagnetic interference), protective measures can be used to either lessen the possibility of exposure or to
minimize the degree of exposure; this section also shows some conditions that unexpected or erratic movements
may cause.
Caution: It is very important that you read this information regarding the possible effects of
electromagnetic interference on your Scooter.
ELECTROMAGNETIC INTERFERENCE (EMI) FROM RADIO WAVE
SOURCES
Powered scooters may be susceptible to electromagnetic interference (EMI), which is interfering
electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM)
transmitters, two-way radios, and cellular phones. The interference (from radio wave sources) can cause the
powered scooter to release its brakes, move by itself, or move in unintended directions. It can also permanently
damage the powered scooter’s control system. The intensity of the interfering EM energy can be measured in
volts per meter (V/m). Each powered scooter can resist EMI up to a certain intensity level”. The higher the
immunity level the greater the protection. At this time, current technology is capable of achieving at least a
20 V/m immunity level, which would provide useful protection from the more common sources of radiated EMI.
This powered scooter model as shipped, with no further modification, has an immunity level of 20 V/m without
any accessories.
There are a number of sources of relatively intense electromagnetic fields in the everyday environment. Some of
these sources are obvious and easy to avoid. Others are not apparent and exposure is unavoidable. However, we
believe that by following the warning listed below, your risk to EMI will be minimized.
The sources of radiated EMI can be broadly classified into three types:
1. Hand-held portable transceivers ( transmitter-receivers with the antenna mounted directly on the
transmitting unit). Examples include: citizens band (CB) or hand held radios,(security, fire, and police transceivers),
cellular telephones and other personal communication devices.
2. Medium-range mobile transceivers, such as those used in police cars, fire trucks, ambulances and taxis
usually have the antenna mounted on the outside of the scooter.
3. Long-range transmitters and transceivers, such as commercial broadcast transmitters (radio and TV
broadcast antenna towers) and amateur (HAM) radios.
NOTE: some cellular telephones transmit a signal while they are ON, even though they are not being used.

Aerolite Plus/Super Mobility Scooter User Manual
7 | P a g e
NOTE: Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV
sets, CD player, and cassette players, and small appliances, such as electric shavers and hair dryers, are
not likely to cause EMI problems to your powered scooter.
POWERED SCOOTER ELECTROMAGNETIC INTERFERENCE (EMI)
EM energy rapidly becomes more intense as one moves closer to a transmitting antenna (source). The EM fields
from hand-held radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high
levels of EM energy very close to the powered scooter’s control system while using these devices; this can affect
your scooters movement and braking. Therefore, the warnings listed below are recommended to prevent possible
interference with the control system of a powered scooter.
WARNING!
Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur radio (HAM)
transmitters, two-way radios, and cellular phones can affect motorized scooters. Following the warnings
listed below should reduce the chance of unintended brake release or powered scooter movement which
could result in serious injuries.
1. Do not operate hand-held transceivers-receivers, such as citizens band (CB) radios, or turn ON personal
communication devices, such as cellular phones, while the powered scooter is turned ON.
2. Be aware of nearby transmitters, such as radio or TV stations, and try to avoid getting close to them.
3. If unintended movement or brake release occurs, turn the powered scooter
OFF as soon as it is safe.
4. Be aware that adding accessories or components, or modifying the powered scooter, may make it more
susceptible to EMI.
5. Report all incidents of unintended movement or brake release to your scooter dealer, and note whether
there were sources of EMI nearby.
IMPORTANT INFORMATION
20 Volts per meter (V/m) is generally a useful immunity level against EMI (the higher the level, the greater the
protection). This product has an immunity level of 20 V/m without any accessories connected to it.

Aerolite Plus/Super Mobility Scooter User Manual
8 | P a g e
PARTS DESCRIPTION: AEROLITE PLUS/SUPER
1. Control panel 10. Horn button
2. Basket 11. Throttle lever
3. Tiller adjustment bolt 12. Speed dial
4. Carrying handle 13. Diagnostic light
5. Removable flip-up arm rest 14. Battery gauge
6. Detachable swivel seat with fold-down back 15. Charger socket
7. Connecting device 16. Anti-tip wheels
8. Battery pack 17. Freewheel mode lever
9. Key switch
16
8
17
15
1
6
5
2
3
7
4
8
9
14
11
12
10
13

Aerolite Plus/Super Mobility Scooter User Manual
9 | P a g e
OPERATION
5.1 HOW TO OPERATE YOUR SCOOTER
Power switch
Turn the Key to power ON or OFF
｢ON｣：Power is turned on
｢OFF｣：Power is turned off
Forward, Reverse and Braking
1. Pull the throttle lever towards you with your right first finger and the scooter will move forward.
2. Pull the throttle lever towards you with your left first finger and the scooter will move backward.
3. The horn will beep when the scooter is in reverse.
4. When you release the throttle lever while in either forward or reverse direction, the electromagnetic
brake in the motor will be activated and the scooter will stop.
Horn Button
The warning horn will be activated when you push the button, release the button the horn will stop.
Braking
Electro-magnetic brake: Release the throttle lever completely; the electro-magnetic brake will be activated.
WARNING!
When going down an incline, NEVER set to the freewheel mode. When in freewheel mode, the
electromagnetic brake will not function.
Seat
The seat can be turned 90 degrees. Pull swivel seat lever to rotate the seat. The seat has 4 height
adjustments. After adjusting the height to the desired seat position, secure the fixed nut.
CAUTION!
Be sure the seat is in the forward position and locked before driving.
Parts

Aerolite Plus/Super Mobility Scooter User Manual
10 | P a g e
You can disassemble the scooter into five pieces: the seat, the front section, the basket, the battery pack,
and the rear section.
1. Place the scooter in an area where you have sufficient clearance to move the parts around. You may need
assistance to lift some of the scooter components.
2. See “Specifications” for individual component weights.
3. No tools are required to disassemble or assemble your scooter. Always disassemble or assemble your
scooter on a level, dry surface with sufficient space for you to work and move around your scooter. Keep
in mind that the disassembled sections of the scooter take up more floor space than the assembled scooter.
CAUTION!
Lifting weight beyond your physical capability may result in personal injury.
Ask for assistance when necessary while disassembling or assembling your scooter.

Aerolite Plus/Super Mobility Scooter User Manual
11 | P a g e
To Disassemble:
1. Turn key switch to “OFF”.
2. Place the free wheel mode lever in the drive position.
3. Pull upward on the swivel-release lever to remove the seat from the seat post. Remove the plug of power
cable from the battery pack. (See the Fig. 5.1.1)
4. Pick up the battery pack and remove it from the scooter. (See the Fig. 5.1.2)
5. Pull the connecting device upward and the front section will be apart from the rear section. (See the Fig. 5.1.3)
Fig. 5.1.1 Fig. 5.1.2
Fig. 5.1.3

Aerolite Plus/Super Mobility Scooter User Manual
12 | P a g e
ASSEMBLY Note: Raise the tiller before reassembling the scooter.
1. Place the freewheel mode lever in the drive position.
2. Connect the front and rear sections by aligning them and gently lifting the front section and the rear section.
(See Fig 5.1.6)
3. Make sure the connecting device is connected securely to the bracket of rear section.
4. Place the battery pack on the scooter and insert the power cable into battery charger socket.
5. Set down the seat on the seat post –Always hold the seat lever upwards otherwise this can cause the seat
to become stuck onto the seat post.
6. Turn the key switch to “ON”.
Caution
Turn off all power to your scooter and remove the key prior to disassembly.
Ensure the front and rear sections are connected together securely before driving.
Battery gauge
When the key is switched “ON”, the battery gauge will display the battery power capacity by indicating red,
yellow and green areas respectively.
Green area indicates a full charge from the battery. Red area indicates low power.
The remaining power indicated by the battery gauge will be varied by the actual driving
time and how you drive. Repeated starting, stopping or climbing will consume the
power more quickly.
Fig 5.1.6

Aerolite Plus/Super Mobility Scooter User Manual
13 | P a g e
SUGGESTION
1. It is recommended that you charge the battery immediately when the battery gauge is in the red area.
2. In the wintertime, the battery may respond more slowly and the distance you can travel per charge may
also be shortened.
3. When driving on an incline, the battery gauge light might move from green to red, this is a normal
phenomenon, please do not worry.
4. Even if the battery is used properly, it is natural that the battery capability will decay as time passes, which
results in a shortening of travel distance compared to a brand new battery. Therefore, when the travel
distance is reduced to 50% it is time for a replacement battery. Please go to your Scooter dealer and
purchase replacement batteries. If you continue to use the old battery when its lifetime is ending, it could
lead to a decrease in travel distance.
Travel distances will be shortened when driving frequently on an incline or slope, as this leads to a larger
consumption of the power.
5.2 HOW TO SET THE FREE WHEEL MODE
Drive Mode (Fig 5.2.1): Push the free wheel mode lever on the scooter toward the rear direction, and the scooter

Aerolite Plus/Super Mobility Scooter User Manual
14 | P a g e
will be driven by the motor.
Free wheel Mode (Fig 5.2.2): Push the free wheel mode lever on the scooter forward and the scooter can
be pushed by hand.
Fig 5.2.1 Drive Mode Fig 5.2.2 Freewheel Mode
Tiller Adjustment
The Tiller can be adjusted by the following steps.
1. Pull the fold clasp upward, and release it
2. Then pull outward the clasp, fold the tiller (Fig 5.2.3)
Fig 5.2.3
Stopping
1. Release the throttle lever completely and the scooter will naturally brake and stop.
2. Turn the key switch to「OFF」. Then pull out the key (only after stopping).
Caution!
The stopping distance will vary with your forward / reverse speed, please begin braking as early as
possible.

Aerolite Plus/Super Mobility Scooter User Manual
15 | P a g e
CHARGING AND THE BATTERY PACK
6.1 CHARGING THE BATTERY
Be sure to follow the procedures shown below accordingly.
1. Turn the scooter key to ”OFF”.
2. Connect the charger cord to the power outlet.
3. Open the charging socket cap on the scooter’s cover then
connect the charger’s plug to the charging socket.
4. The charger’s LED light will be orange at the beginning of
a charge. The charging duration is at least 8-12 hours
- this will vary based on the status of the battery and temperature.
5. The orange LED will turn to green when charging is complete.
6. Disconnect the cord and remove the round plug from the charge socket.
SUGGESTION
1. Do not disconnect the charger cord if the charging is not complete. The battery life will be shortened if the
battery is repeatedly used without being fully charged.
2. If your scooter is left untouched for a long period of time, it should be charged at least every 2 weeks to
keep the battery at full status.
3. Charging time will be affected by the ambient temperature so it takes longer in the wintertime.
6.2 CHARGER
The charger’s red LED will be ON when you plug it into the power outlet. The orange LED will change to
green when the charging is complete.
6.3 BATTERY
BATTERY SPECIFICATIONS for AEROLITE PLUS/SUPER
Type
Deep-cycle (Sealed Lead Acid Battery)
Size
151 x 64 x 116 mm (L x W x H) –12Ah Other Amperage may vary.
Voltage
12 V
Amperage
12 Ah / 18Ah / 21Ah
Do not expose the battery to temperatures below -10 ℃or above 50 ℃. The battery used on your scooter
is sealed lead acid, which is maintenance free.

Aerolite Plus/Super Mobility Scooter User Manual
16 | P a g e
INSPECTION AND MAINTENANCE
7.1 DAILY CHECKING
Check the following items before driving. If you find anything abnormal, contact your scooter dealer for a further
inspection before using it.
Item
Inspection Content
Handle bar
Is it tight?
Can they be turned left or right smoothly?
Speed Dial
Can it be adjusted freely and function well?
Throttle Lever
Does the scooter move when the lever is engaged?
Does the scooter stop when the lever is released completely?
Motor
Is there any abnormal noise from the motor?
Does the electromagnetic brake work properly?
Battery Gauge
Does the gauge move to green when switched “ON”?
Is the remaining power enough for your trip?
Horn Button
Does the horn work?
Seat
Is the seat on properly?
7.2 REGULAR CHECKING RECORD
To make sure your scooter is in good condition, go to your Scooter dealer regularly.

Aerolite Plus/Super Mobility Scooter User Manual
17 | P a g e
7.3 CIRCUIT BREAKER
Circuit Breaker
There is one button for the circuit breaker (located on the Battery pack), if the power switch is “ON” and the
battery gauge does not move, it is possible an electric current has overloaded the scooter, Reset the circuit
breaker by pressing the button.
7.4 TYRES
Tyres
The condition of the tyres depends on how you drive and use your scooter.
Inspecting Tyre Treads
Please check the tread depth regularly. Replace the tyres when the tread depth is less than 0.5 mm.
7.5 MAINTENANCE
1. Do not use water, oil or other chemical solutions to clean your scooter. Be sure NOT to spray the scooter
with the water as this can damage the electronic components. Please clean the scooter by wiping it
with either a dry or moist cloth.
2. Please take the scooter to authorized dealers for repairs and adjustments. Improper adjustments could
lead to accidents and scooter malfunction.

Aerolite Plus/Super Mobility Scooter User Manual
18 | P a g e
BASIC TROUBLESHOOTING
This table is only a guide to aid you in getting your scooter operating, should you have any problems. If you are
unable to get your scooter operating, please contact your Scooter Dealer.
Table1 Basic troubleshooting
Symptom
Possible
Solution
Scooter does not
move
1. Key switch is not “ON”
2. Main circuit breaker tripped
3. Brake release lever in ‘Freewheel
Mode’
4. Charger connected to outlet
5. Battery power low
6. Scooter shuts down to conserve battery
7. Controller error
1. Turn key switch to ”ON”
2. Reset circuit breaker
3. Place lever in ‘Drive Mode’
4. Disconnect charger
5. Recharge battery
6. Turn key switch “OFF”, then “ON”
7. Check diagnostic light for Flash Code(See Table 2
to get solution)
Range less than
expected
1. Charging too infrequently
2. Defective or worn out battery
3. Cold weather reduces battery life
4. Defective charger
1. Charge scooter more often
2. Load test batteries. If necessary replace.
3. Allow batteries to reach room temperature and
then fully recharge
4. Contact your Scooter Dealer
Brake squeals
1. Dirt in brake pad
1. Blow dirt out with air pressure hose
Brake release
lever sticks
1. Rust and corrosion
1. Spray ball detent area with lubrication oil.
Table 2 Scooter controller internal diagnostics

Aerolite Plus/Super Mobility Scooter User Manual
19 | P a g e
The diagnostic flash codes for your scooter are designed to help you perform basic troubleshooting quickly
and easily. A diagnostic flash code flashes from the diagnostic light in the event one of the conditions listed
below develops.
Flash code
Possible
Solution
1
The battery needs charging or there is a bad
connection to the battery.
Check the connections to the battery. If the
connections are good, try charging the battery.
2
There is a bad connection to the motor.
Check all connections between the motor and the
controller.
3
The motor has a short circuit to a battery
connection.
Please contact your Authorized Service Center.
4
The Controller is overloaded
Stop scooter, switch off and allow to cool, before
continuing.
5
Not available
6
The controller is being inhibited from driving.
Check the battery charger connector.
Remove the battery charger from the scooter.
7
A speed control lever fault is indicated.
Make sure that the speed control lever is in the
rest position before switching on the scooter.
8
A controller fault is indicated.
Make sure that all connections are secure.
9
The parking brake has a bad connection.
Check the parking brake and motor connections.
Make sure the controller connections are secure.
10
Excessive voltage has been applied to the
controller.
Check the battery connections. This is usually
caused by a poor battery connection.
