KOMFI-RIDER Phoenix User manual

MOBILITY SCOOTER USER
MANUAL

Congratulations on the purchase of your new Phoenix Mobility Scooter! The
advanced design of the Phoenix ensures many years of enhanced trouble-free
mobility. Correct use improves your mobility and quality of life.
Your safety is important to us.
Please read this owner’s manual before using the scooter. Improper use of the
scooter could result in harm, injury or trac accidents. Correct use improves your
mobility and quality of life.
This owner’s manual includes operation instructions for every aspect of the scooter.
Contents
1.0 SAFETY GUIDELINES 3
2.0 PRE RIDE SAFETY CHECK 4
3.0 SPECIFICATION 5
4.0 COMPONENTS OF THE SCOOTER 6
5.0 OPERATION - CONTROL PANEL 7-9
6.0 OPERATION - BEFORE GETTING ON YOUR SCOOTER 10-11
7.0 OPERATION - GETTING ON YOUR SCOOTER 12-15
8.0 OPERATION - DRIVING YOUR SCOOTER 16-17
9.0 OPERATION - GETTING OFF YOUR SCOOTER 18
10.0 OPERATION - BATTERIES AND CHARGING 18-20
11.0 EMI 20-21
12.0 DAILY CHECKING 23
13.0 MAINTENANCE & STORAGE 24
14.0 BASIC TROUBLESHOOTING 24
15.0 FLASH CODES 25
16.0 WARRANTY 26-27
2 KOMFI-RIDER

WARNING! An authorized Provider or qualified technician must perform the
initial setup of this scooter and must perform all of the procedures
in this manual.
1.0 SAFETY GUIDELINES
The symbols below are used throughout this owner's manual and on the scooter to identify
warnings and important information. It is very important for you to read them and
understand them completely.
WARNING! Indicates a hazardous situation that could result in serious injury or
death if it is not avoided.
CAUTION! Indicates a hazardous situation that could result in minor or slight
injury if it is not avoided.
IMPORTANT! Indicates a hazardous situation that could result in damage to
property if it is not avoided.
USEFUL TIP! Recommendations and information for ecient, trouble-free use.
Your scooter is a state-of-the-art life-enhancement device designed to increase mobility.
We provide an extensive variety of products to best fit the individual needs of the scooter
user. Please be aware that the final selection and purchasing decision regarding the type of
scooter to be used is the responsibility of the scooter user who is capable of making such a
decision and his/her health care professional (i.e., medical doctor, physical therapist, etc.).
The contents of this manual are based on the expectation that a mobility device expert has
properly fitted the scooter to the user and has assisted the prescribing health care
professional and/or the authorized provider in the instruction process for the use of the
product.
There are certain situations, including some medical conditions, where the scooter user will
need to practice operating the scooter in the presence of a trained attendant. A trained
attendant can be defined as a family member or care professional specially trained in
assisting a scooter user in various daily living activities.
As you begin using your scooter during daily activities you will probably encounter situations
in which you will need some practice. Simply take your time and you will soon be in full and
confident control when using the scooter.
Additional general information can be found on the supplemental information sheets and
booklets included in your Owner’s Package. Please fully read and review the information and
keep it readily available for future reference.
KOMFI-RIDER 3

2.0 PRE-RIDE SAFETY CHECKS
Get to know the feel of your scooter and its capabilities. We recommend that you perform
a safety check before each use to make sure your scooter operates smoothly and safely.
Perform the following inspections prior to using your Travel Scooter:
■ Check the condition of the tyres. Make sure they are not damaged or excessively worn.
■ Check all electrical connections. Make sure they are tight and not corroded.
■ Check the battery condition meter to ensure the batteries are fully charged.
■ Ensure the manual freewheel lever is in drive mode before sitting on the Travel Scooter.
If you discover a problem, contact your authorized Provider for assistance. Please refer to
the Contact Information insert in your Owner’s Package.
WARNING! This complete user manual should be read and fully understood
before using and driving the scooter.
WARNING! Never exceed the maximum permissible load – see 3.0 Specifications
and never use the scooter to transport more than one person.
WARNING! Never drive the scooter under the influence of medication or alcohol.
WARNING! Never attempt to get onto or o your scooter without first removing
the key from the key switch. This will prevent the scooter from moving if
accidental throttle control lever contact is made.
WARNING! This scooter is not intended for use as a seat in a motor
vehicle. The scooter could fail in a vehicle impact, leading to serious
injury or death of the occupant or injury to others.
4 KOMFI-RIDER

3.0 SPECIFICATION
Model Reference Phoenix
Speed (Max) 8 mph
Travel Range (Max)* 25 mil.
Battery 2 x 24V 50Ah AGM
User Weight (Max) 21st. (135kg)
Total Weight With Batteries 101 kg
Overall Length 1220 mm (48in.)
Overall Width 630 mm (24.7in.)
Overall Height 1160 mm (46in.)
Climbing Gradient (Max) 10 Degrees
Turning Radius (Min) 1490 mm
Ground Clearance (Max Mid Frame) 100mm
Seat Type Deluxe Adjustable Captain
Seat Width 460mm (18in.)
Seat Height 400-450mm
Front Tyre 290 mm (11in.) Solid Puncture Proof/Pneumatic
Rear Tyre 290 mm (11in.) Solid Puncture Proof/Pneumatic
Pneumatic Tyre Pressure 35 psi (Max)
Suspension Front & Rear
Lights Front & Rer
Basket Black Plastic
Tiller Type Gas Assisted Delta Handle
Mirrors Yes
Charger 2 Amp Lithium
Charging Type Tiller Charger
Brake Automatic Electromagnetic & Hand Brake
REMARK: Komfi-Rider reserves the right to modify the specification if necessary. The final
specification is subject to the individual scooter you purchase from your dealer.
*Subject to user weight and terrain
KOMFI-RIDER 5

4.0 COMPONENTS OF THE SCOOTER
Your scooter is equipped with a number of elements and parts. You should know these
before using the scooter. Designs and specifications may change without prior notice.
6 KOMFI-RIDER
1
1 Seat 9 Seat Slider Lever
2 Sear Arm Pad 10 Seat Rotation Lever
3 Arm Rest Retaining Screw 11 Front Wheel
4 Seat Post 12 Front Bumper
5 Rear Light 13 Front Light
6Free Wheel Lever 14 Basket
7Anti Tip Wheel 15 Mirror
8Rear Wheel 16 Tiller Handle
2
3
4
14
5
6
7
8
9
10
15
11
12
13
16

5.0 CONTROL PANEL
5.2 Battery Indicator/Gauge: (C-2)
Indicates the voltage of the batteries:
• F(Green) – batteries are fully charged.
• Yellow – batteries are half full.
• E(Red) – batteries need charging.
• Beeping sound continuing – batteries are out of charge. Please re charge batteries.
This dial allows you to preselect and limit your Scooter’s top speed in the range of
0mph – 8mph:
• The image of the Turtle represents the slowest speed setting.
• The image of the Rabbit represents the fastest speed setting.
KOMFI-RIDER 7
C-1 Key Switch C-5 High-Low Switch
C-2 Battery Indicator C-6 Hazard Light Button
C-3 Speed Adjustment Dial C-7 Horn Button
C-4 Direction Indicator Button C-8 Throttle Control Lever - Forward/Back
5.3 Speed Adjustment Dial: (C-3)
5.4 Direction Indicator Button: (C-4)
Press the Direction Indicator Button for turning left or right.
• When turning left press the button down on the left side, the left indicator will flash.
• When turning right press the button down on the right side, the right indicator will flash.
C-2
C-3
C-4
C-5
C-6
C-7
C-1
5.1 Key Switch: (C-1)
This turns the power on and o your scooter.
•Insert the key into the key switch.
•Turn the key clockwise to turn on your scooters power. The battery indicator will light up
to indicate that the power is on.
•Turn the key anti-clockwise to turn o your scooter’s power. The battery indicator light
will turno to indicate the power is o.
•Turn the key to to turn on the main lights.
C-8
C-9

This lever allows you to control the forward speed and the reverse speed of your scooter up
to the maximum speed you pre-set with the speed adjustment dial.
Place your right hand on the right hand tiller handle and your left hand on the left hand
tiller handle.
To move forward, use either of the following:
• Use your left thumb to push the left side of the throttle control lever.
• Use your right hand fingers to pull back on the right side of the throttle control lever.
To move backward, use either of the following:
• Use your right thumb to push the right side of the throttle control lever.
• Use your left hand fingers to pull back on the left side of the throttle control lever.
Release the lever and allow your scooter to come to a complete stop before pushing the
other side of the lever to move in reverse. When the scooter is moving in reverse, the re-
verse beeper will sound. When the throttle is completely released, it automatically returns
to the centre “stop” position and engages your scooter’s brakes.
8 KOMFI-RIDER
5.5 High-Low Switch: (C-5)
Located on the front of the control panel the High-Low switch has two positions ‘Hi’ (High
speed) or ‘Lo’(Low speed) and limits the maximum speed to either 4mph or 8mph.
• Hi – Position allows the scooter to travel at a maximum speed of 8mph.
• Lo – Position allows the scooter to travel at a maximum speed of 4mph.
5.6 Hazard Light Button: (C-6)
When you press this button the front and rear hazard lights will flash.
• Press to turn on the hazard lights.
• Press again to turn o the hazard lights.
This button activates a warning horn. Your scooter must be turned on for the horn to be
operational. Do not hesitate to use the warning horn when doing so may prevent an
accident or injury.
5.7 Horn Button: (C-7)
5.8 Throttle Control Lever - Forward/Back: (C-8)
C-5
C-6
C-7
C-8
C-9

KOMFI-RIDER 9
WARNING! Chargers are selected precisely for particular applications and are
especially matched to the type, size, and chemical formulation of specific
batteries. For the safest and most ecient charging of your scooter’s
batteries, we recommend use of the charger supplied as original equipment with
your product only. Any charging method resulting in batteries being charged
individually is especially prohibited.
WARNING! Do not attempt to disassemble the battery from the battery pack or
refit the battery.
WARNING! If your battery charger has not been tested and approved for o
utdoor use, then do not expose it to adverse or extreme weather conditions. If
the battery charger is exposed to adverse or extreme weather conditions, then
it must be allowed to adjust to the dierence in environmental conditions
before use indoors. Refer to the manual supplied with the battery charger for
more information.
The Tiller Charger Socket is postioned on the tiller (Fig 5.9.1) to allow the batteries to be
charged without having to bend down – see ‘11.0 Batteries and Charging’ for further infor-
mation.
5.9 Charger Socket:
FIG 5.9.1
5.9 Hand Brake: (C-9)
The hand brake has also been provided for stopping the scooter when quicker stopping is
required or in emergency situations.

10 KOMFI-RIDER
6.0 OPERATION - BEFORE GETTING ON YOUR SCOOTER
• Keep your batteries fully charged and avoid deeply discharging your batteries.
• Never leave the manual freewheel lever in the forward position unless you are manually
pushing your scooter.
The Freewheel lever on the scooter is located on the rear section of the scooter. Before driv-
ing the scooter needs to be put into the drive position. The two positions are:
1) Drive position - is indicated by ‘D’ - pull the lever downwards for this position (Fig 6.1.1).
2) Freewheel position - is indicated by ‘N’ – push the lever forwards for this position(Fig 6.1.2).
WARNING! Never attempt to get onto or o your scooter without first removing
the key from the key switch. This will prevent the scooter from moving if acci-
dental throttle control lever contact is made.
WARNING! Never sit on the scooter when it is in freewheel mode.
WARNING! Never exceed the maximum permissible load – see 3.0 Specifica-
tions and never use the scooter to transport more than one person.
WARNING! Never drive the scooter under the influence of medication or alcohol
6.1 Freewheel Lever
FIG 6.1.1 FIG 6.1.2

KOMFI-RIDER 11
WARNING! Always remove the key switch before placing your scooter into or
taking it out of freewheel mode.
WARNING! Never sit on the scooter when it is in freewheel mode.
WARNING! Never put your scooter in freewheel mode on any incline.
WARNING! When your scooter is in freewheel mode, the braking system is disen-
gaged.
WARNING! Disengage the drive motors only on a level surface.
WARNING! Ensure the key is removed from the key switch.
WARNING! Stand to the side of the scooter to engage or disengage freewheel
mode. Never sit on a scooter to do this.
WARNING! After you have finished pushing your scooter, always return it to the
drive mode to lock the brakes.

7.0 OPERATION - GETTING ON YOUR SCOOTER
12 KOMFI-RIDER
WARNING! Never attempt to get onto or o your scooter without first removing
the key from the key switch. This will prevent the scooter from moving if acci-
dental throttle control lever contact is made.
7.1 Seat Adjustments
FIG 7.0.1
You can make several more adjustments to the seat as follows:
• Headrest Height – Press the button to adjust the height of the headrest (Fig 7.1.1).
• Backrest Angle – Lift the lever positioned on the left side of the seat (Fig 7.1.2) to adjust
the back angle. Note this lever can also be used to fold down the backrest for transport
and storage.
• Seat Slider – Lift up the lever (Fig 7.1.3) to disengage the seat slider, while holding the
lever up at the same time push the seat forwards or back to the desired position and then
release the lever to lock.
• Seat Swivel – Lift up the lever (Fig 7.1.4) to disengage the seat swivel lever, while holding
the lever up you will then be able to swivel the seat either left or right.
• Armrest Angle – Adjust the screw (Fig 7.1.5) positioned under the armpad to change an-
gle of the armrest to the desired angle.
• Seat Arms Width – The Width can be adjusted by adjusting the bolt at the back of the
seat to move the armrest out or in (Fig 7.1.6).
• Make certain that the key is removed from the key switch.
• Stand at the side of your scooter and disengage the seat rotation lever by pulling up
(Fig 7.0.1) and rotate the seat until it is facing you.
• Position yourself comfortably and securely in the seat.
• Disengage the seat rotation lever again by pulling up (Fig 7.0.1) and rotate the seat until
you are facing forward.
• Make certain that the seat is secured into position.
• Make certain that your feet are safely on the floorboard.

KOMFI-RIDER 13
FIG 7.1.1 FIG 7.1.2
FIG 7.1.3 FIG 7.1.4
FIG 7.1.5 FIG 7.1.6

14 KOMFI-RIDER
7.2 Seat Height Adjustment
CAUTION! Lifting weight beyond your physical capability may result in personal
injury. Ask for assistance when necessary while disassembling or assembling
your scooter.
CAUTION! The seat lever is sprung loaded, handle the seat slowly and carefully
whilst putting it down into the folded position.
WARNING! The following can adversely aect steering and stability while oper-
ating your scooter:
IMPORTANT! Always keep both hands on the tiller and your feet on the floor-
board while operating your scooter. This driving position gives you the most
control over your vehicle.
FIG 7.2.1 FIG 7.2.2 FIG 7.2.3
The seat height is adjustable by the adjusting the seat post height.
• Fold the seat back down. (Fig 7.2.1)
• Then stand behind the scooter and with both hands lift the seat o the seat post (Fig
7.2.2).
• Remove the rear battery cover, then remove the seat post bolt, then adjust seat post to
the required height, then re-insert bolt and fully tighten.
• Refit the seat back onto the seat post.
• Holding onto or attaching a leash to walk your pet.
• Carrying passengers (including pets).
• Hanging any article from the tiller.
• Towing or being pushed by another motorized vehicle.

KOMFI-RIDER 15
7.3 Tiller Adjustment
The Tiller Adjuster Lever is situated in front of the Tiller under the Tille Handle as shown in
(Fig 7.3.1). This allows you to quickly adjust the angle of the tiller. To adjust the position of
the tiller:
• Push the Tiller Adjuster Lever down to disengage the Lever.
• With the Tiller Adjuster Lever disengaged continue to hold and at the same time pull or
push the tiller to the desired position.
• Release the Tiller Adjuster Lever to lock the Tiller in position.
7.4 Anti Tip Wheels
Your scooter is fitted with two rear anti tip wheels as shown (Fig 7.4.1). Never drive the
scooter without these correctly fitted.
WARNING! Never drive the scooter if the anti tip wheels are missing, or dam-
aged.
WARNING! The anti-tip wheels are only eective on firm ground. They will sink
into soft ground such as grass, snow or mud if the scooter rests on them. They
will lose their eect and the scooter can tip over.
FIG 7.3.1
FIG 7.4.1

16 KOMFI-RIDER
8.0 OPERATION - DRIVING YOUR SCOOTER
8.1 Starting
• Make sure you are seated safely and properly on your scooter.
• Turn the speed adjustment dial fully anti-clockwise to the slowest setting.
• Insert the key into the key switch.
• Turn the key clockwise to the “On” position.
• Place your hands on the handgrips:
• Pull on the left-hand grip to steer your scooter to the left.
• Pull on the right-hand grip to steer your scooter to the right.
• Move the tiller to the centre position to drive straight ahead.
• Slowly engage the throttle control lever to gently accelerate your scooter forwards by ei-
ther:
• Use your left thumb to push the left side of the throttle control lever forward.
• Use your right-hand fingers to pull back on the right side of the throttle control lever.
• To stop, release the throttle control lever to allow your scooter to stop gradually. The elec-
tronic brakes will automatically engage when your scooter comes to a stop. The hand brake
has also been provided for stopping the scooter when quicker stopping is required or in
emergency situations.
8.2 Steering
• Place both hands on the handgrips of the tiller, turn the tiller to the right to travel right –
never turn at high speeds as this will result in loss of control.
• Turn the tiller to the left to turn left – never turn at high speeds as this will result in loss of
control.
• Make sure to maintain sucient clearance when turning your scooter so that the rear
wheels will be clear of any obstacles.
• Show even greater caution when steering in reverse.
• Note the scooter has a ‘slowing device’ for when cornering, even with this, you must still
show extreme caution when corning.
WARNING! Turning your scooter too sharply at high speed will cause loss of
control and balance and will result in the scooter tipping over resulting in serious
injury or death.
WARNING! Do not use the scooter if the slowing device has stopped working.

KOMFI-RIDER 17
• When driving your scooter, never descend or climb a gradient which is greater than rec-
ommended – see 3.0 Specifications. Failure to do so could result in serious injury or death.
• When driving up a ramp, curb or incline - lean forward to move the centre of gravity of
the scooter forward for maximum stability and safety.
• Drive with extreme caution when attempting to drive up or down any incline, access
ramp etc. Always drive at a slow speed.
• Always drive straight up or straight down an incline, ramp, slope etc.
• Never drive across (traverse) an incline, ramp etc, in any direction – Driving across an
incline, ramp etc. could result in turning the scooter over resulting in serious injury or death.
• Try to keep your scooter moving when climbing or descending an incline. If you have to
stop, restart and accelerate slowly and carefully.
8.3 Driving on inclines, hills, slopes & ramps
• Always be cautious when descending a curb.
• Approach the curb so that both back wheels of your scooter go over the curb at the
same time.
• Never go down curbs by traversing them. Doing this will cause the scooter to tip over
resulting in serious injury or death.
• Drive down curbs slowly to avoid jarring bumps.
8.4 Driving on curbs
8.5 Driving on grass & gravel
• Your scooter performs well on short firm grass and hills, but you must follow the opera-
tional parameters presented in this manual. If you are unsure about any situation, avoid it.
• Avoid driving in long grass, this will result in grass wrapping around you scooters axle
and potential damage to the scooter.
• Avoid driving on loose gravel, this will result in loss of control of the scooter.
WARNING! The anti-tip wheels are only eective on firm ground. They will sink
into soft ground such as grass, snow or mud if the scooter rests on them. They
will lose their eect and the scooter can tip over.
WARNING! Never descend or climb a gradient which is greater than the recom-
mended maximum see 3.0 Specifications.
WARNING! Never drive across (traverse) an incline, ramp etc, in any direction.
WARNING! While you are driving down a slope, if your scooter starts to move
faster than you feel safe, release the throttle control lever slowly. It will allow
your scooter to decelerate and slow down.

18 KOMFI-RIDER
9.0 OPERATION - GETTING OFF YOUR SCOOTER
10.0 OPERATION - BATTERIES AND CHARGING
1. Bring your scooter to a complete stop.
2. Remove the key from the key switch.
3. Disengage the seat rotation lever and rotate the seat until you are facing toward the side
of your
scooter.
4. Make certain that the seat is secured into position.
5. Carefully and safely get out of the seat and stand to the side of your scooter.
6. You can leave the seat facing to the side to facilitate boarding your scooter next time.
WARNING! Never attempt to get onto or o your scooter without first removing
the key from the key switch. This will prevent the scooter from moving if acci-
dental throttle control lever contact is made.
Your Scooter requires 2 x lead acid batteries that are sealed and maintenance free. They
are recharged by the
supplied charging system.
• Fully charge your travel scooter’s batteries for at least 10 to 12 hours prior to using it for
the first time. New batteries will be at their full capacity after having run through approx.
10-20 charging cycles (break-in period). This break-in period is necessary to fully activate
the battery for maximum performance and longevity.
• Keep the batteries fully charged to keep your scooter running smoothly. Charge the
batteries daily after every discharge even after partly discharge. Depending on the level of
discharge, it can take up to 12 hours until the batteries are fully charged again.
• If the battery indicator has reached the red LED range, charge the batteries for 16 hours
minimum, ignoring the charge complete display!
• Even if the scooter is unused for long period of time, the batteries should have a charge
regularly to make sure that both batteries are fully charged.
• Do not cycle your batteries at a low state of charge without regularly recharging them
fully.
• Do not charge your batteries under extreme temperatures. High temperatures above
30°C are not recommended for charging as well as low temperatures below 10°C.
• Protect your charger from sources of heat such as heaters and direct sunlight. If the
battery charger overheats, charging current will be reduced and the charging process de-
layed.
10.1 General Information & Instructions on Charging

KOMFI-RIDER 19
10.2 Charging Your Batteries
• Make sure you read and understand the battery charger user manual, if supplied, as
well as the safety notes on the charger.
• Turn o the scooter power and remove the key.
• Slide away the battery charger socket cover (Fig 10.2.1.)
• Put the charger plug into the outlet point.
• Do not switch on the battery charger until all the plugs are in position.
• The LED light on the battery charger will show amber while charging.
• The LED light on the battery charger will show green when batteries are fully charged.
• Turn o the mains power to the charger before removing the charger plug from charg-
ing outlet.
FIG 10.2.1
WARNING! Risk of explosion and electric shock if batteries are charged when
incorrectly wired. Never attempt to disconnect or reconnect the batteries. If the
batteries do not appear to be working correctly, contact your authorized provider.
WARNING! Risk of explosion and destruction of batteries if the wrong battery
charger is used. Only every use the battery charger supplied with your vehicle, or
a charger that has been approved by Komfi-Rider.
WARNING! Never attempt to open or disassemble the charger. If the battery
charger does not appear to be working correctly, contact your authorized provid-
er.
WARNING! Risk of electric shock and damage to the battery charger if it gets wet.
Always protect the battery charger from water and always charge in a dry envi-
ronment.
WARNING! Risk of short circuit and electric shock if the battery charger has been
damaged. Never use the charger if it has been dropped or damaged.
WARNING! Risk of electric shock and damage to the batteries – Never attempt to
recharge the batteries by attaching cables directly to the battery terminals.

20 KOMFI-RIDER
WARNING! Risk of fire and electric shock if a damaged extension cable is used.
Only ever use an extension cable if it is absolutely necessary. If you have to use
an extension cable, make sure it is in good condition.
WARNING! Risk of injury if using the scooter during charging. Do not attempt to
recharge the batteries and operate the scooter at the same time. Do not sit in the
scooter while charging the batteries.
WARNING! Chargers are selected precisely for particular applications and are es-
pecially matched to the type, size, and chemical formulation of specific batteries.
For the safest and most ecient charging of your scooter’s batteries, we recom-
mend use of the charger supplied as original equipment with your product only.
Any charging method resulting in batteries being charged individually is especial-
ly prohibited.
WARNING! Never attempt to disassemble the batteries from the scooter or refit
the batteries. Contact your authorized provider.
WARNING! If your battery charger has not been tested and approved for outdoor
use, then do not expose it to adverse or extreme weather conditions. If the battery
charger is exposed to adverse or extreme weather conditions, then it must be al-
lowed to adjust to the dierence in environmental conditions before use indoors.
Refer to the manual supplied with the battery charger for more information.
• When disassembling or assembling your scooter, always make sure you have sucient
room to move the
parts around. You may need assistance to lift some of the scooter components.
• See 3.0 Specifications for scooter weights.
• No tools are required to disassemble or assemble your scooter. Always disassemble or
assemble your scooter on a level, dry surface with sucient space for you to work and
move around your scooter. Keep in mind that the disassembled sections of the scooter
take up more floor space than the assembled scooter.
11.0 OPERATION - DISASSEMBLY AND ASSEMBLY
CAUTION! Lifting weight beyond your physical capability may result in personal
injury. Ask for assistance when necessary while disassembling or assembling
your scooter.
WARNING! Remove the key for the key switch before you disassemble your
scooter!
