KOMFI-RIDER Vantage User manual

MOBILITY SCOOTER USER
MANUAL
VANTAGE

Congratulations on the purchase of your new Vantage Mobility Scooter! The
advanced design of the Vantage with its streamline design ensures many years of
enhanced trouble-free mobility. Correct use improves your mobility and quality of
life.
Your safety is important to us.
Please read this owner’s manual before using the scooter. Improper use of the
scooter could result in harm, injury or trac accidents. Correct use improves your
mobility and quality of life.
This owner’s manual includes operation instructions for every aspect of the scooter.
Contents
1.0 SAFETY GUIDELINES 3
2.0 PRE RIDE SAFETY CHECK 4
3.0 SPECIFICATION 5
4.0 COMPONENTS OF THE SCOOTER 6
5.0 OPERATION - CONTROL PANEL 7-9
6.0 OPERATION - SCOOTER ASSEMBLY 9-14
7.0 OPERATION - SCOOTER DISASSEMBLY 15-16
8.0 OPERATION - GETTING ON YOUR SCOOTER 17-18
9.0 OPERATION - OPERATING YOUR SCOOTER 18-20
10.0 OPERATION - GETTING OFF YOUR SCOOTER 20
11.0 OPERATION - BATTERIES AND CHARGING 21-24
12.0 EMI 25
13.0 CARE & MAINTENANCE 26-27
14.0 OTHER INFORMATION 28
15.0 BASIC TROUBLESHOOTING 29
16.0 FLASH CODES 30
17.0 WARRANTY 31-33
2 KOMFI-RIDER

WARNING! An authorized Provider or qualified technician must perform the
initial setup of this scooter and must perform all of the procedures
in this manual.
1.0 SAFETY GUIDELINES
The symbols below are used throughout this owner's manual and on the scooter to identify
warnings and important information. It is very important for you to read them and
understand them completely.
WARNING! Indicates a hazardous situation that could result in serious injury or
death if it is not avoided.
CAUTION! Indicates a hazardous situation that could result in minor or slight
injury if it is not avoided.
IMPORTANT! Indicates a hazardous situation that could result in damage to
property if it is not avoided.
USEFUL TIP! Recommendations and information for ecient, trouble-free use.
Your scooter is a state-of-the-art life-enhancement device designed to increase mobility.
We provide an extensive variety of products to best fit the individual needs of the scooter
user. Please be aware that the final selection and purchasing decision regarding the type of
scooter to be used is the responsibility of the scooter user who is capable of making such a
decision and his/her health care professional (i.e., medical doctor, physical therapist, etc.).
The contents of this manual are based on the expectation that a mobility device expert has
properly fitted the scooter to the user and has assisted the prescribing health care
professional and/or the authorized provider in the instruction process for the use of the
product.
There are certain situations, including some medical conditions, where the scooter user will
need to practice operating the scooter in the presence of a trained attendant. A trained
attendant can be defined as a family member or care professional specially trained in
assisting a scooter user in various daily living activities.
As you begin using your scooter during daily activities you will probably encounter situations
in which you will need some practice. Simply take your time and you will soon be in full and
confident control when using the scooter.
Additional general information can be found on the supplemental information sheets and
booklets included in your Owner’s Package. Please fully read and review the information and
keep it readily available for future reference.
KOMFI-RIDER 3

2.0 PRE-RIDE SAFETY CHECKS
Get to know the feel of your scooter and its capabilities. We recommend that you perform
a safety check before each use to make sure your scooter operates smoothly and safely.
Perform the following inspections prior to using your Travel Scooter:
■ Check the condition of the tyres. Make sure they are not damaged or excessively worn.
■ Check all electrical connections. Make sure they are tight and not corroded.
■ Check the battery condition meter to ensure the batteries are fully charged.
■ Ensure the manual freewheel lever is in drive mode before sitting on the Travel Scooter.
If you discover a problem, contact your authorized Provider for assistance. Please refer to
the Contact Information insert in your Owner’s Package.
WARNING! This complete user manual should be read and fully understood
before using and driving the scooter.
WARNING! Never exceed the maximum permissible load – see 3.0 Specifications
and never use the scooter to transport more than one person.
WARNING! Never drive the scooter under the influence of medication or alcohol.
WARNING! Never attempt to get onto or o your scooter without first removing
the key from the key switch. This will prevent the scooter from moving if
accidental throttle control lever contact is made.
WARNING! Never drive the scooter with tiller lock in the locked position.
WARNING! This scooter is not intended for use as a seat in a motor vehi-
cle. The scooter could fail in a vehicle impact, leading to serious injury or
death of the occupant or injury to others.
4 KOMFI-RIDER

3.0 SPECIFICATION
Model Reference Vantage AGM
Speed (Max) 4mph (6km/h)
Travel Range (Max)* 2 mil. (32 km)*
Battery 2 x 12V 22Ah AGM
User Weight (Max) 26st. (170kg)
Heaviest Part when Disassembled 18 kg
Total Weight W/O Batteries 47kg
Total Weight With Batteries 63kg
Overall Length 1200mm
Overall Width 550mm
Overall Height 940mm
Climbing Gradient (Max) 6 Degrees
Turning Radius (Min) 1540mm
Ground Clearance (Max Mid Frame) 110mm (4.5in.)
Seat Type Deluxe Adjustable
Seat Width 460mm (18in.)
Seat Height 440-500mm
Front Tyre 230mm (9in.) Solid
Puncture Proof/Pneumatic
Rear Tyre 230mm (9in.) Solid Puncture Proof/Pneumatic
Pneumatic Tyre Pressure 35 psi (Max)
Suspension Adjustable Front & Rear
Lights Front LED
Basket Black Plastic
Tiller Lock Yes
Tiller Type Delta Handle
Charger 2 Amp
Charging Type O-board via Battery Box/Tiller Charger
Brake Automatic Electromagnetic
REMARK: Komfi-Rider reserves the right to modify the specification if necessary. The final
specification is subject to the individual scooter you purchase from your dealer.
*Subject to user weight and terrain
KOMFI-RIDER 5

4.0 COMPONENTS OF THE SCOOTER
1. Seat
2. Seat Arm Pad
3. Arm Rest Retaining Screw
4. Seat Swivel Lever
5. Seat Post Retaining Screw
6. Freewheel Lever
7. Anti Tip Wheel
8. Rear Wheel
9. Re-set Button
10. Charger Socket - Battery Box
11. Hub Cap
12. Front Wheel
13. Battery Box
14. Seat Post Pin
15. Seat Post
16. Control Panel
17. Basket
18. Front Light
19. Tiller Adjuster
20. Tiller Lock
Your scooter is equipped with a number of elements and parts. You should know these
before using the scooter. Designs and specifications may change without prior notice.
6 KOMFI-RIDER
1
2
3
4
5
6
7
89
10
11 12
14
15
17
18
19
20
13
16

5.0 CONTROL PANEL
21. Battery Indicator/Gauge
22. Speed Adjustment Dial
23. Key Switch
24. Tiller Handle
25. Horn Button
26. Throttle Lever Forward/Back
27. Charger Socket – Tiller
28. Light Switch
5.1 Battery Indicator/Gauge: (21)
Indicates the voltage of the batteries:
• Green – batteries are fully charged.
• Yellow – batteries are half full.
• Red – batteries need charging.
• Beeping sound continuing – batteries are out of charge. Please re charge batteries.
5.2 Speed Adjustment Dial: (22)
This dial allows you to preselect and limit your Scooter’s top speed in the range of
0mph – 4mph:
• The image of the snail represents the slowest speed setting.
• The image of the hare represents the fastest speed setting.
5.3 Key Switch: (23)
This turns the power on and o your scooter.
•Insert the key into the key switch.
•Turn the key clockwise to turn on your scooters power. The battery indicator will light up
to indicate that the power is on.
•Turn the key anti-clockwise to turn o your scooter’s power. The battery indicator light
will turno to indicate the power is o.
5.4 Horn Button: (25)
This button activates a warning horn. Your scooter must be turned on for the horn to be
operational. Do not hesitate to use the warning horn when doing so may prevent an
accident or injury.
KOMFI-RIDER 7
21 22
23 24
25 26
2728

5.5 Throttle Control Lever – Forward/Back: (26)
This lever allows you to control the forward speed and the reverse speed of your scooter up
to the maximum speed you pre-set with the speed adjustment dial.
Place your right hand on the right hand tiller handle and your left hand on the left hand
tiller handle.
To move forward, use either of the following:
• Use your left thumb to push the left side of the throttle control lever.
• Use your right hand fingers to pull back on the right side of the throttle control lever.
To move backward, use either of the following:
• Use your right thumb to push the right side of the throttle control lever.
• Use your left hand fingers to pull back on the left side of the throttle control lever.
Release the lever and allow your scooter to come to a complete stop before pushing the
other side of the lever to move in reverse. When the scooter is moving in reverse, the re-
verse beeper will sound. When the throttle is completely released, it automatically returns
to the centre “stop” position and engages your scooter’s brakes.
5.6 Charger Socket – Tiller: (27)
The Tiller Charger Socket allow the batteries to be charged without having to bend down
and charge from the battery box charging socket – see ‘11.0 Batteries and Charging’ for
further information.
WARNING! Chargers are selected precisely for particular applications and are
especially matched to the type, size, and chemical formulation of specific
batteries. For the safest and most ecient charging of your scooter’s
batteries, we recommend use of the charger supplied as original equipment with
your product only. Any charging method resulting in batteries being charged
individually is especially prohibited.
WARNING! Do not attempt to disassemble the battery from the battery pack or
refit the battery.
WARNING! If your battery charger has not been tested and approved for o
utdoor use, then do not expose it to adverse or extreme weather conditions. If
the battery charger is exposed to adverse or extreme weather conditions, then
it must be allowed to adjust to the dierence in environmental conditions
before use indoors. Refer to the manual supplied with the battery charger for
more information.
8 KOMFI-RIDER

KOMFI-RIDER 9
5.7 Light Switch: (28)
The light switch turns the front LED light on and o.
USEFUL TIP! There is also a switch on the back of the light so check that this is on if
the light is not working.
The scooter assembles from five main pieces: the basket, front section, rear section, seat
and battery box as shown below:
• When disassembling or assembling your scooter, always make sure you have sucient
room to move the parts around. You may need assistance to lift some of the scooter
components.
• See “Specifications” for individual component weights.
• No tools are required to disassemble or assemble your scooter. Always disassemble or
assemble your scooter on a level, dry surface with sucient space for you to work and
move around your scooter. Keep in mind that the disassembled sections of the scooter
take up more floor space than the assembled scooter.
CAUTION! Lifting weight beyond your physical capability may result in
personal injury. Ask for assistance when necessary while disassembling or
assembling your scooter.
6.0 ASSEMBLY OF YOUR SCOOTER
1. Front Section
2. Rear Section
3. Battery Box
4. Seat
5. Basket

6.1 Tiller Adjustment Knob
The scooter Tiller (handlebar) can be quickly folded and un-folded by the following:
• To un-fold, loosen o the Tiller adjustment knob (Fig 6.1.1.) by turning it anti-clockwise.
• Raise the tiller to the required position and hold in position.
• With your other hand fully tighten the Tiller adjustment knob making sure the teeth are
fully engaged.
• Reverse the procedure to fold the Tiller back down. Be careful not to let the Tiller fall as
doing so can damage the Tiller part.
Fully tighten the adjustment knob by turning clockwise making sure the tiller is securely
positioned with the teeth fully engaged together.
Tiller adjustment knob
WARNING! Never operate the scooter unless the tiller is raised, the teeth are fully
engaged and the tiller adjustment bolt fully tightened and securely positioned.
6.2 Tiller Lock
The scooter has been provided with a tiller lock which makes transporting and carrying the
scooter easier. It is only to be used when the scooter is dismantled, either for
transportation or storage.
• To unlock - fully press the tiller lock button down then quickly release your finger. The
button will spring up to the unlocked position (Fig 6.2.1). The tiller will now move sideways.
• To lock – set the wheels to be directly facing forward, press the tiller lock button down
firmly and release your finger. The button will stay down in the locked position (Fig 6.2.2).
Tiller Lock in un-locked position: Tiller Lock in locked position:
WARNING! Never drive the scooter with tiller lock in locked position.
→
→
→
Fig 6.2.2
Fig 6.2.1
Fig 6.1.1.
10 KOMFI-RIDER

6.3 Connecting Front & Rear Sections
The unique design of your Komfi-Rider scooter allows for quick and easy assembly of the
front and rear scooter sections.
You need to set up your scooter on a flat surface area such as a tarmac car park and
where you have enough space to assembly the scooter parts. Do not try and set up the
scooter on bumpy eneven ground as this may prevent you connecting the scooter togeth-
er correctly.
CAUTION! When assembling the front and rear sections together keep fingers
well clear of ‘pinch points’.
• Connect the front and rear sections by aligning them (Fig 6.3.1),making sure the rear sec-
tion is tipping back as shown in Fig 6.3.1.
• Carefully lift the rear of the front section by holding onto the seat post and gently lower
the front section onto the two rear hooks of the rear section (Fig 6.3.2).
• Once you have located the front section correctly onto the rear section hooks (Fig 6.3.2)
then push down gently on the seat post making sure the splitting release lever (Fig 6.3.3)
has fully located correctly and 'sprung back' level with plastic shroud.
Fig 6.3.1 Fig 6.3.2
Fig 6.3.3
KOMFI-RIDER 11
→

6.5 Fitting the Battery Box & Basket
The scooter battery box can be fitted or removed from the scooter quickly and simply as
below. Note; it is easier to fit or remove the battery box with the seat removed.
• Carefully lower the battery box into position onto the scooter (Fig 6.5.1) making sure the
box is securely and fully connected to the battery connector. (Fig 6.5.2)
• Place basket onto bracket and make sure it is securely fixed. (See Fig 6.5.3)
The scooter seat post can be quickly adjusted in height by the following:
• First make sure the seat post is installed into the lower section fixed to the chassis.
• Remove the seat post pin (Fig 6.4.1).
• Then loosen o the seat post retaining screw (Fig 6.4.1).
• You will now be able to move the seat post up or down as required to your desired
height.
• Line-up the hole in the seat post with the lower section hole and re-insert the seat post
pin.
• Lastly fully tighten up seat post retaining screw (Fig 6.4.2)
Fig 6.4.1
6.4 Seat Post Installation
WARNING! Never sit on the seat without the seat pin and seat post retaining
screw being correctly fitted.
Fig 6.5.1 Fig 6.5.2 Fig 6.5.3
12 KOMFI-RIDER
Seat Post
Pin
Seat Post
Retaining Screw

The scooter seat is designed to be fitted by the following method.
• Hold the seat with both hands and lower the seat onto the seat post (Fig 6.6.1) making
sure the seat pin fully locates into the top of the seat post (Fig 6.6.2).
• To swivel the seat, lift the swivel lever (Fig 6.6.3) and turn the seat to your desired posi-
tion.
• To lock the seat from turning, gently release the seat swivel lever to allow it to lock the
seat in your desired position. (Fig 6.6.4).
• Fix arm rests and adjust to the required width by inserting the lock pin in the desired
setting (Fig 6.6.5). Then tighten arm rest retaining screws securely (Fig 6.6.6).
Fig 6.6.3
Fig 6.6.4
WARNING! The seat mechanism is fixed to the base of the seat. Do not
change this position as doing so could dramatically change the stability of
the scooter.
6.6 Fitting the Seat
KOMFI-RIDER 13
Fig 6.6.1
Fig 6.6.5 Fig 6.6.6
Fig 6.6.2
CAUTION! Make sure the seat is fully inserted onto the seat post before sit-
ting. Never seat on the seat if the seat is still able to swivel.

6.7 Freewheel Lever
The Freewheel lever on the scooter is located on the rear section of the scooter. Before
driving the scooter the lever needs to be placed into the drive position. The two positions
are:
1. Drive position - is indicated by ‘Closed’ - pull the lever backwards for this position.
(Fig 6.7.1)
2. Freewheel position - is indicated by ‘Open’ – push the lever forwards for this position.
(Fig 6.7.2)
WARNING! Before placing your scooter into or taking it out of freewheel mode,
remove the key from the key switch. Never sit on the scooter when it is in
freewheel mode. Never put your scooter in freewheel mode on any incline.
WARNING! When your scooter is in freewheel mode, the braking system is
disengaged.
WARNING! Disengage the drive motors only on a level surface.
WARNING! Ensure the key is removed from the key switch.
WARNING! Stand to the side of the scooter to engage or disengage freewheel
mode. Never sit on a scooter to do this.
WARNING! After you have finished pushing your scooter, always return it to the
drive mode to lock the brakes.
WARNING! Never sit on the scooter when it is in freewheel mode.
Fig 6.7.1 Drive Mode (Closed) Fig 6.7.2 Freewheel Mode (Open)
14 KOMFI-RIDER

The scooter assembles from five main pieces: the basket, front section, rear section, seat
and battery box as shown below:
• When disassembling or assembling your scooter, always make sure you have sucient
room to move the parts around. You may need assistance to lift some of the scooter
components.
• See “Specifications” for individual component weights.
• No tools are required to disassemble or assemble your scooter. Always disassemble or
assemble your scooter on a level, dry surface with sucient space for you to work and
move around your scooter. Keep in mind that the disassembled sections of the scooter
take up more floor space than the assembled scooter.
CAUTION! Lifting weight beyond your physical capability may result in
personal injury. Ask for assistance when necessary while disassembling or
assembling your scooter.
7.1 Removing the seat: Stand behind the scooter and fold the seat back down, then with
both hands lift seat directly upwards.
7.2 Removing the battery box: Grip the battery box handle firmly and lift directly up-
wards and o the scooter.
7.3 Removing the basket: Stand in front of the scooter and lift basket directly upwards
o the basket bracket.
7.4 Folding down the tiller:
• Loosen the tiller adjustment knob by tuning anti-clockwise.
•Carefully lower the tiller.
• With the tiller in its lowered position, tighten the adjustment knob by turning clockwise
making sure the tiller is securely positioned – see Assembly 6.1
• Lock the tiller lock – see Assembly 6.2
7.0 DISASSEMBLY OF YOUR SCOOTER
KOMFI-RIDER 15
1. Front Section
2. Rear Section
3. Battery Box
4. Seat
5. Basket

7.5 Disconnecting Front & Rear Sections
• Push down the splitter release/lock lever and at the same time lift the seat post up-
wards lifting the front section o the rear section hooks, disconnecting the front section
from the rear. (See Fig 7.5.1)
Fig 7.5.1
7.6 Lifting and Handling
• With the scooter disassembled, if possible, lift the front section with the help of another
person. One person can lift by holding the front bumper and the other holding the rear.
• If you are having to lift the front section by yourself, then make sure the tiller is folded
and with the tiller knob tightened and the tiller lock in the ‘lock’ position. You can then lift
the scooter with one hand holding the tiller and your other hand holding either the seat
post (if fitted) or by the holding the rear end of this front section (Fig 7.6.1).
• The rear section of scooter can be lifted with two hands, one holding the front of the
rear section and the other hand holding the rear lift handle (Fig 7.6.2).
CAUTION! Lifting weight beyond your physical capability may result in
personal injury. Ask for assistance when necessary while disassembling or
assembling your scooter.
Fig 7.6.1 Fig 7.6.2
16 KOMFI-RIDER

•Never leave the manual freewheel lever in the forward position unless you are manually
pushing your scooter.
•Make certain that the key is removed from the key switch.
•Make sure the tiller is in the un-locked position.
•Only transfer on and o your scooter on a firm and level surface.
WARNING! Surface temperatures can increase when exposed to external
sources of heat (e.g. sunlight).
WARNING! Never exceed the maximum permissible load – see 3.0
Specifications and never use the scooter to transport more than one person.
WARNING! Never drive the scooter with tiller lock in the locked position.
WARNING! The stopping distance on slopes can be significantly greater than
on level ground.
CAUTION! When transferring onto and o your scooter, always make sure you
are on a firm and level surface.
KOMFI-RIDER 17
8.0 GETTING ON YOUR SCOOTER
4. Position yourself comfortably and securely in the seat.
5. Once safely seated, disengage the seat rotation lever by lifting it upwards (Fig 8.1.1.) and
rotate the seat into the forward facing driving postion. (Fig 8.1.3).
6. Make certain that the seat is secured into position.
7. Make certain that your feet are safely on the floorboard.
Fig 8.1.1 Fig 8.1.2 Fig 8.1.3
8.1 Getting onto your scooter
1. Stand at the side of your scooter.
2. Disengage the seat rotation lever by lifting the lever up (Fig 8.1.1.), you will then be able to
rotate the seat until it is facing you (Fig 8.1.2.).

WARNING! The following can adversely aect steering and stability while
operating your scooter:
■ Holding onto or attaching a leash to walk your pet.
■ Carrying passengers (including pets).
■ Hanging any article from the tiller.
■ Towing or being pushed by another motorized vehicle.
IMPORTANT! Keep both hands on the tiller and your feet on the floorboard at all
times while operating your scooter. This driving position gives you the most
control over your vehicle.
18 KOMFI-RIDER
9.1 Starting:
• Make sure you are seated safely and properly on your scooter.
• Turn the speed adjustment dial fully anti-clockwise to the slowest setting.
• Insert the key into the key switch.
• Turn the key clockwise to the ‘’On’’ position.
• Place your hands on the handgrips:
o Pull on the left hand grip to steer your scooter to the left.
o Pull on the right hand grip to steer your scooter to the right.
• Move the tiller to the centre position to drive straight ahead.
• Slowly engage the throttle control lever to gently accelerate your scooter forwards by
either:
o Use your left thumb to push the left side of the throttle control lever forward.
o Use your right hand fingers to pull back on the right side of the throttle control lever.
• To stop release the throttle control lever to allow your scooter to stop gradually. The
electronic brakes will automatically engage when your scooter comes to a stop.
9.2 Steering:
• Place both hands on the handgrips of the tiller, turn the tiller to the right to travel
right – never turn at high speeds as this will result in loss of control.
• Turn the tiller to the left to turn left – never turn at high speeds as this will result in loss of
control.
• Make sure to maintain sucient clearance when turning your scooter so that the rear
wheels will be clear of any obstacles.
• Show even greater caution when steering in reverse.
WARNING! Turning your scooter too sharply at high speed will cause loss of
control and balance and will result in the scooter tipping over resulting in serious
injury of death.
9.0 OPERATING YOUR SCOOTER

9.3 Driving on inclines, hills, slopes and ramps:
•When driving your scooter, never descend or climb a gradient which is greater than
recommended – see 3.0 Specifications. Failure to do so could result in serious injury or
death.
•When driving up a ramp, curb or incline - lean forward to move the centre of gravity of
the scooter forward for maximum stability and safety (Fig 9.3.2).
• Drive with extreme caution when attempting to drive up or down any incline, access
ramp etc, always drive at a slow speed.
• Always drive straight up or straight down an incline, ramp, slope etc.
• Never drive across (traverse) an incline, ramp etc, in any direction – Driving across an
incline, ramp etc could result in turning the scooter over resulting in serious injury or death.
• Try to keep your scooter moving when climbing or descending an incline. If you have to
stop, restart and accelerate slowly and carefully.
WARNING! Never descend or climb a gradient which is greater than the recom-
mended maximum see 3.0 Specifications°.
WARNING! Never drive across (traverse) an incline, ramp etc, in any direction.
KOMFI-RIDER 19
FIG 9.3.2FIG 9.3.1
General driving posture. When driving up any incline move
your body postion forward.
•The climbing degree will be aected by weight capacity, driving speed, and ramp degree,
and scooter parameter.
•To prevent any danger of damaging the motor, please avoid driving up long ramps & hills
or any ‘o-road’ uneven terrain.
52kg
6 degree
80kg
4 degree
170kg
0 degree
135kg
2 degree
9.4 Weight Climbing limits:
•The weight capacity limits are shown in the below.

9.5 Grass and gravel:
•Your scooter performs well on short firm grass and hills but you must follow the opera-
tional parameters presented in this manual. If you are unsure about any situation, avoid it.
• Avoid driving in long grass, this will result in grass wrapping around you scooters axle and
potential damage to the scooter.
•Avoid driving on loose gravel, this will result in loss of control of the scooter.
WARNINIG! The anti-tip wheels are only eective on firm ground. They will sink
into soft ground such as grass, snow or mud if the scooter rests on them. They
will lose their eect and the scooter can tip over.
10.0 GETTING OFF YOUR SCOOTER
1. Bring your scooter to a complete stop.
2. Remove the key from the key switch.
3. Disengage the seat rotation lever and rotate the seat until you are facing toward the
side of your scooter.
4. Make certain that the seat is secured into position.
5. Carefully and safely get out of the seat and stand to the side of your scooter.
6. You can leave the seat facing to the side to facilitate boarding your scooter next time.
WARNING! Never attempt to get onto or o of your scooter without first
removing the key from the key switch. This will prevent the scooter from moving
if accidental throttle control lever contact is made.
20 KOMFI-RIDER
9.4 Drop curbs
• Always be cautious when descending a drop curb.
• Approach the curb so that both back wheels of your scooter go over the curb at the
same time.
• Never go down curbs by traversing them. Doing this will cause the scooter to tip over re-
sulting in serious injury or death.
• Drive down curbs slowly to avoid jarring bumps.
WARNING! While you are driving down a slope, if your scooter starts to move
faster than you feel safe, release the throttle control lever slowly. It will allow
your scooter to decelerate and slow down.
WARNING! Stopping distances can be significantly increased when driving on
slopes compared to driving on level ground.
