Avaya Solution & Interoperability Test Lab
Application Notes for Konftel 300 Conference Unit with
Avaya Communication Manager - Issue 1.0
Abstract
These Application Notes document compliance testing the Konftel 300 conference unit with
Avaya IP and digital telephones controlled by Avaya Communication Manager. The Konftel
300 attaches to the analog port of an Avaya Media Gateway and enables meeting or
conference participants to simultaneously participate in a telephone conversation.
Information in these Application Notes has been obtained through DevConnect compliance
testing and additional technical discussions. Testing was conducted via the DevConnect
Program at the Avaya Solution and Interoperability Test Lab.
MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 1 of 10 konftel300-CM

1. Introduction
The purpose of these Application Notes is to illustrate how the Konftel 300 conference unit can
be used within a telephone system consisting of Avaya IP and digital telephones controlled by
Avaya Communication Manager. The Konftel 300 conference unit attaches to the analog port of
an Avaya Media Gateway, and contains a microphone and loudspeaker, which effectively
extends the range from which the telephone can be used to include an area of 30 square meters.
Placed within a conference room, the Konftel unit enables all of the participants in the room to
take part in a telephone conversation. The unit also performs echo cancellation to avoid
feedback problems that might otherwise occur.
This document details the configuration used for compliance testing with Konftel 300 with
Avaya Communication Manager. The diagram below depicts the configuration used for
compliance testing.
Avaya G350 Media Gateway
Avaya S8300 Server
Konftel 300
Avaya 4620
IP Telephone
Avaya 2420
Digital Telephone Avaya 9640
IP Telephone
analog
digital LAN LAN
PSTN
E
A
CD
B
Figure 1: Test Configuration
The configuration that was used for testing consists of an Avaya G350 Media Gateway, and an
Avaya S8300 Server. The Avaya telephones and the Konftel 300 were located at physically
separate locations to ensure that sound from the test location could not be heard other than via
the telephone connection.
MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 2 of 10 konftel300-CM

The Konftel 300 has a keypad/display, as shown in Figure 2.
Off-Hook / Flash
On-Hook
Hold
Line Mode
Figure 2: Konftel 300 Keypad /Display
The “Hold” key alternately blocks/unblocks audio signals in both directions, but the Konftel 300
does not send an indication to Avaya Communication Manager that the “hold” key has been
depressed. Consequently, the “hold” key cannot be used to initiate transfer/conference
operations. The “off-hook/flash” key must be used for this purpose, in the same manner as the
“flash” key is used for Avaya analog telephones: when the Konftel is in the “off hook” state,
depression of the “off-hook/flash” key causes the Konftel 300 to send a “flash” signal to Avaya
Communication Manager.
The following table contains additional information about each of the telephone endpoints
depicted in the System Configuration diagram:
Phone Ext PSTN Number Endpoint
A 30201 069 9073 9887 30201 Konftel 300
B 38001 Avaya 2420
C 30094 Avaya 9640 IP
D 38002 Avaya 4620 IP
E 069 7505 6174 PSTN telephone
30000 AUDIX
Table 1: Extensions Used for Testing
MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 3 of 10 konftel300-CM

MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 4 of 10 konftel300-CM
2. Equipment and Software Validated
The following equipment and software were used for the sample configuration:
Equipment Software Version
Avaya S8300 Server /
Communication Manager 5.0 (R015x.00.0.825.4)
Avaya G350 Media Gateway 27.26.0
Avaya G350 Analog Interface HW06 / FW089
Avaya MM712AP DCP HW05 / FW009
Avaya 2410 Digital Telephone 5.0
Avaya 4620 SIP Telephone 2.2.2
Avaya 9640 H.323 Telephone 1.5
Avaya IA 770 INTUITY AUDIX N5.0-12.0
Konftel 300 1.8.469 EU
Table 2: Version Numbers of Equipment and Software
3. Configuration
3.1. Configuration of the Avaya S8300 Media Server
The configuration and verification operations illustrated in this section were performed using the
Avaya Communication Manager System Administration Terminal (SAT).
Although the Avaya IA 770 INTUITY AUDIX voicemail system was used for testing, the
configuration of this component is outside the scope of this document.
The configuration of the Avaya Communication Manager interface to the PSTN is outside the
scope of this document.
3.1.1. Configure Dial Plan
Use the change dialplan analysis command to specify that dialed strings which begin with “3”
are extensions. The “*7” entry is used by the feature codes described in Table 5.
change dialplan analysis Page 1 of 12
DIAL PLAN ANALYSIS TABLE
Percent Full: 1
Dialed Total Call Dialed Total Call Dialed Total Call
String Length Type String Length Type String Length Type
3 5 ext
*7 4 fac
Figure 3: Dialplan Analysis Form

MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 5 of 10 konftel300-CM
3.1.2. Configure Interface to Konftel
Use the add station <x> command to allocate a station for Konftel 300 where <x> is the
extension for the Konftel unit as shown in Table 1.
Parameter Usage
Type Enter the station type for an analog telephone.
Port Enter the designation for the port interface on the Avaya Media
Gateway to which the unit is attached.
Name Enter the name of the user which is to be associated with the phone.
Table 3: Configuration Konftel Station
add station 30201 Page 1 of 4
STATION
Extension: 30201 Lock Messages? n BCC: 0
Type: 2500 Security Code: TN: 1
Port: 001V702 Coverage Path 1: COR: 1
Name: konftel Coverage Path 2: COS: 1
Hunt-to Station: Tests? y
STATION OPTIONS
XOIP Endpoint type: auto Time of Day Lock Table:
Loss Group: 1 Message Waiting Indicator: none
Off Premises Station? n
Survivable COR: internal
Survivable Trunk Dest? y
Figure 4: Konftel Station Form

MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 6 of 10 konftel300-CM
3.1.3. Configure Avaya Stations
Use the add station <x> command to allocate a stations for Avaya Telephones where <x> is the
extension for the each of the units as shown in Table 1.
Parameter Usage
Type Enter the type of station to be configured.
Name Enter the name of the user which is to be associated with the phone.
Security Code Enter a security code, which the telephone can use for authorization.
Table 4: Configuration Konftel Station
add station 1 Page 1 of 5
STATION
Extension: 38001 Lock Messages? n BCC: 0
Type: 4610 Security Code: XXXXX TN: 1
Port: S00009 Coverage Path 1: 99 COR: 1
Name: extn 38001 Coverage Path 2: COS: 1
Hunt-to Station:
STATION OPTIONS
Time of Day Lock Table:
Loss Group: 19 Personalized Ringing Pattern: 1
Message Lamp Ext: 38001
Speakerphone: 2-way Mute Button Enabled? y
Display Language: english
Survivable GK Node Name:
Survivable COR: internal Media Complex Ext:
Survivable Trunk Dest? y IP SoftPhone? n
Customizable Labels? y
Figure 5: Konftel Station Form
3.1.4. Configure Access to Extended Features
Use the change feature-access-codes command to assign unused feature codes to those features
used by the Konftel 300 as shown in the following Table 5. Note the “*7” entry for the dial plan
shown in Figure 3 is used by these entries.
Parameter Usage
Last number dialed
Access Code (p. 2) This is required to allow the Konftel to redial the last number.
Send All Calls
Activation (p. 3) This is required to activate coverage.
Send All Calls
Deactivation (p. 3) This is required to deactivate coverage.
Table 5: Parameters for the Feature Access Codes

MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 7 of 10 konftel300-CM
change feature-access-codes Page 2 of 5
FEATURE ACCESS CODE (FAC)
Contact Closure Pulse Code: *726
Data Origination Access Code: *727
Data Privacy Access Code: *728
Directed Call Pickup Access Code: *729
Directed Group Call Pickup Access Code: *730
Emergency Access to Attendant Access Code: *731
EC500 Self-Administration Access Code: *732
Enhanced EC500 Activation: *733 Deactivation: *734
Enterprise Mobility User Activation: *735 Deactivation: *736
Extended Call Fwd Activate Busy D/A *737 All: *738 Deactivation: *739
Extended Group Call Pickup Access Code:
Facility Test Calls Access Code: *741
Flash Access Code: *742
Group Control Restrict Activation: *743 Deactivation: *744
Hunt Group Busy Activation: *745 Deactivation: *746
ISDN Access Code:
Last Number Dialed Access Code: *748
Leave Word Calling Message Retrieval Lock: *749
Leave Word Calling Message Retrieval Unlock: *750
Figure 6: Feature Access Code Form, Page 2
change feature-access-codes Page 3 of 5
FEATURE ACCESS CODE (FAC)
Leave Word Calling Send A Message: *751
Leave Word Calling Cancel A Message: *752
Limit Number of Concurrent Calls Activation: *753 Deactivation: *754
Malicious Call Trace Activation: Deactivation:
Meet-me Conference Access Code Change: *757
PASTE (Display PBX data on Phone) Access Code: *758
Personal Station Access (PSA) Associate Code: Dissociate Code:
Per Call CPN Blocking Code Access Code: *761
Per Call CPN Unblocking Code Access Code: *762
Priority Calling Access Code: *763
Program Access Code: *764
Refresh Terminal Parameters Access Code: *765
Remote Send All Calls Activation: *766 Deactivation: *767
Self Station Display Activation:
Send All Calls Activation: *769 Deactivation: *770
Station Firmware Download Access Code: *771
Figure 7: Feature Access Codes Form, Page 3

MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 8 of 10 konftel300-CM
3.2. Configuration of the Konftel units
The Konftel 300, as shown in Figure 2, can be configured via its keypad.
Use the “Line Mode” key to select “ANALOGUE” mode.
Testing with Avaya Communication Manager was done with a flash value of 60ms. The Konftel
300 flash duration can be configured via its keypad via the following sequence:
Press the “Menu” key
Push the “down” key to select “SETTINGS”
Push the “OK” key
Push the “down” key repeatedly to select “FLASH/R”
Push the “OK” key
Push the “up” and “down” keys as required to select the desired flash time value (60ms –
600ms)
Push the “OK” key to select the desired flash time
Push the “MENU” key to exit the menu
4. Verification Steps
Use the Konftel 300 to make a call to another extension. Verify that both parties can hear
each other well.
Verify that the Konftel 300 can initiate transfer and conference operations using its
“flash” key.
Verify that the keypad keys on the Konftel 300 can be used to navigate the menu of a
voice mail system or other service.
Verify that Konftel 300 can redial numbers using the “Last Number Dialed” access
code”.
Verify that Konftel 300 can activate/deactivate voicemail coverage via the “Send All
Calls Activation/Deactivation” access codes.
5. Support
Support for Konftel products is available at
Web-based support: http://www.konftel.com/
Email: [email protected]
International help desk: [phone]
North American help: [phone]
6. Conclusion
The Konftel 300 conference unit can be attached to the analog port of an Avaya Media Gateway
to enable all those present in a room to participate in a telephone conversation. The configuration
described in these Application Notes has been successfully compliance tested.

MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 9 of 10 konftel300-CM
7. Additional References
This section references documentation relevant to these Application Notes. The Avaya product
documentation is available at http://support.avaya.com.
[1] Administrator Guide for Avaya Communication Manager, January 2008, Issue 4.0,
Document Number 03-300509.
[2] Feature Description and Implementation for Avaya Communication Manager, January
2008, Issue 6, Document Number 555-245-205.
[3] User Guide Konftel 300 (English), available at www.konftel.se.

MRR; Reviewed:
SPOC 5/1/2008 Solution & Interoperability Test Lab Application Notes ©2008 Avaya Inc. All Rights Reserved. 10 of 10 konftel300-CM
©2008 Avaya Inc. All Rights Reserved.
Avaya and the Avaya Logo are trademarks of Avaya Inc. All trademarks identified by ® and ™
are registered trademarks or trademarks, respectively, of Avaya Inc. All other trademarks are the
property of their respective owners. The information provided in these Application Notes is
subject to change without notice. The configurations, technical data, and recommendations
provided in these Application Notes are believed to be accurate and dependable, but are
presented without express or implied warranty. Users are responsible for their application of any
products specified in these Application Notes.
Please e-mail any questions or comments pertaining to these Application Notes along with the
full title name and filename, located in the lower right corner, directly to the Avaya DevConnect
Program at [email protected].
