Konica Minolta bizhub 501/421/361
Specification & Installation Guide
1
bizhub 501/421/361 Specifications
Type Black and white printer/copier/scanner/fax
with stationary platen
Document holder Stationary (mirror scanning)
Photoconductor OPC
Luminous source White inert gas fluorescent lamp
Copying system Laser exposure electrostatic copy system
Developing system Dry-type dual-component reverse
magnetic brush developing method
Fusing system Heat roller fixing
Resolution Scanning: 600 x 600 dpi
Copying: 2,400 x 600 dpi equivalent
Printing: 2,400 x 600 dpi equivalent
Document holder Types: Sheets, books (spreads),
three-dimensional objects
Size: Maximum 11" x 17" (A3)
Weight: 15 lb. (three-dimensional objects)
Paper Plain paper (16 lb. to 28 lb.), Thick paper
(29 lb. to 56lb.)*, Thin paper (13 lb. to 15 lb.),
overhead projector transparencies*,
letterheads, colored paper, envelopes*,
label sheets*, trace paper*
*Can only be fed through the bypass tray
Copy sizes 1st & 2nd tray:
11" x 17" to 5.5" x 8.5"
Bypass tray:
11" x 17" to 5.5" x 8.5"
Paper tray capacity
1st tray: (Universal Cassette)
Plain paper: 500 sheets
2nd tray: (Universal Cassette)
Plain paper: 500 sheets
Bypass tray:
Plain paper: 150 sheets
Thick paper, overhead projector
transparencies, label sheets, envelopes:
10 sheets or less, label sheets, blueprint
master: 1 at a time
Exit tray capacity 100 sheets
Warm-up time 501: Less than 60 seconds
421/361: Less than 30 seconds
(at room temperature)
Image area Copying: Leading edge: < 3 mm
Trailing edge: < 6 mm
Left & Right Sides: < 3 mm
Printing: Leading edge: < 3 mm
Trailing edge: < 4 mm
Left & Right Sides: < 2 mm
First copy 501: 3.2 seconds or less
421/361: 3.6 seconds or less
Print/copy speed:*
bizhub 501 (Simplex)
5.5" x 8.5" R 50 ppm
8.5" x 11" R 37 ppm
8.5" x 11" 50 ppm
8.5" x 14" 31 ppm
11" x 17" 27 ppm
bizhub 421 (Simplex)
5.5" x 8.5" R 42 ppm
8.5" x 11" R 31 ppm
8.5" x 11" 42 ppm
8.5" x 14" 26 ppm
11" x 17" 23 ppm
bizhub 361 (Simplex)
5.5" x 8.5" R 42 ppm
8.5" x 11" R 31 ppm
8.5" x 11" 36 ppm
8.5" x 14" 26 ppm
11" x 17" 23 ppm
*R = Reverse Orientation (Landscape)
Magnification ratios Full size: 100% ± 0.5% or less
Enlarge: 121%, 129%, 155%, 200%
Reduce: 79%, 77%, 65%, 50%
Minimal (93%)*
Zoom: 25% to 400% (in 0.1% increments)
Stored zoom ratios: 3
*Minimal zoom ratio: 90% to 99.9%
Multiple copies 1 to 999 copies
Density control Background density: Manual (9 levels);
Copy density: Automatic and manual
(9 levels)
Power requirements 120 V, 12 A, 60 Hz
Power consumption Less than 1,560 W (including option)
Dimensions Main body + DF-613:
26.7" (W) x 27.9" (D) x 35.23" (H)
Main body + DF-613 + PC-206/PC-407:
26.7" (W) x 27.9" (D) x 45.28" (H)
Space requirements 38.5" (W) x 27.9" (D) (main body/DF-613)
Memory (available 1,024 MB RAM (205 MB file memory)
hard disk space) (Optional 120 GB HD)
Weight Approx. 215 lb. (Main unit and ADF)
03/2011

2
Konica Minolta bizhub 501/421/361
Specification & Installation Guide
64.5
(1637)
45.3
(1150)
46.7
(1185.3)
19.2
(487)
3.9
(100)
25.8
(654.7)
13
(330.6)
3.9
(100)
21.7
(550)
6.95
(176.4) 7.8
(200)
61.5
(1561.4)
25
(635)
Unit: Inch(mm)
25.8
(654.7)
(432)
13
(330.6)
63.7
(1617.3)
45.3
(1150)
36.5 12.6
17
(928)
64.5
(1637)
49.5
(1258)
20.9
(532)
3.9
(100) 25
(635)
61.5
(1561.4)
21.7
(550)
7.8
(200)
6.9
(176.4)
(320)
Unit: Inch(mm)
bizhub 501/421/361 + DK-506
bizhub 501/421/361 + PC-206 + FS-522
25.7
(652)
27
(685)
23.2
(590)
6
4.5
637)
53.2
(1350)
45.3
(1150)
20.8
(530)
15.6
(397)
79.8
(2027) 61.5
(1561.4)
25.3
(642)
3.9
(100) 25
(635)
21.7
(550)
7.8
(200)
6.9
(176.4)
Unit: Inch(mm)
bizhub 501/421/361 + PC-206 + FS-522 + SD-507 + LU-203
Space Requirements
Duty Cycle
bizhub 501: 175,000; bizhub 421: 150,000;
bizhub 361: 150,000. Maximum monthly copy/print
volume supported under standard vendor supplied
service. Defines the upper end of the expected
customer volume for the device. Customers should
consider multiple machines if average monthly volume
approaches duty cycle on a continual basis.

Konica Minolta bizhub 501/421/361
Specification & Installation Guide
3
Space Requirements (continued)
Environmental Requirements
Temperature 50° to 86° F
Humidity 10–80% RH
Noise while engine under operation 501: < 75 dB
421: < 73.7 dB
361: < 71.6 dB
Ozone emission < 1.5 mg/h
Fusing range 165C–190C
Electrical Requirements
Line options: Dedicated NEMA Diagram for 5-15R
(Recommended)
Voltage: 120 V AC
Amperage: 12 A
Cycles: 60 Hz
NEMA Part No.: 5–15R
Cord Length: 8 ft. 2 in.
418
Unit: Inch(mm)
3.9
(100)
21.7
(550)
6.9
(176.4) 25
(635)
64.5
(1637)
24.3
(618)
27
(685)
23.2
(590)
56.1
(1425)
49
(1245)
16.5
(418)
15.6
(397)
78.5
(1993)
61.5
(1561.4)
7.8
(200)
93.9
(2385)
3.9
(100) 35.8
(910)
27
(685)
26.8
(680)
3.9
(100) 21.7
(550)
61.5
(1561.4)
64.5
(1637)
45.3
(1150) 37.1
(943)
19.2
(487)
23.2
(590)
15.6
(397)
7.8
(200)
6.95
(176.4) 25
(635)
Unit: Inch(mm)
bizhub 501/421/361 + PC-206 + FS-522 + MT-501 + LU-203
bizhub 501/421/361 + PC-407 + FS-523 + LU-203

4
Konica Minolta bizhub 501/421/361
Specification & Installation Guide
Component Considerations
FK-502 Fax Kit
Communication ECM/Super G3
Compatible Lines PSTN, PBSX/NCC, fax line (G3)
Line Density G3: R8 x 3.85, R8 x 7.7, R8 x 15.4, R16 x 15.4 (1/mm)
Modem Speed 2.4 kbps-33.6 kbps
Compression MH/MR/MMR/JBIG
Sending Paper Size Max. 11" x 17"
Recording Paper Size 11" x 17" to 5.5" x 8.5"
Transmission Speed Less than 3 sec. (V.34, JBIG)
Scan Speed 1 second (letter, fine mode)
Number of Abbr. 2,000
Number of Program Dial 400
Number of Group Dial 100 (500 destinations per group)
Sequential Multiple Max. 621
Station Transmission
ML-503 Multi Line Fax Kit (Includes Fax Kit FK-502)
Function Supports two fax lines. One line can be set up to send and one line
receive, or both can be set up to send.
DF-613 Automatic Document Feeder (Standard)
Type Automatic Document Feeder
Support Paper Size 5.5" x 8.5" to 11" to 17"
Support Paper Weight Single-sided: 9.25 lb. to 34 lb.
Double-sided: 13.25 lb. to 34 lb.
Paper Capacity Max. 80 sheets (20 lb.)
Paper Transfer Speed 600 dpi: 50 opm/Simplex (25 opm/Duplex)
300 dpi: 70 opm/Simplex
Power Requirements Supplied from main unit
Max. Power Consumption 48 W or less
Dimensions W x D x H 23" x 22" x 5.7"
Weight 22.1 lbs.
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P

Konica Minolta bizhub 501/421/361
Specification & Installation Guide
5
Component Considerations (continued)
FS-523 Console Finisher
Type Staple Finisher (Floor Type)
Support Paper Type Plain Paper (16 lb. to 24 lb.), Thick Paper (25 lb. to 115 lb.),
Thin paper (13 lb. to 15 lb.), OHP, Envelopes, Labels
Support Paper Size 5.5" x 8.5" to 11" x 17"
Mode Sort, group, sort punch, group punch, sort/offset, group/offset,
sortpunch/offset, group punch/offset, sort and staple, sort staple
and punch
Stacking Capacity Tray 1 (Primary Tray): 250 sheets (Plain Paper, Recycled Paper); 20
sheets (Thick, Specialty Paper)
Tray 2 (Secondary Tray) 3,000 sheets (Letter or smaller),
1,500 sheets (Legal or larger)
Staple Mode Corner upper/lower: 1 point/Center: 2 points
Staple Capacity Max. 50 sheets or 100 sets of 2-page documents
Hole Punch Standard 2/3-Hole Punch (Selectable)
Supported paper sizes: 8.5" x 11", 8.5" x 14", 11" x 17"
Support paper weight: 60 to 90 gsm
Power Requirements Supplied from main unit
Max. Power Consumption 63 W or less
Dimensions W x D x H 21.2" x 25" x 41.5"
Weight Approx. 86.3 lbs.
Consumables Staples (MS-5D)
FS-522 Base Finisher
Type Staple Finisher (Inner type)
Support Paper Type Plain Paper (16 lb. to 24 lb.), Thick Paper (25 lb. to 115 lb.),
Thin paper (13 lb. to 15 lb.), OHP, Envelopes, Labels
Support Paper Size 5.5" x 8.5" to 11" x 17"
Mode Sort, group, sort/offset, group/offset, sort and staple
Stacking Capacity
Main Tray (Finishing Tray 1):
Plain Paper: 200 sheets; Thick/Specialty Paper: 20 sheets
Sub Tray 2 (Finishing Tray 2):
Plain Paper (50 to 90 gsm): 1,000 sheets letter or smaller, 500 sheets
legal or larger; Thick/Specialty Paper: 20 sheets
Staple Mode Corner upper/lower-1 point/Center-2 points
Staple Capacity Max. 50 sheets
Available Opt. Mailbin Kit MT-502, Saddle Stitcher SD-507, Punch Kit PU-501,
Output Tray OT-602
Power Requirements Supplied from main unit
Max. Power Consumption 66 W or less
Dimensions W x D x H 12.5" x 22" x 22.5"
Weight Approx. 47.2 lbs.
Consumables Staples (MS-5D)
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P

6
Konica Minolta bizhub 501/421/361
Specification & Installation Guide
Component Considerations (continued)
JS-502 Job Separator Tray (Requires OT-504)
Support Paper Types Plain Paper, Recycled Papers, Thick Stock, Thin paper, OHP,
Envelopes, Labels
Support Paper Size 5.5" x 8.5" to 11" x 17"
Support Paper Weight Plain Paper (16 lb. to 24 lb.), Thick Paper (25 lb. to 115 lb.),
Thin paper (13 lb. to 15 lb.)
Paper Capacity 100 sheets
Power Requirements Supplied from MFP main body
Dimensions W x D x H 17.7" x 20.1" x 7.2"
Weight Approx. 3.7 lbs.
OT-602 Output Tray (for FS-522)
Applicable FS-522
Function Extra output tray for outputting either copy, print or fax documents
Number of Bins 1
Paper Capacity Plain Paper (13.25 to 24 lb.): Maximum 200 sheets
Thick Paper (24.25 to 56 lb.): 20 sheets
Max. Stacking Capacity 200 sheets
Dimensions W x D x H 11.1" x 14.5" x 2.2"
Weight Approx. 1.5 lbs.
SD-507 Saddle Stitcher (for FS-522)
Support Paper Types Plain Paper, Recycled Papers (56-90 gsm)
Function Half-fold, Crease & Center Staple
Support Paper Size 8.5" x 11" and 11" x 17"
Support Paper Weight 15 lb. to 24 lb.
Stacking Capacity 200 sheets or 20 sets
Staple Mode Center: 2 point
Binding Capacity 2–15 sheets (Max. 60 sheets)
Dimensions W x D x H 17.5" x 8.0" x 18.8"
Weight Approx. 20.5 lbs.
Staple Type MS-2C
MT-502 Mail Bin Kit (for FS-522)
Support Paper Types Plain Paper, Recycled Papers (56-90 gsm)
Support Paper Size 5.5" x 8.5" and 8.5" x 11"
Support Paper Weight Plain Paper (17 lb. to 24 lb.)
Function Allows for outputting documents in various trays. Each tray can be set
for different users.
Number of Bins 4
Stacking Capacity 125 sheets per bin (total 500 sheets)
Empty/Full Sensor Yes/Yes
Dimensions W x D x H 13.5" x 20" 15.25"
Weight Approx. 17.6 lbs.
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P

Konica Minolta bizhub 501/421/361
Specification & Installation Guide
7
Component Considerations (continued)
PU-501 Punch Kit (for FS-522)
Number of holes 2/3-holes
Support Paper Weight 16 lb. to 34 lb.
Support Paper Size 8.5" x 11" to 11" x 17"
Power Requirements from FS-522
Max. Power Consumption 70W or less
Dimensions W x D x H 4.5" x 17.8" x 5.3"
Weight Approx. 4.2 lbs.
LU-203 Large Capacity Unit
Support Paper Types Plain Paper
Support Paper Size 8.5" x 11" only
Paper Capacity 2,000 sheets (20 lb.)
Support Paper Weight 16 lb. to 28 lb.
Power Requirements Supplied from MFP main body
Max. Power Consumption 30W or less
Dimensions W x D x H 16.7" x 20.3" x 11.6"
Weight Approx. 35.3 lbs.
DK-506 Copy Desk
Function Stores copying material such as paper or toner.
Required when no additional paper drawers are installed to bring
device to operational height.
PC-206 Paper Feed Cabinet
Type 2 x 500 sheet universal drawers
Support Paper Type Plain Paper (16 to 28 lb.)
Support Paper Size 5.5" x 8.5" to 11" x 17"
Paper Capacity 500 sheets x 2 (20 lbs.)
Power Requirements Supplied from the MFP main body
Max. Power Consumption 15W or less
Dimensions W x D x H 22.5" x 21.5" x 10.25"
Weight Approx. 57.3 lbs.
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P

8
Konica Minolta bizhub 501/421/361
Specification & Installation Guide
Component Considerations (continued)
PC-407 Paper Feed Cabinet
Type Large capacity cassette
Support Paper Type Plain Paper (16 to 28 lb. bond)
Support Paper Size 8.5" x 11"
Paper Capacity 2,500 sheets (20 lb.)
Power Requirements Supplied from the MFP main body
Max. Power Consumption 45W or less
Dimensions W x D x H 22.4" x 21.6" x 10.3"
Weight Approx. 57.3 lbs.
IC-207 Image Controller
Type Internal Type
CPU Celeron-M 600 MHz/32-bit (Shared with the copier)
Memory 1,024 MB RAM (205 MB file memory)(Shared with the copier);
120 GB HDD (Shared with the copier)
Print Speed bizhub 501: 50 ppm
bizhub 421: 42 ppm
bizhub 361: 36 ppm
Print Resolution 600 x 600 dpi/2,400 dpi (equivalent) x 600 dpi
PDL PCL5e/PCL6 (XL 3.0), PS3 Emulation (3016), XPS (XML paper specification)
Protocol TCP/IP (IPv4/IPv6), IPX/SPX, AppleTalk
Support OS Windows NT4.0 SP6, Windows 2000, Windows XP/x64,
Windows Server 2003/Server x64, Windows Vista/Vista x64,
Windows Server 2008/Server x64, Windows 7/x64, Mac OS 9.2,
OS X 10.2, 10.3, 10.4, 10.5, 10.6; Mac OS X (Intel-based) 10.4, 10.5, 10.6
Font PCL Resident Fonts: 80 outline
PS3 Emulation Resident Fonts: 137 outline
EK-703 Local USB Interface Kit
Type USB 2.0 Interface (mini-B plug).
Function Required for local USB printing.
HD-509 Hard Disk
Type Internal HDD
Capacity 120 GB
Functions Added File Memory, Scan-to-User Boxes, Print User Boxes.
SC-505 Security Kit
Type Embedded
Function Encrypts data stored on the MFP's hard disk drive
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P

Konica Minolta bizhub 501/421/361
Specification & Installation Guide
9
Component Considerations (continued)
AU-101 Biometric Authentication Unit
Compatible Finger Width 1.1" (Top); 1.2" (Bottom)
Interface USB 2.0 requires WT-502 Working Table
Dimensions (W x D x H) 3.1"(W) x 3.7"(D) x 2.2"(H)
Weight 0.311 lb (not including USB Cable)
AU-201H HID Card Authentication Unit (IC Card Type)
Dimensions (WxHxD) 3.625"x2.5"x0.625"
Weight 0.25 lb.
Power Supply Supplied from USB Port
System Conditions Ambient Temperature: 32°to 104° F
(operating mode) Humidity: 20% to 85%
System Conditions Ambient Temperature: -4°to 122° F
(non-operating mode) Humidity: 20% to 85%
Radio Law Division Self-Guided Read-Write Communication Facility
Applicable Card ISO 14443 Type A, FeliCa-based non-contact IC Card
Acquired Standard VCCI Class B
Compatible Computer CPU: PC/T Compatible, 1 GHz or more
Memory: 128 MB or more
HDD: 100 MB or more free space
Monitor: 800x600 pixels, 16-bit color or more
Network: TCP/IP
Application: Microsoft Internet Explorer 6.0 (SP1) or later
Microsoft .NET Framework (SP1) or later
MFP Compatibility bizhub 652, 552, 751, 601, 501, 423, 363, 283, 223, C652DS, C652,
C650, C552DS, C552, C550, C452, C451, C360, C353, C280, C253,
C220, C203. Please check MyKonicaMinolta.com on a regular basis
forcompatibility updates.
NOTE: WT-502 Working Table is recommended for AU-201H HID Proximity Card Authentication Unit.
AU-204H Magnetic Stripe Card Reader
Dimensions (WxHxD) 1.28" x 1.23" x 3.94"
Weight 4.5 oz.
Power Supply Supplied from USB Port
System Conditions Ambient Temperature: 40˚ to 158˚ F
(operating mode) Humidity: 10% to 90%
Transmit Frequency 3-60 i.p.s.
Certifications ISO 7810 and ISO 7811/AAMVA
Card Type Compatibility All magnetic stripe cards
MFP Compatibility bizhub C652DS, C652, C650, C552DS, C552, C550, C452, C451,
C360, C353, C280, C253, C220, C203, 751, 601, 501, 423, 421, 363,
361, 283, 223. Please check MyKonicaMinolta.com on a regular basis
forcompatibility updates.
NOTE: WT-502 Working Table required for AU-204H Magnetic Stripe Card Reader.
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P

10
Konica Minolta bizhub 501/421/361
Specification & Installation Guide
Component Considerations (continued)
AU-211P CAC/PIV Solution w/Certificate
Dimensions (WxHxD) 2.75" x 2.75" x 0.39"
Weight 0.13 Ibs.
Power Supply Supplied from USB Port
System Conditions 0˚ to 122˚ F
(operating mode)
Interface Full Speed USB (12 Mbps)
Connector Shape USB A Type Connector
Compatible Card PKI-C-Card (PIV, CAC)
MFP Compatibility bizhub 751, 601, 501, 421, 361, C652, C552, C452, C360, C280,
C220. Please check MyKonicaMinolta.com on a regular basis
forcompatibility updates.
NOTE: WT-502 Working Table required. Please contact your local Government Account Manager for additional information.
WT-502 Working Table
Type External Table
Function Holds AU-101 Biometric Authentication Unit, AU-201H HID
Authentication Unit, AU-204H Magnetic Stripe Card Reader
orAU-211P CAC/PIV Solution; Can be used as place holder
fororiginals and/or output
LK-101 License Kit
Type License Key
Function Web Browser and Image Panel
LK-102 License Kit
Type License Key
Function Enhanced PDF Encryption (128-bit AES Encryption)
UK-202 i-Option Upgrade Kit
Type 1 GB Memory Upgrade, stylus pen, stylus pen holder, face sheet,
and install guide
Function Required for LK-101 and LK-102 License Kits.
AU-201H
AU-204H
AU-101
AU-211P
AU-201H
AU-204H
AU-101
AU-211P

Konica Minolta bizhub 501/421/361
Specification & Installation Guide
11
Image Controller IC-207
Type Internal Type
CPU Celeron-M 600 MHz/32-bit
(Shared with the copier)
Memory 1,024 MB RAM (205 MB file memory)
(Shared with the copier)
120 GB HDD (Shared with the copier)
Print Speed bizhub 501: 50 ppm
bizhub 421: 42 ppm
bizhub 361: 36 ppm
Print Resolution 600 x 600 dpi/
2,400 dpi (equivalent) x 600 dpi
PDL PCL5e/PCL6 (XL 3.0), PS3 Emulation
(3016), XPS (XML paper specification)
Protocol TCP/IP (IPv4/IPv6), IPX/SPX, AppleTalk
Support OS Windows NT4.0 SP6, Windows 2000,
Windows XP/x64, Windows Server 2003/
Server x64, Windows Vista/Vista x64,
Windows Server 2008/x64, Windows 7/x64
Mac OS 9.2, OS X 10.2, 10.3, 10.4, 10.5, 10.6
Mac OS X (Intel-based) 10.4, 10.5, 10.6
Font PCL Resident Fonts: 80 outline
PS3 Emulation Resident Fonts: 137 outline
Network Functions
• Sending the Scanned Data in an Email Message
• Sending the Scanned Data as Files (FTP)
• Sending the Scanned Data to a Computer on the Network (SMB)
• Sending the Scanned Data to WebDAV Server
• Saving the Scanned Data in Boxes
• Using the Machine as a Scanner
• Web Service
Print Drivers
Page Description
Language
Printer
Driver Supported Operating Systems
PCL XL (PCL6) Konica
Minolta
Windows NT 4.0 (SP6+), Windows
2000 Professional/Server (SP3+),
Windows XP Home/Professional,
XP x64 (SP2+), Windows Server
2003, Windows Server 2003 x64,
Windows Vista, Windows Vista x64,
Windows Server 2008, Windows
Server 2008 x64, Windows 7,
Windows 7 x64
PostScript 3
Emulation
Konica
Minolta
Windows 2000 Professional/
Server (SP3+), Windows XP Home/
Professional, Windows XP x64 (SP2+),
Windows 2003 Server, Windows
Server 2003 x64, Windows Vista,
Windows Vista x64, Windows 2008,
Windows Server 2008 x64,
Windows 7, Windows 7 x64
Universal
PCL and PS3
Konica
Minolta
UPD
Windows 2000, Windows XP,
Windows Server 2003,
Windows Vista, Windows Server
2008 (x32,x64)
PostScript
PPD Driver
Mac OS 9.2 or later,
Mac OS X 10.2, 10.3, 10.4, 10.5, 10.6
Mac OS X (Intel-based) 10.4, 10.5, 10.6
Print Specifications
Item Specifications
Power Supply Common with the main body
CPU Celeron-M 600 MHz/32-bit
(Shared with the copier)
RAM 1,024 MB RAM (205 MB file memory)
Optional Hard Disk 120 GB
Interface 10Base-T, 100Base-TX, 1000Base-T,
USB 2.0 (optional)
Frame Type Ethernet 802.2
Ethernet 802.3
Ethernet II
Ethernet SNAP
Protocol TCP/IP (IPv4/IPv6), IPX/SPX, AppleTalk
Printer Language PCL5e Emulation
PCL6 (XL 3.0) Emulation
PostScript 3 Emulation (3016)
XPS (XML paper specification)
Operating Temperature 50° to 86° F
Environment Humidity 10 to 80% RH
Conditions
Resolution Data
Processing
600 x 600 dpi (print and fax functions)
400 x 400 dpi (fax functions)
200 x 200 dpi (fax functions)
Printing 2,400 dpi (equivalent) x 600 dpi
continued

12
Konica Minolta bizhub 501/421/361
Specification & Installation Guide
Print Specifications (continued)
Item Specifications
Supported 5.5" x 8.5" to 11" x 17"
Paper Sizes
Printer Fonts PCL: Latin 80 Fonts
Postscript 3 Emulation: Latin 137 Fonts
Compatible IBM PC or compatible and Macintosh
Computers (PowerPC or Intel)
Support OS Windows NT4.0 SP6, Windows 2000,
Windows XP/x64, Windows Server 2003/
Server x64, Windows Vista/Vista x64,
Windows Server 2008/x64, Windows 7/x64
Mac OS 9.2, OS X 10.2, 10.3, 10.4, 10.5, 10.6
Mac OS X (Intel-based) 10.4, 10.5, 10.6
Page Description
Language
Printer
Driver Supported Operating Systems
PCL XL (PCL6) Konica
Minolta
Windows NT 4.0 (SP6+), Windows
2000 Professional/Server (SP3+),
Windows XP Home/Professional,
XP x64 (SP2+), Windows Server
2003, Windows Server 2003 x64,
Windows Vista, Windows Vista x64
Windows Server 2008, Windows
Server 2008 x64, Windows 7,
Windows 7 x64
PostScript 3
Emulation
Konica
Minolta
Windows 2000 Professional/
Server (SP3+), Windows XP Home/
Professional, Windows XP x64 (SP2+),
Windows 2003 Server, Windows
Server 2003 x64, Windows Vista,
Windows Vista x64, Windows Server
2008, Windows Server 2008 x64,
Windows 7, Windows 7 x64
Universal
PCL and PS3
Konica
Minolta
UPD
Windows 2000, Windows XP,
Windows Server 2003,
Windows Vista, Windows Server
2008 (x32,x64)
PostScript
PPD Driver
Mac OS 9.2 or later,
Mac OS X 10.2, 10.3, 10.4, 10.5, 10.6
Mac OS X (Intel-based) 10.4, 10.5, 10.6
Scanning Function (Standard)
Type Monochrome Image Scanner
Scanning Size 5.5" x 8.5" to 11" x 17"
Scanning Resolution 600/400/300/200 dpi
Scanning Speed 50 opm (600 dpi); 70 opm (400 dpi);
70 opm (300 dpi); 70 opm (200 dpi);
Main Function Scan-to-Email, Scan-to-Box (HDD)
(Requires opt. HDD), Scan-to-FTP,
Scan-to-SMB (Desktop Folder),
Scan-to-WebDAV, Scan-to-USB Memory,
WS-Scan, Network TWAIN, HDD TWAIN
(via Ethernet TCP/IP)
Interface Ethernet 100BaseTX/100BaseT/1000 BaseT
Protocol TCP/IP (FTP, SMTP, HTTP, SMB)
Support OS Windows NT4.0 SP6, Windows 2000,
(Driver) Windows XP, Windows Server 2003,
Windows Vista, Windows Server 2008,
Windows 7
Output Format TIFF, PDF, XPS, Encrypted PDF
Driver TWAIN
Address Setting LDAP, Import/Export address from
PageScope Web Connection
Authentication Authentication in sending Email,
Network User Authentication
*Text and image scanning speeds vary depending on the type of document.
Network & Device Management
Network & Device Management User Tools
PageScope Web Connection
PageScope Net Care PageScope Direct Print
PageScope NDPS Gateway PageScope Box Operator
PageScope EMS Plug-Ins PageScope Print Status Notifier
PageScope Network Setup Font Management Utility
PageScope Data Administrator Print Utility for Unix
Driver Packaging Utility Copy Protection Utility
HDD Back Up Utility
Log Management Utility Management Tool
bizhub vCare Support
Optional Software
PageScope Workware
PageScope Enterprise Suite ver. 1.2
– PageScope Account Manager
– PageScope Authentication Manager
– PageScope MyPanel Manager

Konica Minolta bizhub 501/421/361
Specification & Installation Guide
13
Because information assets are critical, a company needs
to effectively protect against the many security risks it faces.
1) Prevent leaks of proprietary, confidential
or personal information
2) Prevent unauthorized use of equipment
3) Effective data encryption
4) Protect data from being altered, duplicated or deleted
5) Prevent unauthorized access to data via the Internet
6) Protect against cyber attacks
7) Manage log history
Protective Functions:
• HDD Sanitizing (when disposing of machine)
• Delete Graphic Data (after each job) Job Erase
• Lock Job (when printing confidential documents)
• Protect data by requiring department name
and 8-digit password
• Account Track
• HDD Lock
• Prevent Unauthorized Use
• Operation Log with 2,000-event memory
• HDD Encryption
• PDF Scan Encryption
• Encrypted Network Password Printing
• Network Authentication
• Scan-to-USB Memory w/User Authentication
• Print from USB Memory w/User Authentication
• Biometric User Authentication
• SMTP Authentication for Email
• SSL/TSL Compatibility for PS Web Connection, PS Data
• Administrator and LDAP Server
• S/MIME Encryption
• Scan Data Encryption (TCP/socket SSL Compatibility)
• Box Operator Data Encryption
• Verification of Box Data Receipt
• IP Address Filtering
• Detailed Security Logs
• AU-201H HID Authentication
• Secure Printing Only Support
Paper Considerations
Paper Size Conversion Chart
Paper Letter Letter R Legal Tabloid Statement Statement R
Measurement 8.5" x 11" 11" x 8.5" 8.5" x 14" 11" x 17" 5.5" x 8.5" 8.5" x 5.5"
Paper Weight Conversion Chart
Caliper
gsm Bond Offset Cover Tag Index Point Bristol inches mm
60.20 16 40 22 37 33 3.2 27.4 0.0032 0.081
67.72 18 45 24 41 37 3.6 30.9 0.0036 0.092
75.20 20 50 28 46 42 3.8 34.3 0.0038 0.097
90.30 24 60 33 56 50 4.8 41.2 0.0048 0.120
105.35 28 70 39 64 58 5.8 48.1 0.0058 0.147
109.11 29 73 40 62 60 6.0 49.8 0.0060 0.152
116.63 31 81 45 73 66 6.1 53.2 0.0061 0.155
131.68 35 90 48 80 74 6.2 60.1 0.0062 0.157
135.45 36 90 50 82 75 6.8 61.8 0.0068 0.173
146.73 39 100 54 90 81 7.2 67.0 0.0072 0.183
150.50 40 100 56 93 83 7.3 68.7 0.0073 0.185
161.78 43 110 60 100 90 7.4 73.8 0.0074 0.188
165.55 44 110 61 02 92 7.6 75.5 0.0076 0.193
176.83 47 120 65 108 97 8.0 80.7 0.0078 0.198
199.41 53 135 74 122 110 9.0 91.0 0.0085 0.216
203.17 54 137 75 125 113 9.0 92.7 0.0090 0.229
218.22 58 146 80 134 120 9.5 99.6 0.0092 0.234
244.56 65 165 90 50 135 10.0 111.6 0.0095 0.241
252.08 67 170 93 156 140 10.5 115.1 0.0100 0.250
270.90 72 183 100 166 150 11.0 123.7 0.0110 0.289
285.95 76 192 105 175 158 13.0 130.5 0.0130 0.330
308.52 82 208 114 189 170 14.0 140.8 0.0140 0.356
312.00 87 220 120 200 180 15.0 142.4 0.0150 0.380
385.06 105 267 146 244 220 18.0 175.8 0.0175 0.445
Security

14
Konica Minolta bizhub 501/421/361
Specification & Installation Guide
Paper Type Specifications
Normal (Plain Paper)
Normal paper is used for copying in general and is called “PPC
paper”. Normal paper is usually not a recycled paper. Specify
[Normal] for the tray in which normal or recycled paper for
copying is loaded. For this model, Plain Paper is designated
as paper weighing between 16 lb. and 24 lb.
Recycled Paper
Paper made from waste paper pulp instead of virgin wood pulp.
There are several kinds of recycled paper. The main difference
is the actual recycled content of the paper.
Glossy Stock
Paper having a shiny or lustrous surface.
Thick Paper 1
Thick Paper is paper weighing between 24.25 to 40 lb. bond.
It can be fed via any paper tray.
Thick Paper 2
Thick Paper 2 is paper weighing between 40.25 lb. to 55.5 lb.
bond. It can be fed via any paper tray.
OHP
Specify [OHP] for the bypass tray in which transparent film paper
is loaded. OHP Transparencies are supported via the bypass
tray only. Maximum capacity is 20 sheets.
Envelopes
Specify [Envelope] for the bypass tray in which the envelope
is loaded. Envelopes are supported via the bypass tray only.
Maximum capacity is 10 envelopes.
Specialty Paper
A special type of paper that is used for a particular application.
Recommended Paper Stocks
Classification Brand of Paper
Plain Paper Hammermill Tidal MP (75 gsm)
Recycled Paper Hammermill Bond
New Leaf Encore 100
Thick Paper Gilbert Color Copy (163 gsm)
Thin Paper Boise Cascade Bond (16 lb.)
Labels* Avery 5352
OHP Film 3M CG3700
Envelope Preservation Wove (24 lb.)
#C6-3/4, #9, #10 (4.125" x 9.5")
* Labels should be fed one sheet at a time.
See KMBS Media Guide for more information

Konica Minolta bizhub 501/421/361
Specification & Installation Guide
15
Start: bizhub 501/421/361 Base Unit
Comes standard with: Drum, Developer (1), DF-613,
Duplex Unit, 1,024 MB Memory (max.), Tray 1 (500 sheets),
Tray 2 (500 sheets), Intelligent Bypass (150 sheets), Total
Standard Paper Capacity: 1,150 sheets (5,650 max.)
Step 1: Document Handling
DF-613 Reversing Document Feeder (Standard)
Step 2: Output Options
OT-504 Output Tray (Required if no finisher is purchased)
JS-502 Job Separator Tray (Requires OT-504)
Step 3: Finisher Options
Duplex Unit (Standard)
FS-523 Staple Finisher (Includes RU-507)*
FS-522 Base Finisher
MT-502 Mailbin Kit
SD-507 Saddle Stitcher
PU-501 Punch Unit (2/3)
OT-602 Output Tray
Step 4: Paper Supply/Cabinet Stand Option
PC-407 Paper Feed Cabinet
(2,500 sheets; Letter only)
PC-206 Paper Feed Cabinet
(2 x 500 sheets; Universal)
LU-203 Large Capacity Unit (2,000 sheets; Letter only)
DK-506 Copy Desk (2-drawer height cabinet
with paper storage)
Step 5: Analog Faxing Options
FK-502 Fax Kit (Includes MK-708)
SP-501 Stamp Kit (Requires fax option)
ML-503 Fax Multi-Line Kit
Step 6: Controller Option
IC-207 Image Controller (Required for printing)
Step 7: Additional Options
HD-509 120 GB Hard Disk Drive
(for enhanced copy, print and scan functions)
SC-505 HDD Encryption Kit
WT-502 Working Table
EK-703 USB Interface Kit
AU-101 Biometric Authentication Unit (Requires WT-502)
AU-201H HID Card Authentication Unit
(WT-502 is recommended)
AU-204H Mag Stripe Card Reader (Requires WT-502)
AU-211P CAC/PIV Card Authentication Unit
(Requires WT-502)
LK-101 License Kit (Web Browser + Image Panel)
LK-102 License Kit (Enhanced PDF Encryption)
UK-202 i-Option Upgrade Kit
Cannot be
combined
DK-506
Copy Desk
DF-613 Reversing
Document Feeder (Standard)
PU-501
Punch Kit
SD-507
Saddle
Stitcher
FS-522
Base
Finisher
PC-206 Paper Feed Cabinet
(2 x 500 sheets)
LU-203 Large Capacity
Unit
(2,000 sheets)
HD-509 120 GB
Hard Disk Drive
SP-501 Stamp Kit
FK-502 Fax Kit
IC-207 Image Controlle
SC-505 HDD
Encryption Kit (Opt.)
ML-503 Fax
Multi-Line Kit (Optional)
AU-101 Biometric
Authentication Unit
AU-201H HID Card
Authentication Unit
WT-502 Working Table
OT-602
Output Tray
PC-407 Large Capacity
Cabinet
(2,500 sheets)
MT-502
Mailbin Kit
JS-502 Job
Separator Tray
Universal
Drawers
(Standard)
500 Sheets
FS-523
Console Finisher
(Includes RU-507)
AU-204H Mag Stripe
Card Reader
AU-211H CAC/PIV
Card Authentication Un
* Sold se
p
aratel
y
in Direct Channel.
How to Build a bizhub 501/421/361 System (from start to finish)

16
Konica Minolta bizhub 501/421/361
Specification & Installation Guide
11/2010
Accessory Options for bizhub 501/421/361 Digital Printer/Copier/Scanner/Fax
ACCeSSOrieS item NO. DeSCriPtiON NOteS
BASe UNit
bizhub 501 A0R5011 bizhub 501 Digital Copier
Includes: Drum, Developer (1), DF-613, Duplex Unit, 1,024 MB Memory (max.),
Tray 1 (500 sheets), Tray 2 (500sheets), Intelligent Bypass (150 sheets),
Total Standard Paper Capacity: 1,150 sheets (5,650 max.)
bizhub 421 A0R6011 bizhub 421 Digital Copier
Includes: Drum, Developer (1), DF-613, Duplex Unit, 1,024 MB Memory (max.),
Tray 1 (500 sheets), Tray 2 (500sheets), Intelligent Bypass (150 sheets),
Total Standard Paper Capacity: 1,150 sheets (5,650 max.)
bizhub 361 A0R7011 bizhub 361 Digital Copier
Includes: Drum, Developer (1), DF-613, Duplex Unit, 1,024 MB Memory (max.),
Tray 1 (500 sheets), Tray 2 (500sheets), Intelligent Bypass (150 sheets),
Total Standard Paper Capacity: 1,150 sheets (5,650 max.)
DOCUmeNt HANDliNg
DF-613 —
Reversing Document Feeder
(Standard)
80 sheet capacity. Up to 70 opm.
OUtPUt OPtiONS (One of the following is required)
OT-504 A0RA0Y1 Output Tray
Output Tray only (Required when no finisher is purchased).
JS-502 4347711 Job Separator Tray
Separates output. Not available with FS-522 or FS-523 (Requires OT-504).
FS-522 A0HN0Y1 Base Finisher (Internal Type)
Finisher must be installed to support FS-522 options (Internal Finisher).
FS-523* A0PHX001 Staple Finisher (with Relay Unit)
Includes RU-507 Relay Unit. Floor type finisher. Includes 2/3-Hole Punch & Stapling (Standard).
FS-522 FiNiSHer OPtiONS
OT-602 4625246 Output Tray
Adds third tray to FS-522 finisher; used to separate print, copy and fax output.
MT-502 4510761 Mailbin Kit
Requires FS-522; Allows for outputting documents in various trays.
Cannot be combined with SD-507.
PU-501 4512812 Punch Unit
Requires FS-522; Provides 2/3-hole punch.
SD-507 A0PGW21 Saddle Stitcher
Requires FS-522; Provides booklet making capability.
Cannot be combined with FS-522 Mailbin Kit.
PAPer SUPPly OPtiONS (All three models include two universal drawers, each with a 500 sheet paper capacity and a 150-sheet multi bypass tray)
LU-203 A0R90Y1 Large Capacity Unit (2,000 sheets)
Increases paper capacity to 5,650 sheets. Requires PC-206 or PC-407.
PC-206 A0RC0Y1 2-Way Paper Feed Cabinet
(Universal, Two 500-sheet
paper drawers)
Increases paper capacity to 2,150 sheets. Adds 1,000 sheets to standard paper supply.
PC-407 A0RC011 Large Capacity Cabinet
(Letter, 2,500-sheet drawer)
Increases system to maximum paper capacity of 3,650 sheets.
Adds 2,500 sheets to standard paper supply.
PriNter/COPier StAND OPtiON
DK-506 A0RC0Y3 Copy Desk
Required when no additional paper drawers are installed to bring device to operational height.
ADDitiONAl OPtiONS
HD-509 7640008435 120 GB Hard Disk Drive
Required to support Scan-to-HDD and other functions.
See bizhub 501/421/361 Product & Sales Guide for details.
SC-505 A0PAWY1 HDD Encryption Kit
Encrypts all data stored on HDD. Provides encryption priority and overwrite priority selections.
AU-101 A09MWY0 Biometrics Authentication Unit
Compatible with C650, C550, C451, C353, C253, C203 and 751, 601.
AU-201H 7640005064 HID Card Authentication Unit
Compatible with C652, C552, C650, C550, C451 and C353, C253, C203, C353P.
WT-502 is recommended. If WT-502 is not installed, AU-201H must be mounted to machine.
AU-204H 7640013468 Mag Stripe Card Reader
Requires WT-502 Working Table.
AU-211P 7640008082 CAC/PIV Card Authentication Unit
Requires WT-502 Working Table.
WT-502 A07EWW0 Working Table
Required for AU-101 Biometrics Authentication Unit; Compatible with C451, C550 and C650.
EK-703 A0P4WY1 USB Interface Kit
Required for local USB printing.
LK-101 A0PD011 License Kit
Enables Web Browser from the MFP control panel, and image panel functions (move,
combine, restore user files at the MFP) .
LK-102 A0PD012 License Kit
Enables 128-bit AES PDF encryption; PDF file and password are encrypted.
UK-202 A120WY1 i-Option Upgrade Kit
Memory upgrade required for optional License Kit functionality; Only one memory
upgrade needed per device. Includes: 1 GB RAM, Touch Pen, Pen Holder, Face Sheet
and InstallManual.
Continued
* FS-523 and RU-507 sold separately in Direct Channel.
Accessory Options for bizhub 501/421/361 Digital Printer/Copier/Scanner/Fax

Konica Minolta bizhub 501/421/361
Specification & Installation Guide
17
ACCeSSOrieS item NO. DeSCriPtiON NOteS
FAx OPtiONS
FK-502 15LBX004 Fax Kit
33.6 Kbps faxing. Includes MK-708 Mount Kit.
SP-501 4614506 Stamp Kit
Successful fax transmissions are marked (Stamped).
ML-503 7640X024 Fax Multi-Line Kit
Adds second line to bizhub 501/421/361. Kit includes dual Line and fax board FK-502.
CONtrOller OPtiON
IC-207 A0P80Y1 Image Controller
Adds PCL 6/PS 3 emulation, XPS (XML Page Specification) printing capability.
CONSUmABle yielDS
CONSUmABle item NO. DeSCriPtiON NOteS
Toner TN-511 024E Simitri
®
Polymerized Toner
32.2K Yield (6% coverage)
Developer DV-511024G Developer
250K Yield (6% coverage) bizhub 501/421
225K Yield (6% coverage) bizhub 361
Photoconductor
DR-510
024K Drum Unit
250K Yield (6% coverage) bizhub 501/421
225K Yield (6% coverage) bizhub 361
Staples MS-5D 4623361 For FS-523 and FS-522 Finisher
(5,000 staples/cartridge x 3)
Staples MS-2C 4599161 For Saddle Stitcher Kit SD-507
(2,000 staples/cartridge x 4)
PM Parts Kit
361/421
D42GEPM25
PM Parts Kit 225K Yield bizhub 361
250K Yield bizhub 421
PM Parts Kit 501 D50GEPM25 PM Parts Kit
250K Yield
Accessory Options for bizhub 501/421/361 Digital Printer/Copier/Scanner/Fax
