Konica Minolta bizhub PRO 950 Series User manual

Konica Minolta
bizhub PRO 950
Specification & Installation Guide
1
bizhub 950 Specifications
Type Console type
Copying system Laser electrostatic transfer method
(dual beam)
Original glass Stationary
Photoconductor OPC
Light source Xenon lamp
Developing method Dry-type dual-component reverse
magnetic brush developing
Fixing method Heat roller
Density adjustment Automatic and manual (9 levels),
Preset density (2 types)
Magnification ratio 1:1 ± 1.0% or less
Enlargement: ×1.214 (121.4%),
×1.294 (129.4%), ×1.545 (154.5%),
×2.000 (200.0%)
Reduction: ×0.939 (93.9%),
×0.772 (77.2%), ×0.647 (64.7%),
×0.500 (50.0%)
Minimal: ×0.930 (93.0%) (fixed)
XY Zoom (interlocked and individual):
0.250 to 4.000 (25.0%–400.0%)
(in 0.001 increments)
User-set zoom ratio: 3
Resolution 600 dpi
Copy paper Tray 1, 2, 3: 11 to 57 lb. bond (216 g/m2)
Bypass Tray: 11 to 65 lb. bond (244 g/m2)
Any tray using Embossed setting:
14 to 57 lb. bond (216 g/m2)
LCT: 11 to 80 lb. bond (300 g/m2)
NOTE: Ink-jet paper is unavailable.
Copying speed 95 copies/min. (8.5" × 11"), 76 copies/min.
(8.5" × 11"R), 63 copies/min. (8.5" × 14"),
54 copies/min. (11" × 17"), 92 copies/min.
(5.5" × 8.5", 5.5" × 8.5"R)
Set quantity 1 to 9999sheets or 1 to 9999 sets
Memory 256 MB (RAM) + 30 GB (HDD)
Original document Type:sheets/ books (using original glass)
Size: 11.93" × 18.11" (303 mm × 460 mm)
maximum
Copy size Max. 12.36" × 18.11" (314 × 460 mm) –
3.94" × 5.83" (Min. 100 × 148 mm)
Image loss: leading and trailing edges
2.0 mm ± 2.0 mm, front and rear 1.5 mm
± 1.5 mm
Tray capacity Bypass tray: 150sheets (21 lb. paper)
Main body trays 1 and 2 (universal tray):
500sheets (21 lb. paper)
Main body trays 3 (universal tray):
1,000sheets (21 lb. paper)
Warm-up time Approx. 5.5 minutes
First-page copy time Approx. 3.1 seconds (8.5"x11")
Sound power level Main body: 79 dB (operating)/
58 dB (standby)
Power requirements AC 208–240 V, 16 A, 60 Hz
Power consumption 3.66 KW or less (with full options)
Weight Approx. 628.3 lbs. (Main body + ADF)
Dimensions Main body + ADF
39.25" (W)x30.7" (D)x47.4" (H)
Main body + ADF + LU-407
+ FS-611 + MK-721 + TU-502
132.75" (W)x30.7" (D)x47.4 (H)
Space requirements Main body + ADF + LU-407
+ FS-611 + MK-721 + TU-502
144.6" (W)x76" (D)
7.87" (200 mm) or more on the back
5.91" (100 mm) or more on both sides
Duty Cycle
Up to 750,000. Maximum monthly print volume
supported under standard vendor supplied service.
Defines the upper end of the expected customer volume
for the device. Customers should consider multiple
machines if average monthly volume approaches duty
cycle on a continual basis.
4/2009

2
Konica Minolta bizhub PRO 950
Specification & Installation Guide
Space Requirements
Allow sufficient space for facilitating copy operation, changing parts, and periodic inspection.
Leave adequate space behind the machine to let hot air out from the rear fan.
The whole machine can weigh up to 1134.1 lb., depending on the combination of options.
Be sure to choose a level and solid floor for the installation place.
Unit:inches (mm)
bizhub PRO 950 + FS-528 + LU-407
81.4 (2066)
93.2 (2366)
47.4
(1203)
39.0
(990)
5.9
(150)
4.6 (116)
26.6
(675)
38.6
(980)
16.1
(410) 33.1
(840)
17.1
(435)
7.2 (183)
5.9
(150)
27.2
(690)
55.9
(1420)
63.1
(1603)
37.4
(950) 30.7 (780) 7.9
(200)
76.0 (1930)
11.6
(295)
109.1 (2770)
97.3 (2470)
bizhub PRO 950 + FS-528 + PI-506 + ZU-607 + LU-408
63.1
(1603)
55.9
(1420)
27.4
(695)
7.2 (183)
5.9
(150)
20.9
(530)
Unit:inches (mm)
38.6
(980)
26.6
(675)
6.6 (169)
4.6 (116)
5.9 (150)
15.8
(400)
47.4
(1203)
16.1
(410)
33.1
(840)
26.4
(670)
38.6
(980)
11.6
(295)
26.6
(675)
5.9
(150)
4.6 (116)
17.1
(435)
81.4 (2066)
63.1
(1603)
93.2 (2366)
55.9
(1420)
27.2
(690)
39.0
(990)
47.4
(1203)
7.2 (183)
bizhub PRO 950 + FS-611 + LU-407
76.0 (1930)
30.7(780)
37.4
(950)
7.9
(200)
Unit:inches (mm)
16.1
(410) 33.1
(840)
5.9
(150)

Konica Minolta bizhub PRO 950
Specification & Installation Guide
3
Space Requirements continued
15.8
(400)
22.1
(562)
50.4 (1280) 26.4
(670)
132.7 (3369)
144.5 (3669)
6.6(169)
35.4 (899)
Unit:inches (mm)
bizhub PRO 950 + FS-611 + PI-506 + ZU-607 + LU-408 + MK-721 + TU-502
5.9 (150) 4.6 (116)
7.2 (183)
63.1
(1603)
55.9
(1420)
38.6
(980)
20.9
(530)
5.9 (150)
33.1
(840)
16.1
(410)
26.6
(675)
47.4
(1203)
27.4
(695)
Environmental Requirements
Temperature 50° to 86° F
Humidity 10–80% RH
Standby Noise 58 dBA
Operating Noise 79 dBA
Ozone Emission < 0.02 mg/m3
Electrical Requirements
Line Options Dedicated NEMA Diagram for 6-20R
Voltage 208-240V AC
Amperage 16 A
Cycles 60 Hz
NEMA Part No. 6-20R
Cord Length: 7. 5 f t .
Note: The main electrical outlet must be located within 7.5 feet from the right rear corner of the
bizhub PRO 950.
Operation Precautions
To ensure the optimum performance of this machine,
observe the precautions described below.
Power source
The power source requirements are as follows:
• Voltage: 208V to 240V AC
• Frequency: 60Hz
qUse a power source with as little voltage
or frequency fluctuations as possible.
Operating environment
The environmental requirements for correct operation
of the machine are as follows:
• Operating temperature: 50°F to 86°F
• Humidity: 10% to 80%
Storage of copies
To store copies, follow the recommendation listed below:
• Copies that are to be kept for a long time should
be stored where they are not exposed to light or high
temperature in order to prevent them from fading
or sticking together.
• Adhesive that contains solvent (e.g., spray glue)
may dissolve the toner on copies.

4
Konica Minolta bizhub PRO 950
Specification & Installation Guide
Component Considerations
ADF
Feeding speed Single-sided: 95sheets/min. (8.5"x11")
Double-sided: 68sheets/min. (8.5"x11")
Document types Plain paper, 14 to 35 lb. (130 g/m2)
(14 to 53 lb. using Single Feed mode for single-sided original)
Document sizes Max. 11.69"x17" (297 mmx431.8 mm)
Min. 5.04"x5.5" (128 mmx139.7 mm)
Detectable sizes for Auto Paper mode: 11"x17"L, 8.5"x14"L,
8.5"x11"L/P, 5.5"x8.5"L/P, A3L, B4L, A4L/P, B5L/P, B6L
Available to scan mixed originals of AB sizes and inch sizes
Feeder capacity Max. 100sheets (21 lb.)
Document insertion Automatic feed
Weight Approx. 48.5 lb.
Dimensions 25.6" (W) x 22.5" (D) x 6.7" (H)
Power source Supplied from main body
Finisher FS-528
Type Stapler finisher
Mountable options: Z folding unit, punch kit, post inserter
Exit trays Primary (main) tray
Secondary (sub) tray (for straight delivery only)
Function Straight delivery: Output sorted/grouped sets normally to the primary
(main) tray or secondary (sub) tray.
Offset delivery: Output sorted/grouped sets to the primary (main) tray,
having each set offset by approx. 30 mm upon exit.
Staple delivery: Output stapled sets to the primary (main) tray
Paper types Secondary (sub) tray: 11 to 80 lb. bond (300 g/m2)
Primary (main) tray: 14 to 80 lb.; 15 to 65 lb. (244 g/m2) for Staple
Paper sizes See paper section for details.
Stapler capacity 100sheets max. (15 to 21 lb. paper) except for A3L
and 11" x 17"L/ 50sheets max. (22 to 28 lb. paper)
Staples in cartridge 5,000 staples
Dimensions 17.4" (W)* x 25.8" (D) x 39" (H)
Weight Approx. 130 lb.
Power source Supplied from main body
* Effective size (width including Primary (main) tray) will be 27 in./32.5 in. (with the tray edge extended).

Konica Minolta bizhub PRO 950
Specification & Installation Guide
5
Component Considerations
Finisher FS-611
Type Stapler finisher with folding function
Mountable options: Z folding unit, punch kit, post inserter,
trimmer unit
Exit trays Primary (Main) tray (for finished output)
Secondary (Sub) tray (for unfinished output)
Folding mode tray (for folded output)
Function Straight delivery: Output unfinished sets normally to the primary
(main) tray
Offset delivery: Output sorted/grouped sets to the primary (main) tray,
having each set offset by approx. 30 mm upon exit.
Sub tray delivery: Output unfinished sets normally to the secondary
(sub) tray
Staple delivery: Output stapled sets to the primary (main) tray
Fold & Staple delivery: Output stapled (2 positions in the center) and
folded sets to the folding mode tray
Multi Half Fold delivery: Output folded sets to the folding mode tray
Multi Tri-Fold delivery: Output tri-fold (up to 3sheets) sets to the
folding mode tray
Paper types Secondary (sub) tray: 11 to 80 lb. bond (300 g/m2)
Primary (main) tray: 14 to 80 lb.; 14 to 28 lb. for Staple
Folding mode tray: 17 to 28 lb. for Fold & Staple and Multi Half Fold;
17to 21 lb. (1 to 3sheets)/ 22 to 28 lb. (1 sheet) for Multi Tri-Fold
Paper sizes See paper section for details.
Stapler capacity 50sheets max. (21 lb. paper) or 5.5 mm thick or less
Staples in cartridge 5,000 staples
Dimensions 16.2" (W)* x 25.8" (D) x 39"(H)
Weight Approx. 150 lb.
Power source Supplied from main body
*Effective size (width including primary (main) tray) will be 26.6 in./31.2 in. (with the tray edge extended).
Punch Kit PK-505
Function Punching file holes in copies
Number of punch holes 2 holes or 3 holes
Hole diameter 0.315"x0.006" (8.0 ± 0.15 mm)
Hole pitch 2 holes: 2.756" ± 0.020" (70 ± 0.5 mm)
3 holes: 4.252" ± 0.020" (108 ± 0.5 mm)
Paper types Plain paper: 16 to 24 lb.
Thick paper: 25 to 35 lb. (130 g/m2)
Special paper: OHP transparencies, labels
Paper sizes 2 holes: 11"x17"L, 8.5"x14"L, 8.5"x11"L/P, 5.5"x8.5"L/P,
A3L, B4L, A4L/P, B5L/P, A5L/P
3 holes: 11"x17"L, 8.5"x11"L, A3L, B4L, A4P, B5P
Dimensions 5.8" (W) x 20" (D) x 4.8" (H)
Weight Approx. 6.6 lb.
Power source Supplied from finisher

6
Konica Minolta bizhub PRO 950
Specification & Installation Guide
Component Considerations
Post Inserter PI-506
Function Cover sheet feeding into Finisher FS-528/FS-611
Structure Double paper feeding unit (upper and lower)
Cover sheet types 14 to 53 lb. bond (200 g/m2)
Special paper: OHP transparencies
Cover sheet sizes See paper section for details.
Stack capacity 200sheets max. or 30 mm thick or less
Dimensions 20.1' (W) x 24.4" (D) x 8.7" (H)
Weight Approx. 23 lb.
Power source Supplied from finisher
Large Capacity Unit LU-407
Function Paper feeding into main body
Paper capacity 4,500sheets (21 lb. paper)
Paper sizes See paper section for details.
Paper types 11 to 80 lb. bond (300 g/m2)
With paper type specified as Embossed: 14 to 57 lb. bond
Dimensions 16.9" (W) x 25.2" (D) x 27.2" (H)
Weight Approx. 66 lb.
Power source Supplied from main body
Large Capacity Unit LU-408
Function Paper feeding into main body
Paper capacity 4,000sheets (21 lb. paper)
Paper sizes See paper section for details.
Paper types 11 to 80 lb. bond (300 g/m2)
With paper type specified as Embossed: 14 to 57 lb. bond
Dimensions 26.4" (W) x 25.2" (D) x 27.4" (H)
Weight Approx. 92.6 lb.
Power source Supplied from main body

Konica Minolta bizhub PRO 950
Specification & Installation Guide
7
Component Considerations
Z Folding Unit ZU-607
Function Punching file holes and Z-folding the output copies
Number of punch holes 2 or 3 holes
Hole diameter 0.315" ± 0.020" (8.0 ± 0.5 mm)
Hole pitch 2 holes: 2.756" ± 0.020" (70 ± 0.5 mm)
3 holes: 4.252" ± 0.020" (108 ± 0.5 mm)
Paper types in Punch mode 17 to 24 lb. bond
Paper sizes in Punch mode See paper section for details.
Fold types Z-fold, Half fold (8.5"x14" only)
Fold position (width from 11x17"L: 8.46" (215 mm) or less
the edge to the first fold) 8.5"x14"L: 10.30" (261.6 mm) or less
A3L: 8.23" (209 mm) or less
B4L: 7.13" (181 mm) or less
Paper type in Z-Fold mode Plain paper: 16 to 24 lb. bond
Paper sizes in Z-Fold mode 11"x17"L, 8.5"x14"L, A3L, B4L
Paper sizes other than listed above will be output without any fold.
Dimensions 6.7" (W) x 26" (D) x 36.6" (H)
Weight Approx. 83.8 lb.
Power source Supplied from an outlet
Trimmer Unit TU-502
Function Trimming the end of booklet
Trimming width 0.39" (10 mm) or less
Number of trimmedsheets 40sheets max. (21 lb. paper) in Fold & Staple mode
(20-sheet-folded booklet or 19-sheet-folded booklet with 53 lb.
(200 g/m2) paper cover)
6sheets max. (21 lb. paper) in Multi Half Fold mode
(3-sheet-folded booklet)
Paper types 15 to 28 lb. bond (Can be trimmed with a sheet of 53 lb. cover paper)
Paper sizes See paper section for details.
Dimensions 45" (W) x 24" (D) x 22.1" (H)
Weight Approx. 150 lb.
Power source Supplied from an outlet
Other Accessories
PostScript Kit PS-504
Mount Kit MK-721
Staple Kit SK-701
Staple Kit MS-5C
Toner Recycle Cut Kit RC-501 (Available as service parts)
These specifications are subject to change without notice.

8
Konica Minolta bizhub PRO 950
Specification & Installation Guide
Paper Information
This machine is equipped with the following trays
for loading copy paper:
• Trays 1, 2, and 3 (Main body trays)
• Tray 4 (Large capacity unit LU-407/LU-408)
• Bypass Tray
Also, the following equipment is provided for conveying/
processing/delivering copies:
• ADU (Automatic Duplex Unit)
• Finisher (FS-528/FS-611)
• Post inserter (PI-506)
• Punch kit (PK-505)
• Z folding unit (ZU-607)
• Trimmer unit (TU-502)
Paper Weight
Paper Trays Paper Weight
Tray 1, 2 and 3
(Main body trays)
11 to 57 lb. bond
Bypass Tray 11 to 65 lb. bond
Tray 4 (Large Capacity Unit
LU-407/LU-408)
11 to 80 lb. bond
Post Inserter PI-506
Upper/Lower tray (option
for Finisher FS-528/FS-611)
14 to 53 lb. bond
Equipment Paper Weight
Automatic Duplex Unit 15 to 57 lb. bond
Finisher FS-528 Secondary
(sub) tray
11 to 80 lb. bond
Primary
(main) tray
14 to 80 lb. bond
Staple: 14 to 65 lb. bond
Finisher FS-611 Secondary
(sub) tray
11 to 80 lb. bond
Primary
(main) tray
14 to 80 lb. bond
Staple: 14 to 28 lb. bond
Can be stapled with up to two
coversheets (53 lb.) attached.
Folding
mode tray
Fold & Staple: 17 to 28 lb. bond
Can be saddle-stitched with
a cover sheet (53 lb.) attached.
Multi Half Fold: 17 to 28 lb. bond
Multi Tri-Fold of 1 sheet:
22 to 28 lb. bond
Multi Tri-Fold of 1 to 3sheets:
17to 21 lb. bond
Punch Kit PK-505
(option for Finisher
FS-528/FS-611)
17 to 35 lb. bond
Z Folding Unit ZU-607 Z-Fold: 15 to 24 lb. bond
Punch: 17 to 24 lb. bond
Trimmer Unit TU-502 15 to 28 lb. bond
Can be trimmed with a cover
sheet (53 lb.) attached.
NOTE: Be sure to use paper only of the weight specified for the tray; otherwise copy
quality may be deteriorated ormachine trouble may occur.
DETAIL: The setting or registration of paper weight to be specified for each paper
tray is available in the Paper Setting from the Copy Screen or from the Machine
Status Screen. Asto the Paper Setting from the Machine Status Screen, see POD
Administrator’s Reference.
Selecting [Emboss] as paper type for trays 1 to 4 and bypass tray, available setting range
will be limited to 14 to57 lb. for all trays.

Konica Minolta bizhub PRO 950
Specification & Installation Guide
9
Paper Tray/Exit Tray Capacity
Paper Trays Capacity
Tray 1/2 (Main body tray) 500sheets (21 lb.)
Tray 3 (Main body tray) 1,000sheets (21 lb.)
Bypass Tray 150sheets (21 lb.)
1 sheet each for OHP
transparencies
Tray 4
(Large Capacity Unit LU-407)
4,500sheets (21 lb.)
Tray 4
(Large Capacity Unit LU-408)
4,000sheets (21 lb.)
Post Inserter PI-506 Upper/
Lower tray (option for Finisher
FS-528/FS-611)
200sheets (21 lb.)
or within 30 mm thick
Equipment Capacity
Automatic Duplex Unit Unlimited
Finisher FS-528 Secondary
(sub) tray
200sheets (21 lb.)
Primary
(main) tray
(normal)
750sheets (21 lb.)
(5.5"x8.5"L/P, A5L/P, B6L)
3,000sheets (21 lb.)
(8.5"x11"L/P, 9"x11"P,
A4L/P, B5L/P)
1,500sheets (21 lb.) (11"x17"L,
8.5"x14"L, SRA4L, A3L,
B4L, Foolscap, wide paper)
Primary
(main) tray
(Staple)
Max. 100sheets (21 lb.) per set
Adjust the set count according
to the number of stapledsheets.
Finisher FS-611 Secondary
(sub) tray
200sheets (21 lb.)
Primary
(main) tray
(normal)
500sheets (21 lb.)
(5.5"x8.5"L/P, A5L/P, B6L)
2,500sheets (21 lb.)
(8.5"x11"L/P, 9"x11"P,
A4L/P, B5L/P)
1,500sheets (21 lb.) (11"x17"L,
8.5"x14"L, SRA4L, A3L,
B4L, Foolscap, wide paper)
Primary
(main) tray
(Staple)
Max. 50sheets
(14 to 21 lb.) per set
Max. 30sheets
(22 to 28 lb.) per set
Adjust the set count according
to the number of stapledsheets.
continued
Equipment Capacity
Finisher FS-611
(continued)
Folding
mode tray
Max. folded & stapledsheets:
20sheets (17 to 28lb.)/
19sheets (17 to 28 lb.)/
1 sheet (53 lb.)/
Multi Half Fold:
33 sets for 3-sheet-folded
booklet (99sheets, 396 pages)
(25 sets for 8.5"x11"L, A4L)
Fold & Staple:
20 sets for 5-sheet-folded
booklet (100sheets, 400 pages)
(15 sets for 8.5"x11"L, A4L)
Fold & Staple:
5 sets for 20-sheet-folded
booklet (100sheets, 400 pages)
Max. foldedsheets in Multi
Tri-Fold: 3sheets (17 to 21lb.
bond)/1 sheet (22 to 28 lb. bond)
Multi Tri-Fold: 50 sets for
1-sheet-folded set
Z Folding Unit ZU-607 Punch: Unlimited (operated
for each one of output sheets)
Z-Fold: 1 sheet only
Up to 5 Z-folded sheets can
be included in a stapled set.
See the table on page 10 for details of Z-folded
and non-folded sheet count in a stapled set,
aswell as the primary tray capacity.
Punch Kit PK-505 (option
for Finisher FS-528/FS-611)
Unlimited (operated for
each one of output sheets)
DETAIL: Output capacity of Finisher FS-528 may vary depending on the paper type.
NOTE: Primary (main) tray capacity depends on the paper size and number of
stapled sheets. See the table below for guidelines.
Primary (Main) Tray Capacity
in Staple Mode Using Finisher FS-528
No. of Stapled
Sheets
8.5"x11"L/P, 5.5"x8.5"P
(B4L, A4L/P, B5P, A5P)
11"x17"L
(A3L)
2 – 9 100 Sets 50 Sets
10 – 20 50 50
21 – 30 30 30
31 – 40 25 25
41 – 50 20 20
51 – 60 15 —
61 – 100 10 —

10
Konica Minolta bizhub PRO 950
Specification & Installation Guide
Paper Tray/Exit Tray Capacity continued
Primary (Main) Tray Capacity
in Staple Mode Using Finisher FS-611
No. of Stapled
Sheets
8.5"x11"L/P, 5.5"x8.5"P
(B4L, A4L/P, B5P, A5P)
11"x17"L
(A3L)
2 – 9 100 Sets 50 Sets
10 – 20 50 50
21 – 30 30 30
31 – 40 25 25
41 – 50 20 20
NOTE: See the following tables for tray capacity in Z-Fold with Staple mode.
Primary (Main) Tray Capacity in Z-Fold
with Staple Mode Using Finisher FS-528/FS-611
Available Sheet Count
in One Stapled Set Primary (Main)
Tray Capacity
Z-Folded Sheets Regular Sheets
1 Sheet 1 – 40 Sheets 20 Stapled Sets
2 Sheets 0 – 30 10
3 0 – 20 4
4 0 – 10 3
502
6 or more Staple is unavailable with Z-Fold

Konica Minolta bizhub PRO 950
Specification & Installation Guide
11
Paper Size
Note: The machine will automatically detect an appropriate standard size
for trays 1 to 3 and bypass tray specified as Standard in Paper Setting.
Wide paper is not fixed in size. When using wide paper, be sure to specify
actual dimensions in Size Setting.
Paper Trays Available Size
Tray 1, 2 and 3
(Main body trays)
STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
9"x11"P, Foolscap, 5.5"x8.5"P, SRA4L, A3L,
B4L*, A4L/P, B5L/P*, A5P
*B4 and B5 are JIS sizes. To change them to ISO sizes, contact
your service representative.
Available to detect A5P instead of 5.5"x8.5"P.
Available to detect A4Linstead of 8.5"x11"L.
Available to detect Foolscap or SRA4Linstead
of 8.5"x14"L.
Available to detect 9"x11"L instead of 8.5"x11"P.
CUSTOM:
Max. 12.36"x17.52" (314 mmx445 mm)
to min. 7.17"x5.51" (182 mmx140 mm)
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P, 5.5"x8.5"WP,
A3WL, B4WL, A4WL/P, B5WL/P, A5WP
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P, 5.5"x8.5"TP,
A3TL, B4TL, A4TL/P, B5TL/P, A5TP
TAB PAPER (Custom Size):
Max. 12.36"x17.52" (314 mmx445 mm)
to min. 7.17"x5.51" (182 mmx140 mm)
Bypass Tray STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
9"x11"P, Foolscap, 5.5"x8.5"L/P, SRA4L,
A3L, B4L*, A4L/P, B5L/P*, A5L/P, B6L
*B4
Land B5L/Pare JIS sizes. To change them to ISO sizes,
contact your service representative.
Available to detect A5L instead of 5.5"x8.5"P.
Available to detect A4L instead of 8.5"x11"L.
Available to detect Foolscap or SRA4L instead
of 8.5"x14"L.
Available to detect 9"x11"P instead of 8.5"x11"P.
Available to detect A5Lor B6Linstead
of 5.5"x8.5"L.
CUSTOM:
Max. 12.36"x18.11" (314 mmx460 mm)
to min. 3.94"x5.51" (100 mmx140 mm)
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P,
5.5"x8.5"WL/P, A3WL, B4WL, A4WL/P,
B5WL/P, A5WL/P
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P, 5.5"x8.5"TL/P,
A3TL, B4TL, A4TL/P, B5TL/P, A5TL/P
TAB PAPER (Custom Size):
Max. 12.36"x18.11" (314 mmx460 mm)
to min. 3.94"x5.51" (100 mmx140 mm)
Paper Trays Available Size
Tray 4
(Large Capacity
Unit LU-407)
STANDARD:
8.5"x11"P, 9"x11"P, A4P, B5P*, 8KP
* B5
Pis JIS size. To change it to ISO size, contact your service
representative.
CUSTOM:
Max. 12.36"x9.02" (314 mmx229 mm) to min.
9.84"x6.93" (250 mmx176 mm)
WIDE PAPER:
8.5"x11"WP, A4WP, B5WP
TAB PAPER:
8.5"x11"TP, A4TP, B5TP
TAB PAPER (Custom Size):
Max. 12.36"x9.02" (314 mmx229 mm) to min.
9.84"x6.93" (250 mmx176 mm)
Tray 4
(Large Capacity
Unit LU-408)
STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
9"x11"P, Foolscap, SRA4L, A3L, B4L*,
A4L/P
* B4Lis JIS size. To change it to ISO size, contact your service
representative.
CUSTOM:
Max. 12.36"x18.11" (314 mmx460 mm)
to min. 7.68"x7.99" (195 mmx203 mm)
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P, A3WL, B4WL,
A4WL/P
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P, A3TL, B4TL,
A4TL/P
TAB PAPER (Custom Size):
Max. 12.36"x18.11" (314 mmx460 mm)
to min. 7.68"x7.99" (195 mmx203 mm)
continued

12
Konica Minolta bizhub PRO 950
Specification & Installation Guide
Paper Size continued
Equipment Available Size
Post Inserter PI-506
(option for Finisher
FS-528/FS-611)
Upper
Tray
STANDARD:
8.5"x11"L/P, 9"x11"P, 5.5"x8.5"P,
A4L/P, B5L/P
CUSTOM:
Max. 8.5"x11.7" (216 mmx297 mm)
to min. 7.17"x5.47" (182 mm x 139 mm)
WIDE PAPER:
8.5"x11"WL/P, 5.5"x8.5"WP,
A4WL/P, B5WL/P
TAB PAPER:
8.5"x11"TL/P, 5.5"x8.5"TP,
A4TL/P, B5TL/P
TAB PAPER (Custom Size):
Max. 8.5"x11.7" (216 mmx297 mm)
to min. 7.17"x5.83" (182 mm x 148 mm)
Lower
Tray
STANDARD:
12"x18"L, 11"x17"L, 8.5"x14"L,
8.5"x11"L/P, 9"x11"P, 5.5"x8.5"P,
SRA4L, A3L, B4L, A4L/P, B5L/P,
A5P
CUSTOM:
Max. 12.36"x18.03" (314 mmx458 mm)
to min. 7.17"x5.47" (182 mmx139 mm)
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P,
5.5"x8.5"WP, A3WL, B4WL,
A4WL/P, B5WL/P, A5WP
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P,
5.5"x8.5"TP, A3TL, B4TL, A4TL/P,
B5TL/P, A5TP
TAB PAPER (Custom Size):
Max. 12.36"x18.03" (314 mmx458 mm)
to min. 7.17"x5.83" (182 mmx148 mm)
Automatic Duplex Unit Max. 12.36"x18.11" (314 mmx460 mm)
to min. 3.94"x5.51" (100 mmx140 mm)
Tab paper cannot be used.
Finisher FS-528
Secondary
(sub) tray
STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
9"x11"P, Foolscap, 5.5"x8.5"L/P,
SRA4L, A3L, B4L, A4L/P, B5L/P,
A5L/P, B6L, A6L
CUSTOM:
Max. 12.36"x18.03" (314 mmx458 mm)
to min. 3.94"x5.83" (100 mmx148 mm)
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P,
5.5"x8.5"WP, A3WL, B4WL,
A4WL/P, B5WL/P, A5WP
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P,
5.5"x8.5"TP, A3TL, B4TL, A4TL/P,
B5TL/P, A5TP
TAB PAPER (Custom Size):
Max. 12.36"x17.52" (314 mmx445 mm)
to min. 7.17"x5.51" (182 mmx140 mm)
Equipment Available Size
Finisher FS-528
(continued)
Primary
(main)
tray
(normal)
STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
9"x11"P, Foolscap, 5.5"x8.5"P,
SRA4L, A3L, B4L, A4L/P, B5L/P,
A5P, B6L*1, A6L*1
*1 B6Land A6Lare available in straight delivery only.
CUSTOM*2:
Max. 12.36"x18.11" (314 mmx460 mm)
to min. 7.17"x5.83" (182 mmx148 mm)
*2 Max. 12.36"x18.11" (314 mmx460 mm) to min.
5.04"x5.83" (128 mmx148 mm) in straight delivery only.
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P,
5.5"x8.5"WP, A3WL, B4WL,
A4WL/P, B5WL/P, A5WP
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P,
5.5"x8.5"TP, A3TL, B4TL, A4TL/P,
B5TL/P, A5TP
TAB PAPER (Custom Size):
Max. 12.36"x18.03" (314 mmx458 mm)
to min. 7.17"x5.51" (182 mmx140 mm)
Primary
(main)
tray
(Staple)
STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
9"x11"P, Foolscap, 5.5"x8.5"P, SRA4L,
A3L, B4L, A4L/P, B5L/P, A5P
CUSTOM:
Max. 8.27"x11.7" (210 mmx297 mm)
to min. 7.17"x5.83" (182 mm x148 mm)
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P,
5.5"x8.5"WP, A3WL, B4WL,
A4WL/P, B5WL/P, A5WP
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P,
5.5"x8.5"TP, A3TL, B4TL, A4TL/P,
B5TL/P, A5TP
TAB PAPER (Custom Size):
Max. 8.27"x11.7" (210 mmx297 mm)
to min. 7.17"x5.83" (182 mm x148 mm)
Finisher FS-611 Secondary
(sub) tray
STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
9"x11"P, Foolscap, 5.5"x8.5"L/P,
SRA4L, A3L, B4L, A4L/P, B5L/P,
A5L/P, B6L, A6L
CUSTOM:
Max. 13.03"x17.63" (331 mmx448 mm)
to min. 3.94"x5.83" (100 mmx148 mm)
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P,
5.5"x8.5"WP, A3WL, B4WL,
A4WL/P, B5WL/P, A5WP
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P,
5.5"x8.5"TP, A3TL, B4TL, A4TL/P,
B5TL/P, A5TP
TAB PAPER (Custom Size):
Max. 13.03"x17.63" (331 mmx448 mm)
to min. 3.94"x5.83" (100 mmx148 mm)
continued

Konica Minolta bizhub PRO 950
Specification & Installation Guide
13
Paper Size continued
Equipment Available Size
Finisher FS-611
(continued)
Primary
(main)
tray
(normal)
STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
9"x11"P, Foolscap, 5.5"x8.5"L/P*1,
SRA4L, A3L, B4L, A4L/P, B5L/P,
A5L/P*1, B6L*1
*1 5.5"x8.5"L , A5Land B6Lare available
in straight delivery only.
CUSTOM*2:
Max. 12.36"x18.03" (314 mmx458 mm)
to min. 7.17"x5.83" (182 mmx148 mm)
*2 Max. 12.36"x18.03" (314 mmx458 mm) to min.
5.04"x5.83" (128 mmx148 mm) in straight delivery only.
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P,
5.5"x8.5"WP, A3WL, B4WL,
A4WL/P, B5WL/P, A5WP
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P,
5.5"x8.5"TP, A3TL, B4TL, A4TL/P,
B5TL/P, A5TP
TAB PAPER (Custom Size):
Max. 12.36"x18.03" (314 mmx458 mm)
to min. 7.17"x5.83" (182 mmx148 mm)
Primary
(main)
tray
(Staple)
STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
9"x11"P, Foolscap, 5.5"x8.5"P, SRA4L,
A3L, B4L, A4L/P, B5L/P, A5P
CUSTOM:
Max. 12.36"x18.03" (314 mmx458 mm)
to min. 7.17"x5.83" (182 mmx148 mm)
WIDE PAPER:
11"x17"WL, 8.5"x11"WL/P,
5.5"x8.5"WP, A3WL, B4WL,
A4WL/P, B5WL/P, A5WP
TAB PAPER:
11"x17"TL, 8.5"x11"TL/P,
5.5"x8.5"TP, A3TL, B4TL, A4TL/P,
B5TL/P, A5TP
TAB PAPER (Custom Size):
Max. 12.36"x18.03" (314 mmx458 mm)
to min. 7.17"x5.83" (182 mmx148 mm)
Folding
mode
tray
STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L,
SRA4L, A3L, B4L, A4L(8.5"x11"L
and A4Lonly for Multi Tri-Fold)
CUSTOM:
Max. 12.36"x18.03" (314 mmx458 mm)
to min. 8.27"x11.02" (210 mmx280 mm)
WIDE PAPER:
11"x17"WL, 8.5"x11"WL, A3WL,
B4WL, A4WL
continued
Equipment Available Size
Z Folding Unit ZU-607 STANDARD:
11"x17"L, 8.5"x14"L*1, A3L, B4L*2
*1 Double fold for 8.5"x14"Lonly. Any other sizes than
the above mentioned will be output without folded.
*2 Z-Fold and Staple modes are available in combination
for A3LandA4Lmixed, while they cannot be used for B4L
and B5Lmixed.
Trimmer Unit TU-502 STANDARD:
11"x17"L, 8.5"x14"L, 8.5"x11"L, SRA4L,
A3L, B4L, A4L
WIDE PAPER:
11"x17"WL, 8.5"x11"WL, SRA4WL, A3WL,
B4WL, A4WL
* Without Trimming selected, available sizes will be the same
as those in Folding mode tray.
Special Paper in Bypass Tray
Bypass tray accepts the following special paper type that cannot be loaded
in the main body trays.
• OHP transparencies
• Tracing paper
CAUTION: Do not use paper with staples or paper that conducts electricity (silver, carbon, etc.)
REMINDER: To avoid machine trouble, do not use heat-sensitive paper, colored OHP
transparencies, or paper specifically designed for ink-jet printer, such as photo-paper.
Auto Tray Switch Function
If the selected paper tray runs out of paper while a job is being printed and
a different paper tray is loaded with paper meeting the following conditions,
the other paper tray is automatically selected so printing can continue. If the
optional Large Capacity Unit LU-407 is installed, a maximum of 7,350 copies
can be made continuously. (The paper tray is automatically switched only
if the "ATS Permit" in Utility mode is set to "On".)
Operating Conditions
(Set the following condition at “02 Function Setting – 01 Feed Tray Setting”
in Utility mode.)
• Select the paper trays to be selected automatically by “01 Feed Tray
Auto Selection”.
• Select "On" at “02 ATS Permit”
• Select the paper type setting of the tray which is automatically selected
when ATS functions at “03 Auto Paper Type”
Load the following paper into the paper trays.
• The same size in the same orientation.
• The same paper type.
To Store Copy Paper
Observe the following precautions when storing the paper.
• Store paper in a cool, dry area. Using damp paper may cause
a paper misfeed.
• Keep partially used packages tightly wrapped during storage.
• Do not place paper packages vertically to store. Paper curl due
to vertical storage may cause paper misfeeds.

14
Konica Minolta bizhub PRO 950
Specification & Installation Guide
Original Information
When making copies, position the original into the ADF
or on the original glass. To copy originals that cannot be
positioned into the ADF, position them on the original glass.
Using Original Glass
Use the original glass when originals are not suitable
for use with the document feeder, e.g., when size
is incompatible, or when originals are folded, stapled,
torn, or in generally poor condition.
Unsuitable ADF originals
The following types of original should not be positioned
into the ADF, otherwise paper misfeeds, damage to the
original or machine trouble may occur.
• Wrinkled, folded, curled, or torn originals
• Highly translucent or transparent originals, such as
overhead transparencies or trace paper
• Coated originals such as carbon-backed paper
• Originals printed on paper thicker 53 lb. Bond (200 g/m2)
• Originals printed on paper thinner than 14 lb. Bond (50 g/m2)
• Originals that are bound, for example, with staples
or paper clips
• Originals that are bound in a book or booklet
• Originals that are bound together with glue
• Originals pages that have been cut or contain cutouts
• Label sheets
• Offset printing masters
• Originals with binder holes
• Originals that have just been printed with this machine
Specifications for originals using original glass
Item Description
Original size Max. 8.23"x16.54" (209 mmx420 mm)
Detectable original size 11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
5.5"x8.5"L/P
Original weight 15 lb. or less
Original thickness 1.2" or less
DETAIL: Detectable original size can be changed from Inch series to AB series, only A series,
or AB series and Inch series mixed by the administrator.
DETAIL: One of the small sizes A5L, B6L, 5.5"x8.5"L, A4P, and 8.5"x11"P
can be specified as a detectable size.
CAUTION: The original glass is fragile. Do not place heavy originals, or do not press
strongly when thick original is placed and is under pressure of ADF, otherwise the glass may
be broken and you may be injured.
ADF Originals
Following four modes are provided when using the ADF
to scan originals.
• Normal mode
• Mixed mode
• Z-Folded Original mode
• Single Feed mode
Specifications for each mode are described as follows.
DETAIL: Detectable original size can be selected from AB series, Inch series, only.
A series, and AB series and Inch series mixed by the administrator.
NORMAL MODE:
Item Description
Detectable original size 11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
5.5"x8.5"L/P, A3L, B4L, A4P,
B5L/P, Foolscap
Original weight 16 to 35 lb. Bond (50 g/m2to 130 g/m2)
Original size 5.0"x5.5" to 11.7"x17.0"
(128 mmx139.7 mm to 297 mmx431.8 mm)
Feeder capacity 100 sheets (21 lb. Bond)
Curling tolerance 10 mm or less
Original placement Face up
MIXED MODE: Use Mixed mode to copy mixed size originals.
Item Description
Detectable original
size
Two types of size combination are determined
by the ADF guide width.
11"x17"L, 8.5"x14"L, 8.5"x11"P, and
5.5"x8.5"Pmixed, 8.5"x14"L, 8.5"x11"L/P
and 5.5"x8.5"Pmixed.
Original weight 16 to 35 lb. Bond (50 g/m2to 130 g/m2)
Feeder capacity 100 sheets (21 lb. Bond)
Curling tolerance 10 mm or less
Original placement Face up
NOTE: See below for the guide width of each combination.
8.5"x
11"
5.5"x
8.5"
8.5"x11"
11"x17"
Guide
width Guide
width

Konica Minolta bizhub PRO 950
Specification & Installation Guide
15
ADF Originals continued
Z-FOLDED ORIGINAL MODE: Use Z-Folded Original mode to scan folded
originals without using the size detection sensor of the ADF.
Item Description
Detectable original
size
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
5.5"x8.5"L/P, A3L, B4L, A4P, B5L/P
Original weight 16 to 35 lb. Bond (50 g/m2to 130 g/m2)
Original size 5.0"x5.5" to 11.7"x17.0"
(128 mmx139.7 mm to 297 mmx431.8 mm)
Feeder capacity 100 sheets (21 lb. Bond)
Curling tolerance 10 mm or less
Original placement Face up; orientation same as copy paper
SINGLE FEED MODE: Use Single Feed mode to copy thick originals
to be fed one sheet at a time in the ADF.
Item Description
Detectable
original size
11"x17"L, 8.5"x14"L, 8.5"x11"L/P,
5.5"x8.5"L/P, A3L, B4L, A4P, B5L/P
Original weight 16 to 53 lb. Bond (50 g/m2to 200 g/m2)
Original size 5.0"x5.5" to 11.7"x17.0"
(128 mmx139.7 mm to 297 mmx431.8 mm)
Feeder capacity 1 sheet at a time
Curling tolerance 10 mm or less
Original placement Face up

16
Konica Minolta bizhub PRO 950
Specification & Installation Guide
Product Specifications
Type: Built-in box type for the Konica Minolta
bizhub PRO 950 main body
Functions
Resolution Printing System 600 x 600 dpi
Scanning Resolution 200 dpi/300 dpi/
400 dpi/600 dpi
Gradation Binary
Printable Area Margin 2.8 2 mm (left, right, top and
bottom without variation)
No. of Print 1 to 9999
Continuous 95 ppm (A4, 8.5 x 11)
Print Speed (From the 2nd and succeeding copies)
Printer Description PCL5r/6
Language PostScript3
Printer Driver PCL6 (KONICA MINOLTA product)
• Windows 2000 Professional
(SP3 later)/Server
• Windows XP Home Editions/
Professional (SP2 later)
• Windows Server 2003 Standard
• Windows Vista (all versions)
(include the XP (Professional)/
Server 2003/Vista x64)
POSTSCRIPT3 PLUG-IN DRIVER
(optional PS expansion kit required)
• Windows 2000 Professional
(SP3 later)/Server
• Windows XP Home Editions/
Professional (SP2 later)
• Windows Server 2003 Standard
• Windows Vista (all versions)
• Mac OS X 10.3/10.4/10.5
(include the Intel Mac 10.4/10.5)
(include the XP (Professional)/
Server 2003/Vista x64)
POSTSCRIPT3 PPD DRIVER
(optional PS expansion kit required)
• Windows 2000 Professional
(SP3 later)/Server
• Windows XP Home Editions/
Professional (SP2 later)
• Windows Server 2003 Standard
• Windows Vista (all versions)
• Mac OS X 10.3/10.4/10.5
(include the Intel Mac 10.4/10.5)
(include the XP (Professional)/
Server 2003/Vista x64)
Network Function
Printing Method Pserver (IPX/SPX)/LPD/LPR (TCP/IP)
IPP (TCP/IP)
AppleTalk (EtherTalk)
Bonjour (TCP/IP)
Web Service Print (TCP/IP)/NPrinter
RPrinter (IPX/SPX)
RAW Port (TCP/IP)
Print Utilities EMS Plug-in, PageScope Direct Print
(TIFF/PDF (PDF 1.6 support) Direct
Print utility)
Compliant Microsoft Internet Explorer 6 or later*
Web Browser recommended (JavaScript enabled)
Mozilla Firefox 1.0 or later
(JavaScript enabled, Cookies enabled)
Netscape Navigator 7.02 or later
(JavaScript enabled, Cookies enabled)
Flash Player Ver 7.0 or later (In the case
of seeing in Flash form)
* Microsoft XML Parser (MSXML)3.x must be installed when
using Internet Explorer 5.5.
Machine Data
CPU Pentium M 2.0 GHz
System Memory 2 GB
Host Interface Ethernet, USB
Power From main body (bizhub PRO 950)
Network Interface Ethernet
(1000Base-T/100Base-TX/10Base-T)
Frame Type IEEE 802.2/802.3/Ethernet II/
IEEE 802.3 SNMP
Network Connector RJ-45

Konica Minolta bizhub PRO 950
Specification & Installation Guide
17
Step 2b:
Additional Output Options
PI-506 Post Process Inserter (for either FS-611 or FS-528) TU-502 Trimmer (for FS-611) (requires MK-721 Mount Kit) PK-505 Punch Kit (for either FS-611 or FS-528) ZU-607 Z-Fold/Punch Kit (for either FS-611 or FS-528)
Step 3:
Connectivity Option
PS-504 Adobe PostScript Option
(Includes Adobe PS3 and PDF Direct Print)
Start:
bizhub PRO 950 Base Unit
bizhub PRO 950 comes standard with: EDH, 30 GB HD,
256 MB memory, Embedded Image Controller with 2 GB Memory and 80 GB HDD (includes PCL5e/XL (PCL6) and TIFF
Direct Print); Tray 1 (500 sheets), Tray 2 (500 sheets),
Tray 3 (1,000 sheets), Bypass (150 sheets), Total standard
paper capacity: 2,150 sheets (6,650 max).
Step 1:
Paper Supply Options
LU-407 Large Capacity Unit (4,500 sheets Letter Portrait) LU-408 Large Capacity Unit (4,000 sheets up to 12" x 18")
Step 2a:
Output Options (One of the following is required)
FS-528 Stapling Finisher
(Staple up to 100 sheets with staple cutting function)
- OR -
FS-611 Booklet Finisher
(50-sheet Stapling, Half-fold, Tri-fold, Saddle-stitch Booklets)
PostScript3 (Optional) 256 MB Memory (Standard)
FS-528 FS-611
LU-407 LU-408
4,000
4,500
30 GB HDD (Copier) (Standard)
PI-506
ZU-607
MK-721
TU-502
1
2
3
PK-505
500
5001,000
Image Controller (Standard) includes 2 GB Memory, 80 GB HDD, PCL
How to Build a System for the bizhub 950 Printer/Copier/Scanner (from start to finish)

18
Konica Minolta bizhub PRO 950
Specification & Installation Guide
ACCESSORIES ITEM NO. DESCRIPTION NOTES
BASE UNIT
bizhub PRO 950 A0Y5011 bizhub PRO 950
Digital Printer/Copier/Scanner
Includes EDH, 256 MB memory, 30 GB HDD, Embedded Image Controller with 2 GB
Memory, 80 GB HDD, PCL5e/XL (PCL6), TIFF Direct Print, Scan-to-HDD, Email, FTP,
SMB and Box; PC Drum, developer, Tray 1 (500 sheets), Tray 2 (500 sheets), Tray 3 (1,000
sheets), Bypass (150 sheets). Requires 220V, 20A power (NEMA receptacle# 6-20R).
OUTPUT OPTIONS
FS-611 A10VWY1 Booklet/Folding Finisher 50-sheet Stapling, Half-fold, Tri-fold, Saddle-stitch Booklets.
FS-528 A10UWY1 Multi-Stapling Finisher Staples up to 100 sheets with staple cutting function.
PI-506 A10YWY1 Post Process Inserter Add pre-printed covers/inserts post-process (for FS-611 or FS-528).
PK-505 15US Punch Kit Adds selectable 2/3-hole punch to FS-611 or FS-528.
Z U - 6 07 A111W Y2 Z- F o l d / Pu n c h K i t Adds Z-fold and selectable 2/3-hole punch to FS-611 or FS-528.
TU-502 A110WY1 Trimmer Unit Trims folded output from FS-611.
MK-721 A10WWY1 Mount Kit Enables attachment of TU-502 Trimmer.
PAPER SUPPLY OPTIONS
LU-407 A0Y6WY1 Large Capacity Unit 4,500 sheets (20-lb. bond) of letter portrait.
LU-408 A0Y7WY1 Large Capacity Unit 4,000 sheets (20-lb. bond) up to 12" x 18".
CONNECTIVITY OPTION
PS-504 A10R011 Adobe PostScript Option Includes Adobe PS3 and PDF Direct Print.
CONSUMABLES
CONSUMABLE ITEM NO. YIELD NOTES
TN911 Toner A0YP030 80,000 @ 6%
DV910 Developer 022B 1,000,000 @ 6%
DR910 Drum 022H 1,000,000 @ 6%
SK-701 Staple Kit 14YJ 5,000 x 3 for FS-528
MS-SC Staples 4448121 5,000 x 3 for FS-611
Accessory Options for bizhub 950 Printer/Copier/Scanner
