Konica Minolta Magicolor 5430 DL User manual

magicolor 5430 DL
Reference Guide
®
4138-7744-01A
1800761-001A

Copyright Notice
The digitally encoded software and publication included with your printer are
Copyrighted © 2004 by KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.,
Marunouchi Center Building, 1-6-1 Marunouchi, Chiyoda-ku, Tokyo, 100-0005,
Japan. All Rights Reserved.
This software may not be reproduced, modified, displayed, transferred, or copied in
any form or in any manner or on any media, in whole or in part, without the express
written permission of KONICA MINOLTA PRINTING SOLUTIONS U.S.A., INC.
No part of this publication may be reproduced, stored in a retrieval system, or trans-
mitted in any form or by any means, electronic, mechanical, photocopying, record-
ing, or otherwise, without the prior written permission of KONICA MINOLTA. The
information contained in this guide is intended for use with the KONICA MINOLTA
magicolor 5430 DL printers only.
Trademarks
KONICA MINOLTA and the KONICA MINOLTA logo are trademarks or registered
trademarks of KONICA MINOLTA HOLDINGS, INC.
magicolor is a trademark or registered trademark of KONICA MINOLTA PRINTING
SOLUTIONS U.S.A., INC.
Notice
KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. reserves the right to make
changes to this guide and to the equipment described herein without notice. Consid-
erable effort has been made to ensure that this manual is free of inaccuracies and
omissions. However, KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. makes
no warranty of any kind including, but not limited to, any implied warranties of mer-
chantability and fitness for a particular purpose with regard to this manual.
KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. assumes no responsibility
for, or liability for, errors contained in this manual or for incidental, special, or conse-
quential damages arising out of the furnishing of this manual, or the use of this man-
ual in operating the equipment, or in connection with the performance of the
equipment when so operated.

Contents
Contents i
1 Operation on Mac OS X .................................................................................... 1
System Requirements for the Printer Driver 2
Installing the Printer Driver 3
Installing Ghostscript 3
Installing the magicolor 5430 DL Printer Driver 7
Print Center Settings 12
When using a USB connection 12
When using a network connection 15
Rendezvous Setting 15
IP Printing Setting 17
Specifying Port 9100 19
Selecting Print Options 22
Uninstalling the Printer Driver 24
Specifying Page Setup Settings 26
Page Attributes Options 27
Custom Paper Size Options 28
Summary 29
Specifying Print Settings 30
Print Dialog Box 31
Common buttons 32

Contentsii
Copies & Pages 32
Layout 33
Duplex 34
Output Options 35
Paper Feed 36
Printer Features 37
Basic Features 38
Color Matching Options 39
Watermark Orientation 40
Watermark Selection 41
Watermark Setting 42
Summary 43
Checking Print Jobs 44
Deleting a Print Job 44
Troubleshooting 45
2 Understanding the Network Configuration Menus .......................................47
Network Menu 48
Location within the Configuration Menu 48
Accessing the Network Menu 49
Using the Network Menu Options 49
DHCP/BOOTP 49
IP Address 50
Subnet Mask 50
Gateway 50
Mac Address 51
HTTP 51
SNMP 51
3 Network Printing in a Windows Environment ...............................................53
Network Connection 54
Theory 54
Supported Environments 54
Making the Connection 55
Ethernet Interface 55
Using DHCP 55
Setting the Address Manually 56
Network Printing 59
BOOTP 59
DHCP 59
HTTP 59
IPP 60
LPD/LPR 60
SLP 60
SNMP 61
TCP/IP 61

Contents iii
Printing via IPP (Internet Printing Protocol) – Windows Server 2003/XP/
2000 62
Adding an IPP Port 62
Printing via IPP (Internet Printing Protocol) – Windows Me/98SE 65
Adding an IPP port 65
Printing via IPP if the Printer Driver is Already Installed 68
4 Using PageScope Web Connection .............................................................. 69
About PageScope Web Connection 70
Display Language 70
Requirements 70
Setting Up the Printer Web Page 71
Determining the Printer Name 71
Setting Up Your Browser Software 71
Internet Explorer (version 6.0 for Windows) 72
Netscape Navigator (version 7.1) 72
Safari (version 1.1) 73
Understanding the PageScope Web Connection Window 74
Navigation 74
Current Status 75
User Mode 75
Administrator Mode 75
Viewing Printer Status 76
System Page 76
Summary (shown above) 77
Details 78
Counter 82
Online Assistance 83
Job Page 84
Active Job (shown above) 84
Print Page 86
Test Print (shown above) 86
Configuring the Printer 87
System Page 87
User Choice (shown above) 87
Password 89
Preference 91
Online Assistance 93
Network 95
Configuration (shown above) 95

1
Operation on
Mac OS X

System Requirements for the Printer Driver2
System Requirements for the Printer Driver
Before installing the printer driver, make sure that your system meets the fol-
lowing system requirements.
Computer Apple Macintosh computer with a PowerPC
G3 or later processor (PowerPC G4 or later is
recommended)
Connecting the computer
and printer
USB connection, Network connection
(10Base-T/100Base-TX)
Operating system Mac OS X v10.2 or later
RAM More than OS recommendation
Available disk space 256 MB or more (for storing images)

Installing the Printer Driver 3
Installing the Printer Driver
" You must have administrator privileges in order to install the printer
driver.
" Before proceeding with the installation, be sure to exit all running
applications.
Installing Ghostscript
You need to install Ghostscript before installing the printer driver. The follow-
ing procedure is not required with Mac OS X 10.3 or later.
1The latest version of Ghostscript can be downloaded from <http://
www.cups.org/ghostscript.php>.
" Here we explain how to install the software from the
espgs-7.05.5-0.ppc.dmg disk image file.
2Double click the espgs-7.05.5-0.ppc.dmg file.
The disk image Install ESP Ghostscript 7.05.5 appears on the desktop.
3Double click the ESP Ghostscript.mpkg package file in the disk image.
4Enter the administrator user name and password in the Authenticate dia-
log box, and then click OK.

Installing the Printer Driver4
5Click Continue.
6Check the details of the license agreement and click Continue.

Installing the Printer Driver 5
7Click Agree in the confirmation dialog box, if you agree to the terms of the
license.
8In the Select a Destination page, select the disk in which you wish to
install the software, and then click Continue.

Installing the Printer Driver6
9Click Install in the Easy Install page.
Installation starts.
10 After the installation has been completed, click Close.
This completes the installation of Ghostscript.

Installing the Printer Driver 7
Installing the magicolor 5430 DL Printer Driver
" The procedure for installing the printer driver on Mac OS 10.2.x is
described below. The following procedure or some steps may be dif-
ferent depending on the version of the operating system being used.
Complete the installation according to the instructions in the dialog
boxes that appear.
1Insert the magicolor 5430 DL Utilities & Documentation CD-ROM in the
CD-R/DVD drive of your Macintosh.
2Double click the magicolor5430DL-x.x.x-ppc.dmg disk image file.
The disk image KONICA MINOLTA magicolor 5430 DL appears on the
desktop.
3Double-click the magicolor5430DL.pkg package file in the disk image.
The installer for the printer driver starts up.

Installing the Printer Driver8
4Enter the administrator user name and password in the Authenticate dia-
log box, and then click OK.
5Click Continue.

Installing the Printer Driver 9
6Check the information in the Read Me, and then click Continue.
7Check the details of the license agreement, and then click Continue.

Installing the Printer Driver10
8Click Agree in the confirmation dialog box if you agree to the terms of the
license.
9In the Select a Destination page, select the disk in which you wish to
install the software, and then click Continue.

Installing the Printer Driver 11
10 Click Install in the Easy Install page.
Installation starts.
11 After the installation has been completed, click Close.
This completes the installation of the magicolor 5430 DL printer driver.

Print Center Settings12
Print Center Settings
When using a USB connection
1Use the USB cable to connect the printer to your computer.
2Check that the printer is turned on, and then restart the computer.
3Open Print Center, which can be accessed by clicking Macintosh HD,
then Applications, then Utilities.
4In the Printer List, click Add while pressing the Option key in the key-
board.
5Select Advanced from the pop-up menu.

Print Center Settings 13
6Select mc5430DL from the Device pop-up menu.
" If mc5430DL does not appear, check that the printer is turned on and
the USB cable is connected, and then restart the computer.
7Select KONICA MINOLTA from the Printer Model pop-up menu.
8Select KONICA MINOLTA magicolor 5430 DL in the Name list.

Print Center Settings14
9Click Add.
The new printer appears in the Printer List screen.
