magicolor 2200
Repacking Guide
®
1760337-001A

Trademarks
The following are trademarks or registered trademarks of MINOLTA-QMS, Inc.: MINOLTA-
QMS, the MINOLTA-QMS logo, Crown, and magicolor. Minolta is a trademark of Minolta
Co., Ltd.
Other product names mentioned in this guide may also be trademarks or registered
trademarks of their respective owners.
Proprietary Statement
The digitally encoded software included with your printer is Copyrighted © 2000 by
MINOLTA-QMS, Inc. All Rights Reserved. This software may not be reproduced, modified,
displayed, transferred, or copied in any form or in any manner or on any media, in whole or
in part, without the express written permission of MINOLTA-QMS, Inc.
Copyright Notice
This guide is Copyrighted © 2000 by MINOLTA-QMS, Inc., One Magnum Pass, Mobile, AL
36618. All Rights Reserved. This document may not be copied, in whole or part, nor
transferred to any other media or language, without written permission of MINOLTA-QMS,
Inc.
Notice
MINOLTA-QMS, Inc. reserves the right to make changes to this guide and to the equipment
described herein without notice. Considerable effort has been made to ensure that this guide
is free of inaccuracies and omissions. However, MINOLTA-QMS, Inc. makes no warranty of
any kind including, but not limited to, any implied warranties of merchantability and fitness
for a particular purpose with regard to this guide. MINOLTA-QMS, Inc. assumes no
responsibility for, or liability for, errors contained in this guide or for incidental, special, or
consequential damages arising out of the furnishing of this guide, or the use of this guide in
operating the equipment, or in connection with the performance of the equipment when so
operated.
™

Storing the Printer 1
Storing the Printer
Keep the following in mind when storing the printer for an extended period:
1Unplug the printer.
2Remove the OPC drum, the fuser oil roller, and toner cartridges from the printer and
return them to their original packaging. If the original packaging is not available,
protect the toner cartridges from spilling toner, and protect the OPC drum cartridge
from damage and light.
Relocating Your Printer
Occasionally, you may have to move your printer to a different location, either nearby or
to a distant location. To avoid damage to your printer, we advise you to follow the next
instructions very carefully.
1Turn off the power to your printer.
2If the printer has a lower feeder unit and/or a 5-bin mailbox, remove them.
3If you are moving to a distant location, follow the instructions for repacking
the printer.
4Relocate the printer.
WARNING!
The printer weighs about 87.1 lb (39.5 kg). Always have two people to lift and move the
printer to avoid back injury.
5Unpack and set up the printer in its new location.
6Reinstall the accessories you removed in step 2.
Refer to the Service & Support Guide or www.minolta-qms.com for additional
information.

Repacking the Printer2
Repacking the Printer
If you need to relocate or ship your printer after it’s been installed, follow the procedures
in this chapter to prevent damage to the printer and to keep your warranty valid.
5"If you’re returning just the printer for service, do not return the interface cables, power
cable, documentation, media tray(s), or accessories.
Attention
MINOLTA-QMS cannot be held responsible for damage to your printer during
shipment that results from the improper packaging of your printer. You must use the
instructions given in this section before repacking the printer in its original shipping
carton with the original packing materials. These supplies must be replaced prior to
re-shipping the printer.
If you need replacement packaging, in the United States, call MINOLTA-QMS
Spares at 1 [phone] x2530 and request part number 2600674-901 for the
repacking kit. Refer to the Service & Support Guide or www.minolta-qms.com for
locations outside the United States. If you need to return the printer for service, be
sure to write the RMA (Return Merchandise Authorization) number you received
from your customer support representative clearly on the carton before shipping
the printer.
What's Involved?
Repacking your printer for shipment involves the following steps. Each is described in
more detail in the following sections.
1Remove the cables.
2Remove the fuser oil roller.
3Remove the toner cartridges.
4Remove the waste toner pack.
5Remove the OPC drum.
6Remove the transfer belt.
7Remove the duplex unit (if attached).

Repacking the Printer 3
8Remove the 5-bin mailbox (if attached).
9Remove the lower input feeder (if attached).
10 Repack the printer for shipment.
Attention
To avoid toner contamination during shipment, the printer should be repacked
without the fuser oil roller, toner cartridges, waste toner pack, OPC drum cartridge,
or transfer belt installed.
Remove the Cables
1Turn off the printer.
2Remove the power cable and all interface cables.
Remove the Fuser Oil Roller
WARNING!
The fuser unit can become extremely hot and cause severe burns. Make sure the
unit is cool before handling it.
1Open the printer’s top cover.
2Rotate the two lock levers to release the fuser oil roller.
3Remove the fuser oil roller.
4Store the fuser oil roller in its original shipping bag.
5Close the printer’s top cover.
Remove the Toner Cartridges
1Open the printer’s front cover.
2Remove the four toner cartridges and store them in their original packaging.

Repacking the Printer4
Remove the Waste Toner Pack
1With the printer’s front cover open, remove the waste toner pack from
the printer.
2Use the three plugs on the side of the waste toner pack to seal the opening.
3Store the waste toner pack in its original packaging.
Remove OPC Drum Cartridge
Remove the OPC drum cartridge and store it in its original packaging.
Remove Transfer Belt
1Remove the transfer belt and store it in a plastic bag in a box to avoid toner spillage
2Close the printer’s front cover.
Remove the Duplex Unit
5"If you don’t have a duplex unit installed, skip to the next section.
1Open the duplex cover and unhook the spring wire.
2Loosen the two thumbscrews until the duplexer moves freely away from the right
side of the printer.
3Lift duplex unit up and away from the printer.
4Install the original right-side cover that came with the printer.
5Repack the duplex unit in its original shipping carton for storage or shipment.
5"If you’re returning the printer for service, you don’t need to return the
duplex unit, unless the problem is with the duplex unit.
Remove the 5-bin Mailbox
5"If you don’t have a 5-bin mailbox installed, skip to the next section.
1Remove the power cable.
2Remove the side plates and loosen the thumbscrews.
3Lift 5-bin mailbox up and away from the printer.

Repacking the Printer 5
4Replace the original screen covers on the top of the printer.
5Repack the 5-bin mailbox in its original shipping carton for storage or shipment.
5"If you’re returning the printer for service, you don’t need to return the 5-bin mailbox,
unless the problem is with the 5-bin mailbox.
Remove the Lower Feeder Unit
5"If you don’t have a lower feeder unit installed, skip to the next section.
1Remove the rear bracket securing the lower feeder unit to the printer.
2Remove the upper media tray.
3Remove the brackets on the right and left in front that are securing the optional tray to
the printer.
4Replace the upper media tray.
5With the help of another person, lift the printer by its carrying grips and carrying bar,
and place the printer on a table.
WARNING!
The printer weighs approximately 87.1 lbs (39.5 kgs) without consumables. Be sure to have
help when lifting and moving it.
6Repack the lower feeder unit in its original shipping carton
for storage or shipment.
5"If you’re returning the printer for service, you don’t need to
return the lower feeder unit, unless the problem is with the
lower feeder unit.

Repacking the Printer6
Repack the Printer
If you need replacement packaging, in the United States, call MINOLTA-QMS Spares at
1 [phone] x 2530 and request part number 2600674-901 for the repacking kit.
Refer to the Service & Support Guide or www.minolta-qms.com for locations outside the
United States.
1Place the lower cushions into the shipping carton’s base.
2Put the printer’s plastic bag into the shipping carton’s base.
3With another person’s help, put the printer into its plastic bag
and tape the bag closed.
4Replace the outer shipping carton over the printer and the
base, and secure the shipping carton using the plastic inter-
locks that came with the original carton.
5Pack the printer for shipment
as shown.
6If you’re also shipping the
power cord and any manuals
with the printer, place them in
the shipping carton.
5"Don’t ship these items if
you’re returning the printer
for service.
7Securely tape the top flaps of
the shipping carton closed.
