Konig & Meyer 19759 Specification sheet

19759 Smartphone-Stativ
Nutzungsinformation
Bestimmungsgemäße Verwendung
Das Smartphone-Stativ mit der zweifach ausziehbaren Rohrkombination und dem montierten
Halter ist in seiner Anwendung äußerst flexibel. Durch den Fuß wird ein sicherer Stand gewähr-
leistet und durch die Rohrkombination können Höhen von 600-1400 mm erreicht werden. Der
Smartphone-Halter ist zur Aufnahme von einem Smartphone mit einer Breite von 55-85 mm und
einer Höhe von 130-180 mm geeignet. Ebenso können ähnliche Geräte mit dem Halter geklemmt
werden. Durch die gummierten Haltelaschen, welche das Smartphone umschließen ist ein fester
und sicherer Halt gewährleistet. Mithilfe des flexiblen Haltearms und des Schwenkgelenks ist
eine individuelle Einstellung möglich.
Vorhersehbare Fehlanwendung
Während ein Smartphone eingelegt ist, die die Klemm- und Verschraubungen nicht öffnen. Den
Smartphone-Halter nicht über Kopf verwenden.
Allgemeines
uDas Stativ muss mit allen drei Beinen auf einen ebenen und tragfähigen Untergrund abgestellt
uwerden. Der Fußkreisdurchmesser sollte so groß wie möglich eingestellt werden.
uAufstellen und Einstellen:
u● Ohne Smartphone den Halter am Stativ befestigen und die gewünschte Position einstellen.
u● Das Lösen der Verstellschraube mit geklemmtem Smartphone ist nur zulässig, um kleine
u●Korrekturen der Position vorzunehmen. Bei dieser Korrektur ist erhöhte Vorsicht geboten,
u●um ein unerwartetes Herabfallen des Gerätes zu vermeiden.
uDas Smartphone muss von den gummierten Haltelaschen umschlossen werden.
uDas montierte Equipment sollte zentrisch auf dem Stativ sitzen. Ansonsten besteht eine er-
uhöhte Kippgefahr.
uDer Smartphone-Halter ist vor Herabfallen, Schmutz, Feuchtigkeit und ruckartigen Bewegun-
ugen zu schützen.
uNicht mit übermäßiger Krafteinwirkung bedienen.
uDurch Umfallen oder Herabfallen des Smartphone-Statives können Personen und Sachschä-
uden entstehen.
uDurch die Verstellmöglichkeit besteht Quetschgefahr zwischen den Bauteilen.
uDer Nutzer muss körperlich und fachlich geeignet sein.
uDie Nutzungsinformation ist Bestandteil des Artikels und ist für dessen Lebensdauer aufzube-
uwahren bzw. an jeden nachfolgenden Besitzer oder Benutzer weiterzugeben.
Gewährleistung
Keine Gewährleistung wir übernommen für Schäden, die entstanden sind durch:
uNichtbeachtung der Nutzungsinformation und der Allgemeinen Sicherheits- und
uMontagehinweise.
uUngeeignete oder nicht bestimmungsgemäße Anwendung.
uFehlerhaftes Aufstellen bzw. Inbetriebnahme durch den Käufer oder Dritte.
uNatürliche Abnutzung.
uNachlässiger Umgang.
uUnsachgemäße Änderungen bzw. Instandsetzungsarbeiten durch Käufer oder Dritte.
uEinwirkung von Teilen fremder Herkunft.
uVerwendung von nicht originalen Ersatzteilen.
Veränderungen, An- und Umbauten, welche die Sicherheit beeinträchtigen können, sind ohne
Genehmigung des Herstellers untersagt.

Technische Daten
Material
Smartphone-Halter:
Gewindebolzen: Stahl, pulverbeschichtet schwarz
Smartphone-Halter, Kugeladapter, Überwurfmutter, Haltearm: Kunststoff
Arm innen: Aluminium Stab
Stativ:
Grund-, Auszugs-, Endrohr, Füße: Stahl, pulverbeschichtet schwarz
Gewindebolzen, Niet, Linsenkopfschraube, Klemmschraube, Vierkantmutter:
Stahl, verzinkt
Rändelscheibe: Aluminium schwarz eloxiert
Klemmschrauben, Spannschelle, Auszugsicherung, Parkettschoner,
Fußstrebe, Klemmstück: Kunststoff, schwarz
Tragfähigkeit Smartphones und ähnliche Geräte
Maße und
Verstellbereich
Smartphone-Halter: Breite: 55-85 mm, Höhe: 130-180 mm,
Stärke max. 15 mm
Vertikal und horizontal: 180° und 360°
Fußkreis-ø 700 mm
Höhe 600 bis 1400 mm
Verpackung 550 x 100 x 72 mm
Gewicht 1,1 kg
Montage
1.) Auspacken und Artikel auf Beschädigung und Vollständigkeit prüfen
!Durch die Beweglichkeit der Bauteile besteht Quetschgefahr zwischen diesen!
Smartphone-Halter
Haltearm mit Kugeladapter
Stativ
2.) Aufstellen des Statives
Klemmschraube an der Schelle lösen und die Füße
nach außen ziehen, Klemmschraube wieder handfest
anziehen.
Hinweis: Die beste Standsicherheit wird mit einem mög-
lichst großen Fußkreisdurchmesser erreicht. Sind die
Fußstreben parallel zum Untergrund ausgerichtet, ist
der größtmögliche Fußkreisdurchmesser eingestellt.
Die Höhe des Statives kann über die beiden Klemm-
schrauben am Auszugsrohr verstellt werden. Hierzu
eine der beiden Klemmschraube lösen, Höhe einstellen
und Klemmschraube wieder handfest anziehen. Vor-
gang mit der zweiten Klemmschraube wiederhohlen.
Die Demontage erfolgt in umgekehrter Reihenfolge.

3.) Smartphone-Halter mit Kugeladapter verbinden
1Die Klemmmutter am Smartphone-Halter in Richtung
UNLOCK so weit öffnen, bis der Kugeladapter 2mit leich-
tem Druck in den Smartphone-Halter einschnappt. 3
Klemmmutter in Richtung LOCK handfest anziehen.
Zum Verstellen der Lage die Klemmmutter lösen, die ge-
wünschte Lage einstellen und die Klemmmutter handfest
anziehen.
4.) Montage an Stativ
Stativ ist ordnungsgemäß aufgebaut.
Stativ ist auf einem ebenen und tragfähigen
Untergrund aufgestellt.
Haltearm auf das Stativ aufsetzen 1und mit ihm ver-
schrauben 2. Die Demontage erfolgt in umgekehrter Rei-
henfolge.
5.) Smartphone einlegen
Smartphone-Halter ist ordnungsgemäß am
Stativ befestigt.
Den Klemmhebel 1am Smartphone-Halter
öffnen und Smartphone-Halter auseinander-
schieben 2. Das Smartphone von oben auf
die unteren Haltelaschen absetzen 3und das
Smartphone in den Smartphone-Halter able-
gen. Smartphone-Halter zusammenschieben 4.
Mit dem Klemmhebel den geschlossenen
Smartphone-Halter arretieren 5. Klemmhebel
rastet hörbar ein.
Hinweis: Das Smartphone muss flächig mit der
Rückseite am Smartphone-Halter anliegen und
die Haltelaschen müssen das Smartphone um-
schließen Z. Nur so kann ein fester und siche-
rer Halt gewährleistet werden.

Störung und Fehlersuche
Lagerung, Entsorgung
Lagern Sie das Smartphone-Stativ an einem trockenen Ort.
Führen Sie zerlegte Bestandteile der Wiederverwertung zu:
uVerschrotten Sie alle Komponenten aus Metall.
uFühren Sie alle Komponenten aus Kunststoff, Papier und Kartonage der Wiederverwertung
ubzw. Recycling zu.
uSortieren Sie alle anderen Komponenten nach Materialbeschaffenheit und entsorgen Sie
udiese gemäß den örtlichen Bestimmungen.
Kontaktinformation
KÖNIG & MEYER GmbH & Co. KG
Kiesweg 2
97877 Wertheim
Telefon: 09342/8060
Telefax: 09342/806-150
Web: www.k-m.de
19759-000-55 Rev.04 03-80-063-00 9/23
Störung/Ursache Prüfen/Behebung
Stativ wackelt oder steht
instabil
● Standsicherheit und Schraubverbindungen des Statives
●überprüfen.
Smartphone-Halterung
wackelt
● Schraubverbindungen am Smartphone-Halter und Stativ
●überprüfen und gegebenenfalls nachziehen.
Smartphone wackelt im
Halter
● Prüfen, ob Klemmhebel am Smartphone-Halter eingerastet ist.
● Smartphone muss flächig an der Rückseite und in den Haltela-
●schen anliegen.
Wartung, Reinigung und Instandsetzung
uWartung: Regelmäßige Kontrolle auf festen Sitz der Schraubverbindung.
uReinigung: Zum Reinigen des Smartphone-Stativ ein leicht befeuchtetes Tuch benutzen.
uKeine chlorhaltigen oder scheuernde Reinigungsmittel verwenden. Diese verursachen
uSchäden an Oberfläche und Lack.
uInstandsetzen: Auftretende Schäden sofort beheben und Smartphone-Stativ nicht weiter be-
unutzen.Instandhaltungsarbeiten dürfen nur durchgeführt werden, wenn Sie die erforderlichen
uKenntnisse hierfür besitzen. Bei fehlenden Teilen kontaktieren Sie den Hersteller über
uwww.k-m.de.Hier gelangen Sie anhand der Artikelnummer, die Sie auf dem Typenschild
ufinden, zu einementsprechenden Ersatzteilblatt. Über dieses können Sie die fehlenden oder
udefekten Teile Nachbestellen.

19759 Smartphone stand
Information for use
Intended use
The smartphone stand with the 3-piece rod combination and the mounted holder is extremely
flexible in its use. The base ensures a secure stand and the tube combination allows heights of
600-1400 mm to be achieved. The smartphone holder is suitable for holding a smartphone with a
width of 55-85 mm and a height of 130-180 mm. Similar devices can also be clamped. Rubberi-
zed retaining tabs surrounding the smartphone ensure a firm, secure hold. Individual adjustment
is possible thanks to the flexible holding arm and swivel joint.
Foreseeable misapplication
Do not open the clamping and adjusting screws while the smartphone is inserted. Do not use the
smartphone holder overhead .
General
uThe stand should be placed on a level and stable flooring. The diameter of the base should be
uset as far as possible.
uSet up and adjustment:
u● Attach the holder to the stand without the smartphone and set the desired position.
u● When the smartphone is clammed it is only allowed to loosen the adjustment screw to carry
u●out small corrections regarding the position. Increased caution is required during correction,
u●to prevent the device from falling unexpectedly.
uThe smartphone must be enclosed by the rubberized retaining tabs.
uThe mounted device should be placed as centrically as possible on the tripod to avoid
uincreased risk of tipping.
uThe smartphone holder must be protected from falling, dirt, moisture and jerky movements.
uDo not handle with excessive force.
uInjuries und damages can be caused to individuals or property if the smartphone stand should
utip or fall.
uDue to the adjustability of the components, there is finger trap risk between the components.
uThe user should be physically fit and technically competent.
uThe usage information is an integral part of the product and should be kept for its service life
uor passed on to any subsequent owner or user.
Warranty
No warranty is given for damage caused by:
uNon-observance of the usage information and the "General safety and assembly instructions".
uUnsuitable or improper use.
uIncorrect installation or commissioning by the buyer or third parties.
uNatural wear and tear.
uCareless handling.
uImproper modifications or repair work by the buyer and third parties.
uImpact on components of foreign origin.
uUse of non-original spare parts.
Modifications, additions and conversions that may impair safety are prohibited without the manu-
facturer's approval.

Technical data
Material
Smartphone holder:
Threaded bolt: Steel, powder-coated black
Smartphone holder, ball adapter, union nut, holding arm: Plastic
Support arm inside: Aluminum rod
Stand:
Base tube, extension tube, end tube, legs: steel, powder coated black
Threaded bolt, rivet, pan head screw, clamping screw, square nut:
Steel, galvanised
Knurled washer: Aluminum black anodised
Clamping screw, clamp, pull-out protection, floor protector, foot brace,
clamping piece: Plastic, black
Load capacity Smartphones and similar devices
Dimensions and
adjustment range
Smartphone holder: Width: 55-85 mm, height: 130-180 mm,
thickness max. 15 mm
Vertical and horizontal: 180° and 360°
Foot circle: diameter 700 mm
Height: 600 up to 1400 mm
Packing 550 x 100 x 72 mm
Weight 1.1 kg
Assembly
1.) Unpack and check item for damage and completeness
!Due to the mobility of the components, there is a risk of crushing between them!
Smartphone holder
Holding arm with ball adapter
Stand
2.) Setting up the stand
Loosen the clamping screw on the clamp and pull the
feet outwards, tighten the clamping screw hand-tight
again.
Note: The best stability is achieved with the largest pos-
sible foot circle diameter. If the foot struts are aligned
parallel to the ground, the largest possible foot circle
diameter is set.
The height of the stand can be adjusted using the two
clamping screws on the extension tube. To do this,
loosen one of the two clamping screws, adjust the
height and tighten the clamping screw again hand-tight.
Repeat the process with the second clamping screw.
Dismantling is carried out in reverse order.

3.) Connect smartphone holder with swivel joint
1Open the clamping nut on the smartphone holder in the
UNLOCK direction until the swivel joint 2snaps into the
smartphone holder with slight pressure.
3Hand-tighten the clamping nut in the LOCK direction.
To adjust the position, loosen the clamping nut, set the de-
sired position, and hand-tighten the clamping nut.
4.) Mounting on stand
The stand is properly set up.
The stand is set up on a level and load-
bearing surface.
Place the holding arm on the stand 1and screw into place
2. Dismantling follows the same steps in reverse.
5.) Smartphone einlegen
The smartphone holder must be properly
attached to the stand.
Open the clamping lever 1on the smartphone
holder, and slide the smartphone holder apart
2. Lower the smartphone from above onto the
lower retaining tabs 3, and place the smart-
phone in the smartphone holder. Push the
smartphone holder together 4. Use the clam-
ping lever to lock the closed smartphone holder
5. Clamping lever audibly engages.
Note: The back of the smartphone must lie flat
against the smartphone holder, and the retai-
ning tabs must enclose the smartphone Z. This
is the only way to ensure a firm and secure
hold.

Fault and troubleshooting
Storage, disposal
Store the smartphone stand in a dry place.
Recycle disassembled components:
uScrape all components made of metal.
uRecycle or reuse all plastic, paper, and cardboard components.
uSort all other components according to material composition and dispose of them
uaccording to local regulations.
Contact information
KÖNIG & MEYER GmbH & Co. KG
Kiesweg 2
97877 Wertheim
Germany
Phone: +49 9342/8060
Fax: +49 9342/806-150
Web: www.k-m.de
19759-000-55 Rev.04 03-80-063-00 9/23
Fault/cause Check/Remedy
Stand wobbles ● Check the stability and screw connections of the stand.
Smartphone holder
wobbles
● Check the screw connections on the smartphone holder
●and the Stand and tighten if necessary.
Smartphone wobbles
in the holder
● Check whether the clamping lever on the smartphone holder is
●engaged.
● Smartphone must lie flat against the back and in the retaining
●tabs.
Maintenance, cleaning and repair
uMaintenance: Regularly check that the screw connection is tight.
uCleaning: Use a slightly damp cloth to clean the smartphone stand. Do not use chlorinated or
uabrasive cleaning agents. These will cause damage to the surface and varnish.
uRepair: Repair any damage immediately and stop using the smartphone stand. Repair work
umay only be carried out if you have the necessary knowledge. If any parts are missing, contact
uthe manufacturer at www.k-m.de. Here you can find a corresponding spare parts list by ente-
uring the article number on the type label. Use this page to reorder missing or damaged compo
unents.
This manual suits for next models
1
Table of contents
Languages:
Other Konig & Meyer Cell Phone Accessories manuals
