Kontron NSW1U User manual

Kontron IP Network Server NSW1U
Document Revision 2.6

December 2010
Revision
Date
Comments
1.0 11/10/2006 Original version.
1.1 3/19/2007 Updated at SRA. Added Front NIC Bypass SKU.
1.2 5/17/2007 Updated Spares list; new Rack Mount appendix;
misc. updates
2.0 4/17/2008 Added info for Quad-Core Intel® Xeon® processor
L5410 support, changed format, removed Syscon,
added Z-U130 and other additional parts.
2.1 5/13/2008 Fixed NSWCDFILL01W to indicate it is included
Added TMLREK01
2.2 6/06/2008 Added “Copper” to TMWHSNK01W description
Added NSWESCBLNK01W
2.3 1/2009 Added EPSD rails section to Appendix A; updated
processor section with latest steppings; updated
RAID BBU spare to Li-Ion version; updated SSD
spare information; replaced Intel references with
Kontron references.
2.4 5/13/2009 Removed MM# references from Kontron products.
Updated PCI-E and PCI-X riser spares with different
product codes. Noted discontinuance of
AXXBASICRAIL and AXXHERAIL.
2.5 6/29/2009 New Kontron template. Removed MM# references
from Intel-sourced SKUs. All SKUs are now
orderable directly from Kontron.
2.6 12/20/2010 Added TMRDVDCBLSATAW spare.
Copyright © 2010, Kontron

3 www.kontron.com
Document Table of Contents
I. INTRODUCTION 4
II. ORDERING NSW1U SYSTEM SKUS 5
III. ORDERING NSW1U SPARES/ACCESSORIES 10
IV. QUAD PORT BYPASS NIC CAPABILITY 13
APPENDIX A. RACK MOUNTING OPTIONS FOR 1U AND 2U
COMMUNICATIONS RACK MOUNT SERVERS 16

4 www.kontron.com
I. Introduction
The IP Network Server NSW1U system is the first 1U rack mount server to join the
IP Network Server family, characterized by having long product life and a 20” depth
chassis. It features the Quad-Core Intel® Xeon® processor 5400 series, and the
64-bit Dual-Core Intel® Xeon® processor 5100 series, providing improved
performance-per-watt over previous-generation rack mount servers.
IP Network Servers are suited to a host of applications in the network security and
industrial environment. The server is targeted to applications requiring rugged
systems including Intrusion Detection, Intrusion Protection, Firewall, VPN, SSL
VPN, and Application Secure Gateways. It can also support manufacturing,
industrial, utility and military applications where a rugged, highly reliable server is
required for harsh environments such as dust, high altitude, fire hazard,
earthquake propensity, and high ambient temperatures.
More product information is available at the following link on the Kontron website:
http://us.kontron.com/products/systems+and+platforms/communication+rackmount
+servers/ip+network+servers/ip+network+server+nsw1u.html
Purpose of this Document:
This document provides details on what parts are available for ordering of the IP
Network Server NSW1U production systems and associated accessories and
spares. Included are the necessary order codes and other important configuration
information related to the ordering of the product.
Supported third-party components are not covered by this document, and may be
found in the Tested Hardware and Operating System List (THOL) for this product.

5 www.kontron.com
II. Ordering NSW1U System SKUs
The NSW1U System SKUs are listed below:
Product Code Description
Minimum
Order
Qty.
NSRA0201W
IP Network Server NSW1U Rear NIC, Base Model 0 with AC
Power Supply.
Includes support for Quad-Core Intel® Xeon® processor
5400 series and legacy support for Dual-Core Intel® Xeon
processor 5100 series.
1
NSRD0201W
IP Network Server NSW1U Rear NIC, Base Model 0 with DC
Power Supply.
Includes support for Quad-Core Intel® Xeon® processor
5400 series and legacy support for Dual-Core Intel® Xeon
processor 5100 series.
1
NSRA0401W
IP Network Server NSW1U Front NIC with Bypass, Base
Model 0 with AC Power Supply.
Includes support for Quad-Core Intel® Xeon® processor
5400 series and legacy support for Dual-Core Intel® Xeon
processor 5100 series.
1
Legacy Support
NSWA0201W IP Network Server NSW1U Rear NIC, Base Model 0 with AC
Power Supply.
Includes legacy support for Dual-Core Intel® Xeon
processor 5100 series only. 1
NSWD0201W IP Network Server NSW1U Rear NIC, Base Model 0 with DC
Power Supply.
Includes legacy support for Dual-Core Intel® Xeon
processor 5100 series only.
1
NSWA0301W IP Network Server NSW1U Front NIC, Base Model 0 with AC
Power Supply.
Includes legacy support for Dual-Core Intel® Xeon
processor 5100 series only.
1
NSWA0401W IP Network Server NSW1U Front NIC with Bypass, Base
Model 0 with AC Power Supply.
Includes legacy support for Dual-Core Intel® Xeon
processor 5100 series only.
1
See the NSW1U Base Model 0 Configuration table further down in this section
for a list of components included in each base model 0 SKU.
The NSW1U system SKUs are ordered using the Product Code as the order
number. Production SKUs are offered as either an AC or a DC version. The
Product Identification code or PID of all SKUs contains the letter “A” for AC or “D”
for DC as the 4th digit of the PID.

6 www.kontron.com
All Production SKUs are base model 0 SKUs, (no processor, heatsink, memory,
hard drive, power cord, operating system, or plug-in adapters are provided).
Those components must be ordered separately as Accessories from Kontron or
from third party vendors listed in the Tested Hardware and Operating System List
(THOL).
Power cords are not included with the Mod 0 system. For AC Power cords, order
the following North American power cable using the provided product code. This
power cable is RoHS-compliant.
Product Code
Comments
1-340000-0 This AC power cable can be ordered by North America (NA) customers. International customers should
procure their specific power cords directly.
Note: Ensure that customers have the appropriate technical support and contact
before placing their first order.

7 www.kontron.com
NSW1U Base Model 0 Configuration
All Production SKUs are base model 0 SKUs (no CPU, heatsink, memory, hard
drive or plug-in adapters are provided). Those components must be ordered
separately as Accessories from Kontron or from third party vendors listed in the
Tested Hardware and Operating System List (THOL).
The table below lists which components are included in the base model 0 SKUs
and which ones must be ordered separately or as optional accessories.
Component Description
AC Mod 0
Configuration
DC Mod 0
Configuration
AC power supply (450W) 1 included -
DC power supply (450W) - 1 included
Filler Panel in 2
nd
power supply bay 1 included
Chassis (sheet metal, top cover, PCI carrier) 1 included
Bezel (unpainted) 1 included
S5000PHB Baseboard 1 included
FH-FL Bracket with PCI-Express Riser 1 included
FB-DIMM slots (memory not included) 6 included
Drive bays for 3.5” SATA HDD (w/ carrier) 2 included
Server Deployment Toolkit (CD) 1 included
Quick Start Guide 1 included
Power cable Purchase separately
1
SW RAID 0/1/10 Supported
Mounting kit for Z-U130 Solid State Drives Optional Accessory
2
Intel® Remove Management Module 2 Optional Accessory
2
PCI-X Riser Optional Accessory
2
NIC Cable Optional Accessory
2
Cable Management Bracket Optional Accessory
2
Bypass Ethernet Ports Optional Accessory
3
Rack Mount Kits Optional Accessory
4
Rail Enabling Kit (to enable AXXBASRAIL13,
AXXHERAIL2, AXXBASICRAIL, and AXXHERAIL kits) Optional Accessory
4
Processor (refer to “Details on Ordering Processors”) Purchase separately
5
Heatsink (copper required) Accessory or purchase separately
Memory Purchase separately
5
Hard Disk Drive Purchase separately
5
DVD-CDR Optical Drive Purchase separately
5
CD-ROM Carrier SKU Dependant
6
Some items above available as optional accessories as noted:
1Refer to AC power cord accessory in this section
2Refer to “Production Spares/Accessory List” in section IV
3Refer to “Quad Port Bypass NIC Capability” in section IV
4Refer to “Rack Mounts” in Appendix A
5Should be purchased separately (parts not listed in this document)
6Production SKUs NSRA0201W, NSRD0201W, and NSRA0401W include the CD-ROM carrier in
the accessory pack. For other SKUs (NSWxxxxxx), the CD-ROM carrier is not included but may
be ordered separately.

8 www.kontron.com
Notes on the NSW1U Model 0 Configuration and Options:
PCI Riser
oThe base configuration comes standard with one full-height, full-length
PCI Riser supporting one PCI-Express (PCIe) slot.
oAn alternate full-height, full-length, single-slot PCI-X riser is also
supported. It is available as an accessory (refer to “Production
Spares/Accessories List” in section III) and may be purchased as a
replacement for the PCIe riser.
SW RAID
oThe NSW1U supports only SW (Software/Firmware) RAID 0/1.
Solid State Drives
oSupport for solid state drives (with USB interface) is available by purchasing
a mounting kit accessory (TMWVSSDRIVE01W) to mount the drive inside
the chassis (refer to “Production Spares/Accessories List” in section III).
oThe following solid state drives are supported:
SMART Z-U130 eUSB Drive
(http://www.smartm.com/product/m_intel_z-u130.cfm)
Note: This replaces the Intel® Z-U130 Value Solid State Drive
Intel® Z-U130 Value Solid State Drive (legacy support)
oSolid state drives are available in several sizes and securely mount inside
the chassis. They enabling an array of product customization options.
Storage: independent of traditional disk drives
Boot OS from solid state drive; store data on hard drive
Store backup image of boot drive
Add a server partition to the server
Rack Mounting Options
oRack mounting kits for 2-post or 4-post, 19-inch or 23-inch racks are offered
by Kontron for this product. These include TMLCMOUNT21,
TMLPMOUNT41, TMLPMOUNT51, TMLPMOUNT52, and TMLPSLIDE01.
The Rail Enabling Kit (TMLREK01) is not required for these rack mount kits.
Please refer to Appendix A to determine the correct options to suit
your needs. For ordering details, refer to “Production
Spares/Accessories List” in section III.
oIf AXXBASRAIL13, AXXHERAIL2, AXXBASICRAIL, or AXXHERAIL from
Intel will be used, then a Rail Enabling Kit (TMLREK01) must be purchased
from Kontron to enable support of these rails.
For ordering details, refer to “Production Spares/Accessories List” in
section III.

9 www.kontron.com
Details on Ordering Processors:
The NSW1U supports the Quad-Core Intel®Xeon®processor 5400 Series and the
Dual-Core Intel® Xeon processor 5100 series shown in the table below.
Processors Supported by NSW1U:
Processor
Number Cores Speed TDP FSB Kontron P/N
Intel
P/N
Intel
MM#
E5440
Quad 2.83 GHz 80W 1333 MHz K00008-001 AT80574KJ073N 898592
L5410
Quad 2.33 GHz 50W 1333 MHz K00029-001 AT80574JJ053N 898603
Legacy
5140 Dual 2.33 GHz 65W 1333 MHz N/A HH80556KJ0534M 891730
5130
Dual 2.00 GHz 65W 1333 MHz
N/A
HH80556KJ0414M 891731
LV 5148
Dual 2.33 GHz 40W 1333 MHz
N/A
HH80556JJ0534M 891675
LV 5128
Dual 1.86 GHz 40W 1066 MHz
N/A
HH80556JH0364M 891704
Notes:
All above processors are on Intel’s long life roadmap.
The E5440 or L5410 processors are recommended with the NSW1U for highest
performance and longest availability and support. They are orderable from
Kontron or Intel using the indicated part numbers.
The above 5100 processor SKUs are also supported on the NSW1U for legacy
purposes, and are orderable from Intel only.
Heat Sinks
oOnly Tray processors are recommended with this product. The
processor thermal solution for this server must include the use of a
copper heat sink (e.g. see TMWHSNK01W in the Spares/Accessories
list below). There are no clips needed for this heat sink, since the heat
sink includes captive screws.
oThe boxed processors previously listed in the “supported” table have
been removed since these now include an aluminum heat sink which
does not provide sufficient heat dissipation to meet thermal
requirements. For this reason, Kontron does not recommend the use
of Boxed processors with this product.

10 www.kontron.com
III. Ordering NSW1U Spares/Accessories
Below are the Spares parts and Accessories that may be ordered with the NSW1U
system. Please read the following notes regarding this parts list.
Spares: Any of these items may be ordered as ‘Spares’ for part replacement
purposes.
Accessories: Some of these items are not included in the NSW1U Mod0 base
model, but may be ordered as ‘Accessories’ to upgrade the base model with
additional features.
3rd Party Accessories: For a listing of compatible 3rd party accessories, please
refer to the Tested Hardware and Operating System List (THOL) document.
Product Code Description Contents Included in Base Model
(Y/N)
Minimum
Order
Size
TMWACPSU01W TIGW1U/NSW1U AC Power Supply AC power
supply Y
one in AC SKU 1
TMWDCPSU01W TIGW1U/NSW1U DC Power Supply DC power
supply, input
power connector
Y
one in DC SKU 1
TMWHSNK01W TIGW1U/NSW1U CPU Heatsink Heatsink
(Copper) N 12
(order in
multiples of
12)
Remote Management
AXXRMM2 Intel® Remote Management Module 2
(RMM2) - Single Pack RMM2 with
GCM (single-
pack) N 1
AXXRMM2BULK Intel® Remote Management Module 2
(RMM2) - Bulk Pack (10) RMM2 with
GCM (10-pack) N 1
(specify ‘1’ for
each 10-pack)
Solid State Drive Support
TMWVSSDRIVE01W
Mounting kit for Z-U130 Solid State
Drives
Interface support for:
SMART Z-U130 eUSB Drive
Intel® Z-U130 Value Solid State Drive
(legacy)
(drives purchased separately)
Interposer
board, cable,
mounting
screws (flash
drive not
included)
N 1
PCI Risers
TMWPCIERSR01W 1U PCI-Express Riser Riser Y 1
TMWPCIXRSR01W 1U PCI-X Riser Riser N 1
Spares
TMWCDRMC01W TIGW1U CD-ROM Carrier; i/f board
(no drive)
Carrier, PBA,
screws, pwr
cable, signal
cable
N 1
NSWFBZL01W NSW1U Bezel - Rear NIC Bezel Y
one in Rear NIC
SKU 1

11 www.kontron.com
Product Code Description Contents Included in Base Model
(Y/N)
Minimum
Order
Size
NSWFBZL02W NSW1U Bezel – Front NIC & ByPass Bezel
Y
one in Front NIC
SKU and Bypass
SKU 1
NSWCBLBRK01W NSW1U Cable Management Bracket Bracket for
chassis face
N 5
(order in
multiples of 5)
TMRDVDCBLSATAW
SATA optical drive power/data
cable kit 5 cables, install
guide N 1
NSWCDFILL01W NSW1U CD-ROM filler CD filler Y 1
NSWSATAHDD01W NSW1U SATA HDD Carriers 2 carriers Y 1
NSWFANSET01W NSW1U Fanset Fans, bracket,
air ducts Y 1
TMWCBL01W TIGW1U Cables, CD-ROM power,
spare
System
cables—
Flex, CD-ROM
power, CD-ROM
signal, SATA
Signal, Front
Panel Panel,
Battery
Y 1
TMWPDB01W TIGW1U/NSW1U Power Distribution
Board Board Y 1
NSWEFPR01W NSW1U Ethernet Front Panel I/O
Board - Rear NIC, Litepipe Board, litepipe Y
one in Rear NIC
SKU 1
NSWEFPF01W NSW1U Ethernet Front Panel I/O
Board - Front NIC, Litepipe Board, litepipe Y
one in Front NIC
SKU 1
NSWBYPSBRD01W NSW1U Ethernet Front Panel - Front
NIC with Bypass Board
Y
one in Front NIC
SKU 1
Rack Mount Kits (refer to Appendix A for additional details)
TMLCMOUNT21 Server Spare TMLPMOUNT21 N 10
TMLPMOUNT41 Server Spare TMLPMOUNT41 N 10
TMLPMOUNT51 Server Spare TMLPMOUNT51 N 1
TMLPMOUNT52 Server Spare TMLPMOUNT52 N 1
TMLPSLIDE01 Server Spare TMLPSLIDE01 N 10
AXXBASRAIL13
(orderable from Intel only –
MM# 899080
Basic Slide Rail Kit (replaces AXXBASICRAIL)
NOTE: Does not support Cable Management Arm.
NOTE: Requires TMLREK01 to attach to NSW1U chassis N 1
AXXHERAIL2
(orderable from Intel only –
MM# 901082
Fully extending Slide Rail Kit (replaces AXXHERAIL)
NOTE: Requires TMLREK01 to attach to NSW1U chassis N 1
AXXRACKARM2
(orderable from Intel only –
MM# 901084
Cable Management Arm
NOTE: To be used with AXXHERAIL2 only N 1

12 www.kontron.com
Product Code Description Contents Included in Base Model
(Y/N)
Minimum
Order
Size
AXXBASICRAIL
(discontinued by Intel) Basic Slide Rail Kit.
NOTE: Requires TMLREK01 to attach to NSW1U chassis N 1
AXXHERAIL
( discontinued by Intel) Tool-less, full extension sliding rail kit.
NOTE: Requires TMLREK01 to attach to NSW1U chassis N 1
TMLREK01
Rail Enabling Kit
Enables AXXBASRAIL13,
AXXBASICRAIL, and AXXHERAIL kits
Supported by NSW1U servers with an “R”
in the 3rd position of their order numbers.
Rackmount ears
(2), rackmount
shoulder screws
(4), screws (2)
per kit
N 10
(order in
multiples of
10)
The following PID Order Code below with the “R” in the 3rd position may be used in all servers as a spare part, and
have support for Quad-Core Intel® Xeon® processor 5400 series and Dual-Core Intel® Xeon processor 5100 series. It
may be used in all servers with either an “R” or “W” in the 3rd digit of the PID Order Code.
NSRBSBRDR01W NSW1U Baseboard - Rear NIC and
ByPass Board
Y
one in Rear NIC
SKU and ByPass
SKU 1
The following 2 PID Order Codes below with the “W” in the 3rd position may be used in all servers as a spare part, and
have legacy support for Dual-Core Intel® Xeon processor 5100 series only, and may only be used in the appropriate
server with “W” in the 3rd digit of the PID Order Code.
NSWBSBRDR01W NSW1U Baseboard - Rear NIC Board Y
one in Rear NIC
SKU 1
NSWBSBRDF01W NSW1U Baseboard - Front NIC Board Y
one in Front NIC
SKU 1

13 www.kontron.com
IV. Quad Port Bypass NIC Capability
This section is intended for customers that plan to add Intel Quad Port NIC with Bypass
capability to the NSW1U. It describes what parts must be ordered to enable this capability.
The IP Network Server NSW1U Front NIC with Bypass has built in support for four ports
of bypass Copper Ethernet ports. In addition, all NSW1U servers are capable of
supporting:
A single FH/FL PCIe NIC board with four ports of bypass Gigabit Ethernet (either
Copper or Fiber) using the Quad NIC adapters designed by Intel.
The front-accessible NIC configuration also requires the purchase of an internal
cabling/mounting kit including an escutcheon for securing the front ports.
The Quad Bypass adapters and the cabling/mounting kits come in packages of five
units each. These kits include five of the NIC cables designed for the NSW1U system,
as well as the escutcheons, cable management bracket, and associated screws to
complete the installation of the Bypass adapter in the system. Also there are bulk pack
(48 count) escutcheon kits (copper, fiber, and filler panel) available to streamline the
customization and painting process of the system.
Below are the Accessories that may be ordered to enable the Quad Port Bypass NIC
capability on the NSW1U system. Parts indicated with an asterisk (*) should be ordered
from Intel. All other parts should be ordered from Kontron.
Product Order Code Description Contents Included in Base Model
(Y/N)
Min.
Order
Qty
Copper NIC
* EXPI9014PTBLK
(Bypass rear access)
(orderable from Intel)
Intel® PRO/1000 PT Quad Port
Bypass Adapter (Copper)
– 5 Pack
Quad-port design,
based on two Intel®
82571GB dual-port
PCI Express*
GbE controllers
N 5
* EXPI9024PTBLK
(Bypass NIC-in-front)
(orderable from Intel)
Intel® PRO/1000 PT Quad Port
Bypass Adapter (Copper, NIC-in-
Front) – 5 Pack
Quad-port design,
based on two Intel®
82571GB dual-port
PCI Express*
GbE controllers
N 5
NSWDBCBL01W NSW1U Copper NIF Kit Cable, PCI Support
Bracket, escutcheon,
screws N 5
(order in
multiples
of 5)

14 www.kontron.com
Product Order Code Description Contents Included in Base Model
(Y/N)
Min.
Order
Qty
NSIESCCPR100
Copper escutcheon (unpainted),
packaged in cartons of 48 Escutcheons (48-
pack) N 48
(order in
multiples
of 48)
Blank
Fillers
NSWESCBLNK01W Blank escutcheon (unpainted),
packaged in cartons of 48 Escutcheons (48-
pack) N 48
(order in
multiples
of 48)
Fiber NIC
* EXPI9014PFBLK
(Bypass rear access)
(orderable from Intel)
Intel® PRO/1000 PF Quad Port
Bypass Adapter (Fiber) – 5 Pack
Quad-port design,
based on two Intel®
82571GB dual-port
PCI Express*
GbE controllers
N 5
* EXPI9024PFBLK
(Bypass NIC-in-front)
(orderable from Intel)
Intel® PRO/1000 PF Quad Port
Bypass Adapter (Fiber, NIC-in-
Front) – 5 Pack
Quad-port design,
based on two Intel®
82571GB dual-port
PCI Express*
GbE controllers
N 5
NSWJBCBL01W NSW1U Fiber NIF Kit
LED cable, PCI
Support Bracket,
escutcheon,
LC connectors
screws
N 5
(order in
multiples
of 5
NSIESCFBR100 Fiber Escutcheon (unpainted),
packaged in cartons of 48 Escutcheons (48-
pack) N 48
(order in
multiples
of 48)
Note: For a list of other tested Network Interface Cards (NICs) refer to the Tested Hardware
and Operating System List (THOL).

15 www.kontron.com
Overview of Intel® PRO/1000 Quad Port Bypass Server Adapters:
The Intel® PRO/1000 PT and PF Quad Port Bypass Server Adapters provide in-line server
appliances, such as Intrusion Protection Servers (IPSes), with high-performance, low-latency,
in-line connectivity, and a bypass mode to ensure business continuity. These adapters also
use the PCI Express* serial bus for greater throughput, and they support Intel® I/O
Acceleration Technology (Intel® I/OAT) for further performance enhancement, including the
reduced overhead so important to IPS applications.
The Intel® PRO/1000 PT and PF Quad Port Bypass Server Adapters are intended for use by
equipment manufacturer hardware designers in application-specific in-line server appliances,
where a bypass mode is desirable. Given that equipment manufacturers typically write specific
software applications for their in-line platforms, Intel only provides open source reference
drivers for these adapters. Interested hardware designers may contact their local Intel
representative for additional product or purchase information.
More information on Intel® PRO/1000 Quad Port Bypass Server Adapters is
available at:
http://www.intel.com/network/connectivity/products/pro1000_quad_bypass_server_adap
ters.htm

16 www.kontron.com
Appendix A. Rack Mounting Options for 1U and 2U
Communications Rack Mount Servers
Rack mounting kits for 2-post or 4-post, 19-inch or 23-inch racks are offered for
this product. Please refer to the tables below for the correct options to suit your
needs.
All rack mount kits listed are suitable for 1U and 2U Communications Rack Mount
Servers. Installation instructions are included in each kit.
2-post Rack Mounting Kit Options
Applicable kits: Rack width Post depth Rack fastener hole spacing
19 inch 23 inch 3 inch 5 inch EIA-Wide EIA-Universal ETSI
TMLCMOUNT21     
TMLPMOUNT41    
TMLPMOUNT51     
TMLPMOUNT52      
4-post Rack Mounting Kit Options
Applicable kits: Rack width Front-post to
rear-post distance Rack fastener hole spacing
19 inch 23 inch
Min
(inches) Max (inches) EIA- Wide
EIA-
Universal
ETSI
TMLPMOUNT41  20 24 
TMLPMOUNT51  20 24  
TMLPMOUNT52  20 24   
TMLPSLIDE01† 22.5 28 or 34††

†The TMLPSLIDE01 kit contains server securing brackets.
††34-inch span requires the optional Accuride "Long Bracket" kit.

17 www.kontron.com
TMLCMOUNT21
The TMLCMOUNT21 kit mounts Communication Rack Mount Servers to a 2-post,
central office type, 19” wide rack. This kit consists of simple L-shaped brackets;
which fasten to the sides of the server and to the rack.
TMLCMOUNT21

18 www.kontron.com
TMLPMOUNT41, TMLPMOUNT51 and TMLPMOUNT52
TMLPMOUNT41/51/52 series mounts Communication Rack Mount Servers to 2-
post or 4-post racks.
TMLPMOUNT41 and TMLPMOUNT51 are used for mounting servers on 19” wide
racks. These racks are considered standard EIA (universal hole spacing) racks.
TMLPMOUNT52 is used for mounting servers on 23” wide racks. These racks
could be standard EIA (universal or wide hole spacing) or ETSI (European) racks.
TMLPMOUNT41/51/52 series are designed with a slide-in rail-type system.
Although the mounts are designed as rails, they are not sliding rails. This means
the servers can be slid into the racks for installation purpose, but the rails are not
designed to support a mounted server during service.
TMLPMOUNT4x/5x feature comparison
Slide pull-out
locking feature
Slide interface
material
4-post rack hole
spacing
2U-tall nut bar
2-post chassis
securing screw
location
"HP Mulan
rack
interference"
TMLPMOUNT41 No1Plastic
strips2EIA-Universal Not included Side access6Interference
TMLPMOUNT51 Yes Xylan
coating3EIA-Wide or EIA- Universal4Included5Front access No Interference
TMLPMOUNT52 Yes Xylan
coating3EIA-Wide, EIA- Universal or ETSI Included5Front access N/A
Notes:
1. Extra care must be exercised with TMLPMOUNT41 to securely hold the server with one's
hands when sliding it out of the rack, else the server may fall to the ground as its being
removed.
2. Plastic strips on TMLPMOUNT41 have peeled off in some customer installations.
Consequence: The parts are usable, but the server may have somewhat of a "scrape-in
feel" rather than "slide in". Also, the rails will fit sloppier, so the side-located chassis
securing screws may be difficult to align in 2-post installations. Replacement material is
available from the plastic strip manufacturer.
3. Xylan is a tough, low-friction coating similar to Teflon.
4. EIA-Wide spacing doesn't have the interstitial hole that is present in EIA-Universal.
TMLPMOUNT51 contains an adapter bracket to overcome this EIA-Wide issue.
5. This component (2U Nut Bar) enables installation of a rail kit into a 1U rack slot when there
is already equipment installed both above and below that open slot.
6. The sides of the server must be accessible when using TMLPMOUNT41 in 2-post racks.

19 www.kontron.com
The diagrams above summarize the components and “slide-in rail-type” system of
the TMLPMOUNT41. It can be adapted for a 2-post or 4-post installation.

20 www.kontron.com
The main difference between the TMLPMOUNT41 and TMLPMOUNT51/52 series
is that the TMLPMOUNT41 series uses a screw to lock the server in place via the
Universal Mounting Bracket, whilst the TMLPMOUNT51/52 series has an
additional Slide Pull-Out Locking feature.
The Universal Front Mounting Bracket on the TMLPMOUNT41
The Slide Pull-Out Locking feature on the TMLPMOUNT51/52
