Kontron AM4210 User manual

JP2
J2 JP1
8 6 4 2
7 5 3 1
J4
J3
AMC Gold Fingers
SFP+ Connector
Serial Port Connector
USB Flash Connector
J2
J3
J4
JP2
» AM4210 Quick Reference Sheet «
Connectors
Reserved
JP1
Jumper Settings
Symbols Chart
Hot Swap
Out of Service
Healthy
Serial Port (RJ45)
LEDs Signification available on back.
Cavium Advanced Mezzanine Card
Outlet Sensor
Ethernet Internal Sensor
Cavium Internal Sensor
TS1
TS2
TS3
Temperature Sensors
TS1
TS2
TS3
CN5650 NSP
82571EB
SFP
AM4210
1
20

» AM4210 Quick Reference Sheet «
1032-0559
Support / Download
EMEA
1 . E-Mail : [email protected]
2. Tel : [phone]
North America / Asia - Pacific
1 . E-Mail : [email protected]
2. Tel : [phone]
The Quick Reference Sheet can be downloaded
from the Kontron web site at:
http://www.kontron.com
or from Kontron FTP site at:
ftp://ftp.kontron.ca/Support/
LEDs Significations
Hot Swap (Blue)
Solid On (100 % on): FRU Inactive
Long Blink ( 90 % on): FRU Activation Request
Solid Off ( 0 % on): FRU Activation In Progress / FRU Active
Short Blink ( 10 % on): FRU Deactivation Request / FRU Deactivation In Progress
Out of service (Red/Amber) [ default : Red ]
Solid On : MMC in reset
Fast Blink (~50 % on) : MMC upgrade/rollback in progress
Application Defined : May be controlled by application using PICMG API
Health Led (Amber/Green) [ default : Green ]
Off : Payload power down
Green : Health Ok
Amber : Health Error (Critical)
Application Defined : May be controlled by application using PICMG API
SFP+ Led (Green)
Green On : Link 10Gbit
Green Blink : Activity 10Gbit
Amber On : Link 1Gbit
Amber Blink : Activity 1Gbit
J3 - SFP+ Connector
VeeT
TX_Fault
TX_Disable
SDA
SCL
MOD-ABS
Rate Select 0
RX_LOS
Rate Select 1
VeeR
VeeR
RD-
RD+
VeeR
VccR
VccT
VeeT
TD+
TD-
VeeT
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
JP2 - USB Flash Drive
VCC
N.C.
USB_DATA-
N.C.
USB_DATA+
N.C.
GND
N.C.
N.C. (Key)
N.C.
6
7
8
9
10
1
2
3
4
5
Front Port Assignment
SFP+
«SFP»
Connection
10 GbE xaui1
J2 - AMC Connector
GND
12V
PS1#
MP_3V3
GA0
RSV
GND
RSV
12V
GND
TxD0+
TxD0-
GND
RxD0+
RxD0-
GND
GA1
12V
GND
TxD1+
TxD1-
GND
RxD1+
RxD1-
GND
GA2
12V
GND
TxD2+
(N.C.)
TxD2- (N.C.)
GND
RxD2+
(N.C.)
RxD2- (N.C.)
GND
TxD3+
(N.C.)
TxD3- (N.C.)
GND
RxD3+
(N.C.)
RxD3- (N.C.)
GND
ENABLE#
12V
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
B25
B26
B27
B28
B29
B30
B31
B32
B33
B34
B35
B36
B37
B38
B39
B40
B41
B42
GND
TxD4+
TxD4-
GND
RxD4+
RxD4-
GND
TxD5+
TxD5-
GND
RxD5+
RxD5-
GND
IPMI_CLK
12V
GND
TxD6+
TxD6-
GND
RxD6+
RxD6-
GND
TxD7+
TxD7-
GND
RxD7+
RxD7-
GND
IPMI_DATA
12V
GND
TCLKA+
TCLKA-
GND
TCLKB+
(N.C.)
TCLKB- (N.C.)
GND
FCLKA+
FCLKA-
GND
PS0#
12V
GND
B43
B44
B45
B46
B47
B48
B49
B50
B51
B52
B53
B54
B55
B56
B57
B58
B59
B60
B61
B62
B63
B64
B65
B66
B67
B68
B69
B70
B71
B72
B73
B74
B75
B76
B77
B78
B79
B80
B81
B82
B83
B84
B85
GND
RxD8-
RxD8+
GND
TxD8-
TxD8+
GND
RxD9-
RxD9+
GND
TxD9-
TxD9+
GND
RxD10-
RxD10+
GND
TxD10-
TxD10+
GND
RxD11-
RxD11+
GND
TxD11-
TxD11+
GND
RxD12-
(N.C.)
RxD12+ (N.C.)
GND
TxD12-
(N.C.)
TxD12+ (N.C.)
GND
RxD13-
(N.C.)
RxD13+ (N.C.)
GND
TxD13-
(N.C.)
TxD13+ (N.C.)
GND
RxD14-
(N.C.)
RxD14+ (N.C.)
GND
TxD14-
(N.C.)
TxD14+ (N.C.)
GND
B86
B87
B88
B89
B90
B91
B92
B93
B94
B95
B96
B97
B98
B99
B100
B101
B102
B103
B104
B105
B106
B107
B108
B109
B110
B111
B112
B113
B114
B115
B116
B117
B118
B119
B120
B121
B122
B123
B124
B125
B126
B127
B128
B129
B130
B131
B132
B133
B134
B135
B136
B137
B138
B139
B140
B141
B142
B143
B144
B145
B146
B147
B148
B149
B150
B151
B152
B153
B154
B155
B156
B157
B158
B159
B160
B161
B162
B163
B164
B165
B166
B167
B168
B169
B170
RxD15-
RxD15+
GND
TxD15-
TxD15+
GND
TCLKC-
(N.C.)
TCLKC+ (N.C.)
GND
TCLKD-
(N.C.)
TCLKD+ (N.C.)
GND
RxD17-
(N.C.)
RxD17+ (N.C.)
GND
TxD17-
(N.C.)
TxD17+ (N.C.)
GND
RxD18-
(N.C.)
RxD18+ (N.C.)
GND
TxD18-
(N.C.)
TxD18+ (N.C.)
GND
RxD19-
(N.C.)
RxD19+ (N.C.)
GND
TxD19-
(N.C.)
TxD19+ (N.C.)
GND
RxD20-
(N.C.)
RxD20+ (N.C.)
GND
TxD20-
(N.C.)
TxD20+ (N.C.)
GND
TCK
TMS
TRST#
TDO
TDI
GND
AMC Port Assignment
Port
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
TCLKA
TCLKB
TCLKC
TCLKD
FCLKA
Connection
GbE eth0
GbE eth1
-
-
PCIe Port 0 (Lane 0)
PCIe Port 0 (Lane 1)
PCIe Port 0 (Lane 2)
PCIe Port 0 (Lane 3)
10 GbE xaui0 (Lane 0) or GbE eth2/octeth0
10 GbE xaui0 (Lane 1) or GbE eth3/octeth1
10 GbE xaui0 (Lane 2) or GbE eth4/octeth2
10 GbE xaui0 (Lane 3) or GbE eth5/octeth3
-
-
-
RS232
-
-
-
-
-
From Backplane
-
-
-
PCIe Reference Clock
Region
GbE
GbE
Storage
Storage
Fat Pipe
Fat Pipe
Fat Pipe
Fat Pipe
Fat Pipe
Fat Pipe
Fat Pipe
Fat Pipe
Extended
Extended
Extended
Extended
Extended
Extended
Extended
Extended
Extended
Clock
Clock
Clock
Clock
Clock
Document version 1.0
J4 - RJ45 Serial Port Connector
RTS
DTR
TX#
GND
GND
RX#
DSR
CTS
5
6
7
8
1
2
3
4
