Kontron PC/104-520 User manual

Kontron User’s Guide
PC/104-520
Document Revision 1.2

Table of Contents
Kontron User's Guide PC/104-520
i
Table of Contents
1. USER INFORMATION ........................................................................................................... 1
1.1 About This Document............................................................................................. 1
1.2 Copyright Notice................................................................................................... 1
1.3 Trademarks.......................................................................................................... 1
1.4 Standards............................................................................................................ 1
1.5 Warranty ............................................................................................................. 2
1.6 Technical Support ................................................................................................. 2
2. INTRODUCTION.................................................................................................................. 3
2.1 PC/104-520 ......................................................................................................... 3
2.2 PC/104 an Embedded PC Standard............................................................................ 4
3. GETTING STARTED .............................................................................................................. 5
4. SPECIFICATIONS ................................................................................................................ 6
4.1 Functional Specifications ....................................................................................... 6
4.1.1 Block Diagram...................................................................................................... 8
4.2 Mechanical Specifications....................................................................................... 9
4.2.1 PC/104 Bus Connector ........................................................................................... 9
4.2.2 Module Dimensions ............................................................................................... 9
4.2.3 Height on Top ...................................................................................................... 9
4.2.4 Height on Bottom ................................................................................................. 9
4.3 Electrical Specifications ........................................................................................10
4.3.1 Supply Voltage ....................................................................................................10
4.3.2 Supply Voltage Ripple ...........................................................................................10
4.3.3 Supply Current (typical) ........................................................................................10
4.3.4 External RTC Battery .............................................................................................10
4.4 Environmental Specifications .................................................................................12
4.4.1 Temperature .......................................................................................................12
4.4.2 Humidity ............................................................................................................12
4.5 MTBF .................................................................................................................12
5. CPU, CHIPSET AND SUPER I/O ............................................................................................ 13
5.1 CPU ...................................................................................................................13
5.2 SC520 Microcontroller...........................................................................................13
5.3 Super I/O ...........................................................................................................13
6. ISA BUS EXPANSION......................................................................................................... 14
6.1 PC/104 Bus (ISA part)...........................................................................................14
6.1.1 PC/104 Connectors...............................................................................................14
6.1.2 PC/104 Configuration ...........................................................................................14

Table of Contents
Kontron User's Guide PC/104-520
ii
7. GRAPHICS INTERFACE ....................................................................................................... 15
7.1 CRT Connector .....................................................................................................15
7.2 LCD Panel Connector.............................................................................................15
7.3 Connecting a LCD Panel .........................................................................................16
7.4 Available Video Modes ..........................................................................................16
7.4.1 Standard IBM-Compatible VGA Modes ......................................................................16
7.4.2 Extended VESA VGA Modes .....................................................................................17
7.4.3 Panel Configuration..............................................................................................17
8. SERIAL-PORT INTERFACES ................................................................................................. 19
8.1 Connector ..........................................................................................................19
9. PARALLEL-PORT INTERFACE............................................................................................... 20
9.1 Connector ..........................................................................................................20
10. KEYBOARD INTERFACE ...................................................................................................... 21
10.1 Connector ..........................................................................................................21
10.2 Signal Descriptions ..............................................................................................22
10.2.1 Example Connection AT-keyboard and Other Functions ................................................23
11. PS/2-MOUSE INTERFACE ................................................................................................... 24
11.1 Connector ..........................................................................................................24
12. IDE INTERFACE ................................................................................................................ 25
12.1 Connector ..........................................................................................................25
13. ETHERNET CONTROLLER .................................................................................................... 27
13.1 Connector ..........................................................................................................27
14. FLOPPY-DRIVE INTERFACE ................................................................................................. 28
14.1 Connector ..........................................................................................................28
15. POWER CONNECTOR.......................................................................................................... 29
15.1 Connector ..........................................................................................................29
15.2 Power Pins..........................................................................................................29
15.3 External Battery ..................................................................................................30
16. WATCHDOG TIMER............................................................................................................ 31
16.1 Programming ......................................................................................................31
16.1.1 Initialization.......................................................................................................31
16.1.2 Trigger...............................................................................................................31
16.1.3 Utility SC520Wdt..................................................................................................31
17. DMA CONFIGURATION....................................................................................................... 32
17.1 DMA Acknowledge................................................................................................32
17.2 DMA Request.......................................................................................................33
18. ONBOARD DEVICE CONFIGURATION ..................................................................................... 34

Table of Contents
Kontron User's Guide PC/104-520
iii
19. SETUP GUIDE .................................................................................................................. 35
19.1 Start INSYDE BIOS Setup Utility...............................................................................35
19.2 General Information .............................................................................................35
19.3 Startup Menu ......................................................................................................36
19.4 Video Menu.........................................................................................................36
19.5 Memory Menu......................................................................................................37
19.6 Disks Menu .........................................................................................................37
19.6.1 Hard Disk x Submenu ............................................................................................37
19.7 Components Menu ...............................................................................................38
19.7.1 Keyboard Repeat Submenu ....................................................................................38
19.8 PCI/ISA Menu......................................................................................................39
19.8.1 Configure PCI x Submenu.......................................................................................39
19.8.2 Configure DMA Channels Submenu ..........................................................................39
19.9 Exit Menu ...........................................................................................................40
19.10 Kontron BIOS Extensions.......................................................................................41
19.10.1 JIDA BIOS Extension.............................................................................................41
19.10.2 Remote Control Client Extension .............................................................................41
19.11 Updating the BIOS ...............................................................................................43
19.11.1 Flashing a BIOS ...................................................................................................43
APPENDIX A: SYSTEM RESOURCEN............................................................................................. 44
A.1 Interrupt Request Lines.........................................................................................44
A.2 Direct Memory Access (DMA) Channels .....................................................................45
A.3 I/O Address Map ..................................................................................................46
A.4 Memory Map .......................................................................................................47
A.5 PCI Devices .........................................................................................................47
APPENDIX B: CONNECTOR LAYOUT............................................................................................. 48
B.1 Connector Functions & Interface Cables....................................................................49
B.2 Pinout Table........................................................................................................50
APPENDIX C: LITERATURE HINTS............................................................................................... 53
C.1 General PC Architecture.........................................................................................53
C.2 Buses ................................................................................................................53
C.2.1 ISA, Standard PS/2 - Connectors.............................................................................53
C.2.2 PCI/PC-104.........................................................................................................54
C.3 Ports .................................................................................................................54
C.3.1 RS-232 Serial ......................................................................................................54
C.3.2 ATA ...................................................................................................................54
C.3.3 USB...................................................................................................................54
C.4 Programming ......................................................................................................55
APPENDIX D: REVISION HISTORY .............................................................................................. 56

Chapter 1 User Information
Kontron User's Guide PC/104-520
1
1. User Information
1.1 About This Document
This document provides information about products from Kontron Embedded Modules GmbH and/or its
subsidiaries. No warranty of suitability, purpose, or fitness is implied. While every attempt has been made to
ensure that the information in this document is accurate, the information contained within is supplied “as-
is” - no liability is taken for any inaccuracies. Manual is subject to change without prior notice.
For the circuits, descriptions and tables indicated, Kontron assumes no responsibility as far as patents or
other rights of third parties are concerned.
1.2 Copyright Notice
Copyright © 2007 Kontron Embedded Modules GmbH
All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any form or by any means
(electronic, mechanical, photocopying, recording, or otherwise), without the express written permission of
Kontron Embedded Modules GmbH.
DIMM-PC®, PISA®, ETX®, ETXexpress® , X-board®, DIMM-IO® and DIMM-BUS® are trademarks or re-
gistered trademarks of Kontron Embedded Modules GmbH. Kontron is trademark or registered trademark of
Kontron AG.
1.3 Trademarks
The following lists the trademarks of components used in this board.
IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business
Machines Corp.
Microsoft is a registered trademark of Microsoft Corp.
Intel is a registered trademark of Intel Corp.
All other products and trademarks mentioned in this manual are trademarks of their
respective owners.
1.4 Standards
Kontron Embedded Modules GmbH is certified to ISO 9000 standards.

Chapter 1 User Information
Kontron User's Guide PC/104-520
2
1.5 Warranty
This Kontron Embedded Modules GmbH product is warranted against defects in material and workmanship
for the warranty period from the date of shipment. During the warranty period, Kontron Embedded Modules
GmbH will at its discretion decide to repair or replace defective products.
Within the warranty period, the repair of products is free of charge as long as warranty conditions are
observed.
The warranty does not apply to defects resulting from improper or inadequate maintenance or handling by
the buyer, unauthorized modification or misuse, operation outside of the product’s environmental speci-
fications or improper installation or maintenance.
Kontron Embedded Modules GmbH will not be responsible for any defects or damages to other products not
supplied by Kontron Embedded Modules GmbH that are caused by a faulty Kontron Embedded Modules
GmbH product.
1.6 Technical Support
Technicians and engineers from Kontron Embedded Modules GmbH and/or its subsidiaries are available for
technical support. We are committed to making our product easy to use and will help you use our products
in your systems.
Before contacting Kontron Embedded Modules GmbH technical support, please consult our Website at
http://www.kontron-emea.com/emd for the latest product documentation, utilities, and drivers. If the
information does not help solve the problem, contact us by telephone or email.
Asia Europe North/South America
Kontron Asia Inc. Kontron Embedded Modules GmbH Kontron America
4F, No.415, Ti-Ding Blvd., NeiHu
District,
Taipei 114, Taiwan
Brunnwiesenstr. 16
94469 Deggendorf – Germany
14118 Stowe Drive
Poway, CA 92064-7147
Tel: [phone] Tel: [phone] Tel: [phone]
Fax: + 886 2 2799 7399 Fax: [phone] Fax: [phone]
mailto:[email protected] mailto:[e-mail] mailto:[e-mail]

Chapter 2 Introduction
Kontron User's Guide PC/104-520
3
2. Introduction
2.1 PC/104-520
The PC/104-520 SBC supports the AMD Elan TMSC520 Embedded System Platform. It's a versatile, low-cost,
low-power module that conforms to the industry standard 90mm x 96mm PC/104 form factor.
The PC/104-520 features the following:
Industry-standard Am5x86®CPU with FPU
System ROM (BIOS)
Up to 64 MB SDRAM support
Direct memory access (DMA) controllers
Counters
Interrupt controllers
Keyboard/mouse controllers
Speaker interface
Integrated Drive Electronics (IDE) hard-disk interface
Serial ports (COM1 and COM2)
Parallel port (LPT1)
Real-time clock
Watchdog timer
Graphic controller with 4 MB on-chip memory
10/100Base-TX Ethernet
ISA bus

Chapter 2 Introduction
Kontron User's Guide PC/104-520
4
2.2 PC/104 an Embedded PC Standard
By standardizing hardware and software around the broadly supported PC architecture, embedded system
designers can substantially reduce development costs, risks, and time-to-market.
For these reasons, companies that embed microcomputers as controllers within their products seek ways to
reap the benefits of using the PC architecture. However, the standard form factor of a PC bus (12.4” x 4.8”)
and its associated card cages and backplanes are too bulky and expensive for most embedded control appli-
cations.
The only practical way to embed the PC architecture in space and power sensitive applications has been to
design a PC chip by chip directly into the product. But this runs counter to growing trend away from
“reinventing the wheel.” Whenever possible, management encourages outsourcing of components and
technologies to reduce development costs and accelerate product design cycles.
A need has arisen for a more compact implementation of the PC bus, satisfying the reduced space and power
constraints of embedded control applications. PC/104 was developed in response to this need. It offers full
architecture, hardware and software compatibility with the PC bus but in ultra-compact (3.6” x 3.8”)
stackable modules. PC/104 is ideally suited to the unique requirements of embedded control applications.
Although configuration and application possibilities with PC/104 modules are practically limitless, there are
two ways to use them in embedded system designs:
Standalone module stacks
PC/104 modules are self-stacking. The modules are used like ultra-compact bus boards
but do not need backplanes or card cages.
Component line applications
In this configuration, the modules function as highly integrated components, plugged
into custom carrier boards that contain application specific interfaces and logic.

Chapter 3 Getting Started
Kontron User's Guide PC/104-520
5
3. Getting Started
The easiest way to get the PC/104-520 board running is to use a starter kit from Kontron Embedded Modules
GmbH. Take the following steps:
Connect the power supply to the starter kit baseboard (part of the starter kit).
Plug the PC/104-520 to the PC/104 bus connector on the starter kit baseboard.
Make all necessary connections from the PC/104-520 to the starter kit board.
Connect the CRT monitor to the CRT interface or a LCD panel to the LCD-interface by using the
corresponding adapter cable.
Plug a keyboard to the starter kit’s keyboard connector.
Plug a hard-drive data cable to the PC/104-520 hard-disk interface. Attach the hard disk to the
connector at the opposite end of the cable. If necessary, connect the power supply to the hard
disk’s power connector.
Make sure all your connections have been made correctly. Turn on the power.
Enter the BIOS by pressing the CTRL+ALT+S keys during boot-up. Make all changes in the BIOS
setup. See the BIOS chapter of this manual for details.

Chapter 4 Specifications
Kontron User's Guide PC/104-520
6
4. Specifications
4.1 Functional Specifications
Processor
•Industry-standard Am5x86®CPU with FPU
•100 and 133 MHz operating frequencies
Internal Bus
•33 MHz PCI bus
Power Supply
•5V supply only
•Onboard power supply to low-voltage technology
Super I/O
•Winbond W83977HF
Cache
•On-die 16kB write-back cache
Memory
•Onboard memory up to 64 MB
Two Serial Ports
•COM1 and COM2 (RS232C compatible)
•16550-compatible
One Parallel Port (LPT1)
•Bi-directional and Enhanced Parallel Port (EPP) capability
IDE-Interface (P-ATA)
•Standard IDE port (up to two devices)
Ethernet
•Onboard controller Intel® 82551ER 10/100BASE-T LAN
Video Graphics Array (VGA)
•Onboard controller Silicon Motion SM712 (LynxEM+) with 2D drawing engine, VGA
core, LCD backend controller and 135 MHz RAMDAC
•Cathode ray tube (CRT) and LCD flatpanel interface (up to 1024x768 resolution)
Insyde BIOS, 256kB Flash BIOS
Flash BIOS support for CMOS Setup Retention without Battery

Chapter 4 Specifications
Kontron User's Guide PC/104-520
7
PS/2 Keyboard Controller
PS/2 Mouse Controller
Watchdog timer (WDT)
Real-time Clock (requires external battery)
External ISA Bus
•Full 8/16 bit Memory and I/O access
•All ISA IRQ and DMA signals

Chapter 4 Specifications
Kontron User's Guide PC/104-520
8
4.1.1 Block Diagram
PC/104-520
SDRAM
LCD CRT
IDE Interface
BIOS
PCI BUS
Transformer
PC/104 Connector
Graphic Controller
LynxEM+
Super-I/O W83977
PS/2
Interface Serial Ports
Parallel
Port
Floppy
Interface
LPT
FDD
COM B
COM A
Keyboard
Mouse
SC520 Processor
PCI Bus
Memory
Interface
General
Purpose Bus
GP Bus
ISA BUS
Network Controller
i82551ER
HDD
PCI Bus

Chapter 4 Specifications
Kontron User's Guide PC/104-520
9
4.2 Mechanical Specifications
4.2.1 PC/104 Bus Connector
One 2x32 pin stackthrough and one 2x20 pin stackthrough connector
4.2.2 Module Dimensions
96 x 90mm (3.77” x 3.55”)
4.2.3 Height on Top
Maximum 11.1mm
4.2.4 Height on Bottom
Maximum 10.67mm including PC/104 connector

Chapter 4 Specifications
Kontron User's Guide PC/104-520
10
4.3 Electrical Specifications
4.3.1 Supply Voltage
5V DC +/- 5 %
4.3.2 Supply Voltage Ripple
100 mV peak to peak 0 - 20 MHz
4.3.3 Supply Current (typical)
Power consumption tests were executed during the DOS prompt. The tested boards were equipped with 16
MB SDRAM.
Mode Normal
Power Consumption
100 MHz 0.9 A
Power Consumption
133 MHz 1.0 A
4.3.4 External RTC Battery
Voltage range: 2.4V - 3.6V (typ. 3.0V)
Maximum current: 10µA @ 3.0V
English:
CAUTION ! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.
Deutsch:
VORSICHT ! Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch den selben oder einen vom
Hersteller empfohlenen gleichwertigen Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers.
French:
ATTENTION ! Risque d'explosion avec l'échange inadéquat de la batterie. Remplacement seulement par le même ou un
type équivalent recommandé par le producteur. L'évacuation des batteries usagées conformément à des indications du
fabricant.
Danish:
ADVARSEL ! Lithiumbatteri – Eksplosionsfare ved fejlagtig Håndtering. Udskifting må kun ske med batteri af samme
fabrikant og type. Lever det brugte batteri tilbage til leverand∅ren.

Chapter 4 Specifications
Kontron User's Guide PC/104-520
11
Finnish:
VAROITUS ! Paristo voi rãjãhtãã, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan laltevalmistajan
suosittelmaan tyyppiln. Havita kaytetty paristo valmistajan ohjeiden mukaisesti.
Spanish:
Precaución ! Peligro de explosión si la batería se sustituye incorrectamente. Sustituya solamente por el mismo o tipo
equivalente recomendado por el fabricante. Disponga las baterías usadas según las instrucciones del fabricante.
The battery of this product is not considered to be accessible by the end user. Therefore the safety instructions are only given in
english, german, french, danish, finish and spanish language.
If the battery of this product however is accessible by the end user, it is in the responsibility of the customer to give the
corresponding safety instructions in the required language(s).

Chapter 4 Specifications
Kontron User's Guide PC/104-520
12
4.4 Environmental Specifications
4.4.1 Temperature
The AMD SC520 is specified for proper operation when case temperature is within the specified range of
+5°C to +85°C.
Operating: +5° to +55°C (1)
Non operating: -10° to +80°C
Note: 1The maximum operating temperature is the maximum measurable temperature on any spot on a module’s
surface. You must maintain the temperature according to the above specification.
4.4.2 Humidity
Operating: 10% to 90% (non condensing)
Non operating: 5% to 95% (non condensing)
4.5 MTBF
The following MTBF (Mean Time Between Failure) values were calculated using a combination of manu-
facturer’s test data, if the data was available, and a Bellcore calculation for the remaining parts. The
Bellcore calculation used is “Method 1 Case 1”. In that particular method the components are assumed to be
operating at a 50% stress level in a 40°C ambient environment and the system is assumed to have not been
burned in. Manufacturer’s data has been used wherever possible. The manufacturer’s data, when used, is
specified at 50°C, so in that sense the following results are slightly conservative. The MTBF values shown
below are for a 40°C in an office or telecommunications environment. Higher temperatures and other
environmental stresses (extreme altitude, vibration, salt water exposure, etc.) lower MTBF values.
System MTBF (hours) : tbd
Note: Fans usually shipped with Kontron Embedded Modules GmbH products have 50,000-hour typical operating life.
The above estimates assume no fan, but a passive heat sinking arrangement. Estimated RTC battery life (as
opposed to battery failures) is not accounted for in the above figures and need to be considered for
separately. Battery life depends on both temperature and operating conditions. When the Kontron unit has
external power; the only battery drain is from leakage paths.

Chapter 5 CPU, Chipset and Super I/O
Kontron User's Guide PC/104-520
13
5. CPU, Chipset and Super I/O
5.1 CPU
The central processing unit (CPU) is part of the AMD SC520 Microcontroller with following features
Industry-standard Am5x86®CPU with FPU, 100 and 133 MHz operating frequencies
High performance, low-power core
On-die 16 kByte write-back cache
5.2 SC520 Microcontroller
32 bit 3.3V PCI bus (5V tolerant) Rev. 2.2 compliant
Integrated SDRAM controller supports 16-, 64-, 128- and 256-MBit RAM up to 64
MBytes
General Purpose (GP) bus with programmable timing for 8 and 16 Bit devices
On-Chip Flash controller
Standard PC/AT compatible peripherals as Timer, IRQ and DMA controller
Integrated watchdog function
5.3 Super I/O
The external Super I/O WINBOND W83977F offers the following features:
Integrated keyboard controller with PS/2 mouse support
Two serial ports and one multi-mode parallel port
Floppy disk controller

Chapter 6 ISA Bus Expansion
Kontron User's Guide PC/104-520
14
6. ISA Bus Expansion
The design of the PC/104-520 follows the standard PC/104 form factor and offers ISA bus signals for the use
of standard PC/104 adapter cards.
6.1 PC/104 Bus (ISA part)
The PC/104 bus consists of two connectors that use 104 pins in total.
XT bus connector (64 pins)
AT bus connector (40 pins, which is optional for 16 bit data bus system)
The pinout of the PC/104 bus connectors corresponds to the pinout of the ISA bus connectors with some
added ground pins. The two PC systems with different form factors are electrically compatible.
The XT bus connector, Row A and B.
The corresponding 64-pin stackthrough header (ISA bus = 62pins) has two added ground pins at the end of
the connector (Pin A32 and Pin B32). The pinout between PC/104 bus and XT ISA bus is identical between
A1 - A31 and B1 - B31.
The AT bus extension connector, Row C and D.
The corresponding 40-pin stackthrough header (ISA bus = 36 pins) has four added ground pins, two on each
side of the connector. To avoid confusion, the first two pins are defined as Pin C0 and Pin D0. The additional
ground pins at the end of the connector are defined as C19 and D19. The pinout between PC/104 bus and AT
ISA bus is identical between C1 - C18 and D1 - D18.
6.1.1 PC/104 Connectors
The PC/104-520 features both – XT bus and AT bus extension – on two, dual-row socket connector with
2.54mm x 2.54mm grid (0.1” x 0.1”).
The PC/104 XT bus is available through the X4B connector. The PC/104 AT bus is available through the X4C
connector.
A detailed description of the signals including electrical characteristics and timings is beyond the scope of
this document. Please refer to the official ISA bus and PC/104 specifications for more details.
6.1.2 PC/104 Configuration
When using add-on boards on the PC/104 bus, make sure that there are no resource conflicts in the system.
Carefully choose hardware interrupts, DMA channels, memory and I/O address ranges to avoid resource
conflicts, which are often the reason for a board or a feature not functioning correctly.
PC/104 adapter cards are mounted in a stack-through manner. Adapter cards are designed with plugs on
their undersides that mate with the PC/104 socket connectors of PC/104-520. PC/104 adapters can support
the socket connector version on their topside and allow additional stacking of adapters.
Whenever possible use the PC/104-520 as top module of the PC/104 stack as the CPU board is normally the
board with the highest heat dissipation.

Chapter 7 Graphics Interface
Kontron User's Guide PC/104-520
15
7. Graphics Interface
The graphics controller supports CRT monitors and a variety of LCD panels with single or double clock, color
depths of 18/24 bit and resolutions up to XGA (1024x768).
7.1 CRT Connector
The CRT monitor interface is available through the J4 connector (10 pins). To have the signals available on a
standard DSUB-15 CRT monitor connector, an adapter cable is required. A 15-pin DSUB cable is available
from Kontron (KAB-PC104520-VGA, Part Number 96229-0200-00-0).
Header Pin Signal Name Function DSUB-15
1 GND Signal ground 7
2 GND Signal ground *
3 GND Signal ground *
4 GND Signal ground *
5 RED Analog video red 1
6 HSYNC Horizontal sync 13
7 GREEN Analog video green 2
8 VSYNC Vertical sync 14
9 BLUE Analog video blue 3
10 NC Not connected --
To find the location of the CRT connector on the PC/104-520 board, please see the Appendix “Connector
Layout”.
7.2 LCD Panel Connector
The interface for the LCD Panel is available through the J3 connector (50 pins) on the top side of the board.
Detailed information about available panel cables on request.
When using a LCD Panel, additional voltages may be required to drive the display’s logic and to supply the
backlight converter. The display logic may require +5V for standard or +3.3V for low-power LCDs. The on-
board 3.3V-circuitry of the PC/104-520 and the +3.3V logic voltage of low-voltage panels are share the
same voltage regulators.
To find the location of the LCD Panel interface connector on the PC/104-520 board, please see the Appendix
“Connector Layout”.
Note: You need to supply the +12V for the backlight converter additionally when using such a converter type.

Chapter 7 Graphics Interface
Kontron User's Guide PC/104-520
16
7.3 Connecting a LCD Panel
To determine whether your panel display is supported, check the Kontron Website for panel lists. We regu-
larly update the list of panels that have been tested with the PC/104-520.
If you use one of those cables supplied by Kontron, configuration is easy:
Check whether you have the correct cable for the panel you plan to use. Inspect the cable for
damages. Disconnect the power from your system.
Check Jumper J16 for correct Panel voltage (J16 1-2 = 5V 2-3 = 3.3V). Hint: J16 1-2 default.
Check Jumper J17 for inverting data clock (J17 1-2 = normal 2-3 = inverted). Hint: J17 1-2
default.
Connect the cable to the LCD Panel connector J3 on the PC/104-520 and connect the other end
to your display.
Connect the backlight converter.
Supply power to your system.
If no image appears on your display, connect a CRT monitor to the CRT connector.
If you still do not see improvement, consider contacting the dealer for technical support.
7.4 Available Video Modes
The following list shows the video modes supported by the graphics controller with maximum frame buffer
size. Capability depends on system configuration and on display capabilities. Different operating systems
also may not support all listed modes by the available drivers.
7.4.1 Standard IBM-Compatible VGA Modes
Video Mode Type Characters/Pixels Colors
00h/01h Text 40x25 16
02h/03h Text 80x25 16
04h/05h Graphics 320x200 4
06h Graphics 640x200 2
07h Text 80x25 2
0Dh Graphics 320x200 16
0Eh Graphics 640x200 16
0Fh Graphics 640x350 2
10h Graphics 640x350 16
11h Graphics 640x480 2
12h Graphics 640x480 16
13h Graphics 320x200 256
