Kramer FC-46xl User manual

KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
FC-46xl
HDMI Audio De-Embedder
P/N: 2900-000626 Rev 8

FC-46xl – Contents
i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Recycling Kramer Products 3
3Overview 4
4Defining the FC-46xl 5
5Connecting the FC-46xl 6
6Technical Specifications 8
Figures
Figure 1: FC-46xl HDMI Audio De-Embedder 5
Figure 2: Connecting the FC-46xl HDMI Audio De-Embedder 7

FC-46xl - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer FC-46xl HDMI Audio De-Embedder,
which is ideal for the following typical applications:
Home theater, presentation and multimedia applications
Rental and staging

2
FC-46xl - Getting Started
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check if
firmware upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer FC-46xl away from moisture, excessive sunlight and
dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
Caution:
No operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
i
!
!

FC-46xl - Getting Started
3
2.2 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

4
FC-46xl - Overview
3 Overview
The FC-46xl is a high−performance HDMI audio de−embedder. The unit
de−embeds audio from the HDMI input or from the HDMI output Audio Return
Channel to S/PDIF, TOSLINK® and analog audio outputs simultaneously.
The FC-46xl lets you connect your HDMI source to an HDMI display and enjoy
high-quality digital audio at the same time (for example, when using a high-quality
AV receiver).
When there are more than two channels of audio (for example, 5.1),
the audio is available only on the digital outputs and the analog
output is disabled.
In particular, the FC-46xl features:
A maximum data rate of 6.75Gbps (2.25Gbps per data channel)
HDTV compatibility with support for resolutions up to 1080p@60Hz
HDCP compliance
Kramer re-Klocking™ and Equalization Technology – Rebuilds the digital
signal to travel longer distances.
HDMI support for ARC and HDMI uncompressed audio channels
Input format auto detection; digital RGB or YPbPr
Support for deep color up to 36 bits per pixel at 1080p
I-EDIDPro™ Kramer Intelligent EDID Processing™ an Intelligent EDID
handling and processing algorithm that ensures Plug and Play operation for
HDMI systems
5V DC power
i

FC-46xl - Defining the FC-46xl
5
4 Defining the FC-46xl
Figure 1 defines the FC-46xl HDMI Audio De-Embedder.
Figure 1: FC-46xl HDMI Audio De-Embedder
#
Feature
Function
1
AUDIO SOURCE
SELECT Button
INPUT
Release to select audio from HDMI IN
OUTPUT
Press in to select audio from HDMI OUT TV
audio return signal
2
IN LED
Lights to indicate signal presence at HDMI IN
3
OUT LED
Lights to indicate that an acceptor is
connected to HDMI OUT
4
ON LED
Lights when the unit is powered on
5
HDMI IN Connector
Connect to the HDMI source
6
HDMI OUT Connector
Connect to the HDMI acceptor
7
TOSLINK Connector
AUDIO
OUT
Connect to the digital audio acceptor
8
S/PDIF RCA Connector
9
ANALOG 3.5 Mini
Connector
10
5V DC
+5V DC connector for powering the unit,
center positive

6
FC-46xl - Connecting the FC-46xl
5 Connecting the FC-46xl
Always switch off the power to each device before connecting it to your
FC-46xl. After connecting your FC-46xl, connect its power and then
switch on the power to each device.
To connect the FC-46xl as illustrated in the example in Figure 2:
1. Connect the HDMI source (for example, a Blu-ray disc player) to the HDMI
IN connector.
2. Connect the HDMI OUT connector to the HDMI acceptor (for example, a
plasma display).
3. Connect the audio output(s) to the digital/analog audio acceptor(s),
for example, power amplifier(s) or active speaker(s).
The analog audio output is disabled when there are more than two
channels (for example, 5.1) on the audio input.
4. Using the AUDIO SOURCE SELECT button, select the audio source to be
either the HDMI input (button released, audio is taken from the Blu-ray Disc),
or the HDMI output (button pressed in, audio is taken from the TV audio
return signal).
5. Connect the 5V DC power adapter to the power socket and connect the
adapter to the mains electricity (not illustrated in Figure 2).
i
i

FC-46xl - Connecting the FC-46xl
7
Figure 2: Connecting the FC-46xl HDMI Audio De-Embedder

8
FC-46xl - Technical Specifications
6 Technical Specifications
INPUT:
HDMI connector
OUTPUTS:
1 HDMI connector
1 TOSLINK®optical digital audio connector
1 S/PDIF digital audio on an RCA connector
1 Analog audio on a 3.5 mm mini connector
OPERATION FREQUENCY:
Supports up to 6.75Gbps (2.25Gbps per graphic channel)
1080p @60Hz, 36-bit Deep Color
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI, HDCP
CONTROLS:
Audio Source Select button
INDICATOR LEDS:
ON, IN, OUT
POWER SOURCE:
5V DC, 730mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.4cm x 7cm x 2.4cm (4.9" x 2.8" x 0.94") W, D, H
WEIGHT:
0.4kg (0.88lbs) approx.
INCLUDED ACCESSORIES:
Power supply
OPTIONS:
Kramer 10-Port Universal 5V Power Supply VA-100P-5
RK-3T 19” rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com

For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N:
2900-000626
Rev:
8
!
SAFETY WARNING
Disconnect the unit from the power
supply before opening and servicing
