RTBUS-4C Quick Start
P/N:
2900- 301345QS
Rev:
4
Scan for full manual
RTBUS-4C Quick Start Guide
This guide helps you install and use your RTBUS-4C for the first time.
Go to www.kramerav.com/downloads/RTBUS-4C to download the latest user manual and check if firmware
upgrades are available.
Step 1: Check what’s in the box
1 RTBUS-4C Round Table Mount
Cable Pass-Through
4 Cable bushings
1 Locking screw for locking ring
1 Quick start guide
Step 2: Get to know your RTBUS-4C
#
Feature
1
Enclosure
2
Locking Ring
3
Inner Plate
4
Cable Slot
5
Inner Plate Screws (4)
6
Cable Bushings

Step 3: Mount RTBUS-4C
To mount RTBUS-4C:
1. Cut a hole in the table 115mm in diameter.
2. Remove the four inner plate screws and remove the
inner plate from the enclosure.
3. Run the cables under the table, through the locking
ring, and up through the hole in the table.
4. Insert the cables into the bushings on the slots of the
inner plate.
5. Place the inner plate into the enclosure and secure
the four screws.
6. Place the enclosure into the hole in the table and
secure it with the locking ring.
7. Secure the locking ring with the locking ring screw.
Technical Specifications
Compatibility
Maximum Cable Diameter
8mm
Minimum Strain Relief Width
9mm
Physical
Enclosure & Locking Ring Material
Aluminum
Inner Plate Material
Steel
Cutout Dimensions
115mm Ø
Weight
0.55kg
Specifications are subject to change without notice at www.kramerav.com
