Introduction
1
1 Introduction
Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video,
audio and presentation professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in 8 Groups
1
, which are clearly defined
by function.
Congratulations on purchasing your WP-230 active wall plate, which is ideal for
graphics and audio installations in board, conference and training rooms, as well
as long distance signal distribution.
The package includes the following items:
 WP-230
 Power supply
 This user manual
2
2 Getting Started
We recommend that you:
 Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
 Review the contents of this user manual
 Use Kramer high performance high resolution cables
3
3 Overview
This section summarizes:
 The WP-230, see section 3.1
 Using shielded twisted pair (STP) / unshielded twisted pair (UTP), see
section 3.2
 Recommendations for achieving the best performance, see section 3.3
1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
2
3.1 About the WP-230
The Kramer WP-230 XGA/Video/Audio Line Driver wall plate includes:
 A computer graphics XGA INPUT on a standard HD-15 connector
 An amplified and equalized RGBHV output on 5 BNC connectors
 A composite video input on an RCA connector with a corresponding
composite video output on a 2-pole terminal block
 An s-Video input on a 4p connector with a corresponding s-Video output
on a 4-pole terminal block
 An unbalanced stereo PC AUDIO INPUT on a 3.5mm mini jack with a
corresponding balanced stereo PC AUDIO OUT on a 5-pole terminal block
 An unbalanced stereo LINE AUDIO INPUT on two RCA connectors with
a corresponding balanced stereo LINE AUDIO OUT on a 5-pole terminal block
In particular, the WP-230 has:
 Trimmer controls for XGA EQ.
1
, and CV Level / EQ.
1
 Separate trimmer controls for right and left line audio level, and C and Y
levels
 Resolution exceeding UXGA, that ensures transparent operation
 A standard 12 Volt DC feed
3.2 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP)
The decision whether to use shielded twisted pair (STP) cable or unshielded
twisted pair (UTP) cable depends on the nature of the application. It is
recommended that in applications with high interference, shielded twisted pair
(STP) cable is used. However, the shield itself does create a capacitance that
degrades the frequency response of the machines. For shorter distances, of 50m
or so, shielded twisted pair (STP) cable is preferred because it provides protection
from interference (degradation is non apparent). For a long range application,
unshielded twisted pair (UTP) cable is preferred. However, the unshielded twisted
pair (UTP) cable should be installed far away from electric cables, motors and so
on, which are prone to create electrical interference.
Some Kramer twisted pair products include the Power Connect feature
2
. The
WP-230 does not have this feature.
1 Cable equalization
2 The Power Connect feature lets you power a transmitter / receiver system by connecting just one power adapter to either the
transmitter or the receiver. The other unit is fed over the same cable. The Power Connect feature applies as long as the cable
is heavy gauge cable (that is, it can carry power). The distance does not exceed 50 meters on standard CAT5 cable. For a
distance of 100 meters, separate power supplies must be connected to the transmitter and to the receiver simultaneously,
unless using heavy gauge cable

Your WP-230
3
3.3 Recommendations for Achieving the Best Performance
Achieving the best performance means:
 Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)
 Avoiding interference from neighboring electrical appliances
 Positioning your WP-230 away from moisture, excessive sunlight and dust
4 Your WP-230
This section defines the WP-230:
 Front panel (see section 4.1)
 Left panel (see section 4.2)
 Right panel (see section 4.3)
4.1 Your WP-230 Front Panel
Figure 1 and Table 1 define the front panel of the WP-230:
Figure 1: WP-230 Front Panel

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your WP-230
4
Table 1: WP-230 Front Panel Features
# Feature Function
1 Holes (2) For fastening the wall plate in place
2 XGA
1
INPUT HD15F
Connector
Connect to the computer graphics source
3 CV IN RCA Connector Connects to the composite video source
4 RJ-45 Connector Connect to
2
the RJ-45 connector on a Kramer CAT5 transmitter / receiver
5 Y/C IN 4p Connector Connects to the s-Video source
6 PC AUDIO INPUT
3.5mm Mini Jack
Connects to the unbalanced stereo audio PC source
7 RIGHT RCA
Connector
Connects to the unbalanced right stereo audio source
8
LINE
AUDIO
INPUT
LEFT RCA
Connector
Connects to the unbalanced left stereo audio source
9 ON LED Illuminates when receiving power
4.2 Your WP-230 Left Panel
Figure 2 and Table 2 define the left panel of the WP-230:
Table 2: WP-230 Left Panel
#
Feature Function
1 LINE AUDIO OUT
Terminal Block
Connects to the balanced
stereo audio acceptor
3
2 R Trimmer Adjusts
4
the right audio
output signal level
3
LINE
AUDIO
LEVEL
L Trimmer Adjusts
4
the left audio output
signal level
4 C Trimmer Adjusts
4
the C level
5
Y/C
LEVEL
Y Trimmer Adjusts
4
the Y level
6 Y/C OUT Terminal Block Connects to the s-Video
acceptor
7 PC AUDIO OUT Terminal
Block Connector
Connects to the balanced
stereo audio from the PC
3
Figure 2: WP-230 Left Panel
1 Can be used for any RGBHV resolution (for example, VGA, XGA, UXGA and so on)
2 Using a UTP cable with an RJ-45 connector (the PINOUT is defined in section 5.2)
3 Can be used for unbalanced audio. To do this, connect using the “+” and “G” terminal only (leave the “–” terminal
unconnected – see Figure 6)
4 Insert a screwdriver into the small hole and carefully rotate it, trimming the appropriate level

Your WP-230
5
4.3 Your WP-230 Right Panel
Figure 3 and Table 3 define the right panel of the WP-230:
Table 3: WP-230 Right Panel
#
Feature Function
1 XGA EQ.
1
Trimmer
Adjusts
2
the cable compensation
equalization level
2 +12V
PIN
Connect (+) to the connector for
powering the unit
3
POWER
GND PIN
Connect (-) to the Ground
4 CV LEVEL / EQ.
Trimmer
Adjusts
2
the composite video level /
cable compensation equalization
level
5 GND PIN Connect to the Ground of the
composite video aceptor
6 CV OUT PIN Connect to the composite video
acceptor
Figure 3: WP-230 Right Panel
1 Degradation and VGA/XGA signal loss can result from using long cables (due to stray capacitance), sometimes leading to a
total loss of sharpness in high-resolution signals
2 Insert a screwdriver into the small hole and carefully rotate it, trimming the appropriate level

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Using the WP-230
6
5 Using the WP-230
You can use your WP-230, for example, in a conference room, as the example
in Figure 4 illustrates:
Figure 4: Example of Conference Room WP-230 Installation
For details of how to:
 Install your WP-230, see section 5.1
 Wire the CAT5 RJ-45 connector, see section 5.2
 Operate your WP-230, see section 5.3

Using the WP-230
7
5.1 Installing the WP-230
To install your WP-230:
1. Connect the 5 RGBHV BNC output connectors
1
to the pre-installed
wiring in the wall box opening that connects to the XGA acceptor (for
example, a projector), as Figure 5 defines.
Figure 5: WP-230 RGBHV Outputs
2. Connect the LINE AUDIO OUT and / or the PC AUDIO OUT terminal
blocks, as one of the following:
Figure 6: Connecting the LINE AUDIO OUT / PC AUDIO OUT
3. Connect the wires of the coax cable to the CV OUT pins
2
, taking care that
polarity is correct.
4. Connect the wires of the coax cable to the Y/C OUT pins
3
, taking care
that polarity is correct.
5. Connect your 12V DC power supply to the POWER pins
4
, taking care that
polarity is correct.
6. Insert the WP-230 directly into the wall box opening, and then mount the
front panel securely using the screws.
1 The WP-230 could be used for component HDTV by connecting YPbPr in place of GBR, and not connecting H and V
2 Connect the composite video wire to the CV OUT pin and the Ground wire to the GND pin (see Figure 8)
3 Connect the luminance signal “Y” wire to the Y pin and the Ground wire to its corresponding GND pin, and connect the
chrominance signal “C” wire to the C pin and the Ground wire to its corresponding GND pin (see Figure 8)
4 Connect the wire labeled “+” to the +12V pin, and the wire labeled “–” to the GND pin
