Kramer MTX3-16-M User manual

P/N: 2900-301590 Rev 1 www.kramerav.com
USER MANUAL
MODEL:
MTX3-16-M
16x16 8K Modular Matrix

Kramer Electronics Ltd.
MTX3-16-M –Contents
2
Table of Contents
Table of Contents 2
Introduction 3
Getting Started 3
Overview 4
Typical Applications 5
Defining MTX3-16-M 16x16 8K Modular Matrix 6
Mounting MTX3-16-M 8
Connecting MTX3-16-M 9
Installing Matrix Cards 10
Identifying Input / Output Ports 11
Using MTX3-16-M to Provide PoE 11
Managing MTX3-16-M via Ethernet 11
Managing MTX3-16-M via RS-232 14
Managing MTX3-16-M via USB (VCOM) 14
Securing MTX3-16-M Operation 15
Standard Certification 15
MTX3-16-M Security Means 15
Managing MTX3-16-M 16
Managing MTX3-16-M via Front Panel Buttons 17
Using MTX3-16-M LCD Display Menu 17
Using TAKE Button to Confirm Actions 25
Locking Front Panel Buttons 25
Managing MTX3-16-M from the Embedded Web UI 26
Opening the Embedded Web UI 27
Routing Inputs to Outputs 28
Defining User Accounts 36
Acquiring EDID 39
Configuring MTX3-16-M 40
Upgrading / Restoring Module Card Firmware 42
Configuring Input / Output Ports 43
Monitoring MTX3-16-M Hardware 45
Viewing the about Page 48
Upgrading Firmware 49
Upgrading Firmware from the Web UI 49
Upgrading Firmware –K-Upload 49
Technical Specifications 51
MTX3-16-M CNTL and Chassis 51
Matrix Cards 52
Default Communication Parameters 56
Default EDID 57
Default EDID for Output Cards 59
Protocol 3000 70
Understanding Protocol 3000 70
Protocol 3000 Commands 71
Result and Error Codes 84

Kramer Electronics Ltd.
MTX3-16-M –Introduction
3
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
•Review the contents of this user manual.
Go to www.kramerav.com/downloads/MTX3-16-M to check for up-to-date user manuals,
application programs, and to check if firmware upgrades are available (where appropriate).
Achieving Best Performance
•Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
•Do not secure the cables in tight bundles or roll the slack into tight coils.
•Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
•Position your Kramer MTX3-16-M away from moisture, excessive sunlight and dust.
Safety Instructions
Caution:
•This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
•For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
•There are no operator serviceable parts inside the unit.
Warning:
•Use only the power cord that is supplied with the unit.
•Disconnect the power and unplug the unit from the wall before installing.
•Do not open the unit. High voltages can cause electrical shock! Servicing by qualified
personnel only.
•To ensure continuous risk protection, replace fuses only according to the rating
specified on the product label which is located on the bottom of the unit.

Kramer Electronics Ltd.
MTX3-16-M –Introduction
4
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/il/quality/environment.
Overview
MTX3-16-M is an intelligent and high performance 16x16 modular matrix for switching and
distribution of multi-format audio-visual signals. The chassis includes a CTRL central control
card with secured LAN connectivity for remote management and control, as well as eight card
slots for flexible insertion of modular matrix cards, accommodating matrix cards with quad or
dual ports of either input or output multi-format signals.
Exceptional Quality
•High Resolution Audio-Visual Experience –MTX3-16-M is a professional, 8K-ready
matrix for switching multi-format AV signals. The modular matrix cards support 4K60
4:4:4 multi-format AV signal distribution and the backplane router is ready for 8K audio-
visual signal switching, enabling future upgrades to 8K-capable matrix cards.
•HDMI™Signal Switching –HDCP 2.2 compliant, supporting deep color, x.v.Color™,
CEC, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K,
and 3D as specified by the HDMI 2.0 standard.
•I-EDIDPro™Kramer Intelligent EDID Processing™–Intelligent EDID management of
each input port by a processing algorithm that manages locking and pass-through and
ensures plug & play operation for HDMI sources and display systems.
•Robust Signal Distribution –Kramer Equalization & re-Klocking™technology
professionally rebuilds switched digital signals, preparing them for distribution over long-
distance copper and fiber optic cables.
Advanced and User-friendly Operation
•Comprehensive Matrix Control Options –Control can be remotely, using the Kramer
Control application, for example, or locally.
A user-friendly web-UI provides high-level remote service control.
Locally, the RS-232 service port can be used for high-level Protocol 3000 APIs and there
are front panel control buttons and an LCD screen which can perform switching
operations, storage and recall of switching presets and configuration switching.
•Security-certified Operation –The matrix is certified for OWASP-10 (Open Web
Application Security Project) standard compliance, ensuring secured web-UI user
access and communication, and secured remote operation and management.

Kramer Electronics Ltd.
MTX3-16-M –Introduction
5
•Simple Professional Management –Compatibility with the Kramer enterprise
management platform enables remote matrix operational management, including matrix
automatic discovery and configuration, remote matrix switching operations, matrix and
card diagnostics and firmware upgrade management.
•Cost-Effective Maintenance –Front-panel LED indicators, an LCD display and a low-
noise field-replaceable fan cooling unit for easy matrix maintenance and troubleshooting.
Local firmware upgrades can be performed via a USB port for convenient, lasting, field-
proven deployment.
•Easy Installation –The compact 3U-only 19” enclosure is suitable for rack mounting with
a universal 100-240V AC power supply. PoE (Power over Ethernet) can be provided
over HDBT cables to remote connected end-points, eliminating the need for local mains
powering.
Flexible Connectivity
•Any input/output mix –Flexible matrix card slot support for either input or output cards
service. Mix setup and deployment flexibly to match usage needs.
•Multi-format Distribution –The matrix card range supports multiple market-available
audio-visual signals, such as HDMI™, VGA, and SDI, with analog and digital audio
signals. Kramer Core™technology enables long-distance signal distribution over
standard HDBaseT copper cables and fiber optic infrastructure wiring.
•Independent Signal Switching –Modular matrix switching is fully non-blocking, where
any matrix input signal can be distributed to any single or multiple output ports.
•Market-standard Interoperability –The matrix complies with HDBaseT standards and
interoperates with market available HDBaseT-certified end-points. For best reach and
high-resolution distribution performance, use Kramer HDBaseT cables, and Kramer
transmitter and receiver end-points.
Typical Applications
MTX3-16-M is ideal for the following typical applications:
•Professional large audio-visual switching systems in large-space facilities.
•Enterprise and government applications requiring flexible and secured large-scale multi-
format AV distribution over long-distances.

Kramer Electronics Ltd.
MTX3-16-M –Defining MTX3-16-M 16x16 8K Modular Matrix
6
Defining MTX3-16-M 16x16 8K
Modular Matrix
This section defines MTX3-16-M.
Figure 1: MTX3-16-M 16x16 8K Modular Matrix Front Panel
#
Feature
Function
Numeric
Keypad
Numbers
1 to 0
←(Move left)
Move the LCD display left (when the display is extended).
→(Move right)
Move the LCD display right (when the display is extended).
Double-Function
Selector
Buttons.
Enabled and lit
after pressing
the MENU
button 4 times.
Menu Button
Functions
ALL
Connect an input to all outputs.
STO
Store the current setup in a preset.
EDID
Assign EDID channels.
ESC
Exit the current operation.
OFF
Turn off an output.
RCL
Recall a preset.
DELAY
Set the delay between confirming an action and the
execution of the action on an output port.
ENTER
Confirm the input-output setup when using a one-
digit number instead of two digits. For example, to
enter input 5, you can press either 05 or 5, ENTER.
TAKE Button
Confirm action.
MENU Button
Enable the ALL, STO, EDID, ESC, OFF, RCL, DELAY and
ENTER buttons. Press again to enter the configuration menu.
EXIT MENU Button
Press to exit a menu or return to switching mode.
LOCK Button
Press and hold for approximately 2 sec to lock/unlock the front
panel buttons.
A short press returns the LCD display to the default window.
DEFAULT SETUP Button
Press to open the reset menu on the display.
SERVICE Mini USB Connector
Connect to a PC to send PK3000 commands to the matrix
switcher.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

Kramer Electronics Ltd.
MTX3-16-M –Defining MTX3-16-M 16x16 8K Modular Matrix
7
#
Feature
Function
OUTPUTS/INPUTS LCD Display
(OSD menu)
Displays the outputs (upper row) routed to the selected inputs
(lower row). Displays user interface messages and menus.
POWER LED (PS-1 / PS-2)
Lights green when the power supply is active.
ERROR LED (PS-1 / PS-2)
Lights red when an error is detected. Briefly lights red
immediately following a power disruption (e.g., cable
disconnection, power off, and so on).
Figure 2: MTX3-16-M 16x16 8K Modular Matrix Rear Panel
#
Feature
Function
Slots for up to 4 Matrix Cards
The left side of MTX3-16-M has 4 slots for insertion of matrix cards
and the right side (26) has another 4 slots.
Hot plugging: Cards can be inserted while the device is operating,
and input/output ports are automatically identified and numbered.
Port input/output settings can be changed and flexibly connected to
other module cards’ input/output ports.
Matrix card ports are identified by ID numbers allocated when they
are inserted (see Identifying Input / Output Ports on page 11).
PS-1 Power Module and
Switch
The PS-1 must be connected to the mains and switched on to use
the device. The PS-1 power LED (17) lights green when powered.
This module has a fuse holder.
RESET Recessed Button
Press to reboot the MTX3-16-M control card.
RS-232 3-pin Terminal Block
Connector
Connect to a remote operation PC or a remote controller.
NET 1 RJ-45 Connector
100Mpbs Ethernet port for device management and control via LAN.
NET 2-1G RJ-45 Connector
100/10000Mbps Ethernet port for matrix connection to LAN.
PS-2 (POE) Power Module
and Switch
48V PoE (Power over Ethernet) supply for inserted matrix cards.
PoE is supplied when PS-2 is on and PS-1 is off, but MTX3-16-M
itself will not operate.
When switched on and connected to power, the PS-2 power LED
lights green.
Slots for up to 4 Matrix Cards
See for the explanation. The 4 card insertion slots on the right
side of the device use port IDs 9 to 16.
16
17
18
19
20
21
22
23
24
25
18
26
19

Kramer Electronics Ltd.
MTX3-16-M –Mounting MTX3-16-M
8
Mounting MTX3-16-M
This section provides instructions for mounting MTX3-16-M. Before installing, verify that the
environment is within the recommended range:
•Operation temperature –0to 40C (32 to 104F).
•Storage temperature –-40to +70C (-40 to +158F).
•Humidity –10% to 90%, RHL non-condensing.
Caution:
•Mount MTX3-16-M before connecting any cables or power.
Warning:
•Ensure that the environment (e.g., maximum ambient temperature & air flow) is
compatible for the device.
•Avoid uneven mechanical loading.
•Appropriate consideration of equipment nameplate ratings should be used for avoiding
overloading of the circuits.
•Reliable earthing of rack-mounted equipment should be maintained.
To Mount MTX3-16-M in a rack:
•
•Attach both rack ears (by removing the screws from each side of the machine
and replacing those screws through the rack ears).
For more information go to www.kramerav.com/downloads/MTX3-16-M

Kramer Electronics Ltd.
MTX3-16-M –Connecting MTX3-16-M
9
Connecting MTX3-16-M
You can insert matrix cards into slots while the device is powered.
Figure 3: Connecting to the MTX3-16-M Rear Panel
For optimum range and performance use the recommended Kramer cables available at
www.kramerav.com/downloads/MTX3-16-M.
Using third-party cables may cause damage!
The matrix card slot configuration shown above is for demonstration purposes.
Different input / output matrix card types may be mixed as required.
To connect MTX3-16-M as illustrated in the example in Figure 3:
1. Install the matrix card into the slots.
For matrix card insertion instructions see Installing Matrix Cards on page 10.
2. Connect the matrix card’s ports to the HDMI sources / acceptors and audio components.
3. Connect the RS-232 port to a controller.
See Managing MTX3-16-M via RS-232 on page 14.
4. Connect the NET1 port to the Kramer SL-240C controller via LAN.
See Managing MTX3-16-M via Ethernet on page 11.
5. Connect PS/1 to the mains electricity and switch it on.
6. Review and configure the system, using:
▪The front panel menu, see Managing MTX3-16-M on page 16.
▪The embedded web UI menus, see Managing MTX3-16-M from the Embedded Web
UI on page 26.

Kramer Electronics Ltd.
MTX3-16-M –Connecting MTX3-16-M
10
Installing Matrix Cards
Insert matrix cards into any of the 8 slots on the rear of the MTX3-16-M chassis. For an
explanation of how the system identifies each port, see Identifying Input / Output Ports
on page 11.
You can insert cards into slots while the device is powered.
The insertion process is the same for all cards.
To install an input / output card:
1. Use a Phillips screwdriver to loosen the screws at the top and bottom of the blanking
plate.
2. Remove the blanking plate from the slot and store it for possible future use.
3. Remove the new card from its shipping box and anti-ESD bag.
4. Holding the card by the lower handle, align the card with the plastic guide rails.
5. Slide the card into the chassis until the front of the card contacts the connector inside the
chassis.
6. Press the card firmly into the slot until the connector plate is flush with the rear panel of
the chassis and the connector is fully seated.
7. Tighten the retaining screws at the sides of the card to secure it to the chassis.
8. Power on the new card and configure it using the front panel menu or the embedded
web-UI menu.
Figure 4: Input / Output Card Installation

Kramer Electronics Ltd.
MTX3-16-M –Connecting MTX3-16-M
11
Identifying Input / Output Ports
Matrix cards that are installed into the card slots on the MTX3-16-M, include input and/or
output ports. Each card slot has 2 port ID numbers to be assigned to the inserted card. In total
there are 16 port IDs available. Port input/output directions are defined per port ID number.
A single matrix card can have both input and output ports.
The port ID numbers are written on the chassis, next to each card-insertion point. Ports on the
left side of the card use one port ID number and ports on the right side of the card use the
next port ID number.
Cards can have up to 4 ports. If a card has 4 ports, the 2 on each side of the card use the
same ID number.
Figure 5: Sample Port Numbering
Using MTX3-16-M to Provide PoE
When the MTX3-16-M PS-2 (PoE) power module is switched on and connected to the
mains, the matrix can supply 48V PoE to matrix cards with an HDBaseT connection, for
example DTAxrD2P matrix card, to its PoE-compatible connected end-point.
PoE is supplied, even if PS-2 is on and PS-1 is off (the MTX3-16-M itself does not operate
without PS-1). When PoE is provided, the PS2 power LED lights green.
Managing MTX3-16-M via Ethernet
To manage MTX3-16-M via Ethernet, connect to it using one of the following methods:
•Connecting to a LAN Switch on page 12.
•Connecting Directly to a PC with a Crossover Cable on page 12.
If you need to connect to LAN with IPv6 addressing, ask your IT department for installation
instructions.
25
20
17

Kramer Electronics Ltd.
MTX3-16-M –Connecting MTX3-16-M
12
Connecting to a LAN Switch
Connect the MTX3-16-M NET-1 Ethernet port (on the CNTL card) to a LAN switch port
Typically, LAN DHCP server automatically allocates an IP address to the matrix. To view the
matrix IP address on the front panel, press the MENU button , five times and press 1 to
view the ETH0 IP (Ethernet port NET-1 ) address.
Connecting Directly to a PC with a Crossover Cable
Manage MTX3-16-M by connecting a crossover cable from the device to the Ethernet port on
your PC.
This type of connection is recommended for identifying the MTX3-16-M IP address
during normal operation or following factory reset.
To configure your PC after connecting MTX3-16-M to the Ethernet port:
1. Click Start > Settings > Network & Internet.
2. In the Advanced network settings, click Change adapter options.
3. Highlight the network adapter you want to use to connect to the device and click Change
settings of this connection.
The Local Area Connection Properties window for the selected network adapter appears
as shown below:
Figure 6: Local Area Connection Properties Window
4. Highlight Internet Protocol Version 4 (TCP/IPv4).
5. Click Properties.
The Internet Protocol Properties window relevant to your IT system appears.
23
11
23

Kramer Electronics Ltd.
MTX3-16-M –Connecting MTX3-16-M
13
Figure 7: Internet Protocol Version 4 Properties Window
6. Select Use the following IP Address for static IP addressing and fill in the details as
shown below. You can use any IP address in the range 192.168.1.1 to 192.168.1.255
(excluding 192.168.1.39) that is provided by your IT department.
Figure 8: Internet Protocol Properties Window
7. Click OK.
8. Click Close.

Kramer Electronics Ltd.
MTX3-16-M –Connecting MTX3-16-M
14
Managing MTX3-16-M via RS-232
Control MTX3-16-M via an RS-232 connection using, for example, a controller.
MTX3-16-M features an RS-232 3-pin terminal block connector allowing the RS-232 to control
MTX3-16-M.
Connect the RS-232 terminal block on the rear panel of MTX3-16-M to a PC/controller. From
the RS-232 9-pin D-sub serial port, connect:
•Pin 2 to the TX pin on the MTX3-16-M RS-232 terminal block
•Pin 3 to the RX pin on the MTX3-16-M RS-232 terminal block
•Pin 5 to the G pin on the MTX3-16-M RS-232 terminal block
RS-232 Device MTX3-16-M
Managing MTX3-16-M via USB (VCOM)
The device’s SERVICE Mini USB Connector can work as a virtual COM (VCOM) port.
Verify that the USB port on the PC that connects to MTX3-16-M is configured as a VCOM
port. You may need to install a driver to do this. You can use a tool such as Hercules to use
Protocol 3000 commands over USB (see Protocol 3000 on page 70). You can also use
K-Upload to upgrade firmware over USB (see Upgrading Firmware –K-Upload on page 49).
22
15

Kramer Electronics Ltd.
MTX3-16-M –Securing MTX3-16-M Operation
15
Securing MTX3-16-M Operation
This section describes the MTX3-16-M Security features.
Standard Certification
MTX3-16-M has been tested and certified in compliance with security control requirements of
the OWASP Application Security Verification Standard (ASVS) Project. Go to
www.kramerav.com/downloads/MTX3-16-M to view OWASP certification.
MTX3-16-M Security Means
MTX3-16-M is protected by:
•Password Protection on page 15.
•User Account Protection on page 15.
•HTTPS Protection on page 15.
Password Protection
When accessing the web UI for the first time, the user is required to set a new password that
conforms to a level of complexity. The passwords must conform to the following level of
complexity (see also Defining User Accounts on page 36):
•Length of 8 to 12 characters, upper and lowercase are permitted.
•The password must contain a letter, number and special character (@, $, !, %, *, ?, &).
•Only the administrator account can change passwords.
Default passwords can only be restored following factory reset API command (see Default
Communication Parameters on page 56),.
User Account Protection
There are 3 levels of user accounts (Administrator, Manager and Operator), enabling
administrators to securely manage user access to the matrix according to their roles and
privileges (see also Defining User Accounts on page 36).
The Account password can only be restored following factory reset API command
(see Default Communication Parameters on page 56), not from the front panel or from the
embedded web UI.
HTTPS Protection
By default, all IP-based matrix management and control uses HTTPS, including the
embedded web UI and protocol 3000 API.

Kramer Electronics Ltd.
MTX3-16-M –Managing MTX3-16-M
16
Managing MTX3-16-M
Manage, operate and control MTX3-16-M:
•From the LCD menu (using the front panel buttons), see (see Managing MTX3-16-M via
Front Panel Buttons on page 17).
•Using the embedded web UI menu, see Managing MTX3-16-M from the Embedded Web
UI on page 26.
•Using Protocol 3000 commands, see Protocol 3000 on page 70.
The account default password can only be restored following factory reset API
command, (see Default Communication Parameters on page 56), not from the front
panel or from the embedded web UI.

Kramer Electronics Ltd.
MTX3-16-M –Managing MTX3-16-M via Front Panel Buttons
17
Managing MTX3-16-M via Front
Panel Buttons
Press Menu , to go through the menu that appears on the LCD screen screens.
After 6 seconds of inactivity, the screen reverts to the main menu (current switching
status).
Press the ◄ (backward) or ► (forward) buttons to shift right or left within the LCD
displayed text.
At any point, press the Lock or Exit to exit and return to the normal operation
dislay.
The MTX3-16-M front panel enables performing the following actions:
•Using MTX3-16-M LCD Display Menu on page 17.
•Using TAKE Button to Confirm Actions on page 25.
•Locking Front Panel Buttons on page 25.
Using MTX3-16-M LCD Display Menu
When powering the device, the LCD display runs through various screens and then remains
in the normal operation display, showing the current switching status.
To start up MTX3-16-M:
1. Turn on the power switch.
The LCD display shows a series of screens as MTX3-16-M is booting up:
Figure 9: LCD Display Bootup Screens (shown in sequence)
The last screen in the sequence is the normal operation mode.
2. Press the Menu button to scroll through the menu options.
The menu is ready to use.
1
12
13
11

Kramer Electronics Ltd.
MTX3-16-M –Managing MTX3-16-M via Front Panel Buttons
18
The LCD display menu enables performing the following actions:
•Viewing Ports ID on page 18.
•Switching Input Signals to Outputs on page 19.
•Storing and Recalling Presets on page 22.
•Delaying a Switching Action on page 23.
•Copying EDIDs on page 23.
•Viewing Network Settings on page 24.
•Restarting and Resetting the Matrix Via LCD Menu on page 24.
•Viewing MTX3-16-M Firmware Versions on page 25.
Viewing Ports ID
View the available video and audio port IDs (on the inserted cards) via the LCD display menu.
To view video ports ID:
1. Pres MENU 1 time. The Ports ID window.
2. View the video input and output IDs.
VOUT (video out) –Available video output
port IDs (on the inserted cards) list.
VIN (video in) –Connected (to above output
port ID) video input port IDs.
To view audio ports ID:
1. Pres MENU 1 time. The Ports ID window.
2. View the video input and output IDs.
AOSW (audio output switch) –Available
audio output port IDs list.
AISW (audio input switch) –Connected (to
above output port ID) audio input port IDs.

Kramer Electronics Ltd.
MTX3-16-M –Managing MTX3-16-M via Front Panel Buttons
19
Switching Input Signals to Outputs
MTX3-16-M enables switching inputs to outputs via the LCD display menu, using the
Numeric Keypad .
When using the Numeric Keypad:
•To enter a single digit number (for example 5), either press 0 followed by 5, or 5 followed
by the ENTER Button .
•Press 00 (or 0 followed by the ENTER button) to disconnect the currently entered output
number from the routed input.
•Use the ESC Button to cancel an operation without affecting the current status.
For example, if you enter an incorrect number by mistake, press ESC to cancel the
operation.
At any stage, if no button is pressed within approximately 15 seconds, the automatic timeout
causes MTX3-16-M to exit the operation and revert to the output/input display.
MTX3-16-M enables performing the following switching actions:
•Switching a Video Input Signal to an Output on page 19.
•Switching an Audio Input Signal to an Output on page 20.
•Switching Multiple Inputs to Multiple Outputs on page 20.
•Switching an Input to all Outputs on page 21.
•Turning Outputs Off on page 22.
Switching a Video Input Signal to an Output
Use the MTX3-16-M front panel LCD display to switch a video input signal to an output. In
normal operation mode (switching mode), the switching state is displayed:
VOSW (Video Output SWitch) –Shows
video output port IDs.
VISW (Video Input SWitch) –Shows the
video input ports that are switched to the
video output ports (shown above).
To switch a video input signal to a selected output using the front panel buttons:
1. On the Numeric Keypad, press the number of the desired video output (for example, 01).
The in/out routing appears on the right side of the LCD display with the input blank.
VOSW:
01
02
03
04
05
06
07
08
VISW:
11
12
13
14
15
16
09
IN__=>OUT01
Figure 10: Video Switching –Blank Input
2. Press the number of the desired video input (for example, 16).
The input is displayed, and the video is switched to the new output destination
immediately.
VOSW:
01
02
03
04
05
06
07
08
VISW:
11
12
13
14
15
16
09
IN16=>OUT01
Figure 11: Video Switching –Input Entered
The selected video input signal is switched to the selected output.
16
1
9
5

Kramer Electronics Ltd.
MTX3-16-M –Managing MTX3-16-M via Front Panel Buttons
20
Switching an Audio Input Signal to an Output
Use the MTX3-16-M front panel LCD display to switch an audio input signal to an output.
In the audio switching state:
AOSW (Audio Output SWitch) –Shows the
audio output ports.
AISW (Audio Input SWitch) –Shows the
audio input ports that are switched to the
video output ports (shown above).
To switch an input audio signal to a selected output using the front panel buttons:
1. Press the MENU button twice.
The current audio switching setup is displayed on the LCD display.
AOSW:
01
02
03
04
05
06
07
08
AISW:
13
13
13
13
13
09
09
Figure 12: Audio Switching –Blank Input
2. On the Numeric Keypad , press the number of the desired output.
The in/out routing appears on the right side of the LCD display with the input blank.
AOSW:
01
02
03
04
05
06
07
08
AISW:
13
13
13
13
13
09
09
IN__=>OUT01
Figure 13: Audio Switching –Output Entered
3. Press the number of the desired input.
The input is displayed, and the audio is switched immediately.
AOSW:
01
02
03
04
05
06
07
08
AISW:
11
12
13
14
15
16
09
IN09=>OUT01
Figure 14: Audio Input Entered
The selected audio input is switched to a selected output.
Switching Multiple Inputs to Multiple Outputs
Use the MTX3-16-M front panel LCD display together with the TAKE button to route more
than one input to an output at the same time.
This section describes multiple video switching, but the same applies to multiple audio
switching.
To switch multiple inputs and outputs:
1. Press TAKE on the front panel. The button turns red.
2. On the Numeric Keypad, press the number of the desired video output (for example, 01).
The in/out routing appears on the right side of the LCD display with the input blank.
VOSW:
01
02
03
04
05
06
07
08
VISW:
11
12
13
14
15
16
09
IN__=>OUT01
Figure 15: LCD Video Switching Screen
11
1
