Kramer VP-16x18AK User manual

Kramer Electronics, Ltd.
USER MANUAL
Model:
VP-16x18AK
16 x 18 PC UXGA/Audio Router

Contents
i
Contents
1Introduction 1
2Getting Started 1
2.1 Recycling Kramer Products 1
2.2 Quick Start 2
3Overview 4
3.1 Recommendations for Best Performance 5
3.2 Shielded Twisted Pair and Unshielded Twisted Pair 5
4Defining the VP-16x18AK 16 x 18 PC UXGA/Audio Router 6
4.1 Using the IR Transmitter 10
5Installing the VP-16x18AK in a Rack 11
6Connecting and Configuring the VP-16x18AK 12
6.1 Connecting the VP-16x18AK 12
6.2 Connecting the Audio Outputs to Balanced/Unbalanced Acceptors 13
6.3 Connecting to the VP-16x18AK via RS-232 14
6.4 Connecting to the VP-16x18AK via RS-485 14
6.5 Connecting to the VP-16x18AK via the Ethernet Port 15
6.5.1 Connecting Directly to the Ethernet Port 15
6.5.2 Connecting via a Network Hub, Switch, or Router 17
6.5.3 Configuring the Ethernet Port on the VP-16x18AK Using K-Upload 17
6.6 Setting the RS-485 Termination and Machine Number DIP-switches 17
7Operating the VP-16x18AK Locally via the Front Panel Buttons 19
7.1 The Status Display 19
7.2 Switching Inputs to Outputs 19
7.3 The At Once and Confirm Modes 20
7.3.1 Toggling between At Once and Confirm Modes 20
7.3.2 Confirming a Switching Action 20
7.4 Setting the Audio Gain for Inputs and Outputs 21
7.5Audio Output Bass and Treble Level Setting 21
7.6 Setting the Audio-Follow-Video or Breakaway Option 22
7.6.1 Setting the Audio-Follow-Video Option 22
7.6.2 Setting the Breakaway Option 22
7.7 Storing and Recalling Setup Configurations 22
7.7.1 Storing a Setup Configuration 23
7.7.2 Recalling a Setup Configuration 23
7.8 Locking and Unlocking the Front Panel Buttons 23
7.9 Reading and Writing the EDID 23
8Operating the VP-16x18AK Remotely 24
8.1 Operating the VP-16x18AK via RS-232 24
9Operating the VP-16x18AK Remotely Using a Web Browser 26

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Contents
ii
9.1 Connecting to the VP-16x18AK via your Browser 26
9.2 The Main Switching Matrix Page 28
9.2.1 Switching an Input to an Output 29
9.2.2 Setting the AFV Mode 29
9.2.3 Operating in the Offline Mode 30
9.2.4 Storing and Recalling Setups 31
9.2.5 Locking the Front Panel Buttons 33
9.3 Audio Input Gain Control Page 33
9.4 The Configuration Page 34
10 Firmware Upgrade Using K-Upload 35
11 Technical Specifications 36
12 Default Communication Parameters 37
13 Factory Default EDID 37
14 Table of ASCII Codes for Serial Communication (Protocol 3000) 39
15 Table of Hex Codes for Serial Communication (Protocol 2000) 40
16 Kramer Protocol 42
16.1 Switching Protocols 42
16.1.1 Switching Protocols via the Front Panel Buttons 42
16.1.2 Switching Protocols via Protocol Commands 42
16.2 Kramer Protocol 3000 42
16.2.1 Protocol 3000 Syntax 43
16.2.2 Command Parts Details 43
16.3 Kramer Protocol 2000 50
Figures
Figure 1: VP-16x18AK 16 x 18 PC UXGA/Audio Router Front Panel 6
Figure 2: VP-16x18AK 16 x 18 PC UXGA/Audio Router Rear Panel 8
Figure 3: Connecting the VP-16x18AK 16 x 18 PC UXGA/Audio Router 13
Figure 4: Connecting to a Balanced Acceptor 13
Figure 5: Connecting to an Unbalanced Acceptor 14
Figure 6: Local Area Connection Properties Window 16
Figure 7: Internet Protocol (TCP/IP) Properties Window 16
Figure 8: VP-16x18AK DIP-switches 17
Figure 9: Control Configuration via RS-232 25
Figure 10: Java Test Page Success Message 26
Figure 11: Entering the IP Address in the Address Bar 26
Figure 12: The Loading Page 27
Figure 13: First Time Security Warning 27
Figure 14: Main Switching Matrix Page 28
Figure 15: Selecting a Switching Point on the Matrix 29
Figure 16: Switching an Input to an Output 29
Figure 17: AFV Mode Warning 30
Figure 18: AFV Mode Audio Channels Switched 30

Contents
iii
Figure 19: Switching Audio in the Offline Mode 31
Figure 20: Exiting Offline Warning 31
Figure 21: Selecting Preset 07 32
Figure 22: Selecting Preset 03 32
Figure 23: Recalling a Preset in Offline Mode 33
Figure 24: Audio Gain Control Page 33
Figure 25: Selecting Audio Input Gain for Channel 2 34
Figure 26: Configuration Page 34
Tables
Table 1: VP-16x18AK 16 x 18 PC UXGA/Audio Router Front Panel Features 6
Table 2: VP-16x18AK 16 x 18 PC UXGA/Audio Router Rear Panel Features 9
Table 3: DIP-switch Settings 17
Table 4: Machine Number DIP-switch Settings 18
Table 5: Technical Specifications of the VP-16x18AK 36
Table 6: Communication Parameters 37
Table 7: VP-16x18AK Video Signal Codes for Protocol 3000 39
Table 8: VP-16x18AK Audio Signal Codes for Protocol 3000 39
Table 9: VP-16x18AK Audio Input Gain Codes 39
Table 10: VP-16x18AK Audio Output Gain Codes 40
Table 11: VP-16x18AK Hex Codes for Switching Video Channels via RS-232/RS-485 40
Table 12: VP-16x18AK Hex Codes for Switching Audio Channels via RS-232/RS-485 40
Table 13: VP-16x18AK Hex Codes for Increasing/Decreasing the Audio Input Gain 40
Table 14: VP-16x18AK Hex Codes for Setting the Audio Input Gain 41
Table 15: VP-16x18AK Hex Codes for Increasing/Decreasing the Output Gain 41
Table 16: VP-16x18AK Hex Codes for Setting the Audio Output Gain 41
Table 17: Instruction Codes for Protocol 3000 44
Table 18: Protocol Definitions 50
Table 19: Instruction Codes for Protocol 2000 50

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront video, audio, presentation, and broadcasting
professionals on a daily basis. In recent years, we have redesigned and
upgraded most of our line, making the best even better! Our 1,000-plus
different models now appear in 11 groups1
Congratulations on purchasing your VP-16x18AK, 16 x 18 PC
UXGA/Audio Router which is ideal for the following typical applications:
that are clearly defined by
function.
•Professional display systems requiring a true 16x18 computer
graphics and audio matrix operation
•Multimedia and presentation source and acceptor selection
The package includes the following items:
•VP-16x18AK, 16 x 18 PC UXGA/Audio Router
•Kramer RC-IR3Infrared Remote Control transmitter (including the
required battery and a separate user manual2
•Power cord )
3 2
, rack “ears” and this user manual
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
•Review the contents of this user manual
•Use Kramer high-performance high-resolution cables4
•Use only the power cord that is supplied with this machine
2.1 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive
2002/96/EC aims to reduce the amount of WEEE sent for disposal to
landfill or incineration by requiring it to be collected and recycled. To
comply with the WEEE Directive, Kramer Electronics has made
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories
and Rack Adapters; GROUP 11: Sierra Products
2 Available from http://www kramerelectronics com
3 We recommend that you use only the power cord that is supplied with this machine
4 The complete list of Kramer cables is available from http://www kramerelectronics com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
arrangements with the European Advanced Recycling Network (EARN)
and will cover any costs of treatment, recycling and recovery of waste
Kramer Electronics branded equipment on arrival at the EARN facility. For
details of Kramer’s recycling arrangements in your particular country go to
our recycling pages at
http://www.kramerelectronics.com/support/recycling/.
2.2 Quick Start
This quick start chart summarizes the basic setup and operation steps.

Getting Started
3

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
4
3 Overview
The VP-16x18AK is a high performance, 16x18 computer graphics video
matrix router for high resolution video and stereo audio signals. The
VP-16x18AK is HDTV compatible and lets you simultaneously route any
or all of the 16 inputs to any or all of the 18 outputs.
In particular, the VP-16x18AK,16 x 18 PC UXGA/Audio Router features:
•Kramer’s innovative integrated sync processing; Kr-isp®technology
provides a sharp, stable image by restoring the signal waveform even
when the sync level is too low
•A video bandwidth of over 300MHz that ensures transparent
performance even for the most critical applications
•12 preset memory locations for quick access to common routing
configurations and audio gain status for each output
•Automatic detection of inputs with live connections (the respective
input button lights green)
•A delayed switching mode (ranging from 0 to 3.5sec1
•DC-coupled video inputs and outputs
) for clean
transitions when switching between non-genlocked sources
•Audio-follow-video and breakaway options
•16 VGA (up to UXGA) video inputs on 15-pin HD connectors
•16 unbalanced, stereo audio inputs on 3.5mm mini jacks
•16 VGA (up to UXGA) video outputs on 15-pin HD connectors
•16 balanced stereo audio outputs on 5-pin, removable terminal block
connectors
•Two Twisted Pair outputs on RJ-45 connectors
•Audio level control buttons for adjusting the volume of each input
and output
•Bass and treble control for each output
•The ability to place multiple switching actions in a queue and then to
activate them simultaneously with a one touch button
•The ability to lock the front panel buttons to prevent tampering with
settings
•Support for DDC (Display Data Channel) communication between
input 1 and output 1 high-density 15-pin HD connectors on pins 12
and 15
•Default EDID values programmed on each input
•Customizable bass and treble for each output
1 In ½ second increments

Overview
5
You can operate the VP-16x18AK using the front panel buttons, or
remotely via:
•RS-485, RS-232 serial or Ethernet TCP/UDP commands (using
Kramer 2000 and 3000 protocols) transmitted by a touch screen
system, PC or other serial/Ethernet controller
•The Kramer Infrared Remote Control transmitter or Infrared remote
extension cable transmitter (optional)
•Your Web browser using Ethernet communication over a LAN
The VP-16x18AK is dependable, rugged and fits into three vertical spaces
(3U) of a standard 19” professional rack.
3.1 Recommendations for Best Performance
To achieve the best performance:
•Use only high quality connection cables1
•Do not secure the cables in tight bundles or roll the slack into tight
coils
to avoid interference,
deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)
•Avoid interference from neighboring electrical appliances that may
adversely influence signal quality
•Position your Kramer VP-16x18AK away from moisture, excessive
sunlight and dust
3.2 Shielded Twisted Pair and Unshielded Twisted Pair
We recommend that you use Shielded Twisted Pair (STP) cable, and stress
that the compliance to electromagnetic interference was tested using STP
cable. There are different levels of STP cable available, and we advise you
to use the best quality STP cable that you can afford. Our non-skew-free
cable, Kramer BC-STP is intended for analog signals where skewing is not
an issue.
In cases where there is skewing, our Unshielded Twisted Pair (UTP) skew-
free cable, Kramer BC-XTP, may be advantageous, and UTP cable might
also be preferable for long range applications. In any event when using UTP
cable, it is advisable to ensure that the cable is installed far away from
electric cables, motors and so on, which are prone to create electrical
interference.
1 Available from Kramer Electronics and listed on our Web site at http://www kramerelectronics com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Defining the VP-16x18AK 16 x 18 PC UXGA/Audio Router
6
4 Defining the VP-16x18AK 16 x 18 PC UXGA/Audio Router
Figure 1and Table 1define the front panel of the VP-16x18AK 16 x 18 PC UXGA/Audio Router.
Figure 1: VP-16x18AK 16 x 18 PC UXGA/Audio Router Front Panel
Table 1: VP-16x18AK 16 x 18 PC UXGA/Audio Router Front Panel Features
# Feature Function
1 SELECTOR IN Buttons Press to select an input (from 1 to 16) following the selec ion of an output (see Section 7.2).
When an input signal is detected, the corresponding input button lights
2 SELECTOR OUT Buttons Press to select an output (from 1 to 18) followed by an input selection (see Section 7 2)

Defining the VP-16x18AK 16 x 18 PC UXGA/Audio Router
7
# Feature Function
3 OFF Button Press a SELECTOR OUT button followed by OFF to disconnect the selected output from he input (see Section 7.2).
Press ALL followed by OFF to disconnect all outputs
4 ALL Button Press ALL followed by an INPUT button to switch the selected input to all outputs
1
Section(see 7.2)
5 STATUS LCD Readout Displays the current Input-Output switching configuration2
6 on a 2 line LCD readout IR Sensor IR receiver for the Remote Control IR transmitter
7 IR LED Lights yellow when a signal is received from he IR transmitter
8 POWER LED Lights green when the unit receives power and is switched on
9 VIDEO Button Press for subsequent actions to relate to video. The button lights when the video mode is ac ive.
Press in conjunc ion with AUDIO to set the delay time
10 AUDIO Button Press for subsequent actions to relate to audio. The button lights when the audio mode is active.
Press in conjunc ion with VIDEO to set the delay time
11 TAKE Button Press to set the Confirm mode3
Section
(where user confirma ion is required for switching actions); press again to set the At Once
mode (where user confirmation per action is not required). When in Confirm mode, press he TAKE button to execute pending
ac ions (see 7.3 2)
12 AFV Button Press to make the audio channels follow he video channel switching. The button lights when the AFV mode is ac ive (see
Section 7.6)
13 RCL (Recall) Button Press in conjunc ion with an Output button to recall a switching preset (see Sec ion 7.7.2). Press again to execute he preset.
Press in conjunc ion with STO to set the machine number
14 STO (Store) Button Press followed by an Output button to store the current switching configura ion (see Section 7.7.1).
Press in conjunc ion with RCL to set the machine number
15 AUDIO GAIN Button Press (following selec ion of an output or input) to set he audio input or output gain (see Section 7.4)
16 AUDIO
LEVEL – Button Press (following the Audio Gain button) to decrease the audio signal level (input, output, bass or treble)
17 + Button Press (following the Audio Gain button) to increase he audio input signal level (input, output, bass or treble)
18 LOCK Button Press and hold to lock he front panel buttons, press and hold again to unlock the buttons. The button lights when he front
panel is locked (see Section 9 2.5)
1 For example, press ALL and then IN button 2 to connect input 2 to all the outputs
2 Also displays the number of input and output ports, the firmware version number and the machine number (see Section 6 6)
3 When in the Confirm mode, the TAKE button lights

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Defining the VP-16x18AK 16 x 18 PC UXGA/Audio Router
8
Figure 2and Table 2define the rear panel of the VP-16x18AK 16 x 18 PC UXGA/Audio Router.
Figure 2: VP-16x18AK 16 x 18 PC UXGA/Audio Router Rear Panel

Defining the VP-16x18AK 16 x 18 PC UXGA/Audio Router
9
Table 2: VP-16x18AK 16 x 18 PC UXGA/Audio Router Rear Panel Features
# Feature Function
1 VIDEO INPUTS 15-pin HD (F) Connectors Connect to he VGA1
2 sources (from 1 to 16) AUDIO OUTPUTS Removable Terminal Block
Connectors Connect to balanced stereo audio acceptors (from 1 to 16)
3
VIDEO OUTPUTS
VGA 15-pin HD (F)
Connectors Connect to he VGA
1
acceptors (from 1 to 16)
4 OUTPUT 17, OUTPUT 18
RJ-45 TP Connectors Connect to compa ible TP receivers (for example, TP-122N/TP-142)
5 REMOTE IR Opening2Mount the optional internal IR connection cable that connects to an external IR receiver unit for
controlling he machine via an IR remote controller instead of using the front panel IR receiver
6 AUDIO INPUTS 3.5mm Mini Jacks Connect to he unbalanced stereo audiosources (from 1 to 16)
7 RESET Button Press and hold while powering up the unit to reset all audio, switching and Ethernet settings to
their factory default values (see Section 12)
8 PROG Button For he use of Kramer service personnel only
9 RS-485 3-pin Terminal Block Connect to he corresponding pins A(+), B(–) and G on another device for RS-485
communication (see Sec ion 6.4)
10 RS-232 9-pin D-sub Serial Port Connect to a PC or remote controller (see Sec ion 6.3)
11 ETHERNET RJ-45 Connector Connect to a PC or other controller over a LAN (see Sec ion 6 5)
12 MACH # DIP-switches (1, 2 and 3) Use to set the RS-485 machine number (see Sec ion 6.6)
13 RS-485 TERM DIP-switch (4) Use to set the RS-485 termination3
Sec ion
: ON (down) for RS-485 line termination with 120Ω;
OFF (up) for no RS-485 line termination (see 6.6)
14 Mains Power Connector Connect to he AC mains power supply
15 Fuse Holder Mains fuse holder
16 Power Switch Switch for turning the unit on and off
1 Up to UXGA resolution
2 Covered by a removable cap The 3 5mm mini jack at the end of the internal IR connection cable fits into this opening
3 Terminate the first and the last physical units on the RS-485 bus (on) Leave all other units unterminated (off)

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Defining the VP-16x18AK 16 x 18 PC UXGA/Audio Router
10
4.1 Using the IR Transmitter
You can use the RC-IR3IR transmitter to control the machine via the
built-in IR receiver on the front panel or, instead, via an optional external IR
receiver1. The external IR receiver can be located up to 15m (50ft) away
from the machine. This distance can be extended to up to 60m (200ft) when
used with three extension cables2
Before using the external IR receiver, be sure to arrange for your Kramer
dealer to insert the internal IR connection cable14F
3with the 3.5mm jack that
fits into the REMOTE IR opening on the rear panel. Connect the external IR
receiver to the REMOTE IR 3.5mm jack.
1 Model: C-A35M/IRR-50
2 Model: C-A35M/A35F-50
3 P/N: 505-70434010-S

Installing the VP-16x18AK in a Rack
11
5 Installing the VP-16x18AK in a Rack
This section describes what to do before installing in a rack and how to rack
mount the VP-16x18AK.

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting and Configuring the VP-16x18AK
12
6 Connecting and Configuring the VP-16x18AK
This section describes how to:
•Connect the VP-16x18AK (see Section 6.1
•Connect a balanced stereo audio output (see
)
Section 6.2
•Connect the VP-16x18AK to a remote control device via:
)
RS-232 (see Section 6.3
RS-485 (see ) Section 6.4
Ethernet (see ) Section 6.5
•Set the RS-485 termination and machine number (see
) Section 6.6
6.1 Connecting the VP-16x18AK
)
Always switch off the power on each device before connecting it to your
VP-16x18AK. After connecting your VP-16x18AK, connect its power
and then switch on the power on each device.
To connect1the VP-16x18AK, as illustrated in the example2in Figure 3:
1. Connect the VGA (up to UXGA) sources (for example, computer
graphics sources) to the 15-pin HD VIDEO INPUT connectors.
2. Connect the unbalanced stereo audio sources (for example, the audio
source of the computer) to the 3.5mm mini AUDIO INPUT jacks.
3. Connect the 15-pin HD VGA VIDEO OUTPUT connectors to the
video acceptors (for example, video displays).
4. Connect the AUDIO OUTPUT terminal block connectors to the
balanced stereo audio acceptors (for example, balanced stereo audio
amplifiers with speakers).
5. If required, you can connect a PC and/or controller to the:
RS-232 port (see Section 6.3
RS-485 port (see ) Section 6.4
Ethernet port via a LAN (see
)
Section 6.5
6. Connect the power cord )
3(not shown in Figure 3).
1 You do not need to connect all inputs and outputs
2 Switch off the power on each device before connecting it to your VP-16x18AK After connecting your VP-16x18AK,
switch on its power and then switch on the power on each device Do NOT push in the rear panel PROG button, it is reserved
for service use
3 We recommend that you use only the power cord that is supplied with this machine
i

Connecting and Configuring the VP-16x18AK
13
Figure 3: Connecting the VP-16x18AK 16 x 18 PC UXGA/Audio Router
6.2 Connecting the Audio Outputs to Balanced/Unbalanced
Acceptors
Figure 4illustrates how to connect the VP-16x18AK to a balanced
acceptor.
Figure 4: Connecting to a Balanced Acceptor

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting and Configuring the VP-16x18AK
14
Figure 5illustrates how to connect the VP-16x18AK to an unbalanced
acceptor.
Figure 5: Connecting to an Unbalanced Acceptor
6.3 Connecting to the VP-16x18AK via RS-232
You can connect to the VP-16x18AK via an RS-232 connection using, for
example, a PC. Note that a null-modem adapter/connection is not required.
To connect to the VP-16x18AK via RS-232:
•Connect the RS-232 9-pin D-sub rear panel port on the VP-16x18AK
unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3, and
pin 5 to pin 5 need be connected) to the RS-232 9-pin D-sub port on
your PC
6.4 Connecting to the VP-16x18AK via RS-485
You can operate the VP-16x18AK via the RS-485 port from a distance of
up to 1200m (3900ft) using a PC equipped with a card that provides an
RS-485 port1
To connect a PC or controller to the RS-485 port on the VP-16x18AK:
.
1. Wire the RS-485 port on the device to the RS-485 port on the
controller as follows:
Connect the A(+) pin on the RS-485 port of the PC to the A(+)
pin on the RS-485 port on the rear panel of the VP-16x18AK
Connect the B(–) pin on the RS-485 port of the PC to the B(–)
pin on the RS-485 port on the rear panel of the VP-16x18AK
Connect the G pin on the RS-485 port of the PC to the G pin on
the RS-485 port on the rear panel of the VP-16x18AK
2. Set the DIP-switches (see Section 6.6
3. Terminate the RS-485 line on both the VP-16x18AK (set DIP-switch 1
to ON) and on the PC (see
) so that the machine number on
the VP-16x18AK is any number between 2 and 8.
Section 6.6
).
1 RS-485 can be used for control even for distances exceeding 1km

Connecting and Configuring the VP-16x18AK
15
6.5 Connecting to the VP-16x18AK via the Ethernet Port
You can connect the VP-16x18AK via Ethernet using either of the
following methods:
•Direct connection to the PC using a crossover cable (see
Section 6.5.1
•Connection via a network hub, switch or router using a
straight-through cable (see
)
Section 6.5.2
Note: The following instructions are valid only if your PC uses a fixed IP
address. If your PC receives an IP address from a DHCP server, consult
your IT department regarding a suitable IP address.
)
6.5.1 Connecting Directly to the Ethernet Port
You can connect the Ethernet port of the VP-16x18AK to the Ethernet port
on your PC via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identification of the factory
default IP Address of the VP-16x18AK during the initial configuration
To connect the VP-16x18AK directly to a PC using a crossover cable:
1. Using a crossover cable, connect the VP-16x18AK to the PC via the
Ethernet port on both units.
2. On the PC, click Start > Control Panel.
3. Double-click Network Connections.
4. Right-click, and from the menu select Properties.
The Local Area Connection Properties window appears.
5. Select Internet Protocol (TCP/IP) (see Figure 6).

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting and Configuring the VP-16x18AK
16
Figure 6: Local Area Connection Properties Window
6. Click the Properties button.
7. Select Use the following IP address, and fill in the details as shown in
Figure 7. You can use any IP address in the range 192.168.1.1 to
192.168.1.255 (excluding 192.168.1.39) that is provided by your IT
department.
Figure 7: Internet Protocol (TCP/IP) Properties Window
8. Click OK.
