Kramer Electronics, Ltd.
USER MANUAL



Model:
VP-2x2
2x2 XGA/Audio Matrix Switcher

Contents
i
Contents
1 Introduction 1
2 Getting Started 1
2.1 Quick Start 1
3 Overview 3
4 Your VP-2x2 2x2 XGA/Audio Matrix Switcher 4
5 Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher 5
5.1 Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher Rear Panel 5
5.2 Connecting the Balanced/Unbalanced Stereo Audio Input/Output 7
5.3 Connecting a PC 8
6 Operating Your XGA/Audio Matrix Switcher 9
6.1 Choosing the Audio-Follow-Video or Breakaway Option 9
6.1.1 Setting the Audio-Follow-Video Option 9
6.1.2 Setting the Breakaway Option 9
6.2 Locking the Front Panel 10
7 Technical Specifications 10
8 Kramer Protocol 2000 11
9 Table of Hex Codes for Serial Communication 13
Figures
Figure 1: VP-2x2 2x2 XGA/Audio Matrix Switcher 4
Figure 2: Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher 6
Figure 3: Connecting the Balanced Stereo Audio Input/Output 7
Figure 4: Connecting the Unbalanced Stereo Audio Input 7
Figure 5: Connecting an Unbalanced Output 7
Figure 6: Connecting the PC 8
Tables
Table 1: VP-2x2 2x2 XGA/Audio Matrix Switcher Features 4
Table 2: Technical Specifications of the VP-2x2 2x2 XGA/Audio Matrix Switcher 10
Table 3: Protocol Definitions 11
Table 4: Instruction Codes for Protocol 2000 12
Table 5: Hex Codes 13

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
500-plus different models now appear in eight groups
1
that are clearly defined
by function.
Congratulations on purchasing your Kramer VP-2x2 2x2 XGA/Audio Matrix
Switcher. This product is ideal for the following typical applications:
Any professional display system requiring a true 2x2 matrix operation
Multimedia and presentation sources and acceptors selection
Remote monitoring of computer activity in schools and businesses
The package includes the following items:
VP-2x2 2x2 XGA/Audio Matrix Switcher
Power adapter (12V DC Input)
Windows®-based Kramer control software
2
Null-modem adapter
This user manual
3
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps of the
VP-2x2.
1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 Downloadable from our Web site at http://www.kramerelectronics.com
3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2

Overview
3
3 Overview
The VP-2x2 is a high performance matrix switcher for VGA/SVGA/XGA/UXGA
signals and balanced stereo audio signals. The user can simultaneously route
an input to one or both outputs
1
.
In addition, the VP-2x2 includes:
Videobandwidththatexceeds400MHz, ensuringtransparent
performance in all applications
Audio-follow-video switching and audio breakaway (when audio and
video are switched separately)
A TAKE button that allows the user to pre-select a setting and then
activate it
A LOCK button to prevent tampering via the front panel
Control via the front panel buttons, or remotely by RS-232 serial
commands transmitted by a touch screen system, PC, or other serial
controller
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer VP-2x2 in a
location free from moisture and away from excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit
2
.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
1 Input 1 (or 2) to outputs 1 and 2 simultaneously, or input 1 (or 2) to output 1 and input 2 (or 1) to output 2
2 For example: model number AD2512C, part number 2535-000251

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your VP-2x2 2x2 XGA/Audio Matrix Switcher
4
4 Your VP-2x2 2x2 XGA/Audio Matrix Switcher
Figure 1 and Table 1 define the front and rear panels of the VP-2x2:
Figure 1: VP-2x2 2x2 XGA/Audio Matrix Switcher
Table 1: VP-2x2 2x2 XGA/Audio Matrix Switcher Features
# Feature Function
1 POWER Switch Illuminated switch for turning the unit ON or OFF
2 IN 1 To OUT 2 Switches input 1 to output 2
3 IN 1 To OUT 1 Switches input 1 to output 1
4 IN 2 To OUT 1 Switches input 2 to output 1
5
SELECT Buttons
1
IN 2 To OUT 2 Switches input 2 to output 2
6 VIDEO When illuminated, actions relate to video
7 AUDIO When illuminated, actions relate to audio
8 AFV When illuminated, audio channels follow the video
channels
9 TAKE Pressing TAKE toggles the mode between the Confirm
mode
2
and the At Once mode (user confirmation per
action is unnecessary). In Confirm mode, TAKE
implements the pending action
10
SELECT Buttons
1
LOCK Disengages/engages the front panel buttons
11 AUDIO IN Terminal Block Connectors Connects to the 2 balanced audio inputs
12 INPUT 1 HD15F Connector Connects to the video source 1
13 INPUT 2 HD15F Connector Connects to the video source 2
14 OUTPUT 1 HD15F Connector Connects to the video acceptor 1
15 OUTPUT 2 HD15F Connector Connects to the video acceptor 2
16 AUDIO OUT Terminal Block Connectors
Connects to the 2 balanced audio outputs
17 RS-232 9-pin D-sub Connector Connects to PC or Remote Controller
18 12V DC +12V DC connector for powering the unit
1 Press to select. When selected, the button illuminates
2 When in the Confirm mode, the TAKE button illuminates

Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher
5
5 Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher
This section describes how to connect:
The VP-2x2 rear panel (see section 5.1)
A balanced stereo audio input/output (see section 5.2)
The VP-2x2 to a controlling device via RS-232 (see section 5.2)
5.1 Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher Rear Panel
To connect
1
the VP-2x2, as illustrated in the example in Figure 2, do the
following
2
:
1. Connect the VGA/UXGA computer graphics sources to the INPUT 15-
pin HD computer graphics video connectors.
2. Connect the balanced
3
stereo audio sources to the AUDIO IN balanced
stereo audio 5-pin terminal block connectors.
3. Connect the OUTPUT 15-pin HD computer graphics video connectors to
the VGA/UXGA video acceptors (for example, displays).
4. Connect the AUDIO OUT terminal block connectors to the balanced
3
stereo audio acceptors (for example, amplifiers with speakers).
5. Connect a PC and/or controller (if required) to the RS-232 port (see
section 5.2).
6. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 2).
1 You do not have to connect both inputs or both outputs
2 Switch OFF the power on each device before connecting it to your VP-2x2. After connecting your VP-2x2, switch on its
power and then switch on the power on each device
3 See section 5.2

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher
6
Figure 2: Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher

Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher
7
5.2 Connecting the Balanced/Unbalanced Stereo Audio Input/Output
This section illustrates how to wire:
A balanced input/output connection, see Figure 3
An unbalanced audio input, see Figure 4
An unbalanced audio output, see Figure 5
Figure 3: Connecting the Balanced Stereo Audio Input/Output
Figure 4: Connecting the Unbalanced Stereo Audio Input
Figure 5: Connecting an Unbalanced Output

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the VP-2x2 2x2 XGA/Audio Matrix Switcher
8
5.3 Connecting a PC
You can connect a PC (or other controller) to the VP-2x2 via the RS-232 port
for remote control, and for upgrading the firmware.
To connect a PC to a VP-2x2 unit, using the Null-modem adapter provided
with the machine (recommended):
Connect the RS-232 9-pin D-sub rear panel port on the VP-2x2 unit to the
Null-modem adapter and connect the Null-modem adapter with a 9-wire
flat cable to the RS-232 9-pin D-sub port on your PC
To connect a PC to a VP-2x2 unit, without using a Null-modem adapter:
Connect the RS-232 9-pin D-sub port on your PC to the RS-232 9-pin
D-sub rear panel port on the VP-2x2 unit, forming a cross-connection
1
, as
Figure 6 illustrates



9-pin D-sub
(From PC)
9-pin D-sub
(To Switcher)
If a shielded cable is used, connect the shield to PIN 5



PIN 5 Connected to PIN 5 (Ground)
PIN 3 Connected to PIN 2
PIN 2 Connected to PIN 3
Figure 6: Connecting the PC
1 Also known as a Null-modem connection
