Kramer FC-321 User manual

Kramer Electronics, Ltd.
Preliminary
USER MANUAL
Model:
FC-321
SD/HD-SDI to HDMI Converter/Switcher

Contents
i
Contents
1 Introduction 1
2 Getting Started 1
2.1 Quick Start 2
3 Overview 2
3.1 About HDMI 3
3.2 Recommendations for Best Performance 4
4 Your FC-321 SD/HD-SDI to HDMI Converter/Switcher 4
5 Connecting the FC-321 6
6 Technical Specifications 8
Figures
Figure 1: FC-321 SD/HD-SDI to HDMI Converter/Switcher 5
Figure 2: Connecting the FC-321 SD/HD-SDI to HDMI Converter/Switcher 7
Tables
Table 1: FC-321 SD/HD-SDI to HDMI Converter/Switcher Features 6
Table 2: Technical Specifications of the FC-321 8

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups
1
that are clearly
defined by function.
Thank you for purchasing the Kramer DigiTOOLS
®
FC-321 SD/HD-SDI to
HDMI Converter/Switcher, which is ideal for:
Home theater, presentation and multimedia applications
Rental and staging
The package includes the following items:
FC-321
Power supply (5V DC input)
This user manual
2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
Review the contents of this user manual
Use Kramer high-performance high-resolution cables
3
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
2
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
3 Overview
The FC-321 SD/HD-SDI to HDMI Converter/Switcher is a
high-performance format converter for SDI (SMPTE 259M), HD-SDI
(SMPTE 292M), and 3G HD-SDI (SMPTE 424M) signals. It converts one
of two SDI video and audio signals to an HDMI output signal with the same
resolution and frame rate
1
.
The FC-321 features:
Two SD/HD-SDI/3G HD-SDI inputs on BNC connectors
One HDMI output with HDTV compatibility
An SDI audio group select rotary switch
1 No scaling is performed

Overview
3
Automatic active input LED indicators on the front panel. Green
indicates a standard definition (SDI) input signal and blue indicates a
high-definition (HD-SDI) input signal
5V DC power
3.1 About HDMI
High-Definition Multimedia Interface (HDMI) is an uncompressed
all-digital
1
audio/video interface, widely supported in the entertainment and
home cinema industry. It delivers the highest high-definition image and
sound quality. Note that Kramer Electronics Limited is an HDMI Adopter
2
and an HDCP Licensee
3
. In particular, HDMI
4
:
Provides a simple
5
interface between any audio/video source, such
as a set-top box, DVD player, or A/V receiver and video monitor,
such as a digital flat LCD / plasma television (DTV), over a
single
6
cable
Supports standard, enhanced, high-definition video, and multi-
channel digital audio
7
on a single cable
Transmits all ATSC HDTV standards and supports 8-channel
digital audio, with bandwidth to spare to accommodate future
enhancements and requirements
Benefits consumers by providing superior, uncompressed High
Definition digital video via a single cable
8
, and user-friendly
connector
Is backward-compatible with DVI (Digital Visual Interface)
1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-
to-analog conversions
2 See http://www.hdmi.org/about/adopters_founders.asp
3 See http://www.digital-cp.com/list/
4 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
licensing LLC
5 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables
currently used in A/V systems is reduced
6 HDMI technology has been designed to use standard copper cable construction at up to 15m
7 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to
support Dolby 5.1 audio and high-resolution audio formats
8 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a
simple, cost-effective manner

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your FC-321 SD/HD-SDI to HDMI Converter/Switcher
4
Supports two-way communication between the video source (such
as a DVD player) and the digital television, enabling new
functionality such as automatic configuration and one-button play
HDMI has the capacity to support existing high-definition video formats (720p,
1080i, and 1080p/60), as well as standard definition formats such as NTSC or PAL.
3.2 Recommendations for Best Performance
To achieve the best performance:
Use only good quality connection cables
1
to avoid interference,
deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables).
Avoid interference from neighboring electrical appliances that
may adversely influence signal quality and position your Kramer
FC-321 away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit
2
.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
4 Your FC-321 SD/HD-SDI to HDMI Converter/Switcher
Figure 1 and Table 1 define the FC-321 SD/HD-SDI to HDMI
Converter/Switcher:
1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com
2 For example, part number 2535-052002

Your FC-321 SD/HD-SDI to HDMI Converter/Switcher
5
Figure 1: FC-321 SD/HD-SDI to HDMI Converter/Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the FC-321
6
Table 1: FC-321 SD/HD-SDI to HDMI Converter/Switcher Features
# Feature Function
1 SD/HD-SDI IN 1 BNC Connector Connects to the SD or HD-SDI source 1
2 SD/HD-SDI IN 2 BNC Connector Connects to the SD or HD-SDI source 2
3 SDI AUDIO GROUP SELECT Turn to select the input stereo channel (0 to 7)
4 HDMI OUT Connector Connects to an HDMI acceptor
5 5V DC +5V DC connector for powering the unit
6 REMOTE IR Sensor Receives the input from an IR remote control
7 REMOTE IR LED Flashes red when receiving an IR signal
8 IN SELECT Pushbutton Press to toggle between SDI 1 IN and SDI 2 IN
9 SDI 1 IN LED Illuminates green for an SD input signal and blue for
an HD input signal on HD-SDI 1
10 OUT LED Illuminates green to indicate that the display is
connected
11 SDI 2 IN LED Illuminates green for an SD input signal and blue for
an HD input signal on HD-SDI 2
12 ON LED Illuminates green when receiving power
5 Connecting the FC-321
To connect the FC-321, as the example in Figure 2 illustrates, do the
following
1
:
1. Connect a digital video source (for example, a digital video player 1) to the
SD/HD-SDI IN 1 connector.
2. Connect a digital video source (for example, a digital video player 2) to the
SD/HD-SDI IN 2 connector.
3. Connect the HDMI connector to an HDMI acceptor (for example, a
plasma display).
4. Using a small screwdriver, turn the SDI AUDIO GROUP SELECT rotary
switch to select an SDI stereo channel
2
from 0 to 7.
5. Connect the 5V DC power adapter to the power socket and connect the
adapter to the mains electricity (not illustrated in Figure 2).
1 Switch OFF the power on each device before connecting it to your FC-321. After connecting your FC-321, switch on its
power and then switch on the power on each device
2 SDI audio is made up of 16 channels of audio information or 8 stereo pairs. Whereas most other devices access a group of
2-pairs, the FC-321 accesses a single pair out of a group for higher discrimination

Connecting the FC-321
7
Figure 2: Connecting the FC-321 SD/HD-SDI to HDMI Converter/Switcher

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
8
6 Technical Specifications
The FC-321 technical specifications are shown in Table 2:
Table 2: Technical Specifications
1
of the FC-321
INPUTS: 2 SD/HD-SDI, 3G HD-SDI on a BNC connector
OUTPUT: 1 HDMI connector
MAX DATA RATE: Up to 3Gbps
STANDARD COMPLIANCE: HDMI 1.3
INDICATOR LEDS: SD/HD, OUT, ON
POWER SOURCE: 5V DC, 450mA
DIMENSIONS 12cm x 7.2cm x 2.4cm (4.7" x 2.8" x 1.0") W, D, H
WEIGHT: 0.3kg (0.7lbs)
ACCESSORIES: Power supply
OPTIONS: 19” rack mount adapter
1 Specifications are subject to change without notice
