Kramer 670T User manual

KRAMER ELECTRONICS LTD.
USER MANUAL
MODELS:
670T
HDMI Optical Transmitter
670RN
HDMI Optical Receiver
P/N: 2900-300330 Rev 2

670T, 670RN – Contents
i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3Overview 4
3.1 Defining the 670T, 670RN HDMI Optical Transmitter/Receiver 4
4Connecting the 670T, 670RN 7
5Technical Specifications 9
Figures
Figure 1: 670T HDMI Optical Transmitter 5
Figure 2: 670RN HDMI Optical Receiver 6
Figure 3: Connecting the 670T/670RN Transmitter/Receiver System 8

670T, 670RN - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer 670T and/or 670RN HDMI Optical
Transmitter/Receiver, which is ideal for the following typical applications:
Home theater, presentation and multimedia applications
Long range multimedia distribution for cinemas, stores, and entertainment
centers
Video production and broadcast facilities
Retail stores and other point-of-sale systems

2
670T, 670RN - Getting Started
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check if
firmware upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer 670T, 670RN away from moisture, excessive sunlight
and dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!

670T, 670RN - Getting Started
3
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
Warning:
Avoid direct eye exposure into the optic connectors
when powered, although this product is regulated
strictly enough to operate under the Laser Class 3R for
eye safety
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
!

4
670T, 670RN - Overview
3 Overview
The 670T converts the HDMI signal to an optical signal, and the 670RN converts
the optical signal back into an HDMI signal. Together, the 670T and 670RNform
an HDMI transmitter/receiver over multimode fiber system.
The 670T and 670RNpair features:
A transmission range of 1700m (more than 5570ft) at 1080p @60Hz 12bit
over an optical cable
A transmission range of up to 400m (1300ft) at 4K x 2K
Regulation in accordance with Class 3R Laser Eye Safety in compliance with
channel for passing HDCP, EDID and a Hot Plug Detect (HPD) signal over
one multimode fiber
Compatibility with optional F670 input and output cards of the VS-1616D and
VS-3232DN
A maximum data rate of 10.2Gbps (3.4Gbps per graphic channel) suitable
for resolutions up to 4K at 30Hz, and for all HD resolutions
When connected to the F670 input and/or output cards, 4K is not supported due to
limitations of the VS-1616D and VS-3232DN.
HDCP compliance
5V DC power adapters
Kramer DigiTOOLS®enclosures
3.1 Defining the 670T, 670RN HDMI Optical
Transmitter/Receiver
This section describes the:
670T HDMI Optical Transmitter, see Section 3.1.1
670RNHDMI Optical Receiver, see Section 3.1.2

670T, 670RN - Overview
5
3.1.1 Your 670T HDMI Optical Transmitter
Figure 1 defines the 670T HDMI Optical Transmitter:
Figure 1: 670T HDMI Optical Transmitter
#
Feature
Function
1
HDMI IN Connector
Connects to the HDMI source
2
CONNECTED
LEDs
FIBER
Illuminates when the fiber optic cable is connected
3
SOURCE
Illuminates when a source is connected
4
HOT PLUG LED
Indicates a connected display on the receiver side
5
VIDEO DETECT LED
Indicates a valid video signal on the transmitter side
6
ON LED
Illuminates when receiving power
7
OPTIC CABLE Connector
Connect to the optical connector on the 670RN
(remove dust cap prior to use)
8
5V DC
+5V DC connector for powering the unit

6
670T, 670RN - Overview
3.1.2 Your 670RN HDMI Optical Receiver
Figure 2 defines the 670RNHDMI Optical Receiver:
Figure 2: 670RN HDMI Optical Receiver
#
Feature
Function
1
HDMI OUT Connector
Connects to the HDMI acceptor
2
CONNECTED
LEDs
FIBER
Lights when the fiber optic cable is connected
3
SOURCE
Lights when a source is connected
4
HOT PLUG LED
Indicates a connected display on the receiver side
5
VIDEO DETECT LED
Indicates a valid video signal on the transmitter side
6
ON LED
Illuminates when receiving power
7
OPTIC CABLE Connector
Connect to the optical connector on the 670T
(remove dust cap prior to use)
8
5V DC
+5V DC connector for powering the unit

670T, 670RN - Connecting the 670T, 670RN
7
4 Connecting the 670T, 670RN
Always switch off the power to each device before connecting it to your
670T, 670RN. After connecting your 670T, 670RN, connect its power
and then switch on the power to each device.
Avoid direct eye exposure into the optic connectors when powered,
although this product is regulated strictly enough to operate under the
Laser Class 3R for eye safety
To connect the 670T and 670RN, as illustrated in the example in Figure 3, do the
following:
1. Connect an HDMI source (for example a Blu-ray disc player) to the HDMI IN
connector.
2. Connect the HDMI OUT connector to an HDMI acceptor (for example, an
LCD display).
3. Remove the dust caps and connect the OPTIC CABLE connector of the
670T to the OPTIC CABLE connector of the 670RN, via optic OM3 cabling
with SC connectors (maximum range of 1700m (over 5570ft)).
4. Connect the 5V DC power adapter to the power socket on each unit and
connect the adapter to the mains electricity (not shown in Figure 3).
i

8
670T, 670RN - Connecting the 670T, 670RN
Figure 3: Connecting the 670T/670RN Transmitter/Receiver System

670T, 670RN - Technical Specifications
9
5 Technical Specifications
670T
670RN
INPUTS:
HDMI Connector
1 optical connector
OUTPUTS:
1 optical connector
HDMI Connector
BANDWIDTH:
Supports up to 10.2Gbps bandwidth
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI using fiber optic communication links and
DDC2B
EXTENSION LIMIT:
1700m (5570ft) for 1080p/60Hz
400m (1300ft) at 4K
FIBER-OPTIC CONNECTION:
SC connectors for multimode (OM3) fiber cable (not
supplied with the unit)
INSERTION LOSS FROM
TRANSMITTER TO RECEIVER:
Must not exceed 10dB
INDICATOR LEDs:
Video, source, acceptor fiber and on LEDs
POWER CONSUMPTION:
5V DC, 300mA
5V DC, 500mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12cm x 7.95cm x 2.76cm (4.7" x 3.1" x 1.08") W, D, H
WEIGHT:
0.3kg (0.67lbs) approx. each
ACCESSORIES:
Power supply, bracket installation kit
Specifications are subject to change without notice at http://www.kramerelectronics.com

For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N:
2900-300330
Rev:
2
!
SAFETY WARNING
Disconnect the unit from the power
supply before opening and servicing
