KROHNE OPTISWITCH 3100 C User manual

Electronics module Handbook
Vibrating Level Switch
OPTISWITCH 3100 C - 3300 C

2
Contents
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
Contents
1 About this document ............................................................................................................... 3
1.1 Function ........................................................................................................................... 3
1.2 Target group ..................................................................................................................... 3
1.3 Symbols used................................................................................................................... 3
2 For your safety ......................................................................................................................... 4
2.1 Authorised personnel ....................................................................................................... 4
2.2 Appropriate use................................................................................................................ 4
2.3 Safety instructions for Ex areas ........................................................................................ 4
3 Product description ................................................................................................................. 5
3.1 Conguration.................................................................................................................... 5
3.2 Principle of operation........................................................................................................ 5
3.3 Packaging, transport and storage..................................................................................... 5
4 Mounting................................................................................................................................... 6
4.1 Mounting instructions ....................................................................................................... 6
4.2 Mounting preparations ..................................................................................................... 6
4.3 Installation procedure....................................................................................................... 6
5 Setup ......................................................................................................................................... 8
5.1 Setup................................................................................................................................ 8
6 Maintenance ............................................................................................................................. 9
6.1 How to proceed if a repair is necessary............................................................................ 9
7 Dismount................................................................................................................................. 10
7.1 Dismounting steps.......................................................................................................... 10
7.2 Disposal ......................................................................................................................... 10
8 Supplement ............................................................................................................................ 11
8.1 Technical data ................................................................................................................ 11
8.2 Trademark ...................................................................................................................... 12
Editing status: 2015-08-18

3
1 About this document
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
1 About this document
1.1 Function
This instruction provides all the information you need for mounting,
connection and setup as well as important instructions for mainte-
nance,faultrectication,theexchangeofpartsandthesafetyofthe
user. Please read this information before putting the instrument into
operation and keep this manual accessible in the immediate vicinity
of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Information, note, tip: This symbol indicates helpful additional infor-
mation and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions,
damage to devices or plants.
Caution: Non-observance of the information marked with this symbol
may result in personal injury.
Warning: Non-observance of the information marked with this symbol
may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol
results in serious or fatal personal injury.
Ex applications
This symbol indicates special instructions for Ex applications.
• List
The dot set in front indicates a list with no implied sequence.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of bat-
teries and accumulators.

4
2 For your safety
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
2.2 Appropriate use
Electronics module WE 60 is a replacement insert for OPTISWITCH
3100 C - 3300 C vibrating level switches.
2.3 Safety instructions for Ex areas
For applications in explosion-proof areas (Ex), only devices with cor-
respondingExapprovalmaybeused.ObservetheEx-specicsafety
instructions.These are an integral part of the operating instructions
and are enclosed with every device with Ex approval.

5
3 Product description
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• Electronics module for OPTISWITCH 3100 C - 3300 C (WE 60)
• Documentation
– This operating instructions manual
3.2 Principle of operation
The electronics module WE 60 is suitable for replacement of OPTIS-
WITCH 3100 C - 3300 C vibrating level switches.
3.3 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging of standard instruments consists of environment-
friendly, recyclable cardboard. For special versions, PE foam or PE
foil is also used. Dispose of the packaging material via specialised
recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Not exposed to corrosive media
• Protected against solar radiation
• Avoiding mechanical shock and vibration
• Storage and transport temperature see chapter "Supplement -
Technical data - Ambient conditions"
• Relative humidity 20 … 85 %
With instrument weights of more than 18 kg (39.68 lbs) suitable and
approved equipment must be used for lifting and carrying.
Scope of delivery
Area of application
Packaging
Transport
Transport inspection
Storage
Storage and transport
temperature
Lifting and carrying

6
4 Mounting
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
4 Mounting
4.1 Mounting instructions
If the electronics module is defective, it can be replaced by the user.
In Ex applications, only instruments and electronics modules with ap-
propriate Ex approval may be used.
4.2 Mounting preparations
In general, all electronics modules of series WE60 can be inter-
changed.Ifyouwanttouseanelectronicsmodulewithadier-
ent signal output, you can download the corresponding operating
instructions manual from our homepage under Downloads.
4.3 Installation procedure
To exchange the electronics module, proceed as follows:
1. Switchovoltagesupply
2. Unscrew the housing lid
3. Lift the opening levers of the terminals with a screwdriver
4. Pull the connection cables out of the terminals
5. Loosen the two screws with a screw driver (Torx size T10 or slot
4)
2
1
Fig. 1: Loosen the holding screws
1 Electronics module
2 Screws (2 pcs.)
6. Pull out old electronics module
7. Compare the new electronics module with the old one. The type
label of the electronics module must correspond to that of the old
electronics module.This applies particularly to instruments used
in hazardous areas.
8. Compare the settings of the two electronics modules. Set the
adjustment elements of the new electronics module to the same
setting of the old one.
Installation procedure

7
4 Mounting
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
Information:
Make sure that the housing is not rotated during the electronics ex-
change.Otherwisetheplugmaybeinadierentpositionlater.
9. Insert the electronics module carefully. Make sure that the plug is
in the correct position.
10. Screw in the two holding screws and tighten them
11. Insert the wire ends into the open terminals according to the wir-
ing plan
12. Press down the opening levers of the terminals, you will hear the
terminal spring closing
13. Check the hold of the wires in the terminals by lightly pulling on
them
14. Check cable gland on tightness.The seal ring must completely
encircle the cable.
15. Screw the housing lid back on
Theelectronicsexchangeisnownished.
As a rule, an exchange of electronics must be documented internally
if Ex applications are involved.

8
5 Setup
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
5 Setup
5.1 Setup
When replacing the electronics module, make sure that all adjustment
elements are set to the settings of the old electronics module. Hence
the sensor is immediately ready for operation.
In general, all oscillators of series WE60 can be interchanged.
Ifyouwanttouseanelectronicsmodulewithacompletelydierent
signal output, you have to carry out the complete setup.
The necessary, suitable operating instructions manual can be down-
loaded from our homepage under Downloads.
The adjustment should be carried out according to the description in
the operating instructions manual.
Setup

9
6 Maintenance
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
6 Maintenance
6.1 How to proceed if a repair is necessary
If it is necessary to repair the instrument, please contact the responsi-
ble Krohne agency.

10
7 Dismount
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
7 Dismount
7.1 Dismounting steps
Take note of chapters "Mounting" and "Connecting to voltage supply"
and carry out the listed steps in reverse order.
7.2 Disposal
The replacement module consists of materials which can be recycled
by specialised recycling companies. We have purposely designed the
electronic modules to be easily separable.
WEEE directive
The instrument does not fall in the scope of the EU WEEE directive.
Article 2 of this Directive exempts electrical and electronic equipment
from this requirement if it is part of another instrument that does not
fall in the scope of the Directive. These include stationary industrial
plants.
Pass the instrument directly on to a specialised recycling company
and do not use the municipal collecting points.
If you have no way to dispose of the old instrument properly, please
contact us concerning return and disposal.

11
8 Supplement
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
8 Supplement
8.1 Technical data
Technical data
are stated in the operating instructions manual of the respective sensor.

12
8 Supplement
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907
8.2 Trademark
All the brands as well as trade and company names used are property of their lawful proprietor/
originator.

13
Notes
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907

14
Notes
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907

15
Notes
Electronics module • OPTISWITCH 3100 C - 3300 C
30204-EN-210907

30204-EN-210907
2015-08-18 Subject to change without prior notice
KROHNE - Products, Solutions and Services
• Process instrumentation for ow, level, temperature, pressure
measurement and process analytics
• Flow metering, monitoring, wireless and remote metering solu-
tions
• Engineering, commissioning, calibration, maintenance and train-
ing services
Head O󰀩ce KROHNE Messtechnick GmbH
Ludwig-Krohne-Straße 5
47058 Duisburg (Germany)
Tel.: [phone]
Tel.: [phone]
[email protected]
The current list of all KROHNE contacts and addresses can be
found at:
www.krohne.com
