KROHNE OPTIBAR 5060 Wiring diagram

Pressure transmitter
Category
ATEX: II 1D, 1/2D, 1/3D, 2D Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
II 1/2/-D, 1/2D Ex ia/ia/-, ia/tb, ia IIIC TX°C Da/Db/-, Da/Db
IECEX: Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db
OPTIBAR 5060 Supplementary Instructions
© KROHNE 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en

CONTENTS
2 www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
OPTIBAR 5060
1 Safety instructions 3
1.1 General notes ................................................................................................................... 3
1.2 EU conformity................................................................................................................... 3
1.3 Approval according to the IECEx scheme ........................................................................ 4
1.4 Safety instructions............................................................................................................ 4
2 Device description 5
2.1 Description of device ........................................................................................................ 5
2.2 Marking............................................................................................................................. 5
2.2.1 Marking for ATEX .................................................................................................................... 5
2.2.2 IECEx marking......................................................................................................................... 6
2.3 Flammable products ........................................................................................................ 7
2.4 Equipment category ......................................................................................................... 7
2.5 Protection types................................................................................................................ 9
2.6 Thermal parameters ...................................................................................................... 10
2.6.1 Ingress protection according to 60529 ................................................................................. 12
2.7 Electrical data................................................................................................................. 12
2.7.1 OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/7/S/T*******(*)**************.............................. 12
2.7.2 OPTIBAR * 5060 VGK5/6/D*A/W/V R/S/1******(*)**************....................................... 13
2.7.3 OPTIBAR * 5060 VGK5/6/D*A/W/V S/T******(*)************** .......................................... 14
3 Installation 15
3.1 Mounting......................................................................................................................... 15
3.1.1 Version with compact housing.............................................................................................. 16
3.1.2 Version with remote housing................................................................................................ 18
4 Special conditions 20
4.1 Grounding ....................................................................................................................... 20
4.2 Cable entry...................................................................................................................... 20
4.3 Material resistance......................................................................................................... 20
4.4 Housing cover lock ......................................................................................................... 20
4.5 Mounting / setup............................................................................................................. 22
4.6 USB connection .............................................................................................................. 22
4.7 Removal and replacement of the red thread/dust cover .............................................. 22
4.8 Protection against static electricity ............................................................................... 23

SAFETY INSTRUCTIONS 1
3
OPTIBAR 5060
www.krohne.com04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
1.1 General notes
These safety instructions are valid for the pressure transmitter OPTIBAR * 5060
VGK5/6/D*A/W/V R/H/1/7/S/T with integrated electronics type Z (4…20 mA), H
(4…20 mA/HART®), A (4…20 mA/HART® with SIL qualification), P (Profibus PA), F (Foundation
Fieldbus), S, T (electronic differential pressure measurement) without additional electronics (X)
and OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T with integrated electronics type H (4…20
mA/HART®) or A (4…20 mA/HART® with SIL qualification) with additional electronics (Z)
according to the EU type examination certificate TÜV 16 ATEX 162917 X.
The OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*) pressure transmitters monitor,
control and regulate levels and pressures, even in areas with flammable bulk goods that create
dust.
The OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*) consist of a metallic process
connection element, a sensor and converter electronics in a metal or plastic housing (remote
version, with electronics housing in Ex-free area).
The OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*) are suitable for use in explosive
atmospheres with flammable dust, for applications that require equipment in category 1D, 1/2D,
1/3D, 1/2/-D or 2D.
If the OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*) are installed and operated in
hazardous areas, the general installation conditions for explosion protection EN 60079-14 and
this safety information must be observed.
The requirements of EN 61241-1, in relation to dust accumulation and temperature for example,
must be met.
1.2 EU conformity
The manufacturer declares with the EU declaration of conformity on his own responsibility
conformity with the protection goals of directive 2014/34/EU according to EN IEC 60079-0,
EN 60079-11 and EN 60079-31 for use in hazardous areas with dust.
The EU type test certificate forms the basis of the EU declaration of conformity:
The "X" after the certificate number refers to special conditions for safe use of the device, which
have been listed in these instructions.
If needed the EU type examination certificate can be downloaded from the manufacturer's
website.
TÜV 16 ATEX 162917 X

1 SAFETY INSTRUCTIONS
4
OPTIBAR 5060
www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
1.3 Approval according to the IECEx scheme
Conformity with IECEx standards was tested in accordance with the "IECEx Certification Scheme
for Explosive Atmospheres" according to IEC 60079-0, IEC 60079-11 and IEC 60079-31.
The number of the IEC certificate is:
The "X" after the certificate number refers to special conditions for safe use of the device, which
have been listed in these instructions.
If needed the IEC certificate can be downloaded from the manufacturer's website.
1.4 Safety instructions
Assembly, installation, start-up and maintenance may only be performed by personnel trained in
explosion protection!
IECEx TUN 16.0017 X
CAUTION!
The operator or his agent is responsible for observing any additional standards, directives or
laws if required due to operating conditions or place of installation.

DEVICE DESCRIPTION 2
5
OPTIBAR 5060
www.krohne.com04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
2.1 Description of device
The pressure transmitter of the OPTIBAR 5060 series is designed to measure the pressure of
vaporous, gaseous and liquid media.
2.2 Marking
2.2.1 Marking for ATEX
The marking of the entire device is on the housing, where the following identification plate can be
found.
Figure 2-1: Example for an ATEX nameplate for an OPTIBAR 5060
1 Observe the instructions
2 Marking of notified body and CE marking
3 Hardware version
4 Product name and type code
5 Permissible temperature range
6 Nominal range
Permissible process pressure
7 Electronics power supply and signal output
8 Ingress protection and material of wetted parts
(Diaphragm, process connection, sealing and fill fluid)
9 Approvals and approval directive
TMAX: See manual and approval documents
2022
HW Ver 1.0.0
PED SEP
VGK54ARDUSAGG0SHXA16XDD00K0X
TÜV ATEX 162917 X
9,6...30VDC
II 1D, 1/2D, 1/3D, 2D
Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
II 1/2/-D, 1/2D
Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db

2 DEVICE DESCRIPTION
6
OPTIBAR 5060
www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
2.2.2 IECEx marking
The marking of the entire device is on the housing, where the following identification plate can be
found.
Figure 2-2: Example for an IECEx nameplate for an OPTIBAR 5060
1 Observe the instructions
2 Hardware version
3 Product name and type code
4 Permissible temperature range
5 Nominal range
Permissible process pressure
6 Electronics power supply and signal output
7 Ingress protection and material of wetted parts
(Diaphragm, process connection, sealing and fill fluid)
8 Approvals and approval directive
TMAX: See manual and approval documents
2022
HW Ver 1.0.0
PED SEP
VGK54 WRDUSAGG0SHXA16XDD00K0X
IECEx TUN 16.0017 X
9,6...30VDC
Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db

DEVICE DESCRIPTION 2
7
OPTIBAR 5060
www.krohne.com04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
2.3 Flammable products
Atmospheric conditions:
An explosive atmosphere is a mixture of air and flammable gases, vapours, mists or dusts under
atmospheric conditions. It is defined by the following values
Tatm = -20...+60°C / -4...+140°F and Patm = 0.8...1.1 bar / 11.6...15.9 psi.
Operation outside the specified above standard atmospheric conditions is permitted only via risk
assessment of the user and additional measures, as necessary.
Operating conditions:
Outside of atmospheric conditions, the explosion protection according to directive
2014/34/EU (ATEX) – regardless of the zone assignment – is not applicable due to the lack of key
safety data.
2.4 Equipment category
Category 1D equipment
The OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*) are installed in hazardous areas
requiring equipment category 1D.
Category 1/2D equipment
The electronics housing is installed in hazardous areas requiring equipment category 2D.
The process connection element is installed in the separating wall which separates areas in
which equipment category 2D or 1D are required. The sensor with the mechanical fastener is
installed in hazardous areas requiring equipment category 1D.
Category 1/3D equipment
The electronics housing is installed in hazardous areas requiring equipment category 3D.
The process connection element is installed in the separating wall which separates areas in
which equipment category 3D or 1D are required. The sensor with the mechanical fastener is
installed in hazardous areas requiring equipment category 1D.
Category 1/2/-D equipment
The process connection element is installed in the separating wall which separates areas in
which equipment category 2D or 1D are required. The sensor with the mechanical fastener is
installed in hazardous areas requiring equipment category 1D. The electronics housing is
installed in the safe area, away from the explosive atmosphere caused by dust.
Category 2D equipment
The OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*) are installed in hazardous areas
requiring equipment category 2D.

2 DEVICE DESCRIPTION
8
OPTIBAR 5060
www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
Ignition protection classification:
When it comes to devices with a gas/dust combination approval and two ignition protection
classifications on the nameplate, the device may be used either in gas or in dust. In the case of
devices with an "Ex-t/Ex-ia" combination approval and two ignition protection classifications on
the nameplate, the device may no longer be used as intrinsically safe equipment following non-
intrinsically safe supply.
•OPTIBAR * 5060 VGK5/6/D*A/W/VR*******Z/H/A/S/T/P/F/U**************
•OPTIBAR * 5060 VGK5/6/D*A/W/VR*******H/AZ*************
–– II 1D, 1/2D, 1/3D, 2D Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
–– Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
–– T: see thermal parameters
•OPTIBAR * 5060 VGK5/6/D*A/W/VH*******Z/H/A/S/T/P/F/U**************
•OPTIBAR * 5060 VGK5/6/D*A/W/VH*******H/AZ*************
–– II 1D, 1/2D, 1/3D, 2D Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
–– Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
–– II 1G, 1/2G, 2G Ex ia IIC T6…T1 Ga, Ga/Gb, Gb
–– Ex ia IIC T6…T1 Ga, Ga/Gb, Gb
–– T: see thermal parameters
•OPTIBAR * 5060 VGK5/6/D*A/W/V7*******Z/H/A/S/T/P/F/U**************
–– II 1D, 1/2D, 1/3D, 2D Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
–– Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
–– II 1/2G, 2G Ex d IIC T6…T1 Ga/Gb, Gb
–– Ex d IIC T6…T1 Ga/Gb, Gb
–– T: see thermal parameters
•OPTIBAR * 5060 VGK5/6/D*A/W/V1*******Z/H/A/S/T/P/F/U**************
–– II 1D, 1/2D, 1/3D, 2D Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
–– Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
–– II 1/2G, 2G Ex d ia IIC T6…T1 Ga/Gb, Gb
–– Ex d ia IIC T6…T1 Ga/Gb, Gb
–– T: see thermal parameters
•OPTIBAR * 5060 VGK5/6/D*A/W/VS*******Z/H/A/S/T/P/F/U**************
–– II 1/2/-D, 1/2D Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db
–– Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db
–– T: see thermal parameter
•OPTIBAR * 5060 VGK5/6/D*A/W/VT*******Z/H/A/S/T/P/F/U**************
–– II 1/2/-D, 1/2D Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db
–– Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db
–– II 1/2G, 2G Ex ia IIC T6…T1 Ga/Gb, Gb
–– Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db
–– T: see thermal parameters

DEVICE DESCRIPTION 2
9
OPTIBAR 5060
www.krohne.com04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
2.5 Protection types
The pressure transmitter is designed with protection type dust - protection by enclosure
protection level "ta" according to EN 60079-31 or IEC 60079-31.
The marking according to ATEX is:
II 1D, 1/2D, 1/3D, 2D Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
II 1/2/-D, 1/2D Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db
The marking according to IECEx is:
Ex ta ia, ia/tb, ia/tc, tb ia IIIC TX°C Da, Da/Db, Da/Dc, Db
Ex ia/ia/-, ia/tb ia IIIC TX°C Da/Db/-, Da/Db
The marking contains the following information:
II Explosion protection, group II
1Equipment category 1
DDust ignition protection
Ex ta ia The electronics and sensor housing are designed as protection type Ex ta (protection by
enclosure) for use in Zone 20, the pressure sensor is designed in Ex ia.
Ex ia/tb Partition version: The electronics and sensor housing are designed as protection type Ex tb
(protection by enclosure) for use in Zone 21, the pressure sensor is designed in Ex ia.
Ex tb ia The electronics and sensor housing are designed as protection type Ex tb (protection by
enclosure) for use in Zone 21, the pressure sensor is designed in Ex ia.
Ex ia/ia/- Remote housing: pressure sensor Ex ia (Zone 20) / cable Ex ia (Zone 21) / electronics and
housing in non-hazardous area (-)
Ex ia/tb ia Remote housing: pressure sensor Ex ia (Zone 20) / cable Ex ia, electronics and housing Ex
tb (Zone 21)
IIIC Dust group, suitable for dust groups IIIC, IIIB and IIIA
1/2 Equipment category 1/2
1/3 Equipment category 1/3
2Equipment category 2
1/2/- Equipment category 1/2/ for remote version (pressure sensor category 1 /
cable category 2 / housing in non-hazardous area)
TX°C maximum permissible surface temperature X°C
Da EPL, suitable for zone 20
Da/Db EPL, suitable for zone 20 / zone 21
Da/Dc EPL, suitable for zone 20 / zone 22
Db EPL, suitable for zone 21
Da/Db/- EPL, suitable for Zone 20 / Zone 21 / housing in non-hazardous area
Table 2-1: Protection types

2 DEVICE DESCRIPTION
10
OPTIBAR 5060
www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
2.6 Thermal parameters
For applications in hazardous atmospheres requiring equipment category 1G, the process
pressure must be between 0.8…1.1 bar. The application conditions in areas without hazardous
mixtures are specified in the manufacturer information.
The maximum permissible ambient temperatures are specified in the following tables.
Category 1D equipment
Category 2D equipment
Category 1/2D, 1/3D equipment
Range Permissible temperature range
Electronics housing -40...+60°C / -40...+140°F
Probe -40...+60°C / -40...+140°F
Max. surface temperature
Electronics housing
(Z/H/A/S/T/P/F) Ambient temperature +42 K
Table 2-2: Application for category 1D equipment
Range Permissible temperature range
Electronics housing -40...+60°C / -40...+140°F
Probe -40...+60°C / -40...+140°F
Max. surface temperature
Probe Process temperature +41 K
Table 2-3: Application for category 2D equipment
Range Permissible temperature range
Electronics housing -40...+60°C / -40...+140°F
Probe -40...+60°C / -40...+140°F
Max. surface temperature
Electronics housing
(Z/H/A/S/T/P/F) Ambient temperature +5 K
Probe Process temperature +41 K
Table 2-4: Application for category 1/2D, 1/3D equipment

DEVICE DESCRIPTION 2
11
OPTIBAR 5060
www.krohne.com04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
Category 1/2D, 1/3D equipment with temperature adapter
Range Permissible temperature range
Electronics housing -40...+60°C / -40...+140°F
Probe -40...+130°C / -40...+266°F
Max. surface temperature
Electronics housing
(Z/H/A/S/T/P/F) Ambient temperature +20 K
Probe Process temperature +41 K
Table 2-5: Application for category 1/2D, 1/3D equipment with temperature adapter
(Probe: -40...+130°C / -40...+266°F)
Range Permissible temperature range
Electronics housing -40...+60°C / -40...+140°F
Probe -40...+150°C / -40...+302°F
Max. surface temperature
Electronics housing
(Z/H/A/S/T/P/F) Ambient temperature +20 K
Probe Process temperature +41 K
Table 2-6: Application for category 1/2D, 1/3D equipment with temperature adapter
(Probe: -40...+150°C / -40...+302°F)
Range Permissible temperature range
Electronics housing -40...+60°C / -40...+140°F
Probe -40...+180°C / -40...+356°F
Max. surface temperature
Electronics housing
(Z/H/A/S/T/P/F) Ambient temperature +16 K
Probe Process temperature +41 K
Table 2-7: Application for category 1/2D, 1/3D equipment with temperature adapter
(Probe: -40...+180°C / -40...+356°F)
Range Permissible temperature range
Electronics housing -40...+60°C / -40...+140°F
Probe -40...+200°C / -40...+392°F
Max. surface temperature
Electronics housing
(Z/H/A/S/T/P/F) Ambient temperature +17 K
Probe Process temperature +41 K
Table 2-8: Application for category 1/2D, 1/3D equipment with temperature adapter
(Probe: -40...+200°C / -40...+392°F)

2 DEVICE DESCRIPTION
12
OPTIBAR 5060
www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
Category 1/2/-D equipment
2.6.1 Ingress protection according to 60529
2.7 Electrical data
In order to guarantee the rated voltage Um and not to endanger the type of protection, the power
supply units used must meet the requirements for a SELF or PELV power supply unit.
2.7.1 OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/7/S/T*******(*)**************
With electronics Z (4…20 mA), H (4…20 mA/HART®), A (4…20 mA/HART® with SIL
qualification)
With electronics H (4…20 mA/HART®), A (4…20 mA/HART® with SIL qualification) and
additional electronics Z (second current output)
Range Permissible temperature range
Electronics housing -40...+60°C / -40...+140°F
Max. surface temperature
Probe Process temperature +41 K
Table 2-9: Application for category 1/2/-D equipment
Protection class Ingress protection
At probe, category 1D or 2D IP68
At electronics housing, category 1D or 2D IP68
OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/7/S/T*******(*)Z/H/A/**************
Supply and signal circuit:
(Terminals 1[+], 2[-] in electronics
compartment, in the double chamber
housing version in terminal
compartment)
•Un: 9.6...30 VDC
•In: 4...22 mA
•Um: 30 VDC
Table 2-10: Electrical data for OPTIBAR * 5060 with electronics Z/H/A
OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/7/S/T*******H/AZ*************
Supply and signal circuit I:
(Terminals 1[+], 2[-] in terminal
compartment)
•Un: 9.6...30 VDC
•In: 4...22 mA
•Um: 30 VDC
Supply and signal circuit II:
(Terminals 7[+], 8[-] in terminal
compartment)
•Un: 9.6...30 VDC
•In: 4...22 mA
•Um: 30 VDC
Table 2-11: Electrical data for OPTIBAR * 5060 with electronics Z/H and additional electronics Z

DEVICE DESCRIPTION 2
13
OPTIBAR 5060
www.krohne.com04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
With electronics P (Profibus), F (Foundation Fieldbus)
With electronics S,T (electronic differential pressure)
2.7.2 OPTIBAR * 5060 VGK5/6/D*A/W/V R/S/1******(*)**************
With electronics Z (4…20 mA), H (4…20 mA/HART®)
With electronics U (Modbus)
With electronics in remote version
OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/7/S/T******(*)P/F**************
Supply and signal circuit:
(Terminals 1[+], 2[-] in electronics
compartment, in the double chamber
housing version in terminal
compartment)
•Un: 9.6...32 VDC
•In: 4...11 mA
•Um: 32 VDC
Table 2-12: Electrical data for OPTIBAR * 5060 with electronics P/F
OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/7/S/T******(*)S/T/**************
Supply and signal circuit I:
(Terminals 5, 6, 7, 8) For connection of an OPTIBAR 5060 with integrated electronics H/A/P/F as differential pressure measurement.
Table 2-13: Electrical data for OPTIBAR * 5060 with electronics S/T
OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/7/S/T******(*)H/A/P/F/**************
Supply and signal circuit I:
(Terminals 5, 6, 7, 8) For connection to the circuit (terminals 5, 6, 7, 8) of an OPTIBAR 5060 with integrated electronics S or T as
differential pressure measurement.
Table 2-14: Electrical data for OPTIBAR * 5060 with electronics H/A/P/F
OPTIBAR * 5060 VGK5/6/D*A/W/V R/S/1******(*)Z/H**************
Supply and signal circuit:
(Terminals 1[+], 2[-] in electronics
compartment, in the double chamber
housing version in terminal
compartment)
•Un: 9.6...30 VDC
•In: 4...22 mA
•Um: 30 VDC
Table 2-15: Electrical data for OPTIBAR * 5060 with electronics Z/H
OPTIBAR * 5060 VGK5/6/D*A/W/V R/S/1******(*)U**************
Supply and signal circuit I:
(Terminals 1[+], 2[-] in terminal
compartment)
•Un: 9.6...30 VDC
•In: 4...22 mA
•Um: 30 VDC
Supply and signal circuit II:
(Terminals MB [+], MB [-] in terminal
compartment)
•Un: 5 VDC
•In: 4...22 mA
•MODBUS signal (telegram)
•Um: 5 VDC
Table 2-16: Electrical data for OPTIBAR * 5060 with electronics U
OPTIBAR * 5060 VGK5/6/D*A/W/V R/S/1******(*)H**************
Supply and signal circuit I:
(Terminals 5, 6, 7, 8) For connection to the circuit (terminals 5, 6, 7, 8) of an OPTIBAR 5060 with integrated electronics S or T as
differential pressure measurement.
Table 2-17: Electrical data for OPTIBAR * 5060 with electronics in remote version H

2 DEVICE DESCRIPTION
14
OPTIBAR 5060
www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
2.7.3 OPTIBAR * 5060 VGK5/6/D*A/W/V S/T******(*)**************
With electronics in remote version
OPTIBAR * 5060 VGK5/6/D*A/W/V S/T******(*)Z/H/A/S/T/P/F(U)*************
Probe circuit
(Terminals 1 yellow, 2 white, 3 red, 4
black)
In the version with a line between the electronics housing and
the transmitter housing, the supplied wire may have a
maximum length of 180 m.
The intrinsically safe circuits to the probe are galvanically
connected to the ground potential.
Table 2-18: Electrical data for OPTIBAR * 5060 with electronics in remote version Z/H/A/S/T/P/F(U)

INSTALLATION 3
15
OPTIBAR 5060
www.krohne.com04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
3.1 Mounting
Mounting and setup must be carried out according to the applicable installation standards
(e.g. EN 60079-14 or IEC 60079-14) by qualified personnel trained in explosion protection.
The information given in the manuals and the supplementary instructions must be observed at
all times.
Install pressure transmitters so that:
•the device is not in a pneumatic flow.
•there is no danger from mechanical impact effects.
CAUTION!
The manufacturer is not liable for any damage resulting from improper use or use other than the
intended purpose. This applies in particular to hazards due to insufficient corrosion resistance
and suitability of the materials in contact with product.

3 INSTALLATION
16
OPTIBAR 5060
www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
3.1.1 Version with compact housing
Category 1D and 2D equipment
Figure 3-1: Sensor is completely mounted in zone 20
1 Zone 20
2 Ex ta
3 Ex ia
Figure 3-2: Sensor is completely mounted in zone 21
1 Zone 21
2 Ex tb
3 Ex ia
Observe the thermal data for equipment category 2D.
The hazardous area technical requirements for zone 21 apply to the electronics housing, the cable entries and the filter
element (only stainless steel and aluminium housing with cable entries certified for use in dust Ex environments and no
plug connectors are permitted)

INSTALLATION 3
17
OPTIBAR 5060
www.krohne.com04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
Category 1/2D and 1/3D equipment
Figure 3-3: The sensor is installed in the partition wall between zone 20 and zone 21.
1 Zone 21
2 Ex tb
3 Ex ia
4 Zone 20
Observe the thermal data for equipment category 1/2D.
The hazardous area technical requirements for zone 21 apply to the electronics housing, the cable entries and the filter
element (only stainless steel and aluminium housing with cable entries certified for use in dust Ex environments and no
plug connectors are permitted)
Figure 3-4: The sensor is installed in the partition wall between zone 20 and zone 22.
1 Zone 22
2 Ex tc
3 Ex ia
4 Zone 20
Observe the thermal data for equipment category 1/3D.
The hazardous area technical requirements for zone 21 apply to the electronics housing, the cable entries and the filter
element (only stainless steel and aluminium housing with cable entries certified for use in dust Ex environments and no
plug connectors are permitted)

3 INSTALLATION
18
OPTIBAR 5060
www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
3.1.2 Version with remote housing
Category 1/2/-D equipment
Figure 3-5: Electronics and connection housing in safe area
1 Zone 21
2 Ex ia
3 Ex ia
4 Zone 20
5 Safe area (-)
The connecting line is an intrinsically safe signal circuit.
There are no special Ex technical requirements (plastic housing, electro-polished stainless steel housing and plug con-
nectors are permitted) for the electronics and terminal housing, cable entries and the filter element.
Figure 3-6: Electronics and connection housing as well as connecting cable in safe area
1 Zone 20
2 Ex ia
3 Safe area (-)
The connecting line is an intrinsically safe signal circuit.
There are no special Ex technical requirements (plastic housing, electro-polished stainless steel housing and plug con-
nectors are permitted) for the electronics and terminal housing, cable entries and the filter element.

INSTALLATION 3
19
OPTIBAR 5060
www.krohne.com04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
Figure 3-7: Electronics and connection housing as well as connecting cable in zone 21
1 Zone 21
2 Ex tb ia
3 Ex ia
4 Zone 20
The connecting line is an intrinsically safe signal circuit.
The hazardous area technical requirements for zone 21 apply to the electronics and terminal housing, cable entries and
filter elements (only stainless steel and aluminium housing with cable entries certified for use in dust Ex environments
and no plug connectors are permitted)

4 SPECIAL CONDITIONS
20
OPTIBAR 5060
www.krohne.com 04/2021 - 4005260702 - AD OPTIBAR 5060 Exta R02 en
4.1 Grounding
The OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*)************** must be grounded.
In the case of the version with remote housing of the OPTIBAR * 5060 VGK5/6/D*A/W/V
R/H/1/7/S/T*******(*)************** pressure transmitters, the equipotential bonding must be
provided in the complete mounting area of the connection cable between electronics housing
and transmitter housing.
4.2 Cable entry
The supplied cable entry is suitable for the housing temperature range certified for the
OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*)**************-.
Cable entries may only be replaced by the same type or suitable cable glands separately certified
as per ATEX/IECEx with minimum IP 66 must be used.
If a cable entry other than the one provided is used, the separately certified cable entry
determines the maximum permitted ambient temperature at the electronics housing (maximum
values: -40°C / -40°F, +80°C / +176°F).
4.3 Material resistance
The OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*)************** should only be used
in media against which the wetted materials are sufficiently resistant.
4.4 Housing cover lock
In the case of the single chamber housing versions the housing cover must be turned until it
stops before starting up and using the OPTIBAR * 5060 VGK5/6/D*A/W/V
R/H/1/7/S/T*******(*)************** in explosive atmospheres. It should be secured using the
lock on the cover.
For the double chamber housing versions the housing cover on the terminal compartment and
the housing cover on the electronics compartment must be turned until they stop before starting
up and using the OPTIBAR * 5060 VGK5/6/D*A/W/V R/H/1/7/S/T*******(*)************** in
explosive atmospheres. They should be secured using the appropriate lock on the cover.
