Kruger ALTO-T User manual

ALTO •T
USER MANUAL
ENGLISH GETTING STARTED

Thank you for choosing Krüger home appliances!
Please follow the recommendations and guidelines contained in this manual. This way the
appliance will give you consistent high performance and efciency for many years to come.
Table of Contents
Warnings & Caution
Characteristics
Installation & Usage
Maintenance & Cleaning
2
3
4
8
Rated Voltage
Rated Power Frequency
Lighting Power Consumption
Motor Power Consumption
Total Power
Motor(s)
Dimensions of Outer Adaptor
Dimensions
Product Specications and Technical Parameters
110V - 120V
60Hz
2 x 20W
120W
160W
1
6” (Circular)
35 ¼” (Width) x 19 ½” (Depth) x 28” (Height)

WARNING
TO REDUCE RISK OF FIRE, ELECTRIC SHOCK OR
INJURY TO PERSONS, PLEASE OBSERVE THE
FOLLOWING:
1. Installation work and electric wiring must be done by a qualied professional in accordance with
local applicable codes and standards, including re-rated construction.
2. The stainless steel structural housing may have sharp edges. Be careful to avoid cuts and
abrasions during installation and cleaning.
3. The hood must be placed at a minimum distance of 26” and a maximum of 30” from the cooktop
for best capture of cooking impurities, and a minimum distance of 28” from gas range.
4. Provide sufcient air for proper combustion and exhausting of gases through the chimney of the
burning equipment to prevent backdraft. Follow the heating equipment manufacturer’s guideline
and safety standards such as those published by the National Fire Protection Association, and the
American Society for Heating, Refrigeration and Air Conditioning Engineer (ASHRAE), and the
local code authorities.
5. Ducted fans must always be vented to the outdoors.
6. This appliance is designed to be operated by adults. Children are not allowed to tamper with the
controls or play with this appliance.
7. To reduce the risk of re or electric shock, do not use this fan with any solid-state speed control
device.
8. When cutting or drilling into the wall or ceiling, do not damage electrical wiring and other hidden utilities.
9. This unit is meant for household kitchen use only. To ensure your safety, it needs to be connected
to a GFCI protected branch circuit.
10. Before servicing or cleaning unit, switch power off at the service panel. This will prevent power
from being switched on accidentally.
11. Use this unit only in the manner it is intended for by the manufacturer. If you have any questions
regarding the usage of this appliance, please contact the manufacturer or the local agent closest
to you.
12. Never leave surface units unattended at high settings. Over boiling can cause smoke and grease
spills that may ignite. Heat oils slowly on low or medium settings.
13. Always turn hood ON when cooking at high heat, especially when there is an open ame.
ie: Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé.
14. Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan or lter.
15. Use proper pan size. Always use cookware appropriate for the size of the surface element.
2

3
CHARACTERISTICS
DImensions
35 1/4 ”
19 5/8”
2 3/4”
19 5/8”
10 13/16” 11”
min. height 22 3/8”
extendable
max. height 41 3/8”
1 Hood Body Structure:
Complete with controls, lights, blower, lters, exhaust adaptor.
2 Telescopic Chimney Uprising
2.2 Decorative Chimney Bottom
3 Exhaust port ductwork
6.1 Chimney Mounting Bracket
6.2 Hood Mounting Bracket
2.1 Decorative Chimney Bottom
7 Backdraft Damper
8 Oil Capture Tray
9.a Mounting Screws
9.b Chimney Bracket Mounting Screws
9.c Chimney Bottom Fixing Screws
10 Drywall Anchors

Bracket Installation
INSTALLATION & USAGE
NOTE: Carefully remove the blue coloured plastic protective lm prior to nal installation.
4
1. Draw a vertical line on the supporting wall, from the cooking surface to the ceiling. This will be
the center line of which the hood will be mounted according to.
2. Draw a horizontal line at 25 ½” above an electric element cook top, or 30 ½” above a gas
cooking surface.
3. Place the chimney mounting brackets on the wall approx. ¾” from the ceiling.
4. Mark the wall where the center holes of the brackets are.
5. Place the hood mounting bracket on the wall aligning the central notches to the vertical
reference line.
6. Mark the wall at the center of the holes in the bracket.
6. Attach the brackets to the wall using the mounting screws and drywall anchors.
25 ½” ~ 30 ½”
¾”

Mounting The Hood
1. Hook the body onto the hood mounting brackets.
2. Balance the hood by adjusting the mounting brackets. Gently lower the hood until it securely
engages the bracket.
3. Attach the backdraft damper aps to the exhaust outlet at the top of the unit.
4. Be sure that the damper is rmly attached while the aps can move freely.
5. Attach ductwork to the unit with screws that are included on the two sides of the exhaust outlet.
5
Connecting the Hood
1. Decide the pathway of the ductwork connecting the ventilation unit to the exterior of the house.
2. The shorter and straighter the ductwork, the better the unit will perform.
3. Longer runs, elbows, transitions and other modications will reduce the performance of the
hood. Larger diameter ducts may be required for optimal performance with longer ducts.
4. Attach an adequate length of 6” diameter duct to the exhaust outlet of the unit.
5. Do not exhaust into a shaft, ue, or pipeline that is being used to exhaust the fumes from
other appliances burning gas or other fuels.
6. Install a roof or wall cap on the exterior of the house. Connect round metal ductwork to cap
and work backwards towards hood location. Use duct tape to seal the joints between sections.
Electrical Connection
1. Electrical wiring must be done by a qualied professional in accordance with all applicable
codes and standards. Turn off electrical power at service panel before wiring.
2. Do not extend the cord with an extension cord or splitter that is not supplied with the hood.
3. Grounding of this product is compulsory. Do NOT remove ground prong of the plug.
Telescopic Chimney
1. Attach the inner telescopic chimney sleeve on to the top wall bracket. It can be secured with
two screws (included) from both sides.
2. Attach the outer telescopic chimney sleeve into the recessed area at the top of the hood.
3. Secure the outer telescopic chimney sleeve with three screws (included) from the inside of
the hood body.

6
LIGHTING
The range hood requires two type JCD, 12V, 20W max, G-4 base, halogen bulbs.
WARNING: Always switch off the electrical supply before carrying out any operation or
maintenance on the appliance.
1. Remove the halogen bulb cover with a athead screw driver.
2. Remove the bulb by pulling it out of its socket horizontally. DO NOT ROTATE THE BULB.
3. Replace the bulb with an identical type JCD, 12V 20W G-4 base halogen bulb.
DO NOT touch replacement bulbs with bare hands.
CAUTION: The surface, the cover of the bulbs, and the bulbs themselves may be hot, please use
extra care when removing them.
OPERATION
This range hood is operated using a push
button switch on the front panel.
KT360
(from left to right)
• Power
• Low
• Medium
• High
• Lights

7
Grease Filter
1. Remove the grease lters individually by pulling on the latch. This will disengage the lter from
the hood. Tilt the lter downward and remove.
2. Wash the lters, taking care not to bend them. Allow them to dry completely before reinserting.
3. When inserting the lters, make sure that the latch handle is visible from the outside.
4. Align the rear of the lter tabs with the slots in the crease. Pull out the latch, push lter into
position and release.
5. Make sure the lter is securely engaged after assembly.
NOTE: The grease lter should be cleaned frequently; minimum every two months, or more for
frequent to heavy use.
Oil Capture Tray
1. The oil capture tray is located inside the unit. It can be revealed by removing the center lter.
2. The oil capture tray collects excess grease and oil from within the unit. It should be cleaned
frequently and should not be more than half full.
3. Allow it to dry completely before installing.

8
MAINTENANCE & CLEANING
NOTE: Before servicing or cleaning unit, switch power off at the service panel. This will prevent power
from being switched on accidentally.
1. Hot water with liquid soap can remove most stains easily.
2. Always rinse the surface with clean water and wipe dry with a soft clean cloth to prevent water
marks.
3. Harder to remove stains, discolourations, and persistent deposits can be removed with a
non-abrasive household cleaner or stainless steel polishing powder with a little water.
4. For stubborn stains and deposits, use a scouring pad or soft bristle brush along with a
stainless steel cleaner and water. Always rub in the direction of the polished lines, or “grain” of
the stainless steel nish. Avoid using too much pressure as it may mar the surface.
5. Do not allow deposits to remain for long periods of time. Do not use ordinary steel wool or
steel brushes to clean the range hood.
Stainless steel is one of the easiest materials to keep clean. Occasional care will help preserve its ne
appearance for years to come.
6. Do not allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in contact
with the stainless steel surface for prolonged periods of time. Many of these compounds
contain chemicals that can be harmful to the stainless steel nish. Always rinse with water
after every cleaning and wipe dry with a clean cloth.

ALTO™ and KRÜGER ZENISS™ are all subsidiary development branches of KRÜGER™ electrical appliances LTd. © 2011 All rights reserved.
For more information on how to care for your kitchen ventilation unit, please contact us at www.krugerliving.com
