1 Supplementary Operating Manual
4 of 28 Profibus module
1 Supplementary Operating Manual
1.1 General
This supplementary operating manual accompanies the installation/operating
manual. All information contained in the installation/operating manual must be
observed.
Table1: Relevant operating manuals
Type series Reference number of the operating/installation
manual
PumpDrive 2 4074.81
1.2 Function
The Profibus field bus module serves to connect PumpDrive2 to a Profibus network.
A Profibus module is required for monitoring and open-loop or closed-loop control
purposes for each frequency inverter in single-pump configuration or multiple pump
configuration.
Interface The Profibus module is equipped with a Profibus interface with ProfibusDP protocol
in accordance with the "Profile for Intelligent Pumps" version1.0 specification.
Configuration is done via frequency inverter parameters.
Communication protocol Profibus DP
Bus terminator External
Interface EIA-485 (RS485)
Transmission rate Automatic, 9600-12Mbit/s
Device type Slave
For information on Profibus and downloads for PROFIBUSDP and the "Profile for
Intelligent Pumps" please go to www.Profibus.com.
For further accessories for the Profibus module, such as M12 connectors and
terminating resistors please refer to the type series booklet.
GSD file The characteristic communication configuration data of the frequency inverter, such
as the number of input signals and output signals, diagnosis messages, etc. are
described in an electronic general station description (GSD) file.
The GSD file can be read by a Profibus configuration tool, which is then used to
configure the Profibus Master. The GSD file is a PROFIBUSDPstandard text file,
available for download from the KSB website.
1.3 Field bus module connections
The field bus modules are plug-in modules.
BA
1
3 4 5
2
Fig.1: Field bus module

1 Supplementary Operating Manual
5 of 28
Profibus module
Table2: Field bus module
Position
Component Description
1 M12 connector A B-coded
2 M12 socket B B-coded
3 Amber LED signal lamp Device-internal bus communication OK (heartbeat detected)
4 Green LED signal lamp Communication on field bus side active/possible
5 Red LED signal lamp Profibus fault or communication error
▪Can be retrofitted
▪Internal T-connector (bus looped through); uninterruptible even in the event of a
frequency inverter power failure
▪Connector for self -assembly
1.4 Installing the field bus module
The field bus module can be fitted in an available slot of the frequency inverter.

1 Supplementary Operating Manual
6 of 28 Profibus module
Blind cover
11
Fig.2: Blind cover
1 Blind cover
1. Unscrew the cross recessed head screws in the blind cover.
2. Remove the blind cover.
Field bus module
Fig.3: Inserting the field
bus module
1. Carefully insert the field bus module into the open slot. The plug-in module is
guided on rails until it engages in the contact.
Fig.4: Securing the field bus
module
2. Secure the field bus module using the 4 cross recessed head screws. IP55
enclosure protection is not provided until the screws have been tightened.
CAUTION
Incorrect assembly
Impairment of protection provided by the enclosure (protection may be
compromised)!
▷Cover unused M12 connections with a cap (included in the scope of supply).

1 Supplementary Operating Manual
7 of 28
Profibus module
1.5 Connecting the field bus module
For connecting the field bus module observe the installation guide of the Profibus
user organisation (PNO) (download from "http://www.profibus.com/download/
installation-guide/"). Pay particular attention to the following:
▪Before the bus connection is established among the nodes, potential equalisation
must have been implemented and checked.
▪For high-frequency shielding, use shielded cables and assemble according to EMC
requirements.
▪A minimum distance of 0.3metres is recommended between such cables and
other electric conductors.
▪Do not use the bus cable to make any further connections in addition to the field
bus module (for example, 230V alert and 24V start).
▪A cable specified for the field bus module must be used as the connecting cable.
CAUTION
Incorrect installation
Damage to the field bus module!
▷Never supply power to the field bus module via the M12 connections.
BA BA
21
Fig.5: Connecting the field bus module
Table3: Connecting the field bus module
Item Device M12 connector
1 Frequency inverter 1 M12 connector A: Coming
M12 socket B: Going
2 Frequency inverter 2 M12 connector A: Coming
M12 socket B: Going

1 Supplementary Operating Manual
8 of 28 Profibus module
DC CD
1
2 2
3 3 3
A B A B
4
A B
3
Fig.6: Connecting a multiple pump system to the Profibus network (example)
1 Profibus Master
2 M12 cable for multiple pump configuration
3 M12 cable for Profibus
4 Further Profibus nodes
b)
a)
2
1
5
3
41
5
4
3
2
Fig.7: Pin assignment: a) Contact arrangement of M12 connector, b) Contact
arrangement of M12 socket
Table4: Pin assignment
Pin Core colour code of Profibus cable Assignment of M12 connector/ M12 socket (B-
coding)
1 - VP (+5V output)
2 Green A
3 - GND
4 Red B
5 - Shielding
Thread Shielding Shielding
2
1
5
3
41
5
4
3
2
B
A
Shielding
M N
Fig.8: User-configured cable
ⓂM12 socket ⓃM12 connector

1 Supplementary Operating Manual
9 of 28
Profibus module
1 2 3 4 51 2 3 4 5
B
A
NM
63
52
51
AB
1 2 3 4 5 1 2 3 4 5
A B
Shielding
Fig.9: Wiring diagram
Bus terminator The terminating resistors must conform to the following standard: Profibus standard
DPDIN19245, part3, section6.3.
1390
390
220
2
3
4
Fig.10: Bus terminating resistor M12
The field bus terminating resistor can be plugged directly into the M12 socket. Bus
polarisation does not take place if the field bus module is de-energised. If the bus
terminator is to be independent of the field bus module power supply, it must be
implemented externally using an active bus terminator.
NOTE
The frequency inverter is reset when a field bus module is replaced or retrofitted.
Menu 3-12 for setting the parameters of the field bus module is then enabled in the
control panel.
1.6 Setting the parameters of the field bus module
Field bus control must be activated in the frequency inverter when using the field bus
module.
Settings for the Profibus Slave address and the control point are made at the control
panel of the frequency inverter.
Table5: Profibus module parameters
Parameter Description Possible settings Factory setting
3-12-1-1 Profibus slave address
Profibus slave address of the system
1 - 126 126
3-12-1-2 Number of pump
Unique assignment of the pump in multiple
pump configuration
1 - 6 1

1 Supplementary Operating Manual
10 of 28 Profibus module
Parameter Description Possible settings Factory setting
3-12-1-3 Cycle time, setpoint/control value
Time delay before the message (warning or
alert) is triggered. In a redundant system, only
a warning is output as the auxiliary master can
assume the function. Only if the setpoint/
control value also fails at the auxiliary master is
the alert output, which then triggers the
specified response to setpoint/control value
failure.
0.0...10.0 5
3-12-1-4 Cycle time, actual value
Time delay before the message (warning or
alert) is triggered. In a redundant system, only
a warning is output as the auxiliary master can
assume the function. Only if the actual value
also fails at the auxiliary master is the alert
output, which then triggers the specified
response to actual value failure.
0.0...10.0 1
NOTE
If the field bus is only used for monitoring purposes, the Control Point parameter
(3-6-2) is set to Local.
NOTE
If the cycle times of parameters 3-12-1-3 and 3-12-1-4 are set to 0seconds, the
monitoring function for each of these parameters is disabled.
1.7 Frequency inverter operation with Profibus module
The function and the commissioning procedure described below for the frequency
inverter are based on the device profile and communication profile "Profile for
Intelligent Pumps Version1.0 November2007" (PIP), edition for centrifugal pumps
("Rotodynamic pump"), issued by the Profibus user organisation (PNO).
Profibus for PumpDrive2 is defined as a DPSlave of device type "Drive" and can be
addressed by a class1 or class2 DPMaster.
The Profibus implementation supports the cyclic exchange of I/O data as part of the
MS0 communication relationship and the acyclic services Read/Write (PI function
blocks RDREC and WRREC) as part of the MS1 communication relationship.

1 Supplementary Operating Manual Profibus module 11 of 28
1.7.1 Addressing the parameters defined in the PIP for access via MS1
Table6: Description of column titles
Column title Description
Functional element ID ID of the functional elements defined in the PIP for centrifugal pumps (rotodynamic pumps)
Functional element Name of the functional element defined in the PIP for centrifugal pumps (rotodynamic pumps)
Slot, Index Address information of the functional elements and their parameters for access via MS1
communication protocol
Parameter name Parameter name defined in the PIP
Rel. index Address index of the parameter within the functional element
Access Supported access to the parameter
Data type Data type of the parameter
Size Parameter size in bytes
Description Parameter description to PIP
KSB menu number, Value range, Value (example) Mapping to functions by indicating the corresponding menu number (if available) and the valid
value range for the parameters
The operating values are indicated in the unit shown under Values. It corresponds with the four-digit number code to DINIEC61158
under VALUE_UNIT.
The operating values are indicated in the unit shown under Values. It corresponds with the four-digit number code to DINIEC61158
under "VALUE_UNIT".
Table7: Addressing the parameters defined in the PIP for Profibus interface
ID functional element Functional element Slot Index Parameter name Rel Index Access (r: read, w: write) Data type Size [byte] Description KSB menu number Value range Value (example) Parameter index
2 PhysicalBlock 0 17 DEVICE_ TYPE 1 r VisibleString 20 Device name - PumpDrive
PumpDrive ECO
PumpDrive 0
19 DIAGNOSIS 3 r OctetString 4 Diagnosis event in
the corresponding
component
- 0: No diagnosis event
1: Diagnosis event available
00 00 00 00 1
20 DIAGNOSIS_MASK 4 r OctetString 4 - 00 00 00 FF 2
21 DIAGNOSIS_EXT_H
ARDWARE
5 r OctetString 2 - 00 00 3
22 DIAGNOSIS_EXT_S
OFTWARE
6 r OctetString 2 - 00 00 4

1 Supplementary Operating Manual
12 of 28 Profibus module
ID functional element Functional element Slot Index Parameter name Rel Index Access (r: read, w: write) Data type Size [byte] Description KSB menu number Value range Value (example) Parameter index
2 PhysicalBlock 0 23 DIAGNOSIS_EXT_M
ECHANICS
7 r OctetString 3 Diagnosis event in
the corresponding
component
- 0: No diagnosis event
1: Diagnosis event available
00 00 00 5
24 DIAGNOSIS_EXT_EL
ECTRICS
8 r OctetString 3 - 00 00 00 6
25 DIAGNOSIS_EXT_P
ROC_LIQUID
9 r OctetString 2 - 00 00 7
26 DIAGNOSIS_EXT_P
ROC_VACUUM
10 r OctetString 2 - 00 00 8
27 DIAGNOSIS_EXT_O
PERATION
11 r OctetString 5 - 00 00 00 00
00
9
28 DIAGNOSIS_EXT_A
UX_DEVICE
12 r OctetString 5 - 00 00 00 00
00
10
1 GenericPump 2 17 PUMP_TYPE_ID 1 r Unsigned8 1 Pump type (ID) - 3 to PIP specification 3 11
18 PUMP_TYPE_VERS 2 r Unsigned8 1 - 1 to PIP specification 1 12
19 ON_OFF 3 rw Boolean 1 System start / stop 1-3-1 FALSE: Off (stop)
TRUE: On (start)
FALSE 13
20 FAULT 4 r Boolean 1 Status indication:
Active alerts
- FALSE: No alert
TRUE: Active pump alert or
system alert
FALSE 14
21 RESET_FAULT 5 rw Boolean 1 Reset messages - FALSE: No reset activated
TRUE: Reset activated
FALSE 15
22 REMOTE_ACCESS_
REQUEST
6 rw Boolean 1 Remote control
point access
request
3-6-2 FALSE: No remote request (local)
TRUE: Remote request (field bus)
TRUE 16
23 ACCESS_MODE 7 rw Unsigned8 1 Access to control
point and actual
value (remote or
local)
3-6-2,
3-6-3
1: Control point, local / Actual
value source, local
2: Control point, field bus /
Actual value source, local
129: Control point, local / Actual
value source, field bus
130: Control point, field bus /
Actual value source, field bus
130 17

1 Supplementary Operating Manual Profibus module 13 of 28
ID functional element Functional element Slot Index Parameter name Rel Index Access (r: read, w: write) Data type Size [byte] Description KSB menu number Value range Value (example) Parameter index
3 PumpActuation 3 17 SETPOINT 1 rw Float32 4 Setpoint (closed-
loop control) /
Control value
(open-loop control)
1-3-2,
1-3-3
0-100% of the value range
defined for the process variable
0 18
19 SETPOINT_UNIT 3 r Unsigned16 2 - % 1342 19
23 FEEDBACK 7 rw Float32 4 Actual value
(closed-loop
control)
1-2-1,
1-2-3-1
0-100% of the value range
defined for the process variable
0 20
25 FEEDBACK_UNIT 9 rw Unsigned16 2 - % 1342 21
28 OPERATION_MODE 12 rw Unsigned8 1 Operating mode 1-3-8 128: Off
129: Manual mode
130: Automatic mode
130 22
29 CB_OPERATION_M
ODE
13 r Unsigned8 1 Status: operating
mode
1-3-8 See: Operating mode 130 23
31 CONTROL_MODE 15 rw Unsigned8 1 Type of control 3-6-1 128: Off (open-loop control)
129: Discharge pressure
130: Suction pressure
131: Differential pressure
132: Differential pressure
(sensorless)
133: Flow rate
134: Flow rate (sensorless)
135: Temperature (cooling)
136:Temperature (heating)
137: Suction-side level
138: Discharge-side level
128 24
32 CB_CONTROL_MO
DE
16 r Unsigned8 1 Status: type of
control
3-6-1 See: Type of control 128 25

1 Supplementary Operating Manual
14 of 28 Profibus module
ID functional element Functional element Slot Index Parameter name Rel Index Access (r: read, w: write) Data type Size [byte] Description KSB menu number Value range Value (example) Parameter index
4 MultiPump 4 18 PUMP_ROLE 2 r Unsigned8 1 Role in multiple
pump system
3-7-1 0: Slave (auxiliary control device)
1: Master (active master control
device)
2: Slave and auxiliary master
(redundant master control
device)
1 26
19 OPERATION_MODE 3 r Unsigned8 1 Single-pump/
multiple-pump
operating mode
- 0: Stand alone mode (SPO)
3: Mixed redundancy and
addition operation mode (MPO)
0 27
20 NUMBER_OF_PUM
PS
4 r Unsigned8 1 Number of pumps
installed
- 1...6 1 28
21 PUMP_COLLECTIVE
_IDS
5 r Unsigned8 1 - - 0 0 29
22 MAX_NUM_PUMP_
OPERATION
6 rw Unsigned8 1 Maximum number
of pumps running
3-7-2 1...6 1 30
24 EXCHANGE_EVENT 8 rw Boolean 1 Immediate pump
changeover
1-3-5 FALSE: No pump changeover
requested
TRUE: Pump changeover
requested
FALSE 31
25 EXCHANGE_MODE 9 rw Unsigned8 1 Automatic pump
changeover
3-7-4-1 1: Deactivated
2: Pump changeover after
defined runtime or at specific
time of day after defined
runtime
1 32
26 EXCHANGE_TIME 10 rw TimeOfDay 6 Pump changeover
time
3-7-4-3 Time of day in ms starting at
0:00:00
49500000ms 33
27 EXCHANGE_TIMED
IFFERENCE
11 rw TimeDiffere
nce4
4 Pump runtime 3-7-4-2 Specification of time interval in
ms
14400000ms 34
5 PIDControl 5 28 KP 12 rw Float32 4 Proportional
constant
3-6-4-2 0.01..100.00 1 35
29 TI 13 rw TimeDiffere
nce4
4 Integral time
(integral constant)
3-6-4-3 0.1..9999.9ms 200ms 36

1 Supplementary Operating Manual Profibus module 15 of 28
ID functional element Functional element Slot Index Parameter name Rel Index Access (r: read, w: write) Data type Size [byte] Description KSB menu number Value range Value (example) Parameter index
5 PIDControl 5 30 TD 14 rw TimeDiffere
nce4
4 Rate time
(differential
constant)
3-6-4-4 0.00 100.00ms 0ms 37
6 StandBy 6 17 VALUE 1 r Boolean 1 Status: operational
availability
- FALSE: Not on stand-by
TRUE: On stand-by
TRUE 38
7 PumpActivation 7 17 VALUE 1 r Boolean 1 Status: automatic
mode
1-3-8 FALSE: Not in automatic mode
TRUE: In automatic mode
TRUE 39
8 PumpOperation 8 17 VALUE 1 r Boolean 1 Status: operation - FALSE: Pump not running
TRUE: Pump running
FALSE 40
10 PumpSpeedMax 9 17 VALUE 1 r Boolean 1 Operation at
maximum speed
- FALSE: Pump does not run at
maximum motor speed
TRUE: Pump runs at maximum
motor speed 3-2-2-2
FALSE 41
11 PumpSpeedMin 10 17 VALUE 1 r Boolean 1 Operation at
minimum speed
- FALSE: Pump does not run at
minimum motor speed
TRUE: Pump runs at minimum
motor speed 3-2-21
FALSE 42
15 PumpKick 11 17 VALUE 1 rw Boolean 1 Immediate
functional check
run
1-3-6 FALSE: No functional check run
requested
TRUE: Immediate functional
check run requested
FALSE 43
19 InletPressure 12 17 VALUE 1 r Float32 4 Suction pressure 1-2-3-2 - 0 44
18 VALUE_UNIT 2 r Unsigned16 2 - bar 1137 45
20 OutletPressure 13 17 VALUE 1 r Float32 4 Discharge pressure 1-2-3-3 - 0 46
18 VALUE_UNIT 2 r Unsigned16 2 - bar 1137 47
22 DiffPressure 14 17 VALUE 1 r Float32 4 Differential
pressure
1-2-3-4 - -1 48
18 VALUE_UNIT 2 r Unsigned16 2 - bar 1137 49
24 Head 15 17 VALUE 1 r Float32 4 Head 1-2-3-9 0 50
18 VALUE_UNIT 2 r Unsigned16 2 - m 1010 51
25 VolumeFlow 16 17 VALUE 1 r Float32 4 Flow rate 1-2-3-5 - 0 52

1 Supplementary Operating Manual
16 of 28 Profibus module
ID functional element Functional element Slot Index Parameter name Rel Index Access (r: read, w: write) Data type Size [byte] Description KSB menu number Value range Value (example) Parameter index
25 VolumeFlow 16 18 VALUE_UNIT 2 r Unsigned16 2 - - m3/h 1349 53
29 FlowVelocity 17 17 VALUE 1 r Float32 4 Flow velocity of
fluid handled
1-2-3-8 - 0 54
18 VALUE_UNIT 2 r Unsigned16 2 - - m/s 1061 55
30 Level 18 17 VALUE 1 r Float32 4 Level 1-2-3-6 - 0 56
18 VALUE_UNIT 2 r Unsigned16 2 - - m 1010 57
31 Speed 19 17 VALUE 1 r Float32 4 Speed 1-2-1-1 - 0 58
18 VALUE_UNIT 2 r Unsigned16 2 - - rpm 1085 59
32 Frequency 20 17 VALUE 1 r Float32 4 Output frequency 1-2-1-7 - 0 60
18 VALUE_UNIT 2 r Unsigned16 2 - - Hz 1077 61
33 Torque 21 17 VALUE 1 r Float32 4 Motor torque 1-2-1-11 - 0 62
18 VALUE_UNIT 2 r Unsigned16 2 - - Nm 1136 63
34 PumpLiquidTemp 22 17 VALUE 1 r Float32 4 Temperature 1-2-3-7 - -200 64
18 VALUE_UNIT 2 r Unsigned16 2 - - °C 1001 65
40 ElectronicTemp 23 17 VALUE 1 r Float32 4 PCB temperature 1-2-1-10 - 39,1 66
18 VALUE_UNIT 2 r Unsigned16 2 - - °C 1001 67
41 PowerElectronicTe
mp
24 17 VALUE 1 r Float32 4 Heat sink
temperature
1-2-1-9 - 33,9 68
18 VALUE_UNIT 2 r Unsigned16 2 - - °C 1001 69
48 Power 25 17 VALUE 1 r Float32 4 Motor input power 1-2-1-2 - 0 70
18 VALUE_UNIT 2 r Unsigned16 2 - - kW 1190 71
50 MotorCurrent 26 17 VALUE 1 r Float32 4 Motor current 1-2-1-5 - 0 72
18 VALUE_UNIT 2 r Unsigned16 2 - - A 1209 73
53 MotorVoltage 27 17 VALUE 1 r Float32 4 Motor voltage 1-2-1-6 - 0 74
18 VALUE_UNIT 2 r Unsigned16 2 - - V 1240 75
54 DCLinkVoltage 28 17 VALUE 1 r Float32 4 DC link voltage 1-2-1-8 - 542 76
18 VALUE_UNIT 2 r Unsigned16 2 - - V 1240 77

1 Supplementary Operating Manual Profibus module 17 of 28
ID functional element Functional element Slot Index Parameter name Rel Index Access (r: read, w: write) Data type Size [byte] Description KSB menu number Value range Value (example) Parameter index
56 Energy 29 17 VALUE 1 r Float32 4 Energy meter
(kWh)
1-4-1-1 - 0 78
18 VALUE_UNIT 2 r Unsigned16 2 - - kWh 1179 79
60 OperationTime 30 17 VALUE 1 r Float32 4 Pump operating
hours
1-4-2-3 - 555 80
18 VALUE_UNIT 2 r Unsigned16 2 - - h 1059 81
61 TotalPoweredTime 31 17 VALUE 1 r Float32 4 Frequency inverter
operating hours
1-4-2-1 - 1965 82
18 VALUE_UNIT 2 r Unsigned16 2 - - h 1059 83
65 Motor 32 19 VOLTAGE 3 r Float32 4 Nominal motor
voltage
3-2-1-2 Motor name plate 0..480V 400 84
21 CURRENT 5 r Float32 4 Nominal motor
current
3-2-1-4 Motor name plate 0..150A 2,6 85
23 POWER 7 r Float32 4 Nominal motor
power
3-2-1-1 Motor name plate 0..55kW 7 86
25 FREQUENCY 9 r Float32 4 Nominal motor
frequency
3-2-1-3 Motor name plate 0..100Hz 50 87
28 ROTOR_SPEED 12 r Float32 4 Nominal motor
speed
3-2-1-5 Motor name plate 0..4200rpm 1500 88
29 MAX_ROTOR_SPEE
D
13 r Float32 4 Maximum motor
speed
3-2-2-2 Motor name plate 0..4200rpm 1500 89
66 Converter 33 19 SUPPLY_VOLTAGE_
HIGH
3 r Float32 4 Maximum nominal
voltage
- Technical data PumpDrive2
480V
480 90
20 SUPPLY_VOLTAGE_
LOW
4 r Float32 4 Minimum mains
voltage
- Technical data PumpDrive2
380V
380 91
22 SUPPLY_FREQUENC
Y_HIGH
6 r Float32 4 Maximum mains
frequency
- Technical data PumpDrive2
60Hz
60 92
23 SUPPLY_FREQUENC
Y_LOW
7 r Float32 4 Minimum mains
frequency
- Technical data PumpDrive2
50Hz
50 93

1 Supplementary Operating Manual
18 of 28 Profibus module
ID functional element Functional element Slot Index Parameter name Rel Index Access (r: read, w: write) Data type Size [byte] Description KSB menu number Value range Value (example) Parameter index
66 Converter 33 25 TEMP_HIGH 9 r Float32 4 Maximum in-
service ambient
temperature
- Technical data PumpDrive2
50°C
50 94
26 TEMP_LOW 10 r Float32 4 Minimum in-
service ambient
temperature
- Technical data PumpDrive2 -
10°C
-10 95
28 VOLTAGE_MAX 12 r Float32 4 Maximum rated
voltage
- Name plate PumpDrive 2 400V 400 96
29 CURRENT_MAX 13 r Float32 4 Maximum rated
current
- Name plate PumpDrive2
20..120A
2,6 97
31 POWER_MAX 15 r Float32 4 Maximum rated
power
- Name plate PumpDrive2
0..55kW
7 98
33 FREQUENCY_HIGH 17 r Float32 4 Maximum output
frequency
- 140Hz: KSB SuPremEmotor
70Hz: Other
70 99
34 FREQUENCY_LOW 18 r Float32 4 Minimum output
frequency
- 0Hz 0 100

1 Supplementary Operating Manual
19 of 28
Profibus module
1.7.2 Definition of the "rotodynamic pump” module available in the cyclic data
exchange
The Rotodynamic Pump module serves to enter setpoints and control values for the
pump set in a compact form. It also provides key information on the current
operating status.
A variety of data types is used within the address range of the module. Binary
information and requests in the module are bit-coded; the other data points are
transmitted as integer values.
The Rotodynamic Pump module is the most important data point for control of the
frequency inverter and is structured as follows:
▪Rotodynamic Pump Input = 6Byte (Byte, Byte, Word, Byte Byte)
▪Rotodynamic Pump Output = 5Byte (Byte, Byte, Byte, Word)
NOTE
Depending on the make of PLC, pay special attention to the area of the memory
into which the Rotodynamic Pump module must be integrated.
Consistency on the part of the Rotodynamic Pump module can only be ensured if the
module is located in the process image area or if the module is copied into or out of
a buffered area by special system modules. The Rotodynamic Pump module contains
bit variables, byte variables and word variables. This does not apply to the process
variable view. A process image is not required as byte operations, word operations or
double-word operations are provided there which ensure the module's consistency.
Table8: Rotodynamic Pump module, input
Offset byte. Bit Data type Parameter name Functional element Description Unit
0.7 BOOL AT_MIN_SPEED PumpSpeedMin.VAL
UE
1: Pump running at minimum speed -
0.6 BOOL STANDBY StandBy.VALUE 1: Pump ready for start-up -
0.5 BOOL AT_MAX_SPEED PumpSpeedMax.VAL
UE
1: Pump running at maximum speed -
0.4 BOOL PUMP_ACTIVE PumpActivation.VAL
UE
1: Automatic mode activated
(AUTO is displayed)
-
0.3 BOOL WARNING - 1: Active warning -
0.2 BOOL FAULT - 1: Active pump alert or system alert -
0.1 BOOL ON_OFF GenericPump.ON_OF
F
1: Pump is ON -
0.0 BOOL ACCESS_MODE GenericPump.ACCESS
_MODE
1: Bus control is enabled -
1.7 BOOL DIRECTION - Not supported -
1.6 BOOL ROTATION - Not supported -
1.5 BOOL AT_MAX_POWER - Not supported -
1.4 BOOL SETPOINT_INFLUENCE - Not supported -
2 INT PROCESS_FEEDBACK PumpActuation.FEED
BACK
Actual value of the active process variable (see
CB_CONTROL_MODE)
0,01%
4 BYTE CB_CONTROL_MODE PumpActuation.CB_C
ONTROL_MODE
128: Off
Control system OFF, fixed speed operation
-
129: Discharge pressure -
130: Suction pressure -
131: Differential pressure -

1 Supplementary Operating Manual
20 of 28 Profibus module
Offset byte. Bit Data type Parameter name Functional element Description Unit
4 BYTE CB_CONTROL_MODE PumpActuation.CB_C
ONTROL_MODE
132: Differential pressure (sensorless) -
133: Flow rate -
134: Flow rate (sensorless) -
135: Temperature (cooling) -
136: Temperature (heating) -
137: Suction-side level -
138: Discharge-side level -
5 BYTE CB_OPERATION_MOD
E
PumpActuation.CB_O
PERATION_MODE
128: Off
(display: OFF)
-
129: Manual mode
(display: MAN)
130: Automatic mode
(display: AUTO)
