KTI Networks KFC-241 User manual

KFC-241
Industrial
10/100BASE-T to 100BASE-FX
Media Converters
Installation Guide
DOC.110516
-1-

(C) 2011 KTI Networks Inc. All rights reserved. No part of this documentation may be reproduced in any form
or by any means or used to make any directive work (such as translation or transformation) without permission
from KTI Networks Inc.
KTI Networks Inc. reserves the right to revise this documentation and to make changes in content from time to
time without obligation on the part of KTI Networks Inc. to provide notification of such revision or change.
For more information, contact:
United States KTI Networks Inc.
P.O. BOX 631008
Houston, Texas 77263-1008
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com/
International Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com.tw/
-2-

The information contained in this document is subject to change without prior notice.
Copyright (C) All Rights Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) This device must accept any interference received,
including the interference that may cause undesired operation.
CE NOTICE
Marking by the symbol “CE” indicates compliance of this equipment to the EMC directive of the European
Community. Such marking is indicative that this equipment meets or exceeds the following technical
standards:
EMC Class A
EN 61000-6-3:2007 IEC 61000-6-3:2007
EN 55022:2006/A1:2007 CISPR 22:2005 Class A
EN 61000-3-2:2006 IEC 61000-3-2:2005
EN 61000-3-3:2008 IEC 61000-3-3:2008
EN 55024:1998/A1:2001/A2:2003 CISPR 24:1997
EN 61000-4-2:2009 IEC 61000-4-2:2008
EN 61000-4-3:2006/A1:2008 IEC 61000-4-3:2006
EN 61000-4-4:2004 IEC 61000-4-4:2004
EN 61000-4-5:2006 IEC 61000-4-5:2005
EN 61000-4-6:2009 IEC 61000-4-6:2008
EN 61000-4-8:1993/A1:2001 IEC 61000-4-8:1998/A1:2000
EN 61000-4-11:2004 IEC 61000-4-11:2004
-3-

-4-
Table of Contents
1. Introduction......................................................................................................................................................5
1.1 Features.................................................................................................................................6
1.2 Specifications.........................................................................................................................7
1.3 Model Specifications............................................................................................................11
1.4 Special Functions.................................................................................................................11
2. Installation......................................................................................................................................................13
2.1 Unpacking............................................................................................................................ 13
2.2 Safety Cautions.................................................................................................................... 13
2.3 DIN-Rail Mounting................................................................................................................14
2.4 Mounting on a Plane Surface...............................................................................................18
2.5 Applying Power.................................................................................................................... 21
2.6 Making Copper Port Connection.......................................................................................... 22
2.7 Making Fiber Port Connection..............................................................................................23
3. LED Indicators...............................................................................................................................................24
3.1 States and Indications.......................................................................................................... 24
Appendix. On-board Configuration.................................................................................................................25

1. Introduction
The industrial 10/100BASE-TX to 100BASE-FX media converter series provides industrial strength Ethernet
copper-to-fiber media conversion, allowing for 10Base-T-100Base-FX or 100Base-TX-100Base-FX over
multi-mode or optional single-mode fiber optical media.
In addition to the basic media conversion functions, the converters also provide some special functions to
enhance the flexibility for wide application needs as follows:
AUTO-NEGO FUNCTION
The copper port is featured this function which performs a negotiation process for the speed and duplex
configuration with the connected device automatically when each time a link is being established.
AUTO-CROSS FUNCTION
The copper port is featured this function that allows to auto-detect the twisted-pair signals and adapts itself to
form a valid MDI to MDI-X connection with the remote connected device automatically.
FAR END FAULT FUNCTION
The fiber port is facilitated with this function, which conforms to IEEE 802.3u 100BASE-FX specifications.
When the port detects a link failure on its receiving circuitry, it will send out an FEFI (Far End Fault Indication)
signal to the remote connected device to indicate a remote fault is detected. It also is capable to receive FEFI
signal sent from the remote link partner. Upon receiving an FEFI signal, it indicates a link failure occurred on
the transmitting path. This function allows the converter to report a fiber link fault even when a link failure
occurred on transmitting fiber cable.
SMART-FORWARDING FUNCTION
-5-
The converter uses store-and-forward mechanism for packet forwarding normally when both media ends

-6-
operate at different speed, but switches to direct conversion automatically and with the least latency when both
media ends operate at the same speed.
LINK FAULT PASS THROUGH FUNCTION
The function allows the link fault status passes through from one media end to another media end transparently.
INDUSTRIAL ENHANCEMENT
For industrial environment, the converters are designed with the following enhanced features exceeding that of
commercial media converters:
zHigh and wide operating Temperature
zWide operating voltage range for DC power input
zPower input interfaces: Terminal block for industrial power supply and DC jack for typical power adapter
zDIN-Rail mounting support for industrial enclosure
zScrew plane mounting support for industrial enclosure
zIndustrial-rated Emission and Immunity performance
1.1 Features
zConvert speed and media type
zSupport full wire speed conversion
zSupport 10Mbps and 100Mbps speed on the copper connections
zAuto MDI/MDI-X detection function on the copper port
zAuto-negotiation function on the copper port
zLink fault pass through function
zPlug and play with no complicated configuration
zTransparent conversion to 802.1Q VLAN tagged packets
zFar End Fault function on the fiber port
zSupport wide range of fiber options on the fiber port
zLow power consumption
zTwo power interface types: screw terminal block and DC jack
zWide operating voltage input range
zSupport DIN rail mounting
zSupport plane mounting
zHigh and wide operating temperature range
zIndustrial-rated Emission and Immunity performance

1.2 Specifications
This figure shows the important components of the converters:
Model KFC-241-L
Model KFC-241-H
-7-

-8-
Copper Port (Twisted-Pair Interface)
Connector Shielded RJ-45
Pin Assignments Auto MDI/MDI-X detection
Signal Compliance IEEE 802.3 10BASE-T, 802.3u 100BASE-TX
Data Speed 10Mbps or 100Mbps
Duplex Mode Half-duplex or Full-duplex
Configuration Auto-negotiation capable for speed and duplex
Cable Types 10Mbps - Category 3, 4, or 5 UTP
100Mbps - Category 5 UTP
Supported Link Distance Up to 100 meters
FX Port (Fiber Optic Interface)
Signal Compliance IEEE 802.3u 100BASE-FX
Connector SC, ST, or Single SC (model dependent)
Data Speed 100Mbps
Duplex Mode Full-duplex and optional half duplex
Cable Types Multimode (MMF) - 50/125, 62.5/125μm
Single mode (SMF) - 9/125μm
Supported Link Distance MMF up to 2km
SMF, single SMF (model dependent)
Eye Safety compliance IEC825 Class 1
DC Power Input
KFC-241-L
Interfaces Screw-type Terminal Block 3P (TB-3P)
DC Jack (-D 6.3mm /+D 2.0mm)
Operating Input Voltages +4.5VDC ~ +50VDC
Power Consumption 1.6W @+7.5VDC input
1.6W @+12VDC input
2W @+48VDC input
KFC-241-H
Interface Screw-type Terminal Block 3P (TB-3P)
Operating Input Voltage +110VDC
Power Consumption 2.9W @+110VDC input

-9-
LED Indicators
LED Name Display function
PWR Power status
LINK Link status
100M Copper port operating speed
OL Fiber port optical link
Mechanical
Dimension (base) KFC-241-L - W 34mm x D 49mm x H 56mm
KFC-241-H - W 45.5mm x D 49mm x H 56mm
Weight KFC-241-L - 132g
KFC-241-H - 164g
Housing Enclosed metal with no fan
Mounting Support DIN-rail mounting, Plane mounting
Environmental
Operating Temperature Ambient -20oC ~ 70oC
Storage Temperature -30oC ~ 85oC
Relative Humidity 5% ~ 90%
Basic Information
Forwarding Throughput Full wire speed at 100M full duplex
10Mbps - 14,880pps at 64-byte packets
100Mbps - 148,800pps at 64-byte packets
Packet Types Transparent and no modification for
- IEEE 802.3 standard packets
- IEEE 802.1Q VLAN tagged packets
Packet Length Up to 1600 bytes under 100Mbps-10Mbps conversion
No limit under 100Mbps to 100Mbps conversion
Flow Control Back-pressure for half-duplex mode
802.3x pause-frame base for full duplex mode
Certificate
FCC Part 15 Class A
CE/EMC EMI EN50081-1 Class A
EMS EN55024
CE/LVD Safety EN 60950

-10-
EN 50081-1:
EN55022 CISPR Class B
EN61000-3-2 Device <75W
EN61000-3-3 Clause 5
EN 55024 Severity Level
IEC 61000-4-2 ESD Test Contact +/-6KV/Air +/-8KV
IEC 61000-4-3 RS Test Power/Data Ports Level 1, 2, 3
IEC 61000-4-4 EFT/Burst Test DC IN +/-1KV/Data Ports +/-0.5KV
IEC 61000-4-5 Surge Test DC IN +/-0.5KV/Data Ports +/-1KV
IEC 61000-4-6 CS Test DC IN Level 3
IEC 61000-4-8 PFMF Test Continuous, 100A/m, XY, 30 sec.
IEC 61000-4-11 Voltage Int. Dips Interruption 100% 250 periods
Dips 30% 25 periods
Dips 60% 0.5 period

1.3 Model Specifications
The media converter series provides the following fiber options:
Model Ext. Connector Wavelength Fiber Distance Tx power Sensitivity Rx Power max.
-T Duplex ST 1310nm MMF 2km -20 ~ -14 -32 max. -8 min.
-C Duplex SC 1310nm MMF 2km -20 ~ -14 -31 max. 0 min.
-SL2 Duplex SC 1310nm SMF 20km -15 ~ -8 -30 max. -7 min.
-SL3 Duplex SC 1310nm SMF 30km -15 ~ -8 -34 max. 0 min.
-SL6 Duplex SC 1310nm SMF 60km -5 ~ -0 -35 max. 0 min.
-W3515 BiDi SC Tx 1310nm SMF 15-20km -14 ~ -8 -31 max. 0 min.
Rx 1550nm
-W5315 BiDi SC Tx 1550nm SMF 15-20km -14 ~ -8 -31 max. 0 min.
Rx 1310nm
1.4 Special Functions
Auto MDI/MDI-X Function
This function allows the TP port to auto-detect the twisted-pair signals and adapts itself to form a valid MDI to
MDI-X connection with the remote connected device automatically.
Auto-negotiation Function
The copper port is featured with auto-negotiation function and full capability in speed and duplex. It performs a
negotiation process for the speed and duplex configuration with the connected device automatically when each
time a link is being established.
Far End Fault Function
The FX port is facilitated with this function that conforms to IEEE 802.3u 100BASE-FX specifications. When
the FX port detects a link failure on its receiving circuitry, it will send out an FEFI (Far End Fault Indication)
signal to the remote connected device to indicate a remote fault is detected. It also is capable to receive FEFI
signal sent from the remote link partner. Upon receiving an FEFI signal, it notes a link failure occurred on the
transmitting path. This function allows the converter to report a fiber link fault even when a link failure
occurred on transmitting fiber cable.
-11-

Link Fault Pass Through Function
When this function is enabled, a link fault detected on the TP copper port will force a link down on the FX
fiber port and vice versa. Similarly, a link fault detected on the FX fiber port will also force a link down on the
TP copper port.
The following figure illustrates a link fault on the fiber segment between the local and remote media converter
devices is detected and both devices will force a link down on both copper segments.
The following figure illustrates another example. A link fault happened on the copper cable is detected by the
remote end. The fault is forwarded to the fiber segment and also forwarded to the copper cable at the local end
by remote device and local device respectively.
Smart-Forward Function
With this function, the media converter can change to direct conversion automatically when it detects same
speed on both copper port and fiber port. Direct conversion method converts the signal between the copper port
and the fiber port without storing the received packet on one port then forwarding to another port. The media
converter operates with the minimum latency and has no size limit to the forwarded packets. In the case of
100Mbps to 10Mbps conversion, the media converter adapts itself to store-and-forward method for such
unbalancing conversion automatically.
Note:
1. In direct conversion, be sure both devices connected to the TP port and FX port have same duplex mode for
proper transmission.
2. In direct conversion, 802.3x function is disabled and the media converter will not generate pause frame, but
just forwards the received pause frame directly from one port to another port.
-12-

-13-
2. Installation
2.1 Unpacking
Check that the following components have been included:
zInformation CD
zThe Media Converter unit
zDIN-rail mounting bracket (It may have been pre-installed on the device unit.)
The following are available optional accessories:
zPlane Mounting Bracket: The bracket is used for mounting the converter on a plane surface.
zCommercial-rated AC power adapters:
The adapters are used for supplying DC power to the converter via DC power jack interface.
zIndustrial-rated power supply: The power can be used for supplying DC power to the converter via
terminal block interface.
Contact sales representative for the availability.
Note: The operation temperature rating of the optional power adapters and power supply may differ from the
rating of the media converters.
2.2 Safety Cautions
To reduce the risk of bodily injury, electrical shock, fire and damage to the product, observe the following
precautions.
zDo not service any product except as explained in your system documentation.
zOpening or removing covers may expose you to electrical shock.
zOnly a trained service technician should service components inside these compartments.
zIf any of the following conditions occur, unplug the product from the electrical outlet and replace the part
or contact your trained service provider:
- The power cable, extension cable, or plug is damaged.
- An object has fallen into the product.
- The product has been exposed to water.
- The product has been dropped or damaged.
- The product does not operate correctly when you follow the operating instructions.
zDo not push any objects into the openings of your system. Doing so can cause fire or electric shock by
shorting out interior components.

zOperate the product only from the type of external power source indicated on the electrical ratings
label. If you are not sure of the type of power source required, consult your service provider or local
power company.
2.3 DIN-Rail Mounting
In the product package, a DIN-rail bracket is provided and may have been pre-installed on the device unit for
mounting the converter in an industrial DIN-rail enclosure.
The steps to mount the converter onto a DIN-rail are:
1. Install the mounting bracket onto the device unit as shown below:
Model: KFC-241-L
Model: KFC-241-H
2. Attach bracket to the lower edge of the DIN rail and push the unit upward a little bit until the bracket can
clamp on the upper edge of the DIN rail.
-14-

3. Clamp the unit to the DIN rail and make sure it is mounted securely.
Model: KFC-241-L Model: KFC-241-H
4. Make sure that there is proper heat dissipation from and adequate ventilation around the device.
-15-

The final mechanical dimensions after installing DIN-Rail mounting bracket are:
Model: KFC-241-L with DIN-Rail mounting bracket
-16-

Model: KFC-241-H with DIN-Rail mounting bracket
-17-

2.4 Mounting on a Plane Surface
An optional panel mounting bracket, as shown below is also available for mounting the converter on a plane
surface such as a wall, a wood board, or a metal plate in an industrial enclosure.
Screw the bracket and install it on the converters.
Model: KFC-241-H Model: KFC-241-L
Make sure that there are proper heat dissipation from and adequate ventilation around the device. Do not place
heavy objects on the device.
-18-

The final mechanical dimensions after installing panel mounting bracket are:
Model: KFC-241-L with panel mounting bracket
-19-

Model: KFC-241-H with panel mounting bracket
-20-
