KTI Networks KCD-400 Series User manual

Specifications :
Industrial 1000Base-T to 1000Base-X
Gigabit Media Converters
The industrial KCD-400 media converter series provides industrial strength Gigabit Ethernet copper
-to-fiber media conversion,allowing for 1000Base-T-to-1000Base-Xover multi-mode or optional
single-mode fiber optical media. With the SFP (Mini-GBIC) connector design,the media converter
not only supports existing variety of multimode and single mode fibers,but also preserves the
flexibility to adapt to any change of your fiber network in the future.
Benefits :
 Plug and play design with no configuration setting
 Wide operating temperature range for temperature critical environment
 Support DIN-rail mounting and panel mounting
 Provide two power input types to meet more application needs
 Accept wide power input voltage range for application flexibility
 Industrial-rated Emission and Immunity performance
Key Features :
 Comply with IEEE 802.3ab 1000Base-T,802.3z 1000Base-SX/LX standard
 Provide direct media conversion for Gigabit copper and Gigabit fiber
 Support full wire speed conversion
 Support transparent conversion of any packet types with no packet length limitation
 Support auto-negotiation with link partners
 Provide link pass through between copper and fiber link
 Provide SFP on fiber port for mounting variety of fiber options
 Low power consumption
 Two power interface types:screw terminal block and DC Jack
 Supports DIN-rail mounting and optional screwed plane mounting
Standard IEEE 802.3au, 802.3z
Conversion Direct 1000BASE-T to 1000BASE-X with minimum latency
Packet Types Transparent conversion with no modification to :
- Standard IEEE 802.3 Ethernet packet frames
- IEEE 802.1Q tagged packet frames
Copper Port Shielded RJ-45,1000Mbps
Auto-negotiation capable
Auto-MDI/MDI-X crossover function
Fiber Port SFP connector with pre-configured SFP fiber transceiver
Far End Fault support
Network Cables Copper port : Cat.5e recommended or higher up to 100m
Fiber port : MMF 50/125µm, 62.5/125µm, SMF 9/125µm
LEDs Power status, SFP ON status
Link status, Optical link status
KCD-400
DIN Rail Mounting Bracket
Panel Mounting Bracket
080110

FCC Part 15'Class B
CISPR 22 Class B
Katron Technologies Inc.
15F-7, No. 79, Sec. 1, Hsin Tai Wu Rd.,
Hsi-chih, Taipei Hsien, Taiwan.
Te l :886-2-2698-3878
Fax:[phone]
E-mail:[email protected]
URL:http://www.ktinet.com.tw
KTI Networks Inc.
7400 Harwin Dr., Suite 120 Houston,
Texas 77036 U.S.A.
Te l :713-266-3891
Fax:[phone]
E-mail:[email protected]
URL:http://www.ktinet.com
Trademarks: All brand names are trademarks or registered
trademarks of their respective holders.
This information is subject to change without prior notice.
EMI EMS Safety Environmental Tests :
Specifications
Class B
Class B
< 75 W
Clause 5
Level 3
50Hz 40A/m
Interruption : C
Dips : A
Contact : +/-8KV
Air : +/-16KV
Strength : 10V/m
+/-4KV
+/-4KV
TP, 1500VAC/60sec.
TP, 500VDC/10Mohm
-20OC, 96hrs
+70OC 40%RH 96hrs
+60OC 90%RH 96hrs
Test
FCC/EMI
CE/EMC/EMI
CE/EMC/Harmonic
CE/EMC/VFF
CE/EMC/EMS
ESD Test
RS Test
EFT/BURST
Surge Immunity
CS Test
Magnetic Field Imm.
Voltage Dips Imm.
Safety
Dielectric Voltage
Insulation Resistance
Cold Test
Dry Heat Test
Damp Heat Test
Storage Test
Vibration Test
Standard
FCC Rule Part 15
EN55022, CISPR 22
EN 61000-3-2
EN 61000-3-3
EN 55024
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
EN 60950, IEC 60950
IEEE 802.3
IEEE 802.3
IEC 68-2-1 Test Ad
IEC 68-2-2 Test Bd
IEC 68-2-3
IEC 68-2-48
IEC 68-2-34
+85OC 40%RH 96hrs
-20OC 96hrs
Network Cables Copper port : Cat.5e recommended or higher up to 100m
Fiber port : MMF 50/125µm, 62.5/125µm, SMF 9/125µm
LEDs Power status, SFP On status
Link status, Optical link status
DC Power Input Screwed terminator block : 2 pairs of +/-contacts
1 pair of power alarm relay output contacts
DC jack : -D 6.3mm /+D 2.0mm
Operating voltage range : +7 -+30VDC
Power Consumption 2W max.@30VDC power input
Dimension 28 x 82 x 95 mm (WxDxH)
Weight 240g
Housing Enclosed metal with no fan
Mounting Support DIN-Rail mounting,Panel mounting
Environment Operating Temperature : -20OC ~ 70OC
Storage Temperature : -20OC ~ 85OC
Relative Humidity : 5%~95%non-condensing
Approval FCC Class B
CE/EMC Class B, EN60950 safety
Fiber Optical Specifications:
Model Fiber Wavelength Tx Power Rx Sensitivity Rx Max. Distance
KCD-400-SX LC 62.5/125 MMF 850nm -9.5~ -4dBm -18dBm -1dBm 220m
50/125 MMF 500m
KCD-400-LX LC MMF 1310nm -9.5~ -3dBm -20dBm -3dBm 550m
SMF 10km
KCD-400-LX20 LC SMF 1310nm -7~ 0dBm -24dBm -3dBm 20km
KCD-400-LX100 LC SMF 1550nm 0~+5dBm -30dBm -8dBm 100km
Ordering Information :
-SX
-LX
62.5/125
50/125
Fiber
Mode
Model
KCD-400-xxx
MM
SM
SM-LX20
LC 200m
500m
LC
LC
550m
10km
20km
Ref.
Distance
Connertor
SM-LX100 LC 100km
080110
