KTI Networks KC-351 Series User manual

1
PoE Powered
10/100BASE-TX to 100BASE-FX
Media Converters
KC-351 Series
Installation Guide
DOC.171215A

2
(C) 2017 KTI Networks Inc. All rights reserved. No part of this documentation may be reproduced in
any form or by any means or used to make any directive work (such as translation or transformation)
without permission from KTI Networks Inc.
KTI Networks Inc. reserves the right to revise this documentation and to make changes in content from
time to time without obligation on the part of KTI Networks Inc. to provide notification of such
revision or change.
For more information, contact:
United States KTI Networks Inc.
P.O. BOX 631008
Houston, Texas 77263-1008
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com/
International Fax: [phone]
E-mail: [email protected].tw
URL: http://www.ktinet.com.tw/

3
The information contained in this document is subject to change without prior notice. Copyright (C)
All Rights Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
FCC NOTICE
This device complies with Class B Part 15 the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received including the interference that may cause.
CE NOTICE
Marking by the symbol indicates compliance of this equipment to the EMC directive of the European
Community. Such marking is indicative that this equipment meets or exceeds the following technical
standards:
EMC Class B
EN 61000-6-3
EN55022
EN61000-3-2
EN61000-3-3
EN 55024
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-11

4
Table of Contents
1. Introduction ................................................................................................................................5
1.1 Key Features....................................................................................................... 5
1.2 Specifications...................................................................................................... 6
1.3 Optical Specifications........................................................................................ 10
1.4 Special Functions.............................................................................................. 11
1.4.1 Auto MDI/MDI-X Function .............................................................................. 11
1.4.2 Auto-negotiation Function .............................................................................. 11
1.4.3 Far End Fault Function................................................................................... 11
1.4.4 Link Fault Pass Through Function.................................................................. 12
1.4.5 Remote TP Port Monitoring Function ............................................................. 13
1.4.6 Loop Back Test Function................................................................................ 13
2. Installation ................................................................................................................................14
2.1 Unpacking......................................................................................................... 14
2.2 Safety Cautions................................................................................................. 14
2.3 Mounting the Device ......................................................................................... 15
2.4 Powered by PoE over Cat.5.............................................................................. 16
2.5 Powered by External Power Adapter................................................................. 17
2.6 Making TP Port Connection .............................................................................. 18
2.7 Making FX Port Connection .............................................................................. 19
2.8 LED Indicators .................................................................................................. 21
2.9 Performing Loop Back Test............................................................................... 22
3. Optional Configuration Settings ...............................................................................................23
3.1 User Inaccessible Jumpers............................................................................... 23
3.1.1 Forwarding Mode Setting JP1........................................................................ 24
3.1.2 802.3x Function Setting JP2 .......................................................................... 25
3.1.3 FX Duplex Setting JP3................................................................................... 25
3.2 JP1-JP3 Factory Default Settings...................................................................... 25

5
1. Introduction
The 10/100BASE-TX to 100BASE-FX media converter series provides a media conversion allowing
high-speed integration of fiber optic and twisted-pair segments. With 10BASE-T and 100BASE-TX
support, the converters provide seamless translation between Ethernet and Fast Ethernet networks. A
complete set of LEDs allows for quick status verification. Because of 802.3af compliance, the
converters can draw the power via Cat.5 cable connected to a PoE PSE switch or mid-span injector in
addition to being powered by typical external power adapter. This feature makes the converter ideal for
remote areas of a network without AC power outlets.
1.1 Key Features
Convert speed and media type with full wire speed conversion
Support 10Mbps and 100Mbps speed on TP connections
Auto-negotiation and auto MDI/MDI-X detection function
Link fault pass through function
Provide manual configuration settings for TP port to supportconnection to non-auto-negotiation
devices
Transparent to 802.1Q VLAN tagged packets
Far End Fault function on FX port
Provide LED status display for remote TP port monitoring
Provide Loop Back Test function for installation diagnostics
Support wide range of fiber options on the FX port
Provide user-inaccessible settings for specific system applications
IEEE 802.3af compliant PoE PD (Powered Device) design
Low power consumption

6
1.2 Specifications
Twisted-Pair Interface (TP Port)
Connector Shielded RJ-45
Pin Assignments Auto MDI/MDI-X detection
Signal Compliance IEEE 802.3 10BASE-T, 802.3u 100BASE-TX
Data Speed 10Mbps or 100Mbps
Duplex Mode Half-duplex or Full-duplex
Configuration Auto-negotiation capable and optional forced manual settings
Cable Types 10Mbps - Category 3, 4, or 5 UTP
100Mbps - Category 5 UTP
SupportedLinkDistance Up to 100 meters

7
Fiber Optic Interface (FX Port)
Signal Compliance IEEE 802.3u 100BASE-FX
Connector SC, ST or Single SC
Data Speed 100Mbps
Duplex Mode Full-duplex and optional half duplex
Cable Types Multimode (MMF) - 50/125, 62.5/125 m
Single mode (SMF) - 9/125 m
SupportedLinkDistance MMF up to 2km
SMF up to 100km
Single SMF WDM up to 40km
Eye Safety compliance IEC825 Class 1
Loop Back Test Button (LOOP TEST)
PUSH Start loop back test
RELEASE Stop loop back test
User Accessible Settings (SW)
NO. SETTING STATE FUNCTION
SW1 TP Port Configuration OFF Auto-negotiation (default)
ON Forced mode
SW2 TP Port Duplex OFF Full duplex (default)
ON Half duplex
SW3 TP Port Speed OFF 100Mbps (default)
ON 10Mbps
SW4 Link Fault Pass Through OFF Disable (default)
ON Enable
SW5 Auto-status-report OFF Disable (default)
ON Enable
Optional Settings (User inaccessible JP1-JP3 on board)
NO. SETTING STATE FUNCTION
JP1 Forwarding mode Open Store-and-forward (default)
Short Smart-forward mode
JP2 802.3x function Open Enable (default)
Short Disable
JP3 FX port duplex Open Full duplex mode (default)
Short Half duplex mode

8
LED Indicators
LED DISPLAY STATE INTERPRETATION
PWR Power status ON Power on
OFF Power off
TP LINK TP port link status ON Link up and no traffic
OFF Link fault
Blink Rx/Tx activities
TP 100M TP port speed status ON 100Mbps
OFF 10Mbps
TP FDX TP port duplex status ON Full duplex
OFF Half duplex
Blink Collisions on half duplex
FX LINK FX port link status ON Link up and no traffic
OFF Link fault
Blink Rx/Tx activities
FX OL FX port optical link ON Optical signal is detected
OFF No optical signal
RTP LINK Remote TP port link ON Link up and no traffic
OFF Link fault
RTP 100M RemoteTPport speed ON 100Mbps
OFF 10Mbps
RTP FDX RemoteTPportduplex ON Full duplex
OFF Half duplex
RTP LINK/100M/FDX LEDs are also used for loop back test report.
PoE (Power over Ethernet)
Standard IEEE 802.3af PD (Powered Device)
Power Reception TP port RJ-45 Pin 1,2,3,6 or Pin 4,5,7,8
Input Voltage 36 ~ 57VDC via Cat.5
Power Classification Class 1
DC Power Input
DC Input Jack D 6.3mm D 2.0mm
OperatingInputVoltages +7V ~ +57V
Power Consumption 2W max. (0.27A @+7.5V)
Power Supply Options External AC-DC power adapters
Input options: AC 100V/120V/230V/240V

9
Rated output: DC7.5V 500mA min.
Basic Information
Forwarding Throughput Full wire speed at 100M full duplex
10Mbps - 14,880 pps at 64-byte packets
100Mbps - 148,800pps at 64-byte packets
Packet Types Transparent and no modification for
- IEEE 802.3 standard packets
- IEEE 802.1Q VLAN tagged packets
Packet Length Up to 1522 bytes at store-and-forward mode
No limit at smart-forward mode 100to100
Flow Control Back-pressure for half-duplex mode
802.3x pause-frame base for full duplex mode
Mechanical
Dimension 23mm x 72.5mm x 108mm (LxWxD)
Housing Enclosed metal with no fan
Mounting Desktop, Wall mount, Optional - Din-Rail
Weight 212g
Environmental
Operating Temperature -5oC ~ 50oC
Storage Temperature -20oC ~ 80oC
Relative Humidity 5% ~ 95%
Certificate
FCC Part 15 Class B
CE/EMC EMI EN50081-1 Class B, EMS EN55024
CE/LVD EN 60950

10
1.3 Optical Specifications
The media converter series provides the following fiber options:
Model: KC-351-X
Duplex Fiber Series
X Port Fiber WavelengthTx Power Rx Sensitivity Rx Max.
T ST MMF 1310nm -20 ~ -14dBm -32dBm -8dBm
C SC MMF 1310nm -20 ~ -14dBm -31dBm 0dBm
SL2 SC SMF 1310nm -15 ~ -7dBm -32dBm -3dBm
SL3 SC SMF 1310nm -15 ~ -8dBm -34dBm 0dBm
SL4 SC SMF 1310nm -5 ~ 0dBm -34dBm -3dBm
SL6 SC SMF 1310nm -5 ~ 0dBm -35dBm 0dBm
SL8 SC SMF 1310nm 0 ~ +5dBm -36dBm 0dBm
SL10 SC SMF 1550nm 0 ~ -5dBm -35dBm 0dBm
SL12 SC SMF 1550nm 0 ~ +5dBm -35dBm 0dBm
Single Fiber Bi-Di WDM Series
X Port Fiber Wavelength Tx Power Rx Sensitivity Rx Max.
W3520 SC SMF Tx 1310nm -14 ~ -8dBm -31dBm 0dBm
Rx 1550nm
W5320 SC SMF Tx 1550nm -14 ~ -8dBm -31dBm 0dBm
Rx 1310nm
W3540 SC SMF Tx 1310nm -8 ~ 0dBm -34dBm 0dBm
Rx 1550nm
W5340 SC SMF Tx 1550nm -8 ~ 0dBm -34dBm 0dBm
Rx 1310nm
Single Mode CWDM Series
X Port Fiber Wavelength Tx Power Rx Sensitivity Rx Max.
CxxW40 SC SMF Tx 1xx0nm -5 ~ 0dBm -35dBm 0dBm
Rx 1100-1650nm
CxxW80 SC SMF Tx 1xx0nm 0 ~ +5dBm -37dBm 0dBm
Rx 1100-1650nm

11
1.4 Special Functions
1.4.1 Auto MDI/MDI-X Function
This function allows the TP port to auto-detect the twisted-pair signals and adapts itself to form a valid
MDI to MDI-X connection with the remote connected device automatically.
1.4.2 Auto-negotiation Function
When TP port is set on Auto-negotiation mode (SW1:ON), it is featured with auto-negotiation function
and full capability. It performs a negotiation process for the speed and duplex configuration with the
connected device automatically when each time a link is being established.
1.4.3 Far End Fault Function
The FX port is facilitated with this function, which conforms to IEEE 802.3u 100BASE-FX
specifications. When the FX port detects a link failure on its receiving circuitry, it will send out an
FEFI (Far End Fault Indication) signal to the remote connected device to indicate a remote fault is
detected. It also is capable to receive FEFI signal sent from the remote link partner. Upon receiving an
FEFI signal, it indicates a link failure occurred on the transmitting path. This function allows the
converter to report a fiber link fault even when a link failure occurred on transmitting fiber cable.

12
1.4.4 Link Fault Pass Through Function
When this function is enabled, a link fault detected on the TP port will force a link down on the FX
port. Similarly, a link fault detected on the FX port will also force a link down on the TP port. As
illustrated in the following figure, this function allows to pass TP link fault to the remote link partner
and makes the converter like a TP cable extender.

13
1.4.5 Remote TP Port Monitoring Function
The converter provides LED indicators labeled RTP LINK/100M/FDX to display the TP port status of
its remote link partner on FX port. As illustrated in the following figure, the remote MC must be
enabled for periodical status report.
1.4.6 Loop Back Test Function
As illustrated in the following figure, the local MC starts a loop back test by pressing the loop back test
button. It sends test frames from its FX port to the remote MC. The remote MC forwards the received
test frames back to local MC from its FX port. The local MC verifies the loop back test frames and
display the test result on RTP LINK/100M/FDX LEDs. This function can help installer to check the
full path from a local MC through fiber to a connected remote MC and back to local MC.

14
2. Installation
2.1 Unpacking
Check that the following components have been included:
Installation guide (or contained in the product CD)
The 10/100 Media Converter
If any item is found missing or damaged, please contact your local reseller for replacement.
2.2 Safety Cautions
To reduce the risk of bodily injury, electrical shock, fire, and damage to the product, observe the
following precautions.
Do not service any product except as explained in your system documentation.
Opening or removing covers may expose you to electrical shock.
Only a trained service technician should service components inside these compartments.
If any of the following conditions occur, unplug the product from the electrical outlet and replace the part or
contact your trained service provider:
- The power cable, extension cable, or plug is damaged.
- An object has fallen into the product.
- The product has been exposed to water.
- The product has been dropped or damaged.
- The product does not operate correctly when you follow the operating instructions.
Do not push any objects into the openings of your system. Doing so can cause fire or electric shock by
shorting out interior components.
Operate the product only from the type of external power source indicated on the electrical ratings label. If
you are not sure of the type of power source required, consult your service provider or local power company.

15
2.3 Mounting the Device
Desktop Mounting
The media converter can be mounted on a desktop or shelf. Make sure that there is proper heat
dissipation from and adequate ventilation around the device. Do not place heavy objects on the device.
Wall Mounting
The media converter also can be mounted on a wall. On bottom of the device, wall mounting hole is
provided for wall mounting.
Din-rail Mounting
For a Din-Rail chassis, the media converter can support mounting on a Din-Rail. An optional Din-Rail
bracket, KC-3DR can be purchased separately. Consult your dealer for details. The following figures
show an example after bracket installation:

16
2.4 Powered by PoE over Cat.5
Power supply by a Mid-Span PoE Injector
The following figure illustrates the converter is powered by the PoE delivered from a remote mid-span
PoE injector over Cat.5.
Power supply by a PoE PSE Switched Port
The following figure illustrates the converter is powered by the PoE delivered from a remote PoE PSE
switch over Cat.5.
Note:
1. The Cat.5 used can be the standard Cat.5 cable for Ethernet connection.
2. Check the power LED on the converter to see whether the power is received on the Cat.5.
3. For the compatibility, the remote PoE PSE used must be IEEE 802.3af compliant.

17
2.5 Powered by External Power Adapter
The converter can support being powered by an external power adapter as an alternative when PoE
power is not available on Cat.5. Before you begin the installation, check the AC voltage of your area.
The AC power adapter, which is used to supply the DC power for the unit should have the AC voltage
matching the commercial power voltage in your area.
The AC Power Adapter Specifications
AC input power: AC power voltage of your area,
Rated input options -
AC120V/60Hz, AC230V/50Hz,
AC100V/50-60Hz, Rated AC240V/50Hz
Rated output - DC7.5V 500mA min.
Steps to apply the power to the converters are:
1. Connect power adapter DC plug to the DC input jack located on the back of the converter before
connecting to the AC outlet.
2. To ensure against accidental disconnection, tie the DC cable with the cable tie located the back of
the converter.
3. Connect the power adapter to the AC outlet.
4. Check Power LED indication.

18
2.6 Making TP Port Connection
TP port is featured to support connection to:
Auto-negotiation devices
Auto-negotiation incapable 10BASE-T devices
Auto-negotiation incapable 100BASE-TX devices
Network Cables
10BASE-T: 4-pair UTP Cat. 3,4,5 , EIA/TIA- 568 100-ohm STP
100BASE-TX: 4-pair UTP Cat. 5, EIA/TIA-568 100-ohm STP
Link distance: Up to 100 meters
Configuration Setup
To make a proper connection, the following configuration settings are recommended:
TP port link partner SW1 SW2 SW3
Auto-negotiation device Off: auto Off: full duplex Off: 100M
Fixed 10M half duplex device On: forced On: half duplex On: 10M
Fixed 100M half duplex device On: forced On: half duplex Off: 100M
Fixed 10M full duplex device On: forced Off: full duplex On: 10M
Fixed 100M full duplex device On: forced Off: full duplex Off: 100M

19
2.7 Making FX Port Connection
FX port operates on 100Mbps and full duplex (factory default). A variety of fiber options is provided
as follows:
Model: KC-351-X
Duplex Fiber Series
X Connector Wavelength Fiber Ref. distance
T ST 1310nm Duplex MMF 2km
C SC 1310nm Duplex MMF 2km
SL2 SC 1310nm Duplex SMF 20km
SL3 SC 1310nm Duplex SMF 30km
SL4 SC 1310nm Duplex SMF 40km
SL6 SC 1310nm Duplex SMF 60km
SL8 SC 1310nm Duplex SMF 80km
SL10 SC 1550nm Duplex SMF 100km
SL12 SC 1550nm Duplex SMF 120km
Duplex Fiber CWDM Series
X Connector Wavelength Fiber Ref. Distance
CxxW40 SC Tx 1xx0nm SMF 40km
Rx 1100 - 1650nm
CxxW80 SC TX 1xx0nm SMF 80km
RX 1100 - 1650nm
Tx 1xx0nm : 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610nm

20
Single Fiber Bi-Di WDM Series
X Connector Wavelength Fiber Ref. Distance
W3520 Bi-Di SC Tx 1310nm Single SMF 20km
Rx 1550nm
W5320 Bi-Di SC Tx 1550nm Single SMF 20km
Rx 1310nm
W3540 Bi-Di SC Tx 1310nm Single SMF 40km
Rx 1550nm
W5340 Bi-Di SC Tx 1550nm Single SMF 40km
Rx 1310nm
Since the WDM single fiber media converters use different wavelengths for transmission and receiving
respectively, the link partner device located on the remote end of the single fiber should match the
wavelength used on the single fiber converter.
